Model Whirlpool RF385PXGW1 – Common Parts &amp; Diagrams

1

WPW10016370 Whirlpool Door Trim Backorder WPL WPW10016370 $131.08

1

WPW10256908 Whirlpool Oven Range Rack In Stock WPL WPW10256908 $71.94

1

Trim, Door Top (Black) WPL 3196819 Contact Us For Availability

1

Trim, Door Top (Almond) WPL 3196820 Contact Us For Availability

1

Safer Cooking Tips WPL LIT3191638 Contact Us For Availability

1

Literature Parts (Installation Instr (Templat WPL LIT3195945 Contact Us For Availability

1

Literature Parts (Tech Sheet) WPL LIT8053304 Contact Us For Availability

1

Literature Parts (Guide, Use & Care) WPL LIT8053401 Contact Us For Availability

1

Literature Parts (Instructions, Installation) WPL LIT8053714 Contact Us For Availability

2

W10291024 Whirlpool Range Cooktop Gray Porcel In Stock WPL W10291024 $45.99

2

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $58.28

2

WP3196164 Whirlpool Screw In Stock WPL WP3196164 $3.91

2

WPW10290350 Whirlpool Stove Drip Bowl In Stock WPL WPW10290350 $5.99

2

WPW10290353 Whirlpool Drip Bowl 6" ClimaTek In Stock WPL WPW10290353 $14.99

3

8195532 Whirlpool Cooktop Power Switch Backorder WPL 8195532 $275.99

3

8195534 Whirlpool Cooktop Backorder WPL 8195534 $323.99

3

WP3196076 Whirlpool Broil Pan Backorder WPL WP3196076 $199.59

3

WPW10202216 Whirlpool Door Handle In Stock WPL WPW10202216 $223.82

3

WPW10202217 Whirlpool Door Handle In Stock WPL WPW10202217 $182.99

3

Handle, Door (Almond) WPL 3195921 Contact Us For Availability

3

Cooktop (Almond) WPL 3186232 Contact Us For Availability

4

WP3148952 Whirlpool Range Infinite Switch In Stock WPL WP3148952 $41.49

4

WP3195060 Whirlpool Cooktop Pin Backorder WPL WP3195060 $7.88

4

Liner, Door WPL 3186296 Contact Us For Availability

4

Drawer, Storage WPL 8053342 Contact Us For Availability

5

8522415 Whirlpool Range Wind Gasket Backorder WPL 8522415 $57.31

5

W10838990 Whirlpool Mounting Bracket Backorder WPL W10838990 $54.80

5

W11233072 Whirlpool Screw In Stock WPL W11233072 $19.85

5

Light, Indicator (Surface Unit (2)) WPL 313102 Contact Us For Availability

5

Light, Indicator (Accusimmer) WPL 8053632 Contact Us For Availability

6

3196815 Whirlpool Range Rivet Backorder WPL 3196815 $8.89

6

WP308605 Whirlpool Refrigerator Clamp Backorder WPL WP308605 $7.20

6

WP3196068 Whirlpool Light Lens In Stock WPL WP3196068 $7.99

6

WP3196813 Whirlpool Rivet Backorder WPL WP3196813 $6.64

6

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $6.64

6

WP9758164 Whirlpool Door Glass Backorder WPL WP9758164 $99.32

7

W11219377 Whirlpool Drawer Panel Backorder WPL W11219377 $128.08

7

W11230488 Whirlpool Drawer Panel Backorder WPL W11230488 $128.08

7

WP3195812 Whirlpool Cooktop Rod In Stock WPL WP3195812 $6.99

7

WP3196231 Whirlpool Knob In Stock WPL WP3196231 $23.73

7

Knob, Infinite (4) (White) WPL 3196232 Contact Us For Availability

7

Knob, Infinite (4) (Almond) WPL 3196233 Contact Us For Availability

7

Frame, Glass WPL 3186290 Contact Us For Availability

7

Panel, Drawer Front (Almond) WPL 8053340 Contact Us For Availability

8

WP3195917 Whirlpool Clip Assembly In Stock WPL WP3195917 $5.99

8

Shield, Heat WPL 8053912 Contact Us For Availability

8

Insulation, Door WPL 3186256 Contact Us For Availability

9

814399 Whirlpool Receptacle Kit In Stock WPL 814399 $19.45

9

9761499 Whirlpool Range Retainer Backorder WPL 9761499 $208.37

9

WP8053334 Whirlpool Drawer Glide In Stock WPL WP8053334 $9.86

9

Screw WPL 4449746 Contact Us For Availability

WP3196154 Whirlpool Screw Assembly Backorder WPL WP3196154 $4.82

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $6.99

WP8053807 Whirlpool Range Door Hinge In Stock WPL WP8053807 $77.99

WP8272473 Whirlpool Rear Cover Backorder WPL WP8272473 $133.12

WP660532 Whirlpool Oven Surface Element In Stock WPL WP660532 $45.62

WP9762476 Whirlpool Door Glass Backorder WPL WP9762476 $214.99

WP9762477 Whirlpool Glass Door Backorder WPL WP9762477 $209.99

WPW10259865 Whirlpool Range 8" Surface Elemen In Stock WPL WPW10259865 $141.99

Knob, Accusimmer (Black) WPL 8053475 Contact Us For Availability

Knob, Accusimmer (White) WPL 8053476 Contact Us For Availability

Knob, Accusimmer (Almond) WPL 8053477 Contact Us For Availability

Glass, Outer Door (Almond) WPL 8053483 Contact Us For Availability

WP3196262 Whirlpool Light Switch Backorder WPL WP3196262 $105.50

Control, Range (Black) WPL 6610179 Contact Us For Availability

Control, Range (White) WPL 6610180 Contact Us For Availability

Control, Range (Almond) WPL 6610181 Contact Us For Availability

13

W10491985 Whirlpool Screw Backorder WPL W10491985 $6.99

13

WP3195546 Whirlpool Drawer Glide In Stock WPL WP3195546 $7.99

8184858 Whirlpool Door Trim Backorder WPL 8184858 $102.30

8184859 Whirlpool Range Oven Door Trim Kit (2 In Stock WPL 8184859 $96.87

8184860 Whirlpool Range Door Trim Backorder WPL 8184860 $89.39

WP3196037 Whirlpool Leveling Foot In Stock WPL WP3196037 $53.98

WPW10326122 Whirlpool Black Cover Backorder WPL WPW10326122 $85.37

15

Switch, Accusimmer WPL 8053511 Contact Us For Availability

15

Clip, Glass (6) WPL 3196025 Contact Us For Availability

16

WP3400882 Whirlpool Screw In Stock WPL WP3400882 $3.91

16

Bracket, Latch WPL 3195914 Contact Us For Availability

17

3196200 Whirlpool Clip In Stock WPL 3196200 $7.48

18

WP179051 Whirlpool Screw Backorder WPL WP179051 $4.99

19

WP3196925 Whirlpool Clip Assembly Backorder WPL WP3196925 $7.73

242831 Whirlpool Oven Wire Backorder WPL 242831 $249.73

285006 Whirlpool Spray In Stock WPL 285006 $31.65

3184020 Whirlpool Oven Wire Backorder WPL 3184020 $59.13

3196696 Whirlpool Clip In Stock WPL 3196696 $8.41

3400964 Whirlpool Range Clip Backorder WPL 3400964 $58.09

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

350942 Whirlpool Spray Paint Backorder WPL 350942 $49.86

350956 Whirlpool Spray Assembly In Stock WPL 350956 $29.99

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

72109 Whirlpool Dacor Avocado Touch-Up Paint Backorder WPL 72109 $15.74

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $15.99

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $15.74

814381 Whirlpool Pin In Stock WPL 814381 $4.82

8212471 Whirlpool Oven Paint Backorder WPL 8212471 $46.71

8273888A Whirlpool Range Oven Anchor Anti-Tip In Stock WPL 8273888A $23.74

WPL W10355051 No Longer Available

W11396691 Whirlpool Element Receptacle and Wi In Stock WPL W11396691 $109.86

WP72107 Whirlpool Touchup In Stock WPL WP72107 $14.61

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $56.69

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

Wire (14 Ga. 150 c Blue) WPL 242821 Contact Us For Availability

Wire (14 Ga. 150 c Brown) WPL 242822 Contact Us For Availability

Wire (14 Ga. 150 c Green) WPL 242823 Contact Us For Availability

Wire (14 Ga. 150 c Orange) WPL 242824 Contact Us For Availability

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

Wire, White 14 Ga. 150~c WPL 242826 Contact Us For Availability

Wire (14 Ga. 150 c Yellow) WPL 242827 Contact Us For Availability

Wire (12 Ga. 150 c Black) WPL 242828 Contact Us For Availability

Wire, WPL 242829 Contact Us For Availability

WPL 242830 WPL 242830 Contact Us For Availability

WPL 242832 WPL 242832 Contact Us For Availability

WPL 261582 WPL 261582 Contact Us For Availability

WPL 261886 WPL 261886 Contact Us For Availability

WPL 261888 WPL 261888 Contact Us For Availability

WPL 261890 WPL 261890 Contact Us For Availability

WPL 261891 WPL 261891 Contact Us For Availability

WPL 285365 WPL 285365 Contact Us For Availability

WPL 285366 WPL 285366 Contact Us For Availability

WPL 285367 WPL 285367 Contact Us For Availability

WPL 285368 WPL 285368 Contact Us For Availability

WPL 313660 WPL 313660 Contact Us For Availability

WPL 3196108 WPL 3196108 Contact Us For Availability

WPL 72108 WPL 72108 Contact Us For Availability

WPL 72112 WPL 72112 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

WPL 8053513 WPL 8053513 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

26

WP3196548 Whirlpool Thermal Fuse In Stock WPL WP3196548 $19.99

29

W11728255 Whirlpool Service Bracket Backorder WPL W11728255 $48.35

30

WP112432 Whirlpool Nut Assembly Backorder WPL WP112432 $4.82

38

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $4.99

41

WP3196174 Whirlpool Screw Backorder WPL WP3196174 $4.82

45

3196172 Whirlpool Oven Screw Backorder WPL 3196172 $8.89

46

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $4.82

48

W11244557 Whirlpool Screw Backorder WPL W11244557 $8.89
