Model Whirlpool JFC2070KRW11 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2256087 Whirlpool Refrigerator Bracket Backorder WPL WP2256087 $67.88

1

WP67002332 Whirlpool Refrigerator Glass Pan Backorder WPL WP67002332 $165.90

1

Door, Left (White) WPL 67006589 Contact Us For Availability

1

Door, Left (Black) WPL 67006591 Contact Us For Availability

1

Door, Freezer (Black) WPL 13092204BQ Contact Us For Availability

1

Door, Freezer (White) WPL 13092204WQ Contact Us For Availability

2

W10156818 Whirlpool Refrigerator Fan Blade In Stock WPL W10156818 $51.80

2

WPB5705307 Whirlpool Refrigerator Tube In Stock WPL WPB5705307 $6.80

2

MODULE, LIGHT WPL 67004078 Contact Us For Availability

2

Door, Right (White) WPL 67006593 Contact Us For Availability

2

Door, Right (Black) WPL 67006595 Contact Us For Availability

2

Trim, Crisper WPL 67004724 Contact Us For Availability

3

W10436252 Whirlpool Door Gasket In Stock WPL W10436252 $148.44

3

W10443319 Whirlpool Door Gasket In Stock WPL W10443319 $217.42

3

W11448709 Whirlpool Refrigerator Bracket Backorder WPL W11448709 $16.36

3

WP67003637 Whirlpool Dairy Door Backorder WPL WP67003637 $54.67

3

Overlay WPL 67004722 Contact Us For Availability

3

Clamp WPL 67003932 Contact Us For Availability

3

SCREW WPL 67006608 Contact Us For Availability

3

Basepan WPL 67005889 Contact Us For Availability

4

WP67001279 Whirlpool Refrigerator Dairy Tray Backorder WPL WP67001279 $57.50

4

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.49

4

WPW10464769 Whirlpool Refrigerator Housing Backorder WPL WPW10464769 $74.99

4

Basket, Freezer (Upper) WPL 67004989 Contact Us For Availability

5

67004748 Whirlpool Refrigerator Door Bucket Backorder WPL 67004748 $57.51

5

67004749 Whirlpool Refrigerator Door Shelf Ga Backorder WPL 67004749 $58.57

5

WP67003753 Whirlpool Refrigerator Inlet Valve In Stock WPL WP67003753 $76.87

5

WPW10503278 Whirlpool Refrigerator Electronic In Stock WPL WPW10503278 $209.77

5

MOUNT, HANDLE WPL 67006109 Contact Us For Availability

5

Basket, Freezer (Lower) WPL 67006027 Contact Us For Availability

5

Block, Condenser WPL 67005491 Contact Us For Availability

6

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $25.74

6

WP12722803B Whirlpool Door Guide Backorder WPL WP12722803B $153.55

6

WP12722803W Whirlpool Door Support In Stock WPL WP12722803W $161.26

6

WP12866903 Whirlpool Refrigerator Discharge T Backorder WPL WP12866903 $90.37

6

WP67004028 Whirlpool Refrigerator Shut-Off Ar In Stock WPL WP67004028 $40.55

6

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $5.30

6

Shelf (4) WPL 67003021 Contact Us For Availability

7

W10709795 Whirlpool Refrigerator Screw Backorder WPL W10709795 $8.70

7

W11284721 Whirlpool Refrigerator Cover Backorder WPL W11284721 $69.33

7

W11311945 Whirlpool Refrigerator Screw Backorder WPL W11311945 $8.89

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $4.82

7

Harness, Evap. Heater WPL W10119856 Contact Us For Availability

8

12806601 Whirlpool Refrigerator Light Housing Backorder WPL 12806601 $75.97

8

W10830189 Whirlpool Refrigerator Door Gasket In Stock WPL W10830189 $147.39

8

W11368721 Whirlpool Refrigerator French Door In Stock WPL W11368721 $124.89

8

WP12579803 Whirlpool Refrigerator Drain Pan Backorder WPL WP12579803 $207.03

8

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $5.30

8

WPA3223101 Whirlpool Refrigerator Insert PL Backorder WPL WPA3223101 $4.82

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $6.61

9

WP12850909 Whirlpool Refrigerator Handle Backorder WPL WP12850909 $205.33

9

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $187.20

9

DIVIDER, BASKET (UPPER) WPL 67004127 Contact Us For Availability

9

Grommet (3) WPL 61004743 Contact Us For Availability

W10122561 Whirlpool Refrigerator Cup Fill In Stock WPL W10122561 $17.79

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $8.33

WP67002493 Whirlpool Refrigerator Defrost Hea In Stock WPL WP67002493 $80.03

Divider, Basket (Lower) WPL 67004727 Contact Us For Availability

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $46.55

67003900 Whirlpool Refrigerator Insert Damper Backorder WPL 67003900 $6.02

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $5.02

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $8.39

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $63.89

Clip, Retainer WPL 67007052 Contact Us For Availability

W10613606 Whirlpool Refrigerator Start Device In Stock WPL W10613606 $57.90

W11772394 Whirlpool Screw In Stock WPL W11772394 $8.39

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $59.60

NAMEPLATE WPL 12848704 Contact Us For Availability

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $34.13

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $76.89

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $73.20

WP854334 Whirlpool Air Conditioner Sealing St Backorder WPL WP854334 $8.27

WPW10133608 Whirlpool Refrigerator Screw Backorder WPL WPW10133608 $4.82

14

W11750607 Whirlpool Insulation Backorder WPL W11750607 $32.09

14

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $6.88

14

WPW10165425 Whirlpool Bimetal Defrost Thermos In Stock WPL WPW10165425 $52.91

67005680 Whirlpool Refrigerator Condenser Gro Backorder WPL 67005680 $14.02

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $56.89

WP67003638 Whirlpool Closing Cam In Stock WPL WP67003638 $5.30

WP67003639 Whirlpool Refrigerator Closer In Stock WPL WP67003639 $46.99

WPW10196393 Whirlpool Control Damper In Stock WPL WPW10196393 $169.94

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $31.88

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $15.02

WP67002659 Whirlpool Crisper Pan In Stock WPL WP67002659 $101.84

SCREW WPL 67006573 Contact Us For Availability

WP12227304WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12227304WD $72.58

WP2300868 Whirlpool Refrigerator Fitting In Stock WPL WP2300868 $20.55

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $6.02

WPW10169124 Whirlpool Refrigerator Grommet In Stock WPL WPW10169124 $6.02

W11714300 Whirlpool Insulation Backorder WPL W11714300 $36.39

WP67006131 Whirlpool Refrigerator Condenser Backorder WPL WP67006131 $240.21

WP67006185 Whirlpool Refrigerator Crisper Fra Backorder WPL WP67006185 $126.33

WPD7813010 Whirlpool Refrigerator Wire Harnes In Stock WPL WPD7813010 $37.15

12846902 Whirlpool Refrigerator Screw Backorder WPL 12846902 $8.39

W11361728 Whirlpool Reservoir Assembly In Stock WPL W11361728 $75.97

WP67006655 Whirlpool Refrigerator Crisper Gla Backorder WPL WP67006655 $201.33

WPM0114003 Whirlpool Microwave Speed Clip Cla Backorder WPL WPM0114003 $6.89

67001073 Whirlpool Refrigerator Center Ladder Backorder WPL 67001073 $37.25

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $5.02

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $102.30

W11547653 Whirlpool Refrigerator Drip Tray Backorder WPL W11547653 $35.72

Dispenser WPL W10158503 Contact Us For Availability

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $67.53

WP33001882 Whirlpool Screw Backorder WPL WP33001882 $60.93

Cover, Unit WPL 67006101 Contact Us For Availability

Ladder, Side WPL 67002489 Contact Us For Availability

12002041 Whirlpool Refrigerator Evaporator Re In Stock WPL 12002041 $210.45

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

WP67001668 Whirlpool Water Filter Housing In Stock WPL WP67001668 $8.63

WPW10175909 Whirlpool Grille Assembly In Stock WPL WPW10175909 $39.08

Grille, Toe (Black) WPL W10131134 Contact Us For Availability

WP67006524 Whirlpool Refrigerator Housing In Stock WPL WP67006524 $102.41

WPW10167023 Whirlpool Refrigerator Shroud Backorder WPL WPW10167023 $67.69

Dam (Left Side) WPL 67001083 Contact Us For Availability

Dam (Right Side) WPL 67001084 Contact Us For Availability

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $8.23

W10332340 Whirlpool Refrigerator Mat Backorder WPL W10332340 $79.10

WP12568001 Whirlpool Filter Cover In Stock WPL WP12568001 $63.55

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $24.18

Motor, Fan WPL 67004432 Contact Us For Availability

EDR4RXD1 Whirlpool EveryDrop® Refrigerator W In Stock WPL EDR4RXD1 $65.34

W11673433 Whirlpool Clip Backorder WPL W11673433 $99.38

W11812285 Whirlpool Support Backorder WPL W11812285 $36.28

WP67001255 Whirlpool Ice Bucket Backorder WPL WP67001255 $140.55

WP12227305WD Whirlpool Drawer Support Backorder WPL WP12227305WD $72.41

FIBER, ACOUSTIC WPL 67003796 Contact Us For Availability

Plug, Filter Bypass WPL 12664501 Contact Us For Availability

Harness, Unit with Power Cord WPL 13060101 Contact Us For Availability

27

W10819546 Whirlpool Refrigerator Clip Backorder WPL W10819546 $8.16

27

WP67001719 Whirlpool Refrigerator Track Backorder WPL WP67001719 $4.82

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $22.83

28

67002329 Whirlpool Refrigerator Pantry Gasket Backorder WPL 67002329 $14.02

28

W10160407 Whirlpool Refrigerator Compressor In Stock WPL W10160407 $428.79

29

12656202 Whirlpool Refrigerator Housing Backorder WPL 12656202 $103.70

29

W11519867 Whirlpool Refrigerator Cover In Stock WPL W11519867 $20.02

29

CLIP, EVAPORATOR WPL 10623002 Contact Us For Availability

30

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $59.65

30

WP12575501 Whirlpool Refrigerator Micro Switc Backorder WPL WP12575501 $47.06

30

WP67003793 Whirlpool Refrigerator Temperature Backorder WPL WP67003793 $52.62

12707303SP Whirlpool Refrigerator Plate Backorder WPL 12707303SP $56.05

WP12656018 Whirlpool Drawer Support In Stock WPL WP12656018 $37.16

WP12656105 Whirlpool Drawer Support In Stock WPL WP12656105 $42.17

Shroud WPL W10158508 Contact Us For Availability

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $10.50

67002816 Whirlpool Refrigerator Waterline Cli Backorder WPL 67002816 $11.80

WP67004953 Whirlpool Refrigerator Bracket Backorder WPL WP67004953 $49.60

WP98165 Whirlpool Screw In Stock WPL WP98165 $4.82

33

W11677725 Whirlpool Refrigerator Guide Backorder WPL W11677725 $14.02

33

WP67004954 Whirlpool Refrigerator Screw Backorder WPL WP67004954 $4.82

33

WPW10235370 Whirlpool Refrigerator Glide Backorder WPL WPW10235370 $215.16

34

10547003 Whirlpool Refrigerator Dryer Clip Backorder WPL 10547003 $6.89

34

WP67006415 Whirlpool Refrigerator Screw In Stock WPL WP67006415 $4.82

35

67003794 Whirlpool Refrigerator Temperature C Backorder WPL 67003794 $8.68

36

W11498983 Whirlpool Refrigerator Knob Backorder WPL W11498983 $18.44

36

WPW10137529 Whirlpool Refrigerator Grommet Backorder WPL WPW10137529 $4.82

37

M0286708 Whirlpool Refrigerator Holder Nut As Backorder WPL M0286708 $33.41

37

W11490183 Whirlpool Refrigerator Utility Pan Backorder WPL W11490183 $91.34

38

W10827015 Whirlpool Refrigerator Pantry Drawe In Stock WPL W10827015 $130.63

100

D7824706Q Whirlpool Refrigerator Ice Maker As In Stock WPL D7824706Q $100.10

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $37.41

285006 Whirlpool Spray In Stock WPL 285006 $52.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $30.02

350942 Whirlpool Spray Paint Backorder WPL 350942 $64.04

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $19.58

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $21.50

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $32.12

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $80.02

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $87.85

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $92.18

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $80.29

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $119.63

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $43.17

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $67.02

Valve, Access (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE UNCUT) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Harness, Controls (Refrigerator) WPL 67004756 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI3329A50 Contact Us For Availability

CLEANER, 10 OZ. STAINLESS STEEL WPL 31462 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

Kit, Evaporator Repair (Aluminum Epoxy) WPL 799833 Contact Us For Availability

Important: The spray paint is not to be used WPL ARI3332A41 Contact Us For Availability

Miscellaneous WPL ARI3333A97 Contact Us For Availability

TORX SCREW WRENCH WPL ARI3334A29 Contact Us For Availability

ACCESSORIES WPL ARI3335A35 Contact Us For Availability

Valve, Access (1/2``) WPL 978028 Contact Us For Availability

Following Parts Not Illustrated and Optional WPL ARI3330A17 Contact Us For Availability

REFRIGERANT CHARGE 5.25 Ozs. (R-134A) WPL ARI3331A51 Contact Us For Availability
