Model Whirlpool TS25AFXKS08 REFRIGERATOR – Common Parts &amp; Diagrams

1

BRACKET, MOTOR WPL W10284485 Contact Us For Availability

1

SHELF ASSEMBLY, CANTILEVER (3) WPL W10141749 Contact Us For Availability

2

W11505385 Whirlpool Refrigerator Chute In Stock WPL W11505385 $14.93

2

WP2171713 Whirlpool Refrigerator Ice Door Backorder WPL WP2171713 $55.83

2

WP2256101 Whirlpool Dairy Door In Stock WPL WP2256101 $72.67

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

2

Mounting Bracket WPL 1110629 Contact Us For Availability

3

W10508993 Whirlpool Refrigerator Cover Pan In Stock WPL W10508993 $201.86

3

WP2152713 Whirlpool Refrigerator Solenoid In Stock WPL WP2152713 $172.77

3

WP2156022 Whirlpool Refrigerator Door Trim In Stock WPL WP2156022 $57.99

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $11.99

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

3

SLIDE MEAT PAN CONTROL WPL 2182757 Contact Us For Availability

3

Grommet WPL 2176134 Contact Us For Availability

4

W10756902 Whirlpool Refrigerator Air Duct Backorder WPL W10756902 $76.58

4

W11223328 Whirlpool Refrigerator Shelf Stud In Stock WPL W11223328 $14.99

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $27.81

4

WP489491 Whirlpool Refrigerator Screw Backorder WPL WP489491 $4.82

4

WPW10224328 Whirlpool Refrigerator Spring In Stock WPL WPW10224328 $60.55

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $25.38

5

WP2187172 Whirlpool Refrigerator Door Shelf B In Stock WPL WP2187172 $29.87

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $11.99

5

WP2309718 Whirlpool Refrigerator Door Trim In Stock WPL WP2309718 $51.84

5

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $23.99

6

4389144 Whirlpool Refrigerator Evaporator Fan In Stock WPL 4389144 $62.77

6

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $177.48

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $5.99

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $8.99

6

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $9.65

6

Trim, Handle (White) WPL 2194272W Contact Us For Availability

6

Trim, Handle (Biscuit) WPL 2194272T Contact Us For Availability

7

2159082 Whirlpool Refrigerator Door Gasket Bl In Stock WPL 2159082 $228.51

7

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $30.99

7

WP3-24004-109 Whirlpool Refrigerator Screw Backorder WPL WP3-24004-109 $4.82

7

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $7.20

7

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $3.91

7

TUBE, SUCTION WPL 2205765 Contact Us For Availability

7

Ladder, Shelf WPL 2319866 Contact Us For Availability

8

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $4.96

8

WPW10169511 Whirlpool Refrigerator Coupling In Stock WPL WPW10169511 $19.85

8

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $4.82

8

WPW10307490 Whirlpool Door Trim Assembly In Stock WPL WPW10307490 $13.16

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $63.66

9

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $24.99

9

WP2206670T Whirlpool Refrigerator Grille Backorder WPL WP2206670T $44.34

9

WP3400012 Whirlpool Refrigerator Screw In Stock WPL WP3400012 $4.82

9

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $6.83

2311641 Whirlpool Refrigerator Wire Harness Backorder WPL 2311641 $152.63

W11084324 Whirlpool Refrigerator Wire Harness Backorder WPL W11084324 $73.13

WP2188661 Whirlpool Crisper Pan In Stock WPL WP2188661 $148.73

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $4.82

W10122561 Whirlpool Refrigerator Cup Fill In Stock WPL W10122561 $17.79

W11527119 Whirlpool Refrigerator Shelf Stud Backorder WPL W11527119 $6.79

WP2155789 Whirlpool Refrigerator Gasket Backorder WPL WP2155789 $4.82

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $4.60

WP2182195 Whirlpool Refrigerator Cam Backorder WPL WP2182195 $6.63

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $42.99

WP2186494T Whirlpool Water Filter Cap In Stock WPL WP2186494T $7.99

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $36.34

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $58.99

Lever, Ice Dispenser (Biscuit) WPL 2195089T Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $7.12

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $58.83

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $6.99

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $8.97

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $62.57

WP489483 Whirlpool Screw In Stock WPL WP489483 $7.58

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $59.71

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $4.99

BRACKET, DOOR STOP (CHROME) WPL W10185570 Contact Us For Availability

SCREW WPL W10172289 Contact Us For Availability

2150331 Whirlpool Refrigerator Wire Cover Backorder WPL 2150331 $16.09

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $67.59

W10185566 Whirlpool Bracket Backorder WPL W10185566 $8.57

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $8.89

WP2203771 Whirlpool Refrigerator Door Hinge In Stock WPL WP2203771 $62.99

WP2304241 Whirlpool Refrigerator Gasket Backorder WPL WP2304241 $54.59

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $61.99

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $15.58

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $10.72

WP2188664 Whirlpool Refrigerator Meat Crisper In Stock WPL WP2188664 $57.82

Pivot Arm WPL 1110559 Contact Us For Availability

Cover, Evaporator WPL 2203841 Contact Us For Availability

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $56.13

2203407T Whirlpool Refrigerator Cover Backorder WPL 2203407T $12.83

4389654 Whirlpool Screw Backorder WPL 4389654 $8.89

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $57.37

WP2194272B Whirlpool Refrigerator Handle Endc Backorder WPL WP2194272B $4.82

WP2203407B Whirlpool Refrigerator Cover Backorder WPL WP2203407B $13.08

WP2203407W Whirlpool Refrigerator Cover Backorder WPL WP2203407W $14.39

W10138965 Whirlpool Refrigerator Door Hinge Backorder WPL W10138965 $60.74

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $287.76

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

End Cap (8) WPL 2195917 Contact Us For Availability

4388358 Whirlpool Refrigerator Support Bracke Backorder WPL 4388358 $20.18

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.99

WP2186443 Whirlpool Water Filter Housing In Stock WPL WP2186443 $68.99

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $6.87

Lever, Water Dispenser (Biscuit) WPL 2195090T Contact Us For Availability

Clamp WPL 2161324 Contact Us For Availability

18

W11239891 Whirlpool Refrigerator Light Lens Backorder WPL W11239891 $64.80

18

Filler, Wrapper (White) WPL 2304846 Contact Us For Availability

19

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $14.02

19

W11342242 Whirlpool Refrigerator Ice Level Ar In Stock WPL W11342242 $43.68

19

Grille (Biscuit) WPL 2198468T Contact Us For Availability

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $31.65

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $16.99

WP489497 Whirlpool Screw In Stock WPL WP489497 $6.75

Stud, Rear WPL 2196207 Contact Us For Availability

21

W10845583 Whirlpool Refrigerator Track Backorder WPL W10845583 $81.92

21

W10845585 Whirlpool Refrigerator Track Backorder WPL W10845585 $90.95

21

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $6.84

22

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

23

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $20.97

23

WP2174267 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2174267 $58.88

23

Fastener, Push-On WPL 489285 Contact Us For Availability

24

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

24

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $4.82

24

Spacer, Switch (2) WPL 625834 Contact Us For Availability

2182111 Whirlpool Refrigerator Thermal Knob Backorder WPL 2182111 $18.73

W11566763 Whirlpool Fitting In Stock WPL W11566763 $31.99

W11596045 Whirlpool Refrigerator Control Arm In Stock WPL W11596045 $19.99

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $7.28

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $7.19

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $12.12

W11512417 Whirlpool Drain Connector In Stock WPL W11512417 $17.99

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $9.19

WP2323198 Whirlpool Refrigerator Heater In Stock WPL WP2323198 $45.79

Knob, Air Control WPL 2197871 Contact Us For Availability

27

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $6.92

30

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $4.82

30

WP2203408B Whirlpool Refrigerator Cover Backorder WPL WP2203408B $19.99

30

WP2203408W Whirlpool Refrigerator Cover Backorder WPL WP2203408W $14.54

31

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $8.89

32

WP489236 Whirlpool Refrigerator Ring In Stock WPL WP489236 $7.64

34

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $7.11

35

WP2171706 Whirlpool Refrigerator Light Lens Backorder WPL WP2171706 $65.24

36

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $8.89

39

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $4.82

40

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $13.89

41

WPW10334458 Whirlpool Refrigerator Connector Backorder WPL WPW10334458 $14.46

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

350942 Whirlpool Spray Paint Backorder WPL 350942 $49.86

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $16.99

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.99

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $53.03

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $18.58

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.88

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.85

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

REFINISHING MATERIAL (ENAMEL, WHITE (1 QT. UN WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability
