Model Whirlpool ED20TQXFN01 SIDE BY SIDE REFRIGERATOR – Common Parts &amp; Diagrams

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.82

1

NLA:SCREW Backorder WPL WPW10141645 $4.82

1

LITERATURE PARTS (Service & Wiring Sheet) WPL LIT2186936 Contact Us For Availability

1

LITERATURE PARTS (Use & Care Guide) WPL LIT2205958 Contact Us For Availability

1

Energy Label WPL LIT2206390 Contact Us For Availability

1

Modular Icemaker Service Sheet WPL LIT628370 Contact Us For Availability

1

Refrigerator Door Panel (Almond) WPL 2194612N Contact Us For Availability

1

Refrigerator Door Panel (Biscuit) WPL 2194612T Contact Us For Availability

1

Refrigerator Door Panel (White) WPL 2194612W Contact Us For Availability

1

Freezer, Door Panel (Almond) WPL 2186403N Contact Us For Availability

1

Freezer, Door Panel (Biscuit) WPL 2186403T Contact Us For Availability

1

Freezer, Door Panel (White) WPL 2186403W Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI25960A7 Contact Us For Availability

2

2194744 Whirlpool Refrigerator Escutcheon Backorder WPL 2194744 $62.28

2

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $5.99

2

Blade, Fan WPL 2190685 Contact Us For Availability

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

2

Mounting Bracket WPL 1110629 Contact Us For Availability

2

Front Roller (2) WPL 2174748 Contact Us For Availability

2

Clip WPL 2198369 Contact Us For Availability

2

Slide, Ice Door WPL 1115380 Contact Us For Availability

3

2171712 Whirlpool Refrigerator Ice Door Backorder WPL 2171712 $47.55

3

W10850698 Whirlpool Refrigerator Screw Backorder WPL W10850698 $7.08

3

WP2152713 Whirlpool Refrigerator Solenoid In Stock WPL WP2152713 $172.77

3

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $4.60

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $11.99

3

SLIDE MEAT PAN CONTROL WPL 2182757 Contact Us For Availability

3

Handle (Almond) WPL 2186649N Contact Us For Availability

3

Handle (Biscuit) WPL 2186649T Contact Us For Availability

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $27.81

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $25.38

4

Cap, Hinge Sleeve WPL 509929 Contact Us For Availability

4

Bracket, Fill Tube WPL 2209674 Contact Us For Availability

5

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $14.02

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $11.99

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

5

Bracket, Door Stop WPL 2195950 Contact Us For Availability

6

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $6.90

6

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $4.82

6

WPW10329686 Whirlpool Door Cam Black In Stock WPL WPW10329686 $4.60

7

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $15.88

8

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $7.11

8

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $5.99

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $30.99

8

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $3.91

8

Retainer, Gasket WPL 1117767 Contact Us For Availability

8

Shelf (1) WPL 2174269 Contact Us For Availability

8

Shelf (2) WPL 2174270 Contact Us For Availability

9

W11223328 Whirlpool Refrigerator Shelf Stud In Stock WPL W11223328 $14.99

9

WP2196046 Whirlpool Refrigerator Door Hinge Backorder WPL WP2196046 $70.35

9

Grille, Overflow (White) WPL 2183787W Contact Us For Availability

9

Stud, Rear WPL 2196207 Contact Us For Availability

9

Cover, Unit Compartment WPL 2182057 Contact Us For Availability

2188405A Whirlpool Refrigerator Door Gasket Backorder WPL 2188405A $223.28

W10142289 Whirlpool Air Conditioner Screw Backorder WPL W10142289 $6.10

W10853654 Whirlpool Water Inlet Valve In Stock WPL W10853654 $115.66

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $4.96

Shim, Hinge (2) WPL 2196048 Contact Us For Availability

2182146 Whirlpool Refrigerator Duct Backorder WPL 2182146 $64.58

WP2182195 Whirlpool Refrigerator Cam Backorder WPL WP2182195 $6.63

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $7.60

Hinge Cover (White) WPL 1129262 Contact Us For Availability

Lever, Ice Dispenser (Biscuit) WPL 2195089T Contact Us For Availability

Hinge Cover (Almond) WPL 2150343 Contact Us For Availability

Hinge Cover (Biscuit) WPL 2186858 Contact Us For Availability

Gasket Retainer, Top & Bottom WPL 1118301 Contact Us For Availability

Bin, Freezer WPL 2171707 Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $7.12

2188404A Whirlpool Refrigerator Door Gasket In Stock WPL 2188404A $201.57

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $8.97

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $4.82

Screw WPL 489284 Contact Us For Availability

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $67.59

8201707 Whirlpool Door Hinge In Stock WPL 8201707 $53.71

W10845585 Whirlpool Refrigerator Track Backorder WPL W10845585 $90.95

Grommet (4) WPL 2176134 Contact Us For Availability

Panel, Interior Door WPL 2196140 Contact Us For Availability

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $10.72

WP2196090 Whirlpool Refrigerator Container Backorder WPL WP2196090 $125.90

WP489497 Whirlpool Screw In Stock WPL WP489497 $6.75

Handle, Center (White) WPL 2186649W Contact Us For Availability

Trim, Door Shelf (4) WPL 2169749 Contact Us For Availability

Cover, Wiring WPL 2155572 Contact Us For Availability

W10749708 Whirlpool Refrigerator Coupling Backorder WPL W10749708 $15.42

WP2181911 Whirlpool Refrigerator Shim Backorder WPL WP2181911 $21.08

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $4.99

Pivot Arm WPL 1110559 Contact Us For Availability

Reinforcement, Shelf WPL 2152266 Contact Us For Availability

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $56.13

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $9.65

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $7.20

Filler, Wrapper (White) WPL 2196094 Contact Us For Availability

Filler, Wrapper (Almond) WPL 2196095 Contact Us For Availability

Filler, Wrapper (Biscuit) WPL 2196150 Contact Us For Availability

Tube, Water Line WPL 2196117 Contact Us For Availability

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $177.48

Lever, Water Dispenser (Biscuit) WPL 2195090T Contact Us For Availability

Grille (Almond) WPL 2198469N Contact Us For Availability

Grille (Biscuit) WPL 2198469T Contact Us For Availability

Grille (White) WPL 2198469W Contact Us For Availability

Screw Anchor WPL 941242 Contact Us For Availability

Harness, Door WPL 2198271 Contact Us For Availability

W11233072 Whirlpool Screw In Stock WPL W11233072 $19.85

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $6.99

WP2180279 Whirlpool Refrigerator Switch Backorder WPL WP2180279 $169.83

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $74.99

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $4.82

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

W11457217 Whirlpool Refrigerator Rocker Switc In Stock WPL W11457217 $17.77

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $8.89

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $6.83

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $13.89

20

WP2196483 Whirlpool Refrigerator Shelf Stud In Stock WPL WP2196483 $6.50

20

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $176.99

20

Tube, Door Wiring WPL 2196116 Contact Us For Availability

21

WP3400806 Whirlpool Screw In Stock WPL WP3400806 $4.99

21

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

22

W11566763 Whirlpool Fitting In Stock WPL W11566763 $31.99

22

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $29.99

22

Insulation, Dispenser WPL 2149014 Contact Us For Availability

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $19.72

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $6.87

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $59.71

Front Cover Assembly (Includes Items 18, 19, WPL 2194569T Contact Us For Availability

Front Cover Assembly (Includes Items 18, 19, WPL 2194569W Contact Us For Availability

Chute, Ice WPL 2180204 Contact Us For Availability

WP1108439 Whirlpool Refrigerator Clip Backorder WPL WP1108439 $6.93

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $55.70

WP2182189 Whirlpool Door Shelf Bar In Stock WPL WP2182189 $87.99

Spacer, Switch (2) WPL 625834 Contact Us For Availability

Fastener, Push-On WPL 489285 Contact Us For Availability

Tap, Plate WPL 2196135 Contact Us For Availability

1119787 Whirlpool Refrigerator Hinge Cover Backorder WPL 1119787 $15.75

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $58.83

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $14.02

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $7.19

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $68.41

2182111 Whirlpool Refrigerator Thermal Knob Backorder WPL 2182111 $18.73

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $31.65

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $8.91

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $15.58

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $6.88

WP3400012 Whirlpool Refrigerator Screw In Stock WPL WP3400012 $4.82

Heater, Dispenser WPL 2198094 Contact Us For Availability

WP2188756 Whirlpool Refrigerator Unit Cover Backorder WPL WP2188756 $89.30

WP489483 Whirlpool Screw In Stock WPL WP489483 $7.58

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $71.99

Knob, Air Control WPL 2197871 Contact Us For Availability

Interior Door Panel (Also Order Item No.15) WPL 2196137 Contact Us For Availability

Cement Alumilastic) WPL 542369 Contact Us For Availability

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.99

W10845583 Whirlpool Refrigerator Track Backorder WPL W10845583 $81.92

Trim, Door Shelf (2) WPL 2198488 Contact Us For Availability

Slide, Ice Container (Left Side) WPL 1115383 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

350942 Whirlpool Spray Paint Backorder WPL 350942 $49.86

350956 Whirlpool Spray Assembly In Stock WPL 350956 $29.99

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $53.03

718257 Whirlpool Dishwasher Screw Backorder WPL 718257 $8.89

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $18.58

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $15.99

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

WP2196189 Whirlpool Shelf Retainer Bar Backorder WPL WP2196189 $8.78

WP2196190 Whirlpool Shelf Retainer Bar Suppor In Stock WPL WP2196190 $8.79

WP3400912 Whirlpool Refrigerator Washer Backorder WPL WP3400912 $4.82

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.85

WP72107 Whirlpool Touchup In Stock WPL WP72107 $14.61

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

30

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $20.97

30

WP489491 Whirlpool Refrigerator Screw Backorder WPL WP489491 $4.82

30

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.91

W11342242 Whirlpool Refrigerator Ice Level Ar In Stock WPL W11342242 $43.68

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $4.82

WP2193353W Whirlpool Refrigerator Trim Handle In Stock WPL WP2193353W $5.99

Endcap, Handle (2) (Almond) WPL 2193353N Contact Us For Availability

Endcap, Handle (2) (Biscuit) WPL 2193353T Contact Us For Availability

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $7.28

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $88.98

Retainer, Gasket WPL 1117766 Contact Us For Availability

Compartment Door WPL 2148289 Contact Us For Availability

33

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $12.12

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $16.99

33

Trim, Door Compartment WPL 2188148 Contact Us For Availability

34

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $6.92

34

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $122.18

37

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $71.99

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

38

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $4.82

39

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $8.89

40

WP489236 Whirlpool Refrigerator Ring In Stock WPL WP489236 $7.64

40

Nut, Compression WPL 1129179 Contact Us For Availability

44

Front Cover, Ice Container WPL 2171709 Contact Us For Availability

46

WP2171706 Whirlpool Refrigerator Light Lens Backorder WPL WP2171706 $65.24

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $4.82

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.88

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

NI

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $130.99
