Model Whirlpool KSRX22FNBT02 Refrigerator – Common Parts &amp; Diagrams

1

Control Box WPL 2216588 Contact Us For Availability

2

WP2256096 Whirlpool Refrigerator Fitting In Stock WPL WP2256096 $78.72

2

Retainer, Fan Motor WPL 2155590 Contact Us For Availability

3

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.68

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $7.91

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $22.69

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $25.38

4

Washer WPL 2258220 Contact Us For Availability

5

W10683556 Whirlpool Refrigerator Clip Backorder WPL W10683556 $12.26

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $8.89

5

WP2161460 Whirlpool Refrigerator Thermostat Backorder WPL WP2161460 $187.64

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $11.99

5

WP2223357 Whirlpool Refrigerator Cover In Stock WPL WP2223357 $175.95

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

5

Dish, Butter WPL 2165792K Contact Us For Availability

6

W11223328 Whirlpool Refrigerator Shelf Stud Backorder WPL W11223328 $14.99

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $5.99

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $12.74

6

WP8533993 Whirlpool Refrigerator Screw Backorder WPL WP8533993 $6.83

6

WPW10366605-includeCORE Whirlpool WPW10366605 Backorder WPL WPW10366605-includeCORE $267.52

6

Shelf Bin (4) WPL 2171063K Contact Us For Availability

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $8.89

7

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $5.30

7

Heat Shield And Drain Pan WPL 2304288 Contact Us For Availability

8

2205764 Whirlpool Refrigerator Tube Backorder WPL 2205764 $60.78

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $6.99

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $22.25

8

WP2186443 Whirlpool Water Filter Housing In Stock WPL WP2186443 $57.30

8

Cover, Light Lens WPL 2200096 Contact Us For Availability

8

Glass, Cover WPL 2255144 Contact Us For Availability

9

WP2206671B Whirlpool Refrigerator Grille In Stock WPL WP2206671B $39.17

9

WP2206671W Whirlpool Refrigerator Grille In Stock WPL WP2206671W $45.36

9

Blade, Fixed WPL 2257020 Contact Us For Availability

9

Shim WPL 2209697 Contact Us For Availability

2223314 Whirlpool Refrigerator Clip Backorder WPL 2223314 $8.90

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $61.38

W10822681 Whirlpool Refrigerator Water Inlet In Stock WPL W10822681 $117.48

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $5.30

WP2203771 Whirlpool Refrigerator Door Hinge In Stock WPL WP2203771 $34.12

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $4.82

Hole Plug WPL 940014 Contact Us For Availability

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $4.82

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $6.84

Lever, Ice Dispenser — White WPL 2180259 Contact Us For Availability

Block, Blade WPL 2198602 Contact Us For Availability

Grommet, Light Bar WPL 2172906 Contact Us For Availability

2161466 Whirlpool Refrigerator Slide Backorder WPL 2161466 $14.02

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $33.86

WP2162358 Whirlpool Refrigerator Terminal Cov Backorder WPL WP2162358 $69.36

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $9.64

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $5.19

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $72.32

2203407T Whirlpool Refrigerator Cover Backorder WPL 2203407T $12.83

WP2187145 Whirlpool Refrigerator Overload Backorder WPL WP2187145 $106.42

WP2203407B Whirlpool Refrigerator Cover Backorder WPL WP2203407B $13.08

WP2203407W Whirlpool Refrigerator Cover Backorder WPL WP2203407W $14.39

NLA:SCREW Backorder WPL WPW10141645 $4.82

Shelf Track — Right Side WPL 2301289 Contact Us For Availability

Shelf Track — Left Side WPL 2301290 Contact Us For Availability

Eyelet, Roller WPL 2174478 Contact Us For Availability

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $13.13

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $6.87

Light Bar WPL 2179920 Contact Us For Availability

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

2172931 Whirlpool Refrigerator Shield Backorder WPL 2172931 $51.65

2261599 Whirlpool Refrigerator Tube Backorder WPL 2261599 $177.37

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $6.90

WP2209751 Whirlpool Refrigerator Air Diffuser In Stock WPL WP2209751 $186.46

WPW10272364 Whirlpool Refrigerator Screw Backorder WPL WPW10272364 $6.83

Filler, Wrapper — White WPL 2196094 Contact Us For Availability

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $15.58

WP2206629B Whirlpool Refrigerator Bracket Backorder WPL WP2206629B $23.94

WP2220457 Whirlpool Refrigerator Ice Bin Coup In Stock WPL WP2220457 $23.61

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $7.20

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $4.82

Crisper Pan (Includes 13, 14 18, 19 & 21) WPL 2301481 Contact Us For Availability

2150331 Whirlpool Refrigerator Wire Cover Backorder WPL 2150331 $16.09

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $47.85

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $6.29

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $51.14

WPW10170540 Whirlpool Screw In Stock WPL WPW10170540 $7.53

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $45.27

Meat Pan (Includes 13, 14, 19 & 22) WPL 2301482 Contact Us For Availability

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $16.02

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $4.82

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $4.82

Window, Crisper WPL 2174076 Contact Us For Availability

Relay WPL 2183454 Contact Us For Availability

W10853646 Whirlpool Indicator Light In Stock WPL W10853646 $95.20

WP2198587 Whirlpool Refrigerator Cover Backorder WPL WP2198587 $71.95

WP2256126 Whirlpool Refrigerator Reservoir In Stock WPL WP2256126 $86.55

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $13.89

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $19.72

WPW10122550 Whirlpool Refrigerator Ice Mold Backorder WPL WPW10122550 $153.06

Unit Cover, Bottom WPL 2182057 Contact Us For Availability

Harness, Control Box WPL 2216587 Contact Us For Availability

2172940 Whirlpool Window Backorder WPL 2172940 $13.22

2223285 Whirlpool Refrigerator Cap Backorder WPL 2223285 $14.02

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $7.11

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $4.82

Cap, Crisper Pan — Right Side WPL 2223286 Contact Us For Availability

WP2188822 Whirlpool Refrigerator Evaporator In Stock WPL WP2188822 $203.37

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $63.61

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $29.99

Clip, Wiring WPL 1115375 Contact Us For Availability

23

626753 Whirlpool Refrigerator Ejector Arm Backorder WPL 626753 $9.15

23

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $10.62

23

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $6.83

W10297245 Whirlpool Refrigerator Arm Stripper Backorder WPL W10297245 $53.90

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $81.87

WP2203408B Whirlpool Refrigerator Cover Backorder WPL WP2203408B $12.92

WP2203408W Whirlpool Refrigerator Cover Backorder WPL WP2203408W $14.54

Holder WPL 2212369 Contact Us For Availability

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $7.19

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $73.20

WP2220458 Whirlpool Drive Cam In Stock WPL WP2220458 $24.59

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $58.40

Escutcheon, Control Box WPL 2301067 Contact Us For Availability

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $5.77

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $9.19

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $6.88

WPW10309395 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10309395 $224.45

Light Bar WPL 2179921 Contact Us For Availability

27

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $29.43

27

WP2212370 Whirlpool Washer In Stock WPL WP2212370 $14.75

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $52.34

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.99

W10309990 Whirlpool Refrigerator Compressor In Stock WPL W10309990 $358.95

WP489483 Whirlpool Screw In Stock WPL WP489483 $7.58

Slide, Ice Maker WPL 2212321 Contact Us For Availability

29

W10852956 Whirlpool Refrigerator Spring In Stock WPL W10852956 $14.26

29

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $4.82

2304903 Whirlpool Refrigerator Frame Backorder WPL 2304903 $178.10

WP2179243 Whirlpool Refrigerator Pan Trim Backorder WPL WP2179243 $71.83

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $35.58

WP2186494T Whirlpool Water Filter Cap In Stock WPL WP2186494T $7.35

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $38.88

WP2188917 Whirlpool Drive Shaft In Stock WPL WP2188917 $66.78

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.46

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $7.28

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $66.95

WP2212363 Whirlpool Refrigerator Motor In Stock WPL WP2212363 $131.56

WPW10309401 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10309401 $96.51

33

WP2182770 Whirlpool Refrigerator Thermostat Backorder WPL WP2182770 $167.11

33

WP2323197 Whirlpool Refrigerator Heater Backorder WPL WP2323197 $86.68

33

Bracket, Icemaker Mounting WPL 2212317 Contact Us For Availability

34

W11623163 Whirlpool Refrigerator Clip Backorder WPL W11623163 $7.27

34

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $4.82

34

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $7.55

35

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $62.13

35

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $16.25

35

Window WPL 2172941 Contact Us For Availability

36

WP2212365 Whirlpool Refrigerator Sleeve Backorder WPL WP2212365 $20.81

36

WP2304697 Whirlpool Refrigerator Water Tube Backorder WPL WP2304697 $92.17

37

Motor (Not Serviced, Order #35) WPL N/S Contact Us For Availability

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

39

876811 Whirlpool Grommet Backorder WPL 876811 $4.82

39

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $4.82

39

WP4387558 Whirlpool Refrigerator Compressor G Backorder WPL WP4387558 $4.82

40

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $6.83

41

W10896764 Whirlpool Refrigerator Air Baffle In Stock WPL W10896764 $68.27

42

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $5.30

42

Clip, Heat WPL 2155547 Contact Us For Availability

48

Unit Mounting Rail WPL 2149718 Contact Us For Availability

49

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $8.89

50

Guard, Fan WPL 2186496 Contact Us For Availability

51

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $13.22

52

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $4.99

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $4.82

55

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

59

Clip, Wire & Tube WPL 2208280 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $29.55

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $87.85

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $92.18

WP4373559 Whirlpool Fitting In Stock WPL WP4373559 $29.71

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

Valve, Access WPL 978029 Contact Us For Availability

Valve, Access WPL 978028 Contact Us For Availability

100

WPW10190961 Whirlpool Ice Maker In Stock WPL WPW10190961 $157.86

OPT-1

350942 Whirlpool Spray Paint Backorder WPL 350942 $64.04

OPT-2

285006 Whirlpool Spray In Stock WPL 285006 $52.65

OPT-3

350930 Whirlpool White Spray Paint In Stock WPL 350930 $25.69

OPT-4

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $52.10

OPT-5

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $8.31

OPT-6

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $12.67

OPT-7

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $13.08

OPT-8

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $34.42

OPT-9

Tape, Vinyl WPL 479502 Contact Us For Availability

OPT-11

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $151.82

OPT-13

Kit, Foam Slab WPL 876029 Contact Us For Availability

OPT-14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $119.63

OPT-15

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $80.29

OPT-16

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

OPT-17

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $39.72

OPT-18

Cement, WPL 542639 Contact Us For Availability

OPT-19

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $56.74

OPT-20

Kit, Evaporator WPL 799833 Contact Us For Availability

OPT-21

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

OPT-22

Ice Container WPL 2258230 Contact Us For Availability

OPT-23

Enamel, Black WPL 799340 Contact Us For Availability

OPT-24

Enamel, White WPL 799344 Contact Us For Availability

OPT-25

Enamel, Biscuit WPL 4392900 Contact Us For Availability

OPT-26

Torx Key WPL 1117510 Contact Us For Availability
