Model Whirlpool GC5SHAXVB00 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2223288 Whirlpool Refrigerator Cantilever S Backorder WPL WP2223288 $258.82

1

NLA:SCREW Backorder WPL WPW10141645 $4.82

1

Ice Bin WPL W10174541 Contact Us For Availability

1

LINER (NOT A SEVICEABLE PART) WPL NP Contact Us For Availability

2

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $54.88

2

Fitting, Water WPL 2303216 Contact Us For Availability

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $11.99

3

WP2317240 Whirlpool Refrigerator Ice Auger In Stock WPL WP2317240 $130.99

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

3

DOOR, DAIRY WPL 2255421 Contact Us For Availability

3

SCOOP, AIR WPL 2223298 Contact Us For Availability

3

ASSEMBLY, CONDENSER WPL W10131059 Contact Us For Availability

4

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $17.77

4

Washer, Auger WPL 2258220 Contact Us For Availability

5

W10247725 Whirlpool Water Inlet Valve In Stock WPL W10247725 $166.82

5

W11545866 Whirlpool Refrigerator Clip Backorder WPL W11545866 $7.27

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $8.89

5

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $25.99

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $11.99

5

DUCT, AIR WPL 2223297 Contact Us For Availability

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $5.99

6

WP2180353 Whirlpool Dispenser Door In Stock WPL WP2180353 $8.99

6

WP2255411 Whirlpool Refrigerator Clip In Stock WPL WP2255411 $21.99

6

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $7.20

6

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $23.99

6

Cover, Crusher WPL 2317248 Contact Us For Availability

6

ASSEMBLY, UPPER BASKET WPL 2223690 Contact Us For Availability

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $4.82

7

Glass, Cover WPL 2223591 Contact Us For Availability

8

2223545 Whirlpool Refrigerator Shim Backorder WPL 2223545 $64.02

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $6.99

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $30.99

8

WP3400806 Whirlpool Screw In Stock WPL WP3400806 $4.99

8

Eyelet, Roller WPL 2174478 Contact Us For Availability

9

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $14.02

9

2307008B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008B $30.22

9

2307008T Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008T $90.68

9

WP2206670B Whirlpool Dispenser Tray In Stock WPL WP2206670B $24.99

9

WP2206670T Whirlpool Refrigerator Grille Backorder WPL WP2206670T $44.34

9

WP2206670W Whirlpool Dispenser Tray In Stock WPL WP2206670W $54.67

9

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $176.99

9

Blade, Fixed WPL 2257020 Contact Us For Availability

9

SHELF, WIRE WPL 2223500 Contact Us For Availability

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $57.37

WPW10272168 Whirlpool Refrigerator Water Fill Backorder WPL WPW10272168 $52.03

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $7.55

ASSEMBLY, WATER TUBE & BRACKET WPL 2221562 Contact Us For Availability

COMPARTMENT, DAIRY WPL 2223879 Contact Us For Availability

2317239 Whirlpool Refrigerator Blade Block Backorder WPL 2317239 $7.18

W10152855 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152855 $65.33

W10155161 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10155161 $65.21

WP2317844 Whirlpool Refrigerator Cover Backorder WPL WP2317844 $7.52

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $59.71

WPW10152853 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152853 $61.47

WPW10152854 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152854 $64.64

Basket, Front WPL 2223782 Contact Us For Availability

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $31.65

W10297244 Whirlpool Refrigerator Arm Strip In Stock WPL W10297244 $56.99

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $8.97

HINGE, BOTTOM RIGHT WPL 2307179 Contact Us For Availability

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $68.41

Gasket, Air Baffle WPL 2304597 Contact Us For Availability

SHELF TRACK (RIGHT HAND) WPL 2223787 Contact Us For Availability

SHELF TRACK (LEFT HAND) WPL 2223788 Contact Us For Availability

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $6.88

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $6.87

SPACER, SWITCH HARNESS WPL 625834 Contact Us For Availability

GRILLE (GREY) WPL W10194061 Contact Us For Availability

CLOSER, DOOR WPL 2307050 Contact Us For Availability

Grille (Biscuit) WPL W10194058 Contact Us For Availability

COVER, AIR DIFFUSER WPL 2223403 Contact Us For Availability

Shelf, Fixed WPL 2254615 Contact Us For Availability

2306940 Whirlpool Refrigerator Bracket Backorder WPL 2306940 $65.50

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $6.90

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $71.99

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $13.89

ASSEMBLY, AIR DIFFUSER WPL 2224076 Contact Us For Availability

BASKET, LOWER BASKET WPL 2223692 Contact Us For Availability

2307007B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307007B $90.68

3400524 Whirlpool Refrigerator Screw Backorder WPL 3400524 $8.37

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.99

W11629923 Whirlpool Coupling In Stock WPL W11629923 $15.99

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $10.72

WP2220377 Whirlpool Refrigerator Air Baffle In Stock WPL WP2220377 $245.99

HANDLE, MEAT PAN WPL 2203029 Contact Us For Availability

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $6.90

2306940B Whirlpool Refrigerator Bracket Backorder WPL 2306940B $24.26

W10152860 Whirlpool Refrigerator Dispenser Ar Backorder WPL W10152860 $63.26

WP3400012 Whirlpool Refrigerator Screw In Stock WPL WP3400012 $4.82

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.91

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $6.74

WPW10152858 Whirlpool Refrigerator Dispenser In Stock WPL WPW10152858 $62.59

WPW10152859 Whirlpool Refrigerator Dispenser Backorder WPL WPW10152859 $63.15

WPW10356040-includeCORE Whirlpool WPW10356040 Backorder WPL WPW10356040-includeCORE $256.19

LEVER, WATER DISPENSER (GREY) WPL W10155162 Contact Us For Availability

W11223328 Whirlpool Refrigerator Shelf Stud In Stock WPL W11223328 $14.99

W11566763 Whirlpool Fitting In Stock WPL W11566763 $31.99

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $88.98

WP2224173 Whirlpool Refrigerator Cantilever B Backorder WPL WP2224173 $52.75

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $4.82

WPW10276792 Whirlpool Refrigerator Water Rese In Stock WPL WPW10276792 $69.99

ASSEMBLY, DISPENSER FASCIA (NICKEL) WPL W10171982 Contact Us For Availability

GLIDE ASSEMBLY, BASKET (RIGHT HAND) WPL 2224137 Contact Us For Availability

GLIDE ASSEMBLY, BASKET (LEFT HAND) WPL 2224138 Contact Us For Availability

WPW10209635-includeCORE Whirlpool WPW10209635 Backorder WPL WPW10209635-includeCORE $284.04

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $4.99

Cover, Emitter WPL 2259487 Contact Us For Availability

EXTENSION, DRAIN FITTING WPL 2254566 Contact Us For Availability

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

W10136850 Whirlpool Refrigerator Front Cover Backorder WPL W10136850 $119.93

WP2196483 Whirlpool Refrigerator Shelf Stud In Stock WPL WP2196483 $6.50

Latch, Bin WPL 2317277 Contact Us For Availability

BEZEL, DISPENSER (STAINLESS) WPL W10139842 Contact Us For Availability

Screw WPL 8534064 Contact Us For Availability

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $115.71

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $4.82

WP2304673 Whirlpool Refrigerator Bracket Backorder WPL WP2304673 $9.19

NAMEPLATE, WHIRLPOOL GOLD WPL 2220214 Contact Us For Availability

LENS, LIGHT WPL 2223663 Contact Us For Availability

COVER, UNIT CORD WPL 2223409 Contact Us For Availability

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $287.76

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $7.19

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $59.45

WP2223320 Whirlpool Slide Track Pan In Stock WPL WP2223320 $16.99

SCREW, GAS INLET WPL W10080380 Contact Us For Availability

23

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $10.62

23

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $6.83

23

Clip, Defrost Heater WPL 2161324 Contact Us For Availability

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $85.91

WP2188919 Whirlpool Refrigerator Holder In Stock WPL WP2188919 $5.99

SLEEVE, DISPENSER WPL 2252127 Contact Us For Availability

TUBE, CIRCUIT BOARD WPL 2198665 Contact Us For Availability

25

2317243 Whirlpool Refrigerator Wiper Backorder WPL 2317243 $64.24

25

W11457217 Whirlpool Refrigerator Rocker Switc In Stock WPL W11457217 $17.77

25

HINGE, BOTTOM LEFT WPL 2307152 Contact Us For Availability

26

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $17.54

26

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $23.69

26

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $6.59

2317250 Whirlpool Refrigerator Divider Backorder WPL 2317250 $22.62

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $193.47

WPW10175973-includeCORE Whirlpool WPW10175973 Backorder WPL WPW10175973-includeCORE $257.06

WPW10185438 Whirlpool Ice Maker Cover In Stock WPL WPW10185438 $67.84

28

2306900 Whirlpool Refrigerator Slide Backorder WPL 2306900 $65.69

28

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $65.79

28

SLIDE, ICEMAKER MOUNTING (RIGHT HAND) WPL 2212321 Contact Us For Availability

29

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

29

ENCLOSURE, MOTOR ASSEMBLY WPL 2322488 Contact Us For Availability

29

Door Closer, FC WPL 2307051 Contact Us For Availability

30

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.68

30

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $5.99

30

WP2260518MG Whirlpool Water Filter Cap Backorder WPL WP2260518MG $36.91

32

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $67.99

32

WP2315559 Whirlpool Motor Coupling In Stock WPL WP2315559 $50.80

32

WP489483 Whirlpool Screw In Stock WPL WP489483 $7.58

33

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $9.81

33

Heater, Defrost WPL 2323199 Contact Us For Availability

34

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $7.55

34

WPL 2307049 WPL 2307049 Contact Us For Availability

35

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $28.99

36

Cover, Receiver WPL W10173569 Contact Us For Availability

37

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $7.18

37

WPL W10281289 WPL W10281289 Contact Us For Availability

38

W11629974-includeCORE Whirlpool W11629974 Ref Backorder WPL W11629974-includeCORE $263.39

39

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $4.99

40

SHIELD, LIGHT WPL 2198589 Contact Us For Availability

41

LIGHT LENS COVER COVER WPL 2212340 Contact Us For Availability

42

WP2198641 Whirlpool Refrigerator Ice Maker Co Backorder WPL WP2198641 $6.99

43

2187737 Whirlpool Refrigerator Wire Harness Backorder WPL 2187737 $112.14

43

WPW10119935 Whirlpool Refrigerator Socket In Stock WPL WPW10119935 $66.40

44

W10142289 Whirlpool Air Conditioner Screw Backorder WPL W10142289 $6.10

45

LADDER (LEFT HAND) WPL 2223414 Contact Us For Availability

45

LADDER (RIGHT HAND) WPL 2223415 Contact Us For Availability

46

2303378 Whirlpool Shield Assembly Backorder WPL 2303378 $8.68

100

2198597 Whirlpool Refrigerator Ice Maker In Stock WPL 2198597 $162.99

100

WP2317251 Whirlpool Refrigerator Ice Containe In Stock WPL WP2317251 $301.61

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

350942 Whirlpool Spray Paint Backorder WPL 350942 $49.86

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $16.99

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.99

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $18.58

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.88

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.85

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

VALVE, ACCESS WPL 978029 Contact Us For Availability

MISCELLANEOUS, KIT, FOAM SLAB (30`` X 32 1/2` WPL 876029 Contact Us For Availability

MISCELLANEOUS, TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT. WHITE) WPL 799344 Contact Us For Availability

TORX SCREW WRENCH TORX KEY WPL 1117510 Contact Us For Availability
