Model Whirlpool 4KSRS22QFA01 REFRIGERATOR – Common Parts &amp; Diagrams

1

W11254898 Whirlpool Refrigerator Scroll Fan Backorder WPL W11254898 $212.50

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.82

1

Refrigerator Door (Includes No.7) (Almond) WPL 2194200N Contact Us For Availability

1

Refrigerator Door (Includes No.7) (White) WPL 2194200W Contact Us For Availability

1

Housing, Dispenser (Not a Serviceable Part) WPL ARI14227A8 Contact Us For Availability

1

Use & Care Guide WPL LIT2195135 Contact Us For Availability

1

LITERATURE PARTS (Service & Wiring Sheet) WPL LIT2196927 Contact Us For Availability

1

Modular Icemaker Service Sheet WPL LIT628371 Contact Us For Availability

1

Bracket, Motor WPL 2183728 Contact Us For Availability

2

2194744 Whirlpool Refrigerator Escutcheon Backorder WPL 2194744 $62.28

2

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $4.82

2

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $5.99

2

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $4.99

2

Blade, Fan WPL 2190685 Contact Us For Availability

2

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

2

Load, Lock (4) WPL 2195497 Contact Us For Availability

2

Front Roller (2) WPL 2174748 Contact Us For Availability

2

Motor, Dispenser WPL 2165401 Contact Us For Availability

3

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.68

3

2171712 Whirlpool Refrigerator Ice Door Backorder WPL 2171712 $47.55

3

W10850698 Whirlpool Refrigerator Screw Backorder WPL W10850698 $7.08

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $11.99

3

WP2313637 Whirlpool Cutting Grid Assembly In Stock WPL WP2313637 $235.99

3

WPW10129867 Whirlpool Refrigerator Solenoid Backorder WPL WPW10129867 $130.35

3

SLIDE MEAT PAN CONTROL WPL 2182757 Contact Us For Availability

4

W10850503 Whirlpool Refrigerator Guide Backorder WPL W10850503 $6.94

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $27.81

4

WPW10224328 Whirlpool Refrigerator Spring In Stock WPL WPW10224328 $60.55

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $25.38

4

Beverage Holder WPL 2193409 Contact Us For Availability

5

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $14.02

5

WP2161491 Whirlpool Crisper Drawer Cover In Stock WPL WP2161491 $142.48

5

WP2182770 Whirlpool Refrigerator Thermostat In Stock WPL WP2182770 $156.18

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $11.99

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

5

Tray, Butter WPL 2165792 Contact Us For Availability

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $5.99

6

WP2166867 Whirlpool Refrigerator Defrost Time Backorder WPL WP2166867 $127.71

6

WP2175210 Whirlpool Refrigerator Shroud Backorder WPL WP2175210 $55.95

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $8.99

6

Insert, Handle (White) WPL 2173830 Contact Us For Availability

6

Insert, Handle (Almond) WPL 2173831 Contact Us For Availability

7

2159073 Whirlpool Refrigerator Door Gasket In Stock WPL 2159073 $134.99

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $8.89

7

Door Mechanism Assembly WPL 2180208 Contact Us For Availability

7

Wiring Assembly, Ice Dispenser WPL 2186815 Contact Us For Availability

8

1129563 Whirlpool Shield Backorder WPL 1129563 $55.40

8

2159072 Whirlpool Refrigerator FIP Gasket In Stock WPL 2159072 $134.99

8

4388538 Whirlpool Refrigerator Shelf Stud Kit In Stock WPL 4388538 $15.69

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $30.99

8

WP2181911 Whirlpool Refrigerator Shim Backorder WPL WP2181911 $21.08

8

End Cap, Handle (Almond) WPL 2194778N Contact Us For Availability

8

End Cap, Handle (White) WPL 2194778W Contact Us For Availability

8

Delay Mechanism WPL 2180223 Contact Us For Availability

9

WP2161460 Whirlpool Refrigerator Thermostat Backorder WPL WP2161460 $176.93

9

WP3400852 Whirlpool Refrigerator Screw Backorder WPL WP3400852 $6.83

9

WPW10169511 Whirlpool Refrigerator Coupling In Stock WPL WPW10169511 $19.85

9

Cover, Crisper (Includes 2, 3, 4, 11, 12, 13, WPL 2174250 Contact Us For Availability

9

Grommet (4) WPL 2176134 Contact Us For Availability

9

Grille, Overflow (White) WPL 2180323 Contact Us For Availability

9

Ladder, Shelf (2) WPL 2181796 Contact Us For Availability

9

Grille, Overflow (Almond) WPL 2180324 Contact Us For Availability

9

Shim, Hinge Top WPL 2196048 Contact Us For Availability

2172940 Whirlpool Window Backorder WPL 2172940 $13.22

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $4.96

WP4388152 Whirlpool Refrigerator Fitting In Stock WPL WP4388152 $133.64

Retainer, Insert (Almond) WPL 2194776N Contact Us For Availability

Retainer, Insert (White) WPL 2194776W Contact Us For Availability

Screw WPL 489284 Contact Us For Availability

2182146 Whirlpool Refrigerator Duct Backorder WPL 2182146 $64.58

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $67.99

W10759522 Whirlpool Screw Backorder WPL W10759522 $4.82

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $5.47

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $7.60

Lever, Ice Dispenser (White) WPL 2180259 Contact Us For Availability

Hinge Cover (White) WPL 1129262 Contact Us For Availability

Lever, Ice Dispenser (Almond) WPL 2180260 Contact Us For Availability

Hinge Cover (Almond) WPL 2150343 Contact Us For Availability

Grommet, Light Bar WPL 2172906 Contact Us For Availability

2161466 Whirlpool Refrigerator Slide Backorder WPL 2161466 $14.02

8201707 Whirlpool Door Hinge In Stock WPL 8201707 $53.71

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $8.97

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $4.60

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $3.91

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $67.59

W10845583 Whirlpool Refrigerator Track Backorder WPL W10845583 $81.92

W10845585 Whirlpool Refrigerator Track Backorder WPL W10845585 $90.95

NLA:SCREW Backorder WPL WPW10141645 $4.82

Eyelet, Roller WPL 2174478 Contact Us For Availability

Filler, Wrapper (White) WPL 2196094 Contact Us For Availability

Gasket, Door Compartment WPL 2159124 Contact Us For Availability

Filler, Wrapper (Almond) WPL 2196095 Contact Us For Availability

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $10.72

WP2196089 Whirlpool Refrigerator Container In Stock WPL WP2196089 $134.99

WP489483 Whirlpool Screw In Stock WPL WP489483 $7.58

Light Bar (RC) WPL 2179920 Contact Us For Availability

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

Grille (Almond) WPL 2198469N Contact Us For Availability

Grille (White) WPL 2198469W Contact Us For Availability

W10749708 Whirlpool Refrigerator Coupling Backorder WPL W10749708 $15.42

WP2180226 Whirlpool Ice Dispenser Control Swi In Stock WPL WP2180226 $17.71

WP999367 Whirlpool Refrigerator Screw Backorder WPL WP999367 $4.82

Bracket, Door Stop WPL 2195950 Contact Us For Availability

Washer WPL 486632 Contact Us For Availability

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $14.29

WP2179227 Whirlpool Refrigerator Crisper Pan In Stock WPL WP2179227 $132.84

WP2196046 Whirlpool Refrigerator Door Hinge Backorder WPL WP2196046 $70.35

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $4.82

Shelf Bin (4) WPL 2171063 Contact Us For Availability

Bulb, Light WPL 989331 Contact Us For Availability

Stop, Cone WPL 1118480 Contact Us For Availability

WP3400012 Whirlpool Refrigerator Screw In Stock WPL WP3400012 $4.82

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $62.59

Lever, Water Dispenser (Almond) WPL 2180269 Contact Us For Availability

Feeder Cone WPL 1119074 Contact Us For Availability

2172931 Whirlpool Refrigerator Shield Backorder WPL 2172931 $48.27

W11233072 Whirlpool Screw In Stock WPL W11233072 $19.85

W11566763 Whirlpool Fitting In Stock WPL W11566763 $31.99

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $6.99

WP2180236 Whirlpool Refrigerator Switch Backorder WPL WP2180236 $189.29

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $9.65

Window, Crisper WPL 2174076 Contact Us For Availability

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $19.72

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $8.89

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $13.89

Plaque, Front Cover (Almond) WPL 2195141N Contact Us For Availability

Plaque, Front Cover (White) WPL 2195141W Contact Us For Availability

2311650 Whirlpool Refrigerator Wire Harness Backorder WPL 2311650 $60.71

W10278731 Whirlpool Refrigerator Blade Backorder WPL W10278731 $57.30

WP1108439 Whirlpool Refrigerator Clip Backorder WPL WP1108439 $6.93

Unit Cover, Bottom WPL 2182057 Contact Us For Availability

Control Box Harness WPL 2186804 Contact Us For Availability

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $7.11

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $57.37

WP489115 Whirlpool Refrigerator Rivet Backorder WPL WP489115 $4.82

Front Cover, Housing (Not Available, Order No WPL ARI14228A2 Contact Us For Availability

Cover, Unit WPL 2204420 Contact Us For Availability

1119787 Whirlpool Refrigerator Hinge Cover Backorder WPL 1119787 $15.75

W10278733 Whirlpool Refrigerator Blade Backorder WPL W10278733 $57.37

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $23.85

WP3400906 Whirlpool Refrigerator Screw Backorder WPL WP3400906 $4.82

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $29.99

CLIP, WIRING WPL 1115375 Contact Us For Availability

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $6.87

Front Cover Assembly (Includes Items 18, 19, WPL 2195139N Contact Us For Availability

Front Cover Assembly (Includes Items 18, 19, WPL 2195139W Contact Us For Availability

Service Cord WPL 1129332 Contact Us For Availability

Hole Plug WPL 2166844 Contact Us For Availability

24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $55.70

24

WPW10129864 Whirlpool Refrigerator Diffuser Backorder WPL WPW10129864 $208.86

24

Blade, Fixed (2) WPL 1119009 Contact Us For Availability

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $14.02

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $7.19

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $68.41

WP2212240 Whirlpool Refrigerator Cover Backorder WPL WP2212240 $93.96

WPW10329686 Whirlpool Door Cam Black In Stock WPL WPW10329686 $4.60

Escutcheon, Control Box WPL 2161486 Contact Us For Availability

26

2150331 Whirlpool Refrigerator Wire Cover Backorder WPL 2150331 $16.09

26

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $31.65

26

Light Bar (FC) WPL 2179921 Contact Us For Availability

W10422851 Whirlpool Ice Maker Bucket Auger Backorder WPL W10422851 $125.84

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $71.99

Enclosure, Terminal Block WPL 2188194 Contact Us For Availability

Window WPL 2172941 Contact Us For Availability

28

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $49.99

28

Terminal Block WPL 1129346 Contact Us For Availability

29

4388736 Whirlpool Refrigerator Ice Dispenser In Stock WPL 4388736 $60.55

29

Bushing WPL 1129449 Contact Us For Availability

30

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $6.90

30

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $20.97

30

Wire Assembly, Terminal Block WPL 2165297 Contact Us For Availability

31

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $4.82

31

WP2256126 Whirlpool Refrigerator Reservoir In Stock WPL WP2256126 $123.79

31

Gasket WPL 2167227 Contact Us For Availability

32

W11596045 Whirlpool Refrigerator Control Arm In Stock WPL W11596045 $19.99

32

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $7.28

32

WP489497 Whirlpool Screw In Stock WPL WP489497 $6.75

33

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $12.12

33

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $5.51

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $16.99

34

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $6.92

34

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $7.55

34

Light Lens WPL 2203266 Contact Us For Availability

35

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $6.83

35

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $3.91

36

WP489463 Whirlpool Refrigerator Screw In Stock WPL WP489463 $4.99

37

WPW10185018 Whirlpool Refrigerator Housing In Stock WPL WPW10185018 $88.88

37

Screw (2) WPL 488280 Contact Us For Availability

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

38

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $4.82

38

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $4.82

39

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $8.89

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

350942 Whirlpool Spray Paint Backorder WPL 350942 $49.86

350956 Whirlpool Spray Assembly In Stock WPL 350956 $29.99

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $53.03

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $18.58

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

WP489236 Whirlpool Refrigerator Ring In Stock WPL WP489236 $7.64

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.85

WP72107 Whirlpool Touchup In Stock WPL WP72107 $14.61

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

41

4317870 Whirlpool Refrigerator Auger Sleeve Backorder WPL 4317870 $84.14

44

Front Cover, Ice Container WPL 2171709 Contact Us For Availability

45

WP67002552 Whirlpool Refrigerator Light Bulb In Stock WPL WP67002552 $6.68

46

WP2171706 Whirlpool Refrigerator Light Lens Backorder WPL WP2171706 $65.24

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $4.82

55

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.88

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability
