Model Whirlpool JFX2897DRM02 REFRIGERATOR – Common Parts &amp; Diagrams

1

WPW10272364 Whirlpool Refrigerator Screw Backorder WPL WPW10272364 $6.83

1

WPW10753038 Whirlpool Refrigerator Glass Shel Backorder WPL WPW10753038 $274.55

2

W10610301 Whirlpool Refrigerator Mullion Rail Backorder WPL W10610301 $189.42

2

W10837274 Whirlpool Refrigerator Plate Backorder WPL W10837274 $55.98

2

W10842950 Whirlpool Refrigerator Housing Backorder WPL W10842950 $30.45

2

WP2188935 Whirlpool Refrigerator Fan Blade In Stock WPL WP2188935 $51.03

3

W10570074 Whirlpool Refrigerator Plate Backorder WPL W10570074 $99.48

3

W10606653 Whirlpool Refrigerator Shield Backorder WPL W10606653 $198.91

3

W11400994 Whirlpool Refrigerator Screw Backorder WPL W11400994 $8.39

3

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $8.29

3

WPW10344432 Whirlpool Pivot Block Backorder WPL WPW10344432 $11.48

3

WPW10464016 Whirlpool Refrigerator Screw Backorder WPL WPW10464016 $8.04

4

W10505487 Whirlpool Refrigerator Gasket Backorder WPL W10505487 $17.25

4

W10847834 Whirlpool Clip Backorder WPL W10847834 $8.92

4

W11690163 Whirlpool Refrigerator Evaporator C Backorder WPL W11690163 $143.39

4

WPW10420671 Whirlpool Refrigerator Pad Backorder WPL WPW10420671 $203.82

4

WPW10503522 Whirlpool Refrigerator Shaft Backorder WPL WPW10503522 $63.85

4

WPW10549590 Whirlpool Refrigerator Ice Door Backorder WPL WPW10549590 $228.89

5

W10509275 Whirlpool Refrigerator Crisper Pan Backorder WPL W10509275 $109.19

5

W10904595 Whirlpool Refrigerator Closer Backorder WPL W10904595 $10.45

5

W11509548 Whirlpool Ice Bucket Coupler In Stock WPL W11509548 $19.79

5

W11745092 Whirlpool Dual Evaporator Drain Ext In Stock WPL W11745092 $55.47

5

WPW10341329 Whirlpool Refrigerator Water Valv In Stock WPL WPW10341329 $61.48

5

WPW10577864 Whirlpool Refrigerator Ice Door In Stock WPL WPW10577864 $78.89

5A

W11212164 Whirlpool Refrigerator Door Closer Backorder WPL W11212164 $10.54

6

W10415341 Whirlpool Refrigerator Gasket Backorder WPL W10415341 $23.40

6

W10650427 Whirlpool Refrigerator Freezer Bin Backorder WPL W10650427 $200.04

6

W11025614 Whirlpool Door Support Backorder WPL W11025614 $82.68

6

W11127833 Whirlpool Refrigerator Crisper Draw In Stock WPL W11127833 $97.77

6

W11194438 Whirlpool Water Filter Housing In Stock WPL W11194438 $134.13

6

WPW10435760 Whirlpool Refrigerator Ice Guide In Stock WPL WPW10435760 $16.81

7

W10606641 Whirlpool Refrigerator Drip Tray Backorder WPL W10606641 $76.72

7

W10811115 Whirlpool Refrigerator Cover Backorder WPL W10811115 $74.84

7

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $6.83

8

W11190820 Whirlpool Refrigerator Cover Backorder WPL W11190820 $74.84

8

W11225840 Whirlpool Refrigerator Evaporator T Backorder WPL W11225840 $103.78

8

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $5.30

8

WPW10347093 Whirlpool Refrigerator Ice Maker In Stock WPL WPW10347093 $301.17

8

WPW10402180 Whirlpool Refrigerator Trim Backorder WPL WPW10402180 $42.84

8

WPW10493169 Whirlpool Refrigerator Freezer Bi In Stock WPL WPW10493169 $107.53

9

W10852685 Whirlpool Clip Assembly Backorder WPL W10852685 $6.79

9

W11290115 Whirlpool Refrigerator Light In Stock WPL W11290115 $43.08

9

WP2223877 Whirlpool Door Hook In Stock WPL WP2223877 $64.71

W10507444 Whirlpool Refrigerator Divider Backorder WPL W10507444 $41.42

W11215629 Whirlpool Refrigerator Adapter Backorder WPL W11215629 $125.55

W11573367 Whirlpool Refrigerator Door Bumper In Stock WPL W11573367 $14.02

W11592405 Whirlpool Door Hinge Backorder WPL W11592405 $16.65

WP12729128 Whirlpool Defrost Heater In Stock WPL WP12729128 $79.75

WPW10277949 Whirlpool Refrigerator Filter Cov Backorder WPL WPW10277949 $69.63

WPW10363507 Whirlpool Refrigerator Shroud Backorder WPL WPW10363507 $55.98

10A

W11093718 Whirlpool Refrigerator Adapter Backorder WPL W11093718 $102.31

10A

W11592404 Whirlpool Refrigerator Door Hinge Backorder WPL W11592404 $14.13

W11573362 Whirlpool Screw Assembly Backorder WPL W11573362 $8.89

W11677723 Whirlpool Support Backorder WPL W11677723 $102.46

WPW10154805 Whirlpool Refrigerator Inverter B In Stock WPL WPW10154805 $289.08

WPW10214168 Whirlpool Refrigerator Nameplate Backorder WPL WPW10214168 $60.45

12

W10284709 Whirlpool Refrigerator Cover Backorder WPL W10284709 $50.57

12

W11175811 Whirlpool Refrigerator Front Panel Backorder WPL W11175811 $217.12

12

WPW10407158 Whirlpool Refrigerator Cover Asse Backorder WPL WPW10407158 $14.33

12A

W10294414 Whirlpool Refrigerator Cover Backorder WPL W10294414 $58.12

13

W11452196 Whirlpool Refrigerator Evaporator M In Stock WPL W11452196 $129.96

13

W11686800 Whirlpool Water Tube In Stock WPL W11686800 $56.59

13

ASSEMBLY, TRIVET WPL W10640341 Contact Us For Availability

W10503218 Whirlpool Refrigerator Funnel Backorder WPL W10503218 $11.21

W10850332 Whirlpool Refrigerator Bracket Backorder WPL W10850332 $88.22

W11087201 Whirlpool Refrigerator Heater In Stock WPL W11087201 $70.41

WPW10248856 Whirlpool Refrigerator Cantilever Backorder WPL WPW10248856 $54.18

WPW10308751 Whirlpool Screw Backorder WPL WPW10308751 $5.24

GEAR, SPUR WPL W10277360 Contact Us For Availability

14A

W10858092 Whirlpool Refrigerator Bracket Backorder WPL W10858092 $92.83

15

W10802341 Whirlpool Refrigerator Shaft Backorder WPL W10802341 $62.86

15

W10858802 Whirlpool Refrigerator Freezer Bin Backorder WPL W10858802 $192.19

15

W11240748 Whirlpool Refrigerator Door Hinge Backorder WPL W11240748 $50.70

W10719660 Whirlpool Refrigerator Ladder Backorder WPL W10719660 $131.13

W11624997 Whirlpool Refrigerator Gasket Backorder WPL W11624997 $44.13

W11760073 Whirlpool Condenser Backorder WPL W11760073 $122.87

WPW10485096 Whirlpool Refrigerator Pan Stop Backorder WPL WPW10485096 $58.16

WPW10598013 Whirlpool Refrigerator Cover In Stock WPL WPW10598013 $72.77

16A

WPW10485089 Whirlpool Refrigerator Pan Stop Backorder WPL WPW10485089 $58.16

W11661208 Whirlpool Cover Assembly Backorder WPL W11661208 $14.02

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $4.82

WPW10277361 Whirlpool Refrigerator Collar Backorder WPL WPW10277361 $7.18

ASSEMBLY, ICEBOX (FOAMED) WPL W10811686 Contact Us For Availability

W10668165 Whirlpool Refrigerator Gasket Backorder WPL W10668165 $49.85

W10865826 Whirlpool Refrigerator Water Inlet In Stock WPL W10865826 $70.54

W11435997 Whirlpool Refrigerator Housing Backorder WPL W11435997 $155.81

CNTRL-ELEC+CORE Backorder WPL W11813704-includeCORE $261.41

WPW10530656 Whirlpool Refrigerator Utility Pa Backorder WPL WPW10530656 $150.10

TRAY, DRIP WPL W10342573 Contact Us For Availability

W10467461 Whirlpool Refrigerator Ladder Backorder WPL W10467461 $33.80

W11457241 Whirlpool Drip Pan Kit In Stock WPL W11457241 $81.94

ROLLER-CAB In Stock WPL W11820444 $25.41

COVER, RECEIVER WPL W10258510 Contact Us For Availability

19A

ROLLER-CAB In Stock WPL W11820445 $25.41

20

W10505516 Whirlpool Refrigerator Trim Backorder WPL W10505516 $22.21

20

W10630303 Whirlpool Refrigerator Shelf Frame Backorder WPL W10630303 $161.60

21

W10258502 Whirlpool Refrigerator Cover Backorder WPL W10258502 $58.57

21

W10846539 Whirlpool Fan Motor In Stock WPL W10846539 $145.68

21

W11429989 Whirlpool Refrigerator Solenoid In Stock WPL W11429989 $93.43

W10258540 Whirlpool Refrigerator Slide Backorder WPL W10258540 $6.90

W11127829 Whirlpool Refrigerator Condenser Mo In Stock WPL W11127829 $112.76

W11492867 Whirlpool Evaporator In Stock WPL W11492867 $145.44

WPW10637671 Whirlpool Refrigerator Front Gril In Stock WPL WPW10637671 $72.45

23

W10870822 Whirlpool Refrigerator Electronic C In Stock WPL W10870822 $145.66

23

W11673433 Whirlpool Clip Backorder WPL W11673433 $99.38

W10782690 Whirlpool Refrigerator Floor Backorder WPL W10782690 $173.11

W10878115 Whirlpool Refrigerator Door Hinge Backorder WPL W10878115 $50.12

W11087438 Whirlpool Refrigerator Evaporator M In Stock WPL W11087438 $95.60

W11189618 Whirlpool Refrigerator Wire Harness Backorder WPL W11189618 $99.08

WPW10400825 Whirlpool Refrigerator Retainer Backorder WPL WPW10400825 $19.51

25

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $25.74

25

W11637688 Whirlpool Heater In Stock WPL W11637688 $54.60

25

WPW10347087 Whirlpool Refrigerator Ice Chute In Stock WPL WPW10347087 $31.63

26

W10537691 Whirlpool Refrigerator Heater Backorder WPL W10537691 $57.98

27

W11683243 Whirlpool Module In Stock WPL W11683243 $143.73

27

WPW10258520 Whirlpool Refrigerator Flipper Backorder WPL WPW10258520 $53.58

W10754591 Whirlpool Refrigerator Cover Backorder WPL W10754591 $77.08

W11168403 Whirlpool Refrigerator Thermistor In Stock WPL W11168403 $63.01

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $63.61

WPW10280983 Whirlpool Refrigerator Insulation In Stock WPL WPW10280983 $61.76

W10518378 Whirlpool Refrigerator Cover Backorder WPL W10518378 $16.95

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $10.62

WPW10389152 Whirlpool Support In Stock WPL WPW10389152 $13.89

WPW10406719 Whirlpool Refrigerator Shroud Backorder WPL WPW10406719 $52.27

30

W11482027 Whirlpool Refrigerator Back Cover Backorder WPL W11482027 $75.77

30

WPW10635022 Whirlpool Refrigerator Adapter Backorder WPL WPW10635022 $68.31

W10278140 Whirlpool Refrigerator Unit Cover Backorder WPL W10278140 $68.46

W11038526 Whirlpool Shelf Glass Backorder WPL W11038526 $191.11

W11225849 Whirlpool Refrigerator Retainer Backorder WPL W11225849 $14.02

WPW10499015 Whirlpool Refrigerator Water Tube Backorder WPL WPW10499015 $84.39

32

12702901 Whirlpool Refrigerator Pad Backorder WPL 12702901 $11.36

32

W11230117 Whirlpool Refrigerator Support Backorder WPL W11230117 $111.06

32

TUBE, DRAIN WPL W10503562 Contact Us For Availability

33

W10491355 Whirlpool Refrigerator Air Gasket Backorder WPL W10491355 $15.89

33

WPW10248595 Whirlpool Damper Control Assembly In Stock WPL WPW10248595 $134.21

33

COUPLER, DOOR WPL W10505294 Contact Us For Availability

34

W10212137 Whirlpool Refrigerator Grommet Backorder WPL W10212137 $8.35

34

W11238397 Whirlpool Refrigerator Cover Backorder WPL W11238397 $14.02

34

WPW10626970 Whirlpool Refrigerator Tube Backorder WPL WPW10626970 $117.39

35

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $65.65

35

W10530297 Whirlpool Drawer Support Backorder WPL W10530297 $104.54

35

W11188493 Whirlpool Refrigerator Evaporator C Backorder WPL W11188493 $138.88

36

W10236396 Whirlpool Refrigerator Strap In Stock WPL W10236396 $13.74

36

W10518036 Whirlpool Refrigerator Cover Backorder WPL W10518036 $14.33

36

W11435996 Whirlpool Gasket Backorder WPL W11435996 $15.78

37

W11568592 Whirlpool Refrigerator Gasket Backorder WPL W11568592 $7.62

37

HANDLE, DOOR (STAINLESS) WPL W10564657 Contact Us For Availability

38

W10854958 Whirlpool Refrigerator Screw In Stock WPL W10854958 $4.80

38

WPW10320706 Whirlpool Refrigerator Gasket In Stock WPL WPW10320706 $17.02

39

W10277839 Whirlpool Refrigerator Cover Backorder WPL W10277839 $50.61

39

WPW10280988 Whirlpool Refrigerator Gasket In Stock WPL WPW10280988 $5.30

40

W11170612 Whirlpool Refrigerator Wire Harness In Stock WPL W11170612 $69.51

40

W11209890 Whirlpool Refrigerator Water Tube Backorder WPL W11209890 $77.32

40

WPW10392172 Whirlpool Refrigerator Gasket Backorder WPL WPW10392172 $16.84

41

ASSEMBLY, AIR TOWER WPL W10630762 Contact Us For Availability

42

W10470981 Whirlpool Refrigerator Gasket Backorder WPL W10470981 $16.81

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $37.41

350930 Whirlpool White Spray Paint In Stock WPL 350930 $30.02

350942 Whirlpool Spray Paint Backorder WPL 350942 $64.04

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $20.75

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $56.75

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $19.58

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $21.50

8003RP Whirlpool Refrigerator 25' 1/4" Copper In Stock WPL 8003RP $36.01

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $32.12

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $80.02

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $87.85

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $92.18

W10859326 Whirlpool Refrigerator Wire Harness Backorder WPL W10859326 $85.22

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $80.29

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $119.63

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $43.17

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $67.02

VALVE, ACCESS WPL 978029 Contact Us For Availability

MISCELLANEOUS, KIT, FOAM SLAB (30" X 32 1/2" WPL 876029 Contact Us For Availability

MISCELLANEOUS, TAPE, VINYL (3/4 X 108") WPL 479502 Contact Us For Availability

PAINT, BULK (1 QT. WHITE (UNCUT)) WPL 799344 Contact Us For Availability

TORX SCREW WRENCH, TORX KEY WPL 1117510 Contact Us For Availability
