Model Whirlpool 106.72906201 Refrigerator (Kenmore 10672906201) – Common Parts &amp; Diagrams

1

Refrigerator Door Assembly (White) WPL 2205395 Contact Us For Availability

1

FOR FIELD INSTALLABLE ICEMAKER REPAIR PARTS L WPL N/P Contact Us For Availability

1

Freezer Door Assembly (White) WPL 2205399 Contact Us For Availability

1A

Refrigerator Door Panel WPL 2205397 Contact Us For Availability

1A

Refrigerator Door Panel WPL 2205401 Contact Us For Availability

1B

Refrigerator Door Assembly (Biscuit) WPL 2205396 Contact Us For Availability

1B

Freezer Door Assembly (Biscuit) WPL 2205400 Contact Us For Availability

1C

Refrigerator Door Panel WPL 2218506 Contact Us For Availability

1C

Refrigerator Door Panel WPL 2218507 Contact Us For Availability

1D

Refrigerator Door Assembly (Black) WPL 2205398 Contact Us For Availability

1D

Freezer Door Assembly (Black) WPL 2205402 Contact Us For Availability

2

WP2188785 Whirlpool Water Inlet Valve Backorder WPL WP2188785 $179.86

2

WP2264462 Whirlpool Refrigerator Grommet In Stock WPL WP2264462 $22.00

3

WP2254360 Whirlpool Refrigerator Gasket Backorder WPL WP2254360 $16.47

4

W11745278 Whirlpool Bracket In Stock WPL W11745278 $9.42

4

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $18.65

4

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $59.83

4

Refrigerator Water Tubing Clip WPL 2210523 Contact Us For Availability

4

Refrigerator Defrost Timer WPL 2213493 Contact Us For Availability

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

5

Refrigerator Barrier WPL 2212485 Contact Us For Availability

6

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $13.13

6

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $6.83

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $5.99

6

Refrigerator Crisper Drawer Humidity Control WPL 2176222 Contact Us For Availability

6

Refrigerator Cabinet Hole Plug WPL 2204837 Contact Us For Availability

6A

Plug-hndle WPL 2204839 Contact Us For Availability

6B

Refrigerator Door End Cap Hole Plug (Bisque) WPL 2204838 Contact Us For Availability

6C

Plug-hndle WPL 2204840 Contact Us For Availability

7

WP2212446 Whirlpool Refrigerator Control Body In Stock WPL WP2212446 $46.03

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve Backorder WPL WP2212648 $4.82

7

Refrigerator Wire Harness WPL 2187448 Contact Us For Availability

7A

WP2212649 Whirlpool Refrigerator Button Plug Backorder WPL WP2212649 $4.82

7B

WP2212651 Whirlpool Refrigerator Button Plug Backorder WPL WP2212651 $14.62

8

2159057 Whirlpool Refrigerator Fresh Food Doo In Stock WPL 2159057 $111.95

8

2159327 Whirlpool Refrigerator Door Gasket In Stock WPL 2159327 $89.78

8

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $47.85

8A

2177304 Whirlpool Refrigerator FIP Gasket Backorder WPL 2177304 $214.37

8A

2177305 Whirlpool Refrigerator Door FIP Gaske In Stock WPL 2177305 $154.94

9

Refrigerator Air Damper WPL 2212413 Contact Us For Availability

10

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $4.82

10

WPW10189703 Whirlpool Refrigerator Evaporator In Stock WPL WPW10189703 $48.95

10

WPW10498990 Whirlpool Refrigerator Inlet Valv In Stock WPL WPW10498990 $101.30

11

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $45.89

11

Shim WPL 2172743 Contact Us For Availability

11

Refrigerator Dairy Bin WPL 2210566 Contact Us For Availability

12

Refrigerator Handle WPL 2205451 Contact Us For Availability

12

Refrigerator Control Box WPL 2218689 Contact Us For Availability

12

Refrigerator Handle WPL 2205447 Contact Us For Availability

12A

Refrigerator Handle WPL 2221619 Contact Us For Availability

12A

Refrigerator Handle WPL 2221615 Contact Us For Availability

12B

Refrigerator Handle WPL 2205452 Contact Us For Availability

12B

Refrigerator Handle WPL 2205448 Contact Us For Availability

12C

Refrigerator Handle WPL 2221620 Contact Us For Availability

12C

Refrigerator Handle WPL 2221616 Contact Us For Availability

13

W11594405 Whirlpool Axle In Stock WPL W11594405 $9.85

13

Refrigerator Butter Storage Tray WPL 2159302 Contact Us For Availability

13

Refrigerator Temperature Control WPL 2204984 Contact Us For Availability

14

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $7.04

14

Refrigerator Evaporator Fan Motor Bracket, Fr WPL 2214979 Contact Us For Availability

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $6.10

15

WP693995 Whirlpool Screw In Stock WPL WP693995 $4.09

16

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $7.20

16

Refrigerator Evaporator Cover WPL 2201173 Contact Us For Availability

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $16.02

WP2176275 Whirlpool Refrigerator Wire Shelf Backorder WPL WP2176275 $92.46

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $6.78

Refrigerator Door Trim WPL 2195946 Contact Us For Availability

18

Refrigerator Cold Control Sensor Thermal Weig WPL 2200831 Contact Us For Availability

18

Refrigerator Medallion WPL 2205103 Contact Us For Availability

18

Refrigerator Acceler-Ice Module WPL 2210315 Contact Us For Availability

18A

Refrigerator Medallion WPL 2205104 Contact Us For Availability

18B

Medallion WPL 9744397 Contact Us For Availability

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $6.49

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $23.68

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

Refrigerator Defrost Heater Bracket WPL 2182338 Contact Us For Availability

20

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $187.20

20

Refrigerator Cantilever Shelf WPL 2179605 Contact Us For Availability

20

WIRE ASSEMBLY FREEZER COMPT. WPL 2187568 Contact Us For Availability

21

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $4.53

21

WPW10421484 Whirlpool Refrigerator Door Trim In Stock WPL WPW10421484 $60.49

21

Refrigerator Air Damper Cover WPL 2176281 Contact Us For Availability

WP2195916K Whirlpool End Cap In Stock WPL WP2195916K $8.58

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $29.99

Refrigerator Butter Door Cover WPL 2218109 Contact Us For Availability

Refrigerator Thermostat Knob WPL 2205094 Contact Us For Availability

23

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $63.89

23

Refrigerator Freezer Air Tower WPL 2182340 Contact Us For Availability

23

Refrigerator Door Trim WPL 2159312 Contact Us For Availability

24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $59.60

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $87.86

24

Refrigerator Support Evaporator WPL 2201184 Contact Us For Availability

25

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $73.20

25

Refrigerator Freezer Floor WPL 2189429 Contact Us For Availability

26

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $6.88

26

Refrigerator Diffuser WPL 2179877 Contact Us For Availability

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $52.34

27

WP98129 Whirlpool Screw Backorder WPL WP98129 $4.82

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.99

28

WP2163835 Whirlpool Track Assembly In Stock WPL WP2163835 $14.59

28

Refrigerator Floor WPL 2204746 Contact Us For Availability

29

Orifice WPL 2218696 Contact Us For Availability

30

WP2196003 Whirlpool Refrigerator Bar Riser Backorder WPL WP2196003 $4.82

30

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.46

30

Refrigerator Pan Trim WPL 2195340 Contact Us For Availability

31

WP2184574 Whirlpool Refrigerator Gear Wheel Backorder WPL WP2184574 $48.18

31

WP627792 Whirlpool Refrigerator Shut Off Arm In Stock WPL WP627792 $61.68

32

W10853646 Whirlpool Indicator Light In Stock WPL W10853646 $95.20

32

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $95.20

32A

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $130.74

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $22.41

33

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

34

Refrigerator Thermostat Knob WPL 2204951 Contact Us For Availability

35

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $62.13

35

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $66.62

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $5.99

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $6.17

37

Refrigerator Toe Grille Clip WPL 2189356 Contact Us For Availability

37

Refrigerator Light Lens WPL 2213495 Contact Us For Availability

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

WP487576 Whirlpool Washer In Stock WPL WP487576 $7.54

Trim End Cap WPL 2177340 Contact Us For Availability

Shield WPL 2204639 Contact Us For Availability

39

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $4.82

39

Refrigerator Housing WPL 2201152 Contact Us For Availability

40

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $12.19

40

Refrigerator Seal WPL 2205055 Contact Us For Availability

40A

Cover (Silver) WPL 2213388 Contact Us For Availability

40B

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $11.82

41

Refrigerator Wire Harness WPL 2221682 Contact Us For Availability

42

Insulation WPL 2193491 Contact Us For Availability

43

4396822 Whirlpool Refrigerator Light Bulb In Stock WPL 4396822 $10.96

43

Refrigerator Condenser Fan WPL 2190685 Contact Us For Availability

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.82

Refrigerator Cover Unit WPL 2221776 Contact Us For Availability

Refrigerator Support WPL 2179713 Contact Us For Availability

Refrigerator Ice Maker Module Support Clip WPL 2204881 Contact Us For Availability

45

Refrigerator Support WPL 2179714 Contact Us For Availability

46

2205533 Whirlpool Refrigerator Tube Backorder WPL 2205533 $66.59

46

Refrigerator Freezer Control Thermostat WPL 2204991 Contact Us For Availability

47

Refrigerator Gear Wheel WPL 2204992 Contact Us For Availability

48

Refrigerator Freezer Door Switch Housing Seal WPL 2166284 Contact Us For Availability

49

Refrigerator Bracket WPL 2210510 Contact Us For Availability

50

Refrigerator Evaporator Fan Motor Bracket, Re WPL 2214976 Contact Us For Availability

51

Refrigerator Cover WPL 2219639 Contact Us For Availability

52

Refrigerator Inlet Tube WPL 2210518 Contact Us For Availability

53

Refrigerator Cover WPL 2210521 Contact Us For Availability

54

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $17.24

55

Refrigerator Filter WPL 2206048 Contact Us For Availability

56

Refrigerator Roller WPL 2176246 Contact Us For Availability

57

Refrigerator Fence WPL 2198768 Contact Us For Availability

58

Refrigerator Drain Pan WPL 2210451 Contact Us For Availability

58

Refrigerator Control Housing Clip WPL 2210563 Contact Us For Availability

59

Refrigerator Insulation WPL 2214981 Contact Us For Availability

NI01

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

NI02

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

NI03

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $87.85

NI04

Refrigerator Service Valve WPL 978028 Contact Us For Availability

NI05

Refrigerator Service Valve WPL 978029 Contact Us For Availability

NI06

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $92.18

NI07

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $29.55

NI09

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $34.42

NI10

Refrigerator Vinyl Tape WPL 479502 Contact Us For Availability

NI11

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $151.82

NI13

Foam Slab WPL 876029 Contact Us For Availability

NI14

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $119.63

NI15

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

NI16

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $39.72

NI17

Adhesive WPL 542639 Contact Us For Availability

NI18

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $56.74

NI19

Epoxy WPL 799833 Contact Us For Availability

NI20

Epoxy WPL 799832 Contact Us For Availability

NI21

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $80.29

NI22

350942 Whirlpool Spray Paint Backorder WPL 350942 $64.04

NI23

285006 Whirlpool Spray In Stock WPL 285006 $52.65

NI24

350930 Whirlpool White Spray Paint In Stock WPL 350930 $25.69

NI25

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $52.10

NI26

8171357 Whirlpool Spray Nozzle Backorder WPL 8171357 $58.79

NI27

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $8.31

NI28

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $12.67

NI29

BRUSH TOUCH-UP KIT (BISQUE) WPL 7392899 Contact Us For Availability

NI30

Pnt-blk-qrt WPL 799340 Contact Us For Availability

NI31

Appliance Porcelain Touch-Up Paint, 1-qt (Whi WPL 799344 Contact Us For Availability

NI32

Paint, Bsq WPL 4392900 Contact Us For Availability

NI33

Paint (Graphite) WPL 8171358 Contact Us For Availability

NI34

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

NI35

Refrigerator Ice Maker Torx Key Wrench WPL 1117510 Contact Us For Availability
