Model Whirlpool GT1SHTXLT01 REFRIGERATOR – Common Parts &amp; Diagrams

1

W11023687 Whirlpool Refrigerator Door Assembl Backorder WPL W11023687 $582.56

1

W11023688 Whirlpool Refrigerator Door Assembl Backorder WPL W11023688 $450.46

1

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $7.20

1

Housing, Dispenser WPL 2210500 Contact Us For Availability

2

WP2193353W Whirlpool Refrigerator Trim Handle In Stock WPL WP2193353W $5.99

2

Trim, Handle (Black) WPL 2193353B Contact Us For Availability

2

Trim, Handle (Biscuit) WPL 2193353T Contact Us For Availability

2

Button, Dispenser WPL 2210567 Contact Us For Availability

3

2163762 Whirlpool Refrigerator Cup Assembly Backorder WPL 2163762 $6.49

3

WP2166108 Whirlpool Refrigerator Cabinet Roll In Stock WPL WP2166108 $18.99

3

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $4.82

3

WP8281146 Whirlpool Screw Backorder WPL WP8281146 $4.99

3

Reservoir, Tube WPL 2210513 Contact Us For Availability

4

4387491 Whirlpool Refrigerator Insert In Stock WPL 4387491 $5.99

4

W11745278 Whirlpool Bracket In Stock WPL W11745278 $8.47

4

Flange, Tube WPL 2210523 Contact Us For Availability

5

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $4.82

5

WP2189009 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189009 $4.55

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

5

Wire Assembly WPL 2187291 Contact Us For Availability

6

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $10.72

6

WP8281206 Whirlpool Refrigerator Screw Backorder WPL WP8281206 $4.82

6

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $5.99

7

WP2212648 Whirlpool Refrigerator Hinge Sleeve In Stock WPL WP2212648 $4.82

7

WP2212649 Whirlpool Refrigerator Button Plug Backorder WPL WP2212649 $4.82

7

WP2212651 Whirlpool Refrigerator Button Plug Backorder WPL WP2212651 $14.62

7

Shield, Switch WPL 2210547 Contact Us For Availability

8

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

8

2159061 Whirlpool Refrigerator Door Gasket In Stock WPL 2159061 $112.65

8

2177311 Whirlpool Refrigerator Magnetic Door In Stock WPL 2177311 $253.50

8

285006 Whirlpool Spray In Stock WPL 285006 $31.65

8

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

8

350942 Whirlpool Spray Paint Backorder WPL 350942 $49.86

8

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $16.99

8

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.99

8

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

8

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $53.03

8

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

8

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $18.58

8

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

8

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $141.89

8

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $8.89

8

W11729596 Whirlpool Ice Maker Field Install K In Stock WPL W11729596 $116.71

8

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $75.04

8

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $111.80

8

KIT, FOAM SLAB (30`` X 32 1/2`` X 1 1/2``) WPL 876029 Contact Us For Availability

8

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

8

PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability

8

Torx Key WPL 1117510 Contact Us For Availability

8

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

8

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

8

Enamel, Black (1 Qt. Uncut) WPL 799340 Contact Us For Availability

8

KIT, PORCELAIN REPAIR (WHITE) WPL 799832 Contact Us For Availability

8

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability

9

WP489357 Whirlpool Recessed Screw In Stock WPL WP489357 $3.52

10

WPW10498990 Whirlpool Refrigerator Inlet Valv In Stock WPL WPW10498990 $108.49

11

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $59.57

11

WP2176225 Whirlpool Glass Shelf In Stock WPL WP2176225 $200.95

11

WP3400504 Whirlpool Refrigerator Screw Backorder WPL WP3400504 $4.82

12

WP2183003 Whirlpool Thimble In Stock WPL WP2183003 $4.98

W11594405 Whirlpool Axle In Stock WPL W11594405 $8.90

WP2188236 Whirlpool Refrigerator Shelf Door In Stock WPL WP2188236 $53.99

WP2188785 Whirlpool Water Inlet Valve Backorder WPL WP2188785 $168.54

Thermostat Assembly (Includes Items 5, 18, & WPL 2210491 Contact Us For Availability

14

WP488787 Whirlpool Refrigerator Screw Backorder WPL WP488787 $6.83

15

WP489497 Whirlpool Screw In Stock WPL WP489497 $6.75

15

WP693995 Whirlpool Screw In Stock WPL WP693995 $7.99

16

2212996 Whirlpool Refrigerator Retainer Backorder WPL 2212996 $8.05

17

WP2183854 Whirlpool Refrigerator Shim Backorder WPL WP2183854 $6.78

17

Trim, Door Shelf (2) WPL 2195947 Contact Us For Availability

18

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $4.82

18

Nameplate WPL 2220214 Contact Us For Availability

4388947 Whirlpool Refrigerator Door Handle Ki Backorder WPL 4388947 $163.78

4388950 Whirlpool Refrigerator Handle Backorder WPL 4388950 $154.02

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $17.77

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

Clip, Heater WPL 2182338 Contact Us For Availability

20

WP2204812 Whirlpool Refrigerator Door Bin In Stock WPL WP2204812 $55.45

20

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.85

20

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $176.99

21

WPW10421486 Whirlpool Refrigerator Door Trim In Stock WPL WPW10421486 $46.99

21

Cover, Air Diffuser WPL 2176281 Contact Us For Availability

21

Shim, Bottom Hinge WPL 2172743 Contact Us For Availability

22

WP2218118 Whirlpool Refrigerator Door Compres Backorder WPL WP2218118 $53.83

22

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $29.99

22

Support Block WPL 2201185 Contact Us For Availability

23

WP2201061 Whirlpool Refrigerator Door Trim In Stock WPL WP2201061 $74.99

23

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $59.71

23

Air Tower WPL 2182340 Contact Us For Availability

24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $55.70

24

WP2189452 Whirlpool Refrigerator Diffuser Backorder WPL WP2189452 $82.12

25

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $68.41

26

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $6.88

26

Air Diffuser, Top WPL 2204690 Contact Us For Availability

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $71.99

27

Cement Alumilastic) WPL 542369 Contact Us For Availability

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.99

28

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $49.99

28

Installation Kit WPL 482801 Contact Us For Availability

30

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.91

30

Bracket, Evap. Fan, Front WPL 2214979 Contact Us For Availability

31

WP627792 Whirlpool Refrigerator Shut Off Arm Backorder WPL WP627792 $57.65

32

WP2187464 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187464 $88.98

32

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $122.18

32

Slide, Crisper WPL 2176222 Contact Us For Availability

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $16.99

35

W10190935 Whirlpool Refrigerator Icemaker Mot In Stock WPL W10190935 $71.99

35

WPW10283959 Whirlpool Refrigerator Filler In Stock WPL WPW10283959 $5.99

36

WP2205079 Whirlpool Refrigerator Seal Backorder WPL WP2205079 $6.17

36

WP2212446 Whirlpool Refrigerator Control Body In Stock WPL WP2212446 $46.99

36

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

37

WP2210509 Whirlpool Refrigerator Tub Valve Backorder WPL WP2210509 $62.27

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

38

WP2156007 Whirlpool Refrigerator Endcap Trim In Stock WPL WP2156007 $7.99

38

WP487576 Whirlpool Washer In Stock WPL WP487576 $5.99

WP2156006 Whirlpool Refrigerator Shelf Trim E In Stock WPL WP2156006 $5.47

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $4.82

CLIP, GRILLE WPL 2189356 Contact Us For Availability

Housing Base WPL 2201153 Contact Us For Availability

40

2213364 Whirlpool Refrigerator Cover Backorder WPL 2213364 $11.82

40

WP2213360 Whirlpool Refrigerator Cover Backorder WPL WP2213360 $12.19

40

WP489442 Whirlpool Refrigerator Screw Backorder WPL WP489442 $6.83

41

Wiring Harness, Freezer Light WPL 2221681 Contact Us For Availability

42

Electrical Shield, Freezer Light WPL 2193491 Contact Us For Availability

43

4396822 Whirlpool Refrigerator Light Bulb In Stock WPL 4396822 $14.99

43

WP2195341 Whirlpool Refrigerator Pan Trim Backorder WPL WP2195341 $55.91

43

Fan, Blade WPL 2190685 Contact Us For Availability

44

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.82

44

Bracket Assembly, Water Filter WPL 2210510 Contact Us For Availability

45

Shield, heat WPL 2204639 Contact Us For Availability

46

Post, Damper WPL 2179859 Contact Us For Availability

47

Bracket, Damper Knob WPL 2163810 Contact Us For Availability

48

Gasket, Rear WPL 2166284 Contact Us For Availability

54

Cover, Filter WPL 2210504 Contact Us For Availability

55

Tube, Filter Inlet WPL 2210518 Contact Us For Availability

56

Cover, Tubing WPL 2210521 Contact Us For Availability

57

Cartridge, Filter WPL 2206039 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.88

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

W10823511 Whirlpool Refrigerator Water Tube In Stock WPL W10823511 $15.88

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

Evaporator Tray WPL 2210451 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

59

Clip, Retainer WPL 2210563 Contact Us For Availability

100

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $130.99
