Model Whirlpool 3LBR8255EQ0 WASHER – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

350938 Whirlpool Spray Gun Backorder WPL 350938 $49.86

350956 Whirlpool Spray Assembly In Stock WPL 350956 $29.99

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $15.99

WP72107 Whirlpool Touchup In Stock WPL WP72107 $14.61

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Drain Protector WPL 367031 Contact Us For Availability

Golden Harvest WPL 261890 Contact Us For Availability

Golden Harvest (Uncut) WPL 261891 Contact Us For Availability

LUBRICANT (USE ONLY IN BRAKE SHOE ASSEMBLY ON WPL 285208 Contact Us For Availability

Shipping Kit WPL 3348675 Contact Us For Availability

Stand-Pipe Kit WPL 89121 Contact Us For Availability

Almond (Uncut) WPL 978883 Contact Us For Availability

Installation Instructions WPL LIT3948884 Contact Us For Availability

Label, Wiring Diagram WPL LIT3950563 Contact Us For Availability

Guide, Use and Care WPL LIT3951059 Contact Us For Availability

1

285442 Whirlpool Coupling Backorder WPL 285442 $59.26

1

63580 Whirlpool Washer Fabric Softener Dispen In Stock WPL 63580 $13.99

1

WP273556 Whirlpool Screw In Stock WPL WP273556 $4.99

1

WP357213 Whirlpool Hinge Stopper Backorder WPL WP357213 $4.82

1

Clip, Harness WPL 3349557 Contact Us For Availability

1

Miscellaneous Parts Bag WPL 3976257 Contact Us For Availability

2

285202 Whirlpool Cover Assembly Backorder WPL 285202 $124.99

2

285321 Whirlpool Sleeve Backorder WPL 285321 $54.14

2

WP16123 Whirlpool Washer In Stock WPL WP16123 $4.82

2

WP358237 Whirlpool Agitator Bolt In Stock WPL WP358237 $2.99

2

WP63292 Whirlpool Washer In Stock WPL WP63292 $5.99

2

WP64067 Whirlpool Bracket In Stock WPL WP64067 $9.65

2

Top (For Designer White Model) WPL 3950288 Contact Us For Availability

3

WP285655 Whirlpool Hose Clamp In Stock WPL WP285655 $4.99

3

WP3349019 Whirlpool Upper Agitator Backorder WPL WP3349019 $140.53

3

WP3349985 Whirlpool Shaft Seal In Stock WPL WP3349985 $11.91

3

WP3357331 Whirlpool Clamp Backorder WPL WP3357331 $5.99

3

WP62750 Whirlpool Spacer In Stock WPL WP62750 $5.99

3

WP63907 Whirlpool Washer Suspension Spring In Stock WPL WP63907 $4.98

3

WP91939 Whirlpool Shaft Seal In Stock WPL WP91939 $4.98

4

WP16272 Whirlpool Hose Coupling Backorder WPL WP16272 $4.82

4

WP285195 Whirlpool Sealer Assembly Backorder WPL WP285195 $67.35

4

WP3350830 Whirlpool Agitator Assembly In Stock WPL WP3350830 $112.73

4

WP3357027 Whirlpool Nozzle Assembly In Stock WPL WP3357027 $58.50

4

WP62739 Whirlpool Nut Backorder WPL WP62739 $4.82

4

Support & Brake, Tub WPL 3362087 Contact Us For Availability

4

Shield, Lid Switch WPL 3950995 Contact Us For Availability

5

285320 Whirlpool Washer Siphon Break Kit In Stock WPL 285320 $48.81

5

WPW10001130 Whirlpool Leveling Leg In Stock WPL WPW10001130 $2.99

5

Hinge, Console (2) WPL 387402 Contact Us For Availability

5

Bracket, Spring Outer (L.F.) WPL 64065 Contact Us For Availability

5

Cabinet (For Designer White Model) WPL 63128 Contact Us For Availability

5

Tub Ring WPL 387966 Contact Us For Availability

6

WP3359586 Whirlpool Tub Seal In Stock WPL WP3359586 $58.99

6

WP356427 Whirlpool Shaft Seal In Stock WPL WP356427 $4.98

6

WP62780 Whirlpool Cabinet Clip In Stock WPL WP62780 $7.99

6

Link, Leveling Mechanism (2) WPL 3348725 Contact Us For Availability

7

8316845 Whirlpool Washer Spring In Stock WPL 8316845 $6.49

7

WP356138 Whirlpool Hose Clamp In Stock WPL WP356138 $4.98

7

WP62747 Whirlpool Pad Backorder WPL WP62747 $15.58

7

Balance Ring WPL 387868 Contact Us For Availability

8

WP3356311 Whirlpool Screw In Stock WPL WP3356311 $4.82

8

WP62837 Whirlpool Dowel Pin Backorder WPL WP62837 $7.18

8

WP8519815 Whirlpool Washer Balance Ring Clip In Stock WPL WP8519815 $6.99

8

Ring, Retaining (2) WPL 90369 Contact Us For Availability

9

285244 Whirlpool Leveling Feet In Stock WPL 285244 $22.99

9

285868 Whirlpool Washer Filter Plug Kit In Stock WPL 285868 $13.99

9

62677 Whirlpool Retainer Backorder WPL 62677 $8.13

9

Timer, Control (50 Hz.) (Motor Not A Service WPL 3950560 Contact Us For Availability

10

WP3363661 Whirlpool Bearing Cam Backorder WPL WP3363661 $4.82

10

WP62889 Whirlpool Washer Lid Switch Receptacl Backorder WPL WP62889 $4.82

10

Spring, Agitator WPL 62676 Contact Us For Availability

285811 Whirlpool Washer Agitator Repair Kit In Stock WPL 285811 $11.96

353424 Whirlpool Connector Backorder WPL 353424 $14.02

WP90767 Whirlpool Screw In Stock WPL WP90767 $3.91

Switch, Lid WPL 3950299 Contact Us For Availability

62619 Whirlpool Washer Backorder WPL 62619 $8.89

WP21366 Whirlpool Spanner Nut In Stock WPL WP21366 $4.98

WP3356465 Whirlpool Washer Water Level Switch In Stock WPL WP3356465 $112.06

WP62505 Whirlpool Connector Backorder WPL WP62505 $15.58

WP62691 Whirlpool Grommet In Stock WPL WP62691 $7.92

13

WP8546455 Whirlpool Bearing In Stock WPL WP8546455 $17.86

13

WPW10119828 Whirlpool Screw In Stock WPL WPW10119828 $3.52

13

Basket WPL 3357245 Contact Us For Availability

14

W11095997 Whirlpool Seal In Stock WPL W11095997 $13.63

14

WP63022 Whirlpool Sleeve Backorder WPL WP63022 $29.22

14

Tub (Includes Item 23) WPL 63039 Contact Us For Availability

WP389140 Whirlpool Drive Block or Bell In Stock WPL WP389140 $10.79

WP389387 Whirlpool Agitator Shaft Backorder WPL WP389387 $164.99

WP54584 Whirlpool Hinge Backorder WPL WP54584 $20.16

WPW10250667 Whirlpool Washer Suspension Sprin In Stock WPL WPW10250667 $2.99

285219 Whirlpool Washer Suspension Plate Fric In Stock WPL 285219 $22.76

W10814296 Whirlpool Washer Center Post Seal G In Stock WPL W10814296 $5.99

WP54583 Whirlpool Hinge Backorder WPL WP54583 $18.77

Washer, Cam Thrust WPL 62618 Contact Us For Availability

285205 Whirlpool Bearing Backorder WPL 285205 $4.82

WP353244 Whirlpool Hose In Stock WPL WP353244 $37.95

WP3946509 Whirlpool Skate Plate Backorder WPL WP3946509 $129.15

Bumper, Lid Hinge WPL 19119 Contact Us For Availability

285744 Whirlpool Washer Tub Suspension Rod Ki In Stock WPL 285744 $6.99

80040 Whirlpool Washer Agitator Dog Kit In Stock WPL 80040 $2.61

WP21258 Whirlpool Washer Lid Hinge Bearing In Stock WPL WP21258 $8.53

WP3360397 Whirlpool Valve Backorder WPL WP3360397 $178.51

285459 Whirlpool Washer Base Backorder WPL 285459 $243.38

3363395 Whirlpool Gearcase Backorder WPL 3363395 $263.92

Motor, Main Drive WPL 3950297 Contact Us For Availability

Lid (For Designer White Model) WPL 3947509 Contact Us For Availability

Agitator, Assy. (Complete) WPL 3350829 Contact Us For Availability

20

285587 Whirlpool Thrust Washer In Stock WPL 285587 $1.99

20

WP358684 Whirlpool Strike Assembly In Stock WPL WP358684 $8.99

21

285352 Whirlpool Washer Oil Seal Kit for Gear In Stock WPL 285352 $59.80

21

WPW10074580 Whirlpool Agitator Inner Cap and In Stock WPL WPW10074580 $7.59

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $4.82

WP3363892 Whirlpool Water Pump In Stock WPL WP3363892 $50.94

WP9724509 Whirlpool Bumper In Stock WPL WP9724509 $7.99

WPW10072840 Whirlpool Seal Assembly In Stock WPL WPW10072840 $4.98

WP3362952 Whirlpool Bezel In Stock WPL WP3362952 $3.99

WP8577376 Whirlpool Seal In Stock WPL WP8577376 $4.99

Hose, Bleach WPL 3948705 Contact Us For Availability

Ring, Retaining WPL 3362552 Contact Us For Availability

285203 Whirlpool CP Bearing In Stock WPL 285203 $93.99

WP3347034 Whirlpool Vacuum Break In Stock WPL WP3347034 $58.99

WP3354845 Whirlpool Clip Backorder WPL WP3354845 $15.44

Washer Kit, Thrust WPL 285735 Contact Us For Availability

25

WP63134 Whirlpool Ring Backorder WPL WP63134 $4.82

25

WP8543666 Whirlpool Washer In Stock WPL WP8543666 $6.91

25

WPW10233584 Whirlpool Spin Gear Backorder WPL WPW10233584 $163.49

26

388253A Whirlpool Neutral Drain Kit In Stock WPL 388253A $44.63

26

WPW10145155 Whirlpool Retainer In Stock WPL WPW10145155 $6.57

27

3360629 Whirlpool Washer Gearcase Transmissio In Stock WPL 3360629 $264.98

27

Connector (T.P.A) (3-Circuit) (Pressure Switc WPL 3360056 Contact Us For Availability

28

WP681414 Whirlpool Screw In Stock WPL WP681414 $3.91

29

WP388815 Whirlpool Washer Backorder WPL WP388815 $4.82

30

WP616099 Whirlpool Clamp Backorder WPL WP616099 $4.42

31

WP371502 Whirlpool Clamp Backorder WPL WP371502 $7.16

31

WP90016 Whirlpool Clip Backorder WPL WP90016 $7.16

32

285871 Whirlpool Hose and Clamp In Stock WPL 285871 $9.99

34

Lock Washer WPL 138479 Contact Us For Availability

35

Switch, Water Temperature WPL 3950347 Contact Us For Availability

36

W10915367 Whirlpool Screw Assembly Backorder WPL W10915367 $4.82

39

Panel, Console (For Designer White Model) WPL 3950964 Contact Us For Availability

44

W10807860 Whirlpool White Control Knob In Stock WPL W10807860 $45.60

45

WP3957841 Whirlpool Dial Backorder WPL WP3957841 $42.69

47

WP3957796 Whirlpool Knob In Stock WPL WP3957796 $37.84

49

WP388326 Whirlpool Screw Backorder WPL WP388326 $4.82

50

WP3390631 Whirlpool Screw In Stock WPL WP3390631 $4.99

51

Cap , End (R.H.) (For Designer White Model) WPL 3950974 Contact Us For Availability

59

WP308685 Whirlpool Microwave Screw In Stock WPL WP308685 $3.52

61

WPL 3950818 WPL 3950818 Contact Us For Availability

62

WPL 3950571 WPL 3950571 Contact Us For Availability
