Model Whirlpool 110.88675710 Washer/Dryer (Kenmore 11088675710) – Common Parts &amp; Diagrams

1

285321 Whirlpool Sleeve Backorder WPL 285321 $57.93

1

356746 Whirlpool Clip Backorder WPL 356746 $14.02

1

694304 Whirlpool Channel Cover Backorder WPL 694304 $53.30

1

W10820043 Whirlpool Washer Drive and Brake Ba In Stock WPL W10820043 $161.53

1

WP387095 Whirlpool Cap Backorder WPL WP387095 $39.10

1

WP660658 Whirlpool Clamp In Stock WPL WP660658 $5.30

1

WPW10112403 Whirlpool Miscellaneous Parts Backorder WPL WPW10112403 $32.66

1

Wire Harness WPL 3388244 Contact Us For Availability

1A

Plug WPL 342529 Contact Us For Availability

1B

696073 Whirlpool Connector Backorder WPL 696073 $64.30

1C

W10876590 Whirlpool Connector In Stock WPL W10876590 $7.85

2

285202 Whirlpool Cover Assembly Backorder WPL 285202 $133.74

2

3390046 Whirlpool Protector Backorder WPL 3390046 $5.51

2

W11174025 Whirlpool Support Assembly Backorder WPL W11174025 $36.39

2

WP16123 Whirlpool Washer In Stock WPL WP16123 $4.82

2

WP358237 Whirlpool Agitator Bolt In Stock WPL WP358237 $5.19

2

WP3946432 Whirlpool Timer In Stock WPL WP3946432 $217.64

2

WP63292 Whirlpool Washer In Stock WPL WP63292 $5.99

3

279827 Whirlpool Dryer Drive Motor In Stock WPL 279827 $78.97

3

63977 Whirlpool Agitator Auger Backorder WPL 63977 $135.27

3

WP16272 Whirlpool Hose Coupling Backorder WPL WP16272 $4.82

3

WP285655 Whirlpool Hose Clamp In Stock WPL WP285655 $5.30

3

WP3349985 Whirlpool Shaft Seal In Stock WPL WP3349985 $15.68

3

WP681414 Whirlpool Screw In Stock WPL WP681414 $3.46

3

WPW10080230 Whirlpool Ring Backorder WPL WPW10080230 $7.49

3

Timer Motor WPL 63491 Contact Us For Availability

4

279872 Whirlpool Resistor In Stock WPL 279872 $36.07

4

285320 Whirlpool Washer Siphon Break Kit In Stock WPL 285320 $59.84

4

285353 Whirlpool Ring Backorder WPL 285353 $4.82

4

WP3349098 Whirlpool Agitator Assembly In Stock WPL WP3349098 $79.15

5

285664 Whirlpool Drain Hose In Stock WPL 285664 $30.66

5

285785 Whirlpool Washer Direct Drive Clutch In Stock WPL 285785 $28.58

5

285805 Whirlpool Washer Water Inlet Valve In Stock WPL 285805 $31.16

5

384458 Whirlpool Hinge Assembly Backorder WPL 384458 $61.94

5

696541 Whirlpool Base Backorder WPL 696541 $64.59

5

W11174024 Whirlpool Support Backorder WPL W11174024 $93.31

5

Washer Tub Ring WPL 64175 Contact Us For Availability

5A

285666 Whirlpool Drain Hose 10' In Stock WPL 285666 $43.87

6

285790 Whirlpool Washer Clutch Band and Linin In Stock WPL 285790 $35.11

6

WP21097 Whirlpool Pad In Stock WPL WP21097 $5.99

6

WP21366 Whirlpool Spanner Nut In Stock WPL WP21366 $5.30

6

WP356427 Whirlpool Shaft Seal In Stock WPL WP356427 $5.30

6

WP596669 Whirlpool Hose Clamp In Stock WPL WP596669 $4.99

6

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $4.99

6

Bracket WPL 694338 Contact Us For Availability

6

Rear Panel WPL 3390405 Contact Us For Availability

6

Laundry Center Wire Harness WPL 3388677 Contact Us For Availability

6A

Connector WPL 696074 Contact Us For Availability

6B

WP62889 Whirlpool Washer Lid Switch Receptacl Backorder WPL WP62889 $4.82

6C

WP62505 Whirlpool Connector Backorder WPL WP62505 $15.58

7

WP389387 Whirlpool Agitator Shaft Backorder WPL WP389387 $176.44

7

WP692699 Whirlpool Hose Backorder WPL WP692699 $27.63

7

End Cap WPL 3387741 Contact Us For Availability

7

Harness Clip WPL 696633 Contact Us For Availability

7

Retainer WPL 3350222 Contact Us For Availability

7A

WP348205 Whirlpool Door Backorder WPL WP348205 $97.40

8

8528351 Whirlpool Clip Backorder WPL 8528351 $54.39

8

WP384496 Whirlpool Hose Coupling Backorder WPL WP384496 $62.44

8

WP62646 Whirlpool Cap In Stock WPL WP62646 $4.99

8

Screw WPL 3387742 Contact Us For Availability

8

Cover WPL 307972 Contact Us For Availability

8

Retaining Ring WPL 90369 Contact Us For Availability

8A

Cabinet WPL 696013 Contact Us For Availability

8B

Cabnt Al WPL 696014 Contact Us For Availability

8C

GOLDEN HARVEST WPL 696015 Contact Us For Availability

8D

Toast WPL 696016 Contact Us For Availability

8E

Platinum WPL 696017 Contact Us For Availability

9

3360629 Whirlpool Washer Gearcase Transmissio In Stock WPL 3360629 $304.47

9

62677 Whirlpool Retainer Backorder WPL 62677 $8.13

9

WP692985 Whirlpool Clip Assembly Backorder WPL WP692985 $4.82

9

WP694091 Whirlpool Screw Backorder WPL WP694091 $4.82

9

Washer Outer Tub WPL 63782 Contact Us For Availability

W11213338 Whirlpool Connector Backorder WPL W11213338 $51.27

WP389140 Whirlpool Drive Block or Bell In Stock WPL WP389140 $13.78

WP488234 Whirlpool Air Conditioner Screw Backorder WPL WP488234 $4.67

WP696710 Whirlpool Hose In Stock WPL WP696710 $39.99

Water-Level Switch WPL 3348028 Contact Us For Availability

Spring WPL 62676 Contact Us For Availability

Screw WPL 62735 Contact Us For Availability

10A

WP3402293 Whirlpool Panel Assembly Backorder WPL WP3402293 $238.76

10B

Panel (Almond) WPL 692614 Contact Us For Availability

10C

Panel WPL 692617 Contact Us For Availability

10D

Panel To WPL 692615 Contact Us For Availability

10E

Panel Pl WPL 692616 Contact Us For Availability

11

279570 Whirlpool Dryer Door Latch Kit In Stock WPL 279570 $6.56

11

WP62611 Whirlpool Plate In Stock WPL WP62611 $81.99

11

WP89503 Whirlpool Washer Fill Hose In Stock WPL WP89503 $12.77

11A

692790 Whirlpool Plug Backorder WPL 692790 $57.71

11B

Plug (Almond) WPL 692791 Contact Us For Availability

11C

Plug WPL 692794 Contact Us For Availability

11D

Toast WPL 692792 Contact Us For Availability

11E

Platinum (Platinum) WPL 692793 Contact Us For Availability

62619 Whirlpool Washer Backorder WPL 62619 $8.89

WP3400516 Whirlpool Screw In Stock WPL WP3400516 $4.82

WP371502 Whirlpool Clamp Backorder WPL WP371502 $7.16

WP660975 Whirlpool Button Plug Backorder WPL WP660975 $4.82

WP98129 Whirlpool Screw Backorder WPL WP98129 $4.82

Switch WPL 87136 Contact Us For Availability

Wire WPL 687261 Contact Us For Availability

Clip WPL 693141 Contact Us For Availability

12A

WP384693 Whirlpool Top Backorder WPL WP384693 $202.20

285753A Whirlpool Washer Direct Drive Motor C In Stock WPL 285753A $20.50

693711 Whirlpool Sleeve Backorder WPL 693711 $5.42

WP339956 Whirlpool Foam Seal In Stock WPL WP339956 $5.30

WP63134 Whirlpool Ring Backorder WPL WP63134 $4.82

Bumper, Lid Hinge WPL 19119 Contact Us For Availability

8577411 Whirlpool Pad Backorder WPL 8577411 $5.36

WP21258 Whirlpool Washer Lid Hinge Bearing In Stock WPL WP21258 $5.30

WP3389441 Whirlpool Door Catch In Stock WPL WP3389441 $5.30

WP661600 Whirlpool Drive Motor In Stock WPL WP661600 $148.95

WP693151 Whirlpool Lock Spring Backorder WPL WP693151 $4.82

WP696426 Whirlpool Wheel In Stock WPL WP696426 $41.44

Elbow WPL 695524 Contact Us For Availability

356398 Whirlpool Tube Backorder WPL 356398 $58.38

63636 Whirlpool Bracket Backorder WPL 63636 $32.75

W10854425 Whirlpool Dryer Front Panel Bottom In Stock WPL W10854425 $8.77

WP356471 Whirlpool Cap In Stock WPL WP356471 $4.82

Console Lock Screw WPL 693710 Contact Us For Availability

Shaft WPL 389231 Contact Us For Availability

15A

WP686711 Whirlpool Door Handle In Stock WPL WP686711 $5.30

15B

Handle (Almond) WPL 689497 Contact Us For Availability

15C

Handle WPL 689499 Contact Us For Availability

15D

Handle WPL 695222 Contact Us For Availability

15E

Handle (Platinum) WPL 695223 Contact Us For Availability

686770 Whirlpool Support Bracket Backorder WPL 686770 $8.05

WP356363 Whirlpool Siphon Break In Stock WPL WP356363 $5.30

WP3946532 Whirlpool Shield Backorder WPL WP3946532 $19.73

Timer WPL 696165 Contact Us For Availability

Washer WPL 62618 Contact Us For Availability

285205 Whirlpool Bearing Backorder WPL 285205 $4.82

3399603 Whirlpool Elbow Backorder WPL 3399603 $83.21

384459 Whirlpool Hinge Backorder WPL 384459 $62.36

W10814296 Whirlpool Washer Center Post Seal G In Stock WPL W10814296 $5.87

WP616099 Whirlpool Clamp Backorder WPL WP616099 $4.42

Fastener WPL 693739 Contact Us For Availability

Strut WPL 693175 Contact Us For Availability

WP3363394 Whirlpool Washer Drain Pump In Stock WPL WP3363394 $40.37

WP3390631 Whirlpool Screw In Stock WPL WP3390631 $4.99

WP696394 Whirlpool Hose In Stock WPL WP696394 $46.00

WP90296 Whirlpool Clip Backorder WPL WP90296 $4.82

Switch WPL 693169 Contact Us For Availability

693152 Whirlpool Bumper In Stock WPL 693152 $11.45

W10863713 Whirlpool Support In Stock WPL W10863713 $243.69

WP8546127 Whirlpool Retainer Clip In Stock WPL WP8546127 $5.30

Dryer Thermostat WPL 696818 Contact Us For Availability

Washer WPL 312147 Contact Us For Availability

Gear Case WPL 389229 Contact Us For Availability

3394652 Whirlpool Drum Belt In Stock WPL 3394652 $48.48

WP348023 Whirlpool Hinge Backorder WPL WP348023 $4.82

WP356418 Whirlpool Screw In Stock WPL WP356418 $4.82

O-Ring WPL 64002 Contact Us For Availability

Gear WPL 62528 Contact Us For Availability

Switch WPL 62850 Contact Us For Availability

285352 Whirlpool Washer Oil Seal Kit for Gear In Stock WPL 285352 $40.48

694037 Whirlpool Clip Backorder WPL 694037 $60.49

W10837625 Whirlpool Dryer Motor Pulley In Stock WPL W10837625 $9.23

WP62691 Whirlpool Grommet In Stock WPL WP62691 $7.92

Barrier WPL 693303 Contact Us For Availability

303776 Whirlpool Dishwasher Screw Backorder WPL 303776 $6.92

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $4.82

WP691366 Whirlpool Dryer Idler Pulley Assembl In Stock WPL WP691366 $16.43

WP90767 Whirlpool Screw In Stock WPL WP90767 $3.92

WPW10086010 Whirlpool Motor Retainer Clip Backorder WPL WPW10086010 $4.82

Support WPL 692846 Contact Us For Availability

386011 Whirlpool Screw Backorder WPL 386011 $32.38

WP3355454 Whirlpool Clip Assembly In Stock WPL WP3355454 $4.82

WP358652 Whirlpool Link Backorder WPL WP358652 $58.19

WP692771 Whirlpool Nut Backorder WPL WP692771 $4.82

WP90016 Whirlpool Clip Backorder WPL WP90016 $7.16

Control Panel WPL 694334 Contact Us For Availability

Ring WPL 95082 Contact Us For Availability

696044 Whirlpool Block In Stock WPL 696044 $61.59

W11573574 Whirlpool Screw In Stock WPL W11573574 $11.38

WP359231 Whirlpool Shield In Stock WPL WP359231 $5.99

WP359364 Whirlpool Clip In Stock WPL WP359364 $5.30

Sears Canada Dryer Drum Baffle WPL 685207 Contact Us For Availability

Control Knob WPL 3387766 Contact Us For Availability

Dryer Base WPL 696046 Contact Us For Availability

Washer Kit WPL 285292 Contact Us For Availability

25

WP3352875 Whirlpool Knob Backorder WPL WP3352875 $1.50

25

WP692400 Whirlpool Nut In Stock WPL WP692400 $5.30

25

WP98234 Whirlpool Nut In Stock WPL WP98234 $7.88

388253A Whirlpool Neutral Drain Kit In Stock WPL 388253A $42.58

WP345670 Whirlpool Lock In Stock WPL WP345670 $5.30

WP692926 Whirlpool Cover Appliance Backorder WPL WP692926 $63.22

Knob Wl WPL 388028 Contact Us For Availability

27A

692933 Whirlpool Panel Backorder WPL 692933 $159.16

27A

Washer Front Panel WPL 692628 Contact Us For Availability

27B

Panel (Almond) WPL 692629 Contact Us For Availability

27B

Panel (Almond) WPL 692934 Contact Us For Availability

27C

Panel WPL 692632 Contact Us For Availability

27C

Panel WPL 692937 Contact Us For Availability

27D

Panel To WPL 692630 Contact Us For Availability

27D

Panel To WPL 692935 Contact Us For Availability

27E

Panel Pl WPL 692631 Contact Us For Availability

27E

Panel Pl WPL 692936 Contact Us For Availability

28

WP367594 Whirlpool Leveling Feet In Stock WPL WP367594 $11.69

28

WP692641 Whirlpool Dryer Top Assembly Backorder WPL WP692641 $178.74

28

Dial WPL 388002 Contact Us For Availability

29

WP358594 Whirlpool Leveling Feet In Stock WPL WP358594 $9.46

29

WP388815 Whirlpool Washer Backorder WPL WP388815 $4.82

29

Washer Timer Knob WPL 3387781 Contact Us For Availability

29A

Panel (White) WPL 692607 Contact Us For Availability

29B

Panel (Almond) WPL 692608 Contact Us For Availability

29C

Panel WPL 692611 Contact Us For Availability

29D

Panel To WPL 692609 Contact Us For Availability

29E

Panel Pl WPL 692610 Contact Us For Availability

30

WP308544 Whirlpool Screw In Stock WPL WP308544 $4.82

30

WP688805 Whirlpool Spring Clip In Stock WPL WP688805 $5.30

30

WP693145 Whirlpool Lid Latch In Stock WPL WP693145 $58.20

31

3350013 Whirlpool Foam Seal Backorder WPL 3350013 $62.14

31

WP692983 Whirlpool Console Lock Backorder WPL WP692983 $61.81

31A

WP692781 Whirlpool Closure Assembly Backorder WPL WP692781 $125.69

31B

Closure (Almond) WPL 692782 Contact Us For Availability

31C

Closure WPL 692785 Contact Us For Availability

31D

Closure To WPL 692783 Contact Us For Availability

31E

Closure Pl WPL 692784 Contact Us For Availability

32

60001022 Whirlpool Oven Screw Backorder WPL 60001022 $42.56

32

WP694419 Whirlpool Buzzer Adjuster Backorder WPL WP694419 $94.27

32

Screw WPL 354975 Contact Us For Availability

33

WP348197 Whirlpool Washer Assembly Backorder WPL WP348197 $4.82

33

WP693304 Whirlpool Screw Backorder WPL WP693304 $4.82

36

WP8572717 Whirlpool Capacitor In Stock WPL WP8572717 $55.95

36B

Connector WPL 692998 Contact Us For Availability

37

357030 Whirlpool Clamp Backorder WPL 357030 $14.02

39

279457 Whirlpool Dryer Heating Element Wide S In Stock WPL 279457 $6.11

41

279393 Whirlpool Terminal Block Screw and Nut In Stock WPL 279393 $19.81

42

279318 Whirlpool Terminal In Stock WPL 279318 $52.31

45

Dryer Thermostat Heater WPL 61894 Contact Us For Availability

350572 Whirlpool Oil Transmission 15 Oz In Stock WPL 350572 $34.80

350930 Whirlpool White Spray Paint In Stock WPL 350930 $25.69

350938 Whirlpool Spray Gun Backorder WPL 350938 $64.04

350956 Whirlpool Spray Assembly In Stock WPL 350956 $26.25

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $8.31

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $13.75

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $15.74

WP285195 Whirlpool Sealer Assembly Backorder WPL WP285195 $72.06

WP72107 Whirlpool Touchup In Stock WPL WP72107 $10.96

Paint (White) WPL 799344 Contact Us For Availability

(338471) (ALT.) WPL N/P Contact Us For Availability

Spray (Golden Harvest) WPL 261890 Contact Us For Availability

Natural Gas Paint WPL 261891 Contact Us For Availability

Washer Brake Shoe Roller and Pin Lubricant WPL 285208 Contact Us For Availability

Spray (Toast) WPL 285365 Contact Us For Availability

Spray (Platinum) WPL 285366 Contact Us For Availability

Paint To WPL 285367 Contact Us For Availability

Paint Pl WPL 285368 Contact Us For Availability

Spray Th WPL 350941 Contact Us For Availability

Touch-Up WPL 72112 Contact Us For Availability

Paint (Almond) WPL 978883 Contact Us For Availability

Energy Guide WPL LIT3351225 Contact Us For Availability

Wiring Diagram WPL LIT3387717 Contact Us For Availability

Operating Instructions WPL LIT693018 Contact Us For Availability

Parts List WPL LIT694616 Contact Us For Availability

Laundry Guide WPL LIT694633 Contact Us For Availability

Installation Instructions WPL LIT697087 Contact Us For Availability

Technical Sheet WPL LIT697637 Contact Us For Availability
