Model Whirlpool 8ET8WPKXKT00 REFRIGERATOR – Common Parts &amp; Diagrams

1

Refrigerator Door (Includes No.9 & No.11) (Wh WPL 2183948 Contact Us For Availability

1

Refrigerator Door (Includes No.9 & No.11) (Bi WPL 2205285 Contact Us For Availability

2

WP2193353W Whirlpool Refrigerator Trim Handle In Stock WPL WP2193353W $5.99

2

Shelf (2) WPL 2163856 Contact Us For Availability

2

End Cap (Biscuit) WPL 2193353T Contact Us For Availability

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $18.99

3

WP2314548 Whirlpool Refrigerator Cover Backorder WPL WP2314548 $177.47

4

W10854037 Whirlpool Refrigerator Crisper Pan In Stock WPL W10854037 $134.62

4

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $6.83

5

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $6.49

6

WP2172748 Whirlpool Drawer Support Backorder WPL WP2172748 $67.10

6

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $3.52

6

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $4.82

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $5.99

7

W11594405 Whirlpool Axle In Stock WPL W11594405 $8.90

7

WP2163835 Whirlpool Track Assembly In Stock WPL WP2163835 $14.99

8

876811 Whirlpool Grommet Backorder WPL 876811 $4.82

8

WP2176275 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2176275 $86.42

9

W10856580 Whirlpool Crisper Pan In Stock WPL W10856580 $128.99

10

WP2169921 Whirlpool Refrigerator Glass Shelf Backorder WPL WP2169921 $196.71

11

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $4.98

11

Support Block WPL 2201184 Contact Us For Availability

11

Shelf, Ladder (2) WPL 2210522 Contact Us For Availability

12

Shelf, Ladder WPL 2202821 Contact Us For Availability

13

Nameplate (White) WPL 2195063 Contact Us For Availability

13

Nameplate (Biscuit) WPL 2212596 Contact Us For Availability

14

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

14

Meat Pan WPL 2200920K Contact Us For Availability

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $6.75

15

Trim, Door WPL 2195942 Contact Us For Availability

15

Cover, Meat Pan WPL 2163848 Contact Us For Availability

16

3400518 Whirlpool Oven Foot Mount Screw Backorder WPL 3400518 $8.39

16

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $74.99

17

2254352A Whirlpool Refrigerator Ice Container In Stock WPL 2254352A $14.97

17

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $6.78

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

285006 Whirlpool Spray In Stock WPL 285006 $31.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

350942 Whirlpool Spray Paint Backorder WPL 350942 $49.86

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $16.99

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.99

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $53.03

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $18.58

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $141.89

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $10.99

W11729596 Whirlpool Ice Maker Field Install K In Stock WPL W11729596 $116.71

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.85

WPW10421484 Whirlpool Refrigerator Door Trim In Stock WPL WPW10421484 $61.90

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $17.77

Clip, Heater WPL 2182338 Contact Us For Availability

Freezer Door (Includes No.11 & No.23) (White) WPL 2182487 Contact Us For Availability

Freezer Door (Includes No.11 & No.23) (Biscui WPL 2205279 Contact Us For Availability

20

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $4.82

20

WP2200936 Whirlpool Refrigerator Handle Plug Backorder WPL WP2200936 $4.82

20

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $4.82

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

23

2159057 Whirlpool Refrigerator Fresh Food Doo In Stock WPL 2159057 $136.79

23

Shim, Bottom Hinge WPL 2172743 Contact Us For Availability

23

Air Tower WPL 2182340 Contact Us For Availability

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $82.12

25

WP2195943 Whirlpool Shelf Retainer Bar In Stock WPL WP2195943 $58.03

26

W11745278 Whirlpool Bracket In Stock WPL W11745278 $8.47

27

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $4.82

27

Cover, Hole WPL 2205003 Contact Us For Availability

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $49.99

WP2212648 Whirlpool Refrigerator Hinge Sleeve In Stock WPL WP2212648 $4.82

WP2212649 Whirlpool Refrigerator Button Plug Backorder WPL WP2212649 $4.82

Installation Kit WPL 482801 Contact Us For Availability

29

WP2156007 Whirlpool Refrigerator Endcap Trim In Stock WPL WP2156007 $7.99

30

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $5.47

31

WP2218113 Whirlpool Dairy Door In Stock WPL WP2218113 $47.45

32

WP2195915 Whirlpool Door Shelf Support In Stock WPL WP2195915 $9.99

32

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $122.18

33

4388947 Whirlpool Refrigerator Door Handle Ki Backorder WPL 4388947 $163.78

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $5.99

35

Bracket, Damper Knob WPL 2163810 Contact Us For Availability

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $6.17

37

Trim-Door (2) WPL 2195946 Contact Us For Availability

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $5.99

38

Clip, Defrost Timer WPL 2176341 Contact Us For Availability

39

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $62.27

40

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $11.82

40

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $12.19

40

Shield, heat WPL 2204639 Contact Us For Availability

41

WP2195916K Whirlpool End Cap In Stock WPL WP2195916K $8.71

42

Grille, Clip WPL 2189356 Contact Us For Availability

42

Trim, Door WPL 2195941 Contact Us For Availability

43

Fan, Blade WPL 2190685 Contact Us For Availability

43

Sleeve, Air Tower WPL 2179712 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.82

45

Shield, Heat WPL 2201082 Contact Us For Availability

46

2205533 Whirlpool Refrigerator Tube Backorder WPL 2205533 $62.23

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.88

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

Evap. Tray WPL 2210451 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability
