Model Whirlpool GC3NHAXVA00 REFRIGERATOR – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.72

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.73

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.51

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.92

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.79

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $6.37

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $146.78

8171357 Whirlpool Spray Nozzle Backorder WPL 8171357 $49.39

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.19

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.43

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $33.30

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $40.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $42.85

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $47.27

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $70.54

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.40

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $31.24

PAINT, TOUCH-UP (1/2oz.) (Graphite) WPL 80051 Contact Us For Availability

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

Following Parts Not Illustrated and Optional WPL ARI59488A3 Contact Us For Availability

REFRIGERANT CHARGE 6.00 oz. (R-134A) WPL ARI59489A1 Contact Us For Availability

1

WP2182120 Whirlpool Refrigerator Scroll Fan In Stock WPL WP2182120 $39.77

1

WP2223288 Whirlpool Refrigerator Cantilever S Backorder WPL WP2223288 $290.41

1

WP488234 Whirlpool Air Conditioner Screw Backorder WPL WP488234 $3.38

1

Control Box (Includes 6) WPL 2319752 Contact Us For Availability

2

8201663 Whirlpool Refrigerator Primary Fan Bl Backorder WPL 8201663 $60.29

2

W11458267 Whirlpool Refrigerator Fan Blade In Stock WPL W11458267 $10.85

2

WP2223877 Whirlpool Door Hook In Stock WPL WP2223877 $45.31

2

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $4.19

2

Fitting, Water Tube WPL 2303216 Contact Us For Availability

2

Crusher Bin WPL 2305206 Contact Us For Availability

3

W10852517 Whirlpool Refrigerator Ice Auger Backorder WPL W10852517 $84.24

3

WP2305202 Whirlpool Refrigerator Bracket Backorder WPL WP2305202 $43.66

3

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $5.91

3

Dairy Door WPL 2255421 Contact Us For Availability

3

Air Scoop WPL 2223298 Contact Us For Availability

3

Condenser Assembly WPL W10131059 Contact Us For Availability

4

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $17.32

4

WP2305242 Whirlpool Refrigerator Connector In Stock WPL WP2305242 $36.68

4

WPW10171469 Whirlpool Refrigerator Screw In Stock WPL WPW10171469 $4.72

4

Washer WPL 2258220 Contact Us For Availability

4

Air Duct, Upper WPL 2223303 Contact Us For Availability

5

2223771 Whirlpool Refrigerator Air Duct Backorder WPL 2223771 $125.67

5

3400524 Whirlpool Refrigerator Screw Backorder WPL 3400524 $12.14

5

W11545866 Whirlpool Refrigerator Clip Backorder WPL W11545866 $5.62

5

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $6.23

5

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $25.76

6

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $4.51

6

WP2255411 Whirlpool Refrigerator Clip In Stock WPL WP2255411 $16.85

6

WP2305258 Whirlpool Dispenser Door Assembly Backorder WPL WP2305258 $10.59

6

WPW10159840 Whirlpool Refrigerator Valve In Stock WPL WPW10159840 $200.32

6

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $23.89

6

Control Board Asm WPL 2307037 Contact Us For Availability

6

Cover, Crisper (Includes 2 & 3) WPL 2223307 Contact Us For Availability

6

Housing, Control Board WPL 2223703 Contact Us For Availability

6

Ladder, Shelf (2) WPL 2319866 Contact Us For Availability

7

W10528579 Whirlpool Refrigerator Tube Backorder WPL W10528579 $290.90

7

WP2223506 Whirlpool Refrigerator Light Lens Backorder WPL WP2223506 $58.49

7

WP2223591 Whirlpool Refrigerator Glass Shelf Backorder WPL WP2223591 $139.68

7

WP2305204 Whirlpool Refrigerator Support In Stock WPL WP2305204 $33.40

7

Fan Motor WPL 2259385 Contact Us For Availability

8

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $16.76

8

2223545 Whirlpool Refrigerator Shim Backorder WPL 2223545 $63.41

8

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $18.95

8

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $5.11

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $35.14

8

WP4449745 Whirlpool Screw Backorder WPL WP4449745 $4.77

8

Eyelet, Roller WPL 2174478 Contact Us For Availability

9

2307008B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307008B $29.93

9

WP2304241 Whirlpool Refrigerator Gasket Backorder WPL WP2304241 $31.62

9

Blade, Fixed WPL 2257020 Contact Us For Availability

9

Plate, Mounting WPL 2301979 Contact Us For Availability

9

Clip, Thermistor WPL 2209204 Contact Us For Availability

W10278732 Whirlpool Refrigerator Blade Backorder WPL W10278732 $56.83

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $4.50

W11669856 Whirlpool Grommet Backorder WPL W11669856 $7.05

WP2223879 Whirlpool Refrigerator Compressor D Backorder WPL WP2223879 $85.47

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.71

11

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $60.77

11

Block, Blade WPL 2198602 Contact Us For Availability

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $7.18

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $42.24

WP2223752 Whirlpool Refrigerator Door Cam Backorder WPL WP2223752 $8.28

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $59.14

Hinge Assembly, Bottom-RC WPL 2307179 Contact Us For Availability

Gasket, Air Baffle WPL 2304597 Contact Us For Availability

Harness, Fan Evaporator (Includes 6) WPL W10129813 Contact Us For Availability

Clamp, Cable WPL 2305373 Contact Us For Availability

2301544 Whirlpool Refrigerator Glide Backorder WPL 2301544 $199.39

2301545 Whirlpool Refrigerator Glide Backorder WPL 2301545 $98.28

WP2155789 Whirlpool Refrigerator Gasket Backorder WPL WP2155789 $4.51

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $4.19

WP2305235 Whirlpool Refrigerator Spigot Backorder WPL WP2305235 $58.79

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $12.28

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $5.88

Cover, Emitter WPL 2259487 Contact Us For Availability

Air Diffuser Assembly WPL 2224076 Contact Us For Availability

Tube, Condenser to Heat Loop WPL W10132546 Contact Us For Availability

2306940 Whirlpool Refrigerator Bracket Backorder WPL 2306940 $64.88

2306940B Whirlpool Refrigerator Bracket Backorder WPL 2306940B $24.02

WP2198661 Whirlpool Refrigerator Washer Backorder WPL WP2198661 $5.91

WP2220377 Whirlpool Refrigerator Air Baffle In Stock WPL WP2220377 $245.91

Screw WPL 8534064 Contact Us For Availability

2307007B Whirlpool Refrigerator Butt Hinge Backorder WPL 2307007B $89.81

4388500 Whirlpool Refrigerator Gasket Backorder WPL 4388500 $32.28

WP2198635 Whirlpool Refrigerator Spring Backorder WPL WP2198635 $31.00

WP2220457 Whirlpool Refrigerator Ice Bin Coup In Stock WPL WP2220457 $12.34

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $50.57

Handle WPL 2203029 Contact Us For Availability

Baseplate WPL 2306932 Contact Us For Availability

2223413 Whirlpool Refrigerator Evaporator Cov Backorder WPL 2223413 $221.15

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.88

W11223328 Whirlpool Refrigerator Shelf Stud Backorder WPL W11223328 $10.90

WP2198634 Whirlpool Door Pin Backorder WPL WP2198634 $6.96

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $2.59

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $4.19

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $6.29

4389654 Whirlpool Screw Backorder WPL 4389654 $10.90

W11566763 Whirlpool Fitting In Stock WPL W11566763 $22.78

WP2188823 Whirlpool Refrigerator Evaporator In Stock WPL WP2188823 $275.26

WP2224173 Whirlpool Refrigerator Cantilever B In Stock WPL WP2224173 $50.13

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $3.22

Tube, P.C. Board WPL 2198665 Contact Us For Availability

W11457217 Whirlpool Refrigerator Rocker Switc In Stock WPL W11457217 $17.32

WP2187467 Whirlpool Refrigerator Wire Harness Backorder WPL WP2187467 $55.72

WP2196483 Whirlpool Refrigerator Shelf Stud Backorder WPL WP2196483 $5.56

WP2305382 Whirlpool Refrigerator Washer In Stock WPL WP2305382 $5.37

Tube, Extension WPL 2254566 Contact Us For Availability

Clamp WPL 2161324 Contact Us For Availability

WP2188874 Whirlpool Refrigerator Condenser Mo In Stock WPL WP2188874 $85.46

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $7.50

Light Lens WPL 2223663 Contact Us For Availability

BRACKET, ICEMAKER MOUNTING WPL 2303583 Contact Us For Availability

WP2198608 Whirlpool Refrigerator Spring In Stock WPL WP2198608 $4.19

WP2223320 Whirlpool Slide Track Pan In Stock WPL WP2223320 $16.85

WPW10185438 Whirlpool Ice Maker Cover In Stock WPL WPW10185438 $50.89

Nameplate WPL 2220214 Contact Us For Availability

Cover, Unit WPL 2223409 Contact Us For Availability

Wire Assembly, User Interface (Includes 10) WPL 2187814 Contact Us For Availability

Tray, Evaporator WPL 2223398 Contact Us For Availability

2306900 Whirlpool Refrigerator Slide Backorder WPL 2306900 $65.06

Wire Assembly, IDI Motor WPL 2187813 Contact Us For Availability

Slide, Ice Maker Mounting (Right Side) WPL 2212321 Contact Us For Availability

Support, R.S WPL 2223395 Contact Us For Availability

Heat Shield WPL 2224022 Contact Us For Availability

4388358 Whirlpool Refrigerator Support Bracke Backorder WPL 4388358 $17.42

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $7.10

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $3.22

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $17.11

Holder WPL 2212369 Contact Us For Availability

24

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $12.60

24

8201675 Whirlpool Refrigerator Compressor In Stock WPL 8201675 $377.82

24

WP2220458 Whirlpool Drive Cam In Stock WPL WP2220458 $14.65

2223800 Whirlpool Refrigerator Spacer Backorder WPL 2223800 $11.53

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $37.17

WP2198628 Whirlpool Door Seal In Stock WPL WP2198628 $6.14

Hinge Assembly, Bottom-FC WPL 2307152 Contact Us For Availability

2260503MG Whirlpool Refrigerator Button Backorder WPL 2260503MG $15.50

2260503W Whirlpool Refrigerator Button Backorder WPL 2260503W $23.46

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $10.08

WP2212370 Whirlpool Washer Backorder WPL WP2212370 $14.61

WP2310122 Whirlpool Refrigerator Wire Harness Backorder WPL WP2310122 $229.88

27

W10852956 Whirlpool Refrigerator Spring In Stock WPL W10852956 $10.42

27

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $6.29

27

Fan, Motor Bracket WPL 2224024 Contact Us For Availability

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $65.34

WP2198633 Whirlpool Refrigerator Flipper In Stock WPL WP2198633 $16.40

WP2305243 Whirlpool Refrigerator Shaft Backorder WPL WP2305243 $101.48

Heater, Defrost WPL 2323199 Contact Us For Availability

W11623163 Whirlpool Refrigerator Clip Backorder WPL W11623163 $7.20

WP2252130 Whirlpool Refrigerator Motor In Stock WPL WP2252130 $133.66

Door Closer, FC WPL 2307051 Contact Us For Availability

Cover, Receiver WPL 2255558 Contact Us For Availability

2315398 Whirlpool Refrigerator Slide Backorder WPL 2315398 $7.44

W10629033 Whirlpool Refrigerator Inverter Con In Stock WPL W10629033 $287.30

WP2260518B Whirlpool Water Filter Cap In Stock WPL WP2260518B $22.87

WP2260518MG Whirlpool Water Filter Cap Backorder WPL WP2260518MG $32.84

Bracket, Motor WPL 2305208 Contact Us For Availability

31

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $5.84

31

Screw WPL 489387 Contact Us For Availability

WP2198643 Whirlpool Refrigerator Lens In Stock WPL WP2198643 $2.59

WP2212365 Whirlpool Refrigerator Sleeve Backorder WPL WP2212365 $13.34

WP489483 Whirlpool Screw In Stock WPL WP489483 $5.85

Tube, Discharge WPL 2223352 Contact Us For Availability

4388295 Whirlpool Refrigerator Mounting Kit Backorder WPL 4388295 $118.16

WP4387558 Whirlpool Refrigerator Compressor G Backorder WPL WP4387558 $5.76

Door Closer (RC) WPL 2307049 Contact Us For Availability

Light Shield WPL 2198589 Contact Us For Availability

34

2223394 Whirlpool Extension Backorder WPL 2223394 $64.97

34

Light Lens WPL 2212340 Contact Us For Availability

35

WP2198641 Whirlpool Refrigerator Ice Maker Co In Stock WPL WP2198641 $3.22

35

Clip, Heat Shield WPL 2155547 Contact Us For Availability

36

2310121 Whirlpool Refrigerator Wire Harness Backorder WPL 2310121 $298.82

36

W11496481 Whirlpool Refrigerator Water Tube In Stock WPL W11496481 $15.43

36

WPW10119935 Whirlpool Refrigerator Socket Backorder WPL WPW10119935 $40.77

37

8201597 Whirlpool Inlet Water Fill Tube Kit F In Stock WPL 8201597 $28.79

37

Ladder (Left Side) WPL 2198609 Contact Us For Availability

37

Ladder (Right Side) WPL 2198610 Contact Us For Availability

38

2303378 Whirlpool Shield Assembly Backorder WPL 2303378 $12.60

63

WP2300868 Whirlpool Refrigerator Fitting In Stock WPL WP2300868 $12.13
