Samsung DV448AEP/XAA-02 Dryer Parts List

1

Dryer Drum SMG DC97-14849A Contact Us For Availability

View on Model

1

Dryer Drive Motor SMG DC93-00101B Contact Us For Availability

View on Model

1-1

6021-001201 Samsung Dryer Left Turn Nut 3/8"- In Stock SMG 6021-001201 $3.68

View on Model

1-1

Dryer Electronic Control Board SMG DC92-00123A Contact Us For Availability

View on Model

1-2

6002-001306 Samsung Washer Tapping Screw Backorder SMG 6002-001306 $1.69

View on Model

1-3

DC47-00018A Samsung Thermostat In Stock SMG DC47-00018A $35.92

View on Model

1-3

DC97-07618A Samsung Dryer Drum Gasket Seal As In Stock SMG DC97-07618A $126.54

View on Model

1-4

DC47-00019A Samsung Dryer Heating Element Ass In Stock SMG DC47-00019A $84.26

View on Model

1-5

DC47-00016A Samsung Thermostat In Stock SMG DC47-00016A $17.72

View on Model

1-5

DC65-00013A Samsung Dryer Terminal Block Backorder SMG DC65-00013A $6.71

View on Model

1-5

DC66-00395A Samsung Dryer Door Lever Strike L In Stock SMG DC66-00395A $8.61

View on Model

1-6

DC32-00007A Samsung Dryer Thermistor Sensor Backorder SMG DC32-00007A $23.98

View on Model

1-6

DC61-01576A Samsung Support Hinge Assembly Backorder SMG DC61-01576A $11.19

View on Model

1-6

Dryer Heater Box, Upper SMG DC67-00132A Contact Us For Availability

View on Model

1-7

DC61-01214A Samsung Spring Plate Assembly Backorder SMG DC61-01214A $4.49

View on Model

1-7

Dryer Heating Element Housing, Lower SMG DC67-00133A Contact Us For Availability

View on Model

1-8

DC31-00055D Samsung Clothes Dryer Induction M In Stock SMG DC31-00055D $256.86

View on Model

1-8

DC61-00891A Samsung Washer Dryer Hinge Guide In Stock SMG DC61-00891A $1.69

View on Model

1-8

DC96-00887C Samsung Dryer Thermal Cut-Off Fus In Stock SMG DC96-00887C $49.78

View on Model

1-10

DC62-00262A Samsung Dryer Door Seal Assembly In Stock SMG DC62-00262A $61.60

View on Model

1-12

6002-000241 Samsung Self Tapping Screw Backorder SMG 6002-000241 $1.18

View on Model

1-32

DC61-02348A Samsung Duct Fan Guide Assembly Backorder SMG DC61-02348A $91.11

View on Model

1-81

DC47-00015A Samsung Dryer 250V Thermostat In Stock SMG DC47-00015A $35.04

View on Model

1-82

DC61-01204A Samsung Dryer Thermostat Bracket Backorder SMG DC61-01204A $2.70

View on Model

1-91

DC61-01213A Samsung Motor Bracket Assembly In Stock SMG DC61-01213A $120.09

View on Model

1-92

DC61-01215B Samsung Dryer Idler Tension Sprin In Stock SMG DC61-01215B $6.65

View on Model

1-93

DC63-00919A Samsung Switch Cover Assembly Backorder SMG DC63-00919A $3.35

View on Model

1-94

3405-001077 Samsung Micro Switch Backorder SMG 3405-001077 $21.24

View on Model

1-95

Dryer Screw SMG 6002-000488 Contact Us For Availability

View on Model

1-96

6009-001342 Samsung Dryer Special Puller Scre Backorder SMG 6009-001342 $1.69

View on Model

1-97

DC93-00634A Samsung Dryer Idler Pulley Assemb In Stock SMG DC93-00634A $60.18

View on Model

2

6602-001655 Samsung Dryer Drive Belt In Stock SMG 6602-001655 $52.37

View on Model

2

DC61-01522A Samsung Dryer Drying Rack Assembl Backorder SMG DC61-01522A $149.63

View on Model

2

DC61-02016A Samsung Die Heater Backorder SMG DC61-02016A $29.28

View on Model

3

DC97-07895A Samsung Dryer Connector Duct Asse Backorder SMG DC97-07895A $56.12

View on Model

3

Dryer electronic control board SMG DC92-00127A Contact Us For Availability

View on Model

3-1

DC63-10001C Samsung EPDM Sponge Backorder SMG DC63-10001C $3.90

View on Model

3-1

Duct-conne SMG DC67-00130A Contact Us For Availability

View on Model

3-2

Dryer Drum Light Lens SMG DC63-00531A Contact Us For Availability

View on Model

3-2

Sponge SMG DC72-00032E Contact Us For Availability

View on Model

3-3

6001-001773 Samsung Washer Dryer Machine Scre Backorder SMG 6001-001773 $1.69

View on Model

3-4

4713-001199 Samsung Dryer Drum Incandescent L Backorder SMG 4713-001199 $10.61

View on Model

3-4

DC64-00828A Samsung Dryer Door Switch Assembl Backorder SMG DC64-00828A $34.97

View on Model

3-5

DC47-00021A Samsung Socket Lamp Assembly Backorder SMG DC47-00021A $26.09

View on Model

3-6

DC97-08894A Samsung Dryer Moisture Sensor Gui Backorder SMG DC97-08894A $37.79

View on Model

3-7

6002-000239 Samsung Air Conditioner Tapping S Backorder SMG 6002-000239 $1.18

View on Model

3-7

DC63-00675A Samsung Dryer Filter Cover Backorder SMG DC63-00675A $29.35

View on Model

3-8

DC97-07510B Samsung Dryer Door Lever Holder C In Stock SMG DC97-07510B $17.32

View on Model

3-9

Dryer Lint Screen SMG DC61-01521A Contact Us For Availability

View on Model

3-10

DC97-16782A Samsung Dryer Plastic Roller Whee In Stock SMG DC97-16782A $49.43

View on Model

3-11

DC60-50145A Samsung Hex Nut Backorder SMG DC60-50145A $3.35

View on Model

3-61

DC97-08889A Guide Sensor Assembly MDE9700A fo In Stock SMG DC97-08889A $25.03

View on Model

3-62

DC96-00766A Samsung Dryer Wire Harness Assemb In Stock SMG DC96-00766A $14.53

View on Model

4-1

DC63-10001K Samsung Dryer Absorber Sponge Backorder SMG DC63-10001K $3.74

View on Model

5

DC61-01428A Samsung Power Holder Assembly Backorder SMG DC61-01428A $1.69

View on Model

5-4

Dryer Heat Duct SMG DC97-07521A Contact Us For Availability

View on Model

5-61

DC66-00394A Samsung Roller Assembly Backorder SMG DC66-00394A $19.90

View on Model

5-62

DC61-01228A Samsung Dryer Drum Support Roller In Stock SMG DC61-01228A $2.23

View on Model

6

DC63-00534B Samsung Back Cover Assembly Backorder SMG DC63-00534B $52.73

View on Model

7

DC96-01595D Samsung Dryer M.Wire Harness Asse Backorder SMG DC96-01595D $220.87

View on Model

8-1

DC61-02008B Samsung Dryer Guide Panel Backorder SMG DC61-02008B $24.49

View on Model

13

DC97-07519A Samsung Dryer Exhaust Duct Assemb Backorder SMG DC97-07519A $80.58

View on Model

14

DC97-14486A Samsung Dryer Heating Element Duc In Stock SMG DC97-14486A $286.60

View on Model

15

DC97-12150A Samsung Dryer Leg Assembly In Stock SMG DC97-12150A $20.23

View on Model

1971

Bracket SMG DC61-01230B Contact Us For Availability

View on Model

1972

Dryer Idler Pulley SMG DC97-07509B Contact Us For Availability

View on Model

1973

Idler Shaft SMG DC66-00401A Contact Us For Availability

View on Model

3611

DC61-01231A Samsung Dryer Wings Plate Sensor Backorder SMG DC61-01231A $6.15

View on Model

3612

DC61-01235A Samsung Sensor Guide Assembly Backorder SMG DC61-01235A $6.39

View on Model

9721

Samsung Oil Bearing SMG 6601-001291 Contact Us For Availability

View on Model

9722

Dryer Idler Pulley SMG DC66-00402A Contact Us For Availability

View on Model

O

Duct Motor SMG DC93-00188A Contact Us For Availability

View on Model
