Model Whirlpool 106.51049101 Refrigerator (Kenmore 10651049101) – Common Parts &amp; Diagrams

1

W11254898 Whirlpool Refrigerator Scroll Fan Backorder WPL W11254898 $227.38

1

W11505385 Whirlpool Refrigerator Chute In Stock WPL W11505385 $14.48

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.82

1

FOR FIELD INSTALLABLE ICEMAKER REPAIR PARTS L WPL N/P Contact Us For Availability

2

2194744 Whirlpool Refrigerator Escutcheon Backorder WPL 2194744 $66.63

2

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $4.99

2

Refrigerator Condenser Fan WPL 2190685 Contact Us For Availability

2

Refrigerator Evaporator Fan Motor Retainer WPL 2155590 Contact Us For Availability

2

Refrigerator Thermistor Bracket WPL 1110629 Contact Us For Availability

3

2171712 Whirlpool Refrigerator Ice Door Backorder WPL 2171712 $50.88

3

WP2152713 Whirlpool Refrigerator Solenoid In Stock WPL WP2152713 $110.99

3

WP2194719 Whirlpool Refrigerator Clip In Stock WPL WP2194719 $7.91

3

WP2203828 Whirlpool Door Shelf Bin In Stock WPL WP2203828 $70.59

3

Refrigerator Deli Drawer Temperature Control WPL 2182757 Contact Us For Availability

3

Refrigerator Condenser WPL 2204484 Contact Us For Availability

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $24.67

4

WP2156022 Whirlpool Refrigerator Door Trim In Stock WPL WP2156022 $60.18

4

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $25.38

4

Cabinet Louver WPL 2182147 Contact Us For Availability

5

W10777924 Whirlpool Refrigerator Wine Rack Backorder WPL W10777924 $14.29

5

WP2196195 Whirlpool Refrigerator Door Pin In Stock WPL WP2196195 $11.99

5

Refrigerator Tube WPL 2211760 Contact Us For Availability

6

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $8.39

6

W10822278 Whirlpool Defrost Timer In Stock WPL W10822278 $28.72

6

W10864399 Whirlpool Glass Shelf In Stock WPL W10864399 $131.60

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $8.89

7

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $5.99

7

Refrigerator Shield WPL 2149293 Contact Us For Availability

8

2205764 Whirlpool Refrigerator Tube Backorder WPL 2205764 $60.78

8

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $24.19

8

WP2203770 Whirlpool Refrigerator Door Hinge Backorder WPL WP2203770 $66.95

8

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $3.46

8

Refrigerator Control Panel Hole Plug WPL 940014 Contact Us For Availability

9

WP2158826 Whirlpool Refrigerator Dampener In Stock WPL WP2158826 $0.91

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $57.74

9

WP2203771 Whirlpool Refrigerator Door Hinge In Stock WPL WP2203771 $37.09

9

WP2206671W Whirlpool Refrigerator Grille In Stock WPL WP2206671W $49.31

9

Refrigerator Ladder WPL 2206270 Contact Us For Availability

9A

WP2206671B Whirlpool Refrigerator Grille In Stock WPL WP2206671B $42.58

W10683556 Whirlpool Refrigerator Clip Backorder WPL W10683556 $12.26

WP2176759 Whirlpool Refrigerator Grommet In Stock WPL WP2176759 $5.30

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $5.30

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $6.51

2182146 Whirlpool Refrigerator Duct Backorder WPL 2182146 $69.10

W10759522 Whirlpool Screw Backorder WPL W10759522 $4.82

WP2179343 Whirlpool Refrigerator Control Body Backorder WPL WP2179343 $22.47

WP2182195 Whirlpool Refrigerator Cam Backorder WPL WP2182195 $6.63

WP2203407W Whirlpool Refrigerator Cover Backorder WPL WP2203407W $14.39

WP627018 Whirlpool Refrigerator Nut In Stock WPL WP627018 $7.60

11A

WP2203407B Whirlpool Refrigerator Cover Backorder WPL WP2203407B $13.08

11B

2203407T Whirlpool Refrigerator Cover Backorder WPL 2203407T $12.83

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $7.12

WP2162358 Whirlpool Refrigerator Terminal Cov Backorder WPL WP2162358 $69.36

WP2179342 Whirlpool Refrigerator Slide Backorder WPL WP2179342 $20.20

WP2180224 Whirlpool Dispenser Funnel Guide In Stock WPL WP2180224 $10.48

2180200 Whirlpool Refrigerator Socket Backorder WPL 2180200 $72.32

4387535 Whirlpool Refrigerator Compressor Rel In Stock WPL 4387535 $91.25

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $23.85

WP3400012 Whirlpool Refrigerator Screw Backorder WPL WP3400012 $4.82

Refrigerator Freezer Shelf Support Grommet WPL 2176134 Contact Us For Availability

Refrigerator Light Cover WPL 2200096 Contact Us For Availability

Refrigerator Shim WPL 2209697 Contact Us For Availability

13A

W10845585 Whirlpool Refrigerator Track Backorder WPL W10845585 $97.31

WP2162361 Whirlpool Switch In Stock WPL WP2162361 $14.28

WP2196062 Whirlpool Refrigerator Clip Backorder WPL WP2196062 $6.89

WP2196090 Whirlpool Refrigerator Container Backorder WPL WP2196090 $134.70

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $4.82

Refrigerator Trim Cap WPL 2196094 Contact Us For Availability

Refrigerator Defrost Clip WPL 2161324 Contact Us For Availability

15

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $42.05

15

Refrigerator Damper Control Pivot Arm WPL 1110559 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $62.95

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $8.05

WP489497 Whirlpool Screw In Stock WPL WP489497 $6.64

Start Device WPL 2216722 Contact Us For Availability

17

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $47.85

17

WP4387764 Whirlpool Run Capacitor Backorder WPL WP4387764 $130.74

17

Refrigerator Wire Cover WPL 2150330 Contact Us For Availability

2179350 Whirlpool Refrigerator Deflector Backorder WPL 2179350 $60.06

W11233072 Whirlpool Screw In Stock WPL W11233072 $11.38

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $19.72

WP1119005 Whirlpool Refrigerator Spacer Backorder WPL WP1119005 $6.99

Refrigerator Clip WPL 2200097 Contact Us For Availability

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $17.42

WP1119007 Whirlpool Refrigerator Spacer Backorder WPL WP1119007 $8.89

WP2256126 Whirlpool Refrigerator Reservoir In Stock WPL WP2256126 $94.08

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $13.89

20

W11223328 Whirlpool Refrigerator Shelf Stud Backorder WPL W11223328 $14.99

20

Refrigerator Wire Harness WPL 2216742 Contact Us For Availability

20

Refrigerator Cover Unit WPL 2200451 Contact Us For Availability

21

489396 Whirlpool Refrigerator Clip Backorder WPL 489396 $7.11

21

WP1115374 Whirlpool Refrigerator Clip Backorder WPL WP1115374 $4.82

WP2188822 Whirlpool Refrigerator Evaporator In Stock WPL WP2188822 $221.06

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $29.99

Refrigerator Shelf Stud WPL 2196207 Contact Us For Availability

Refrigerator Retainer Clip WPL 1115375 Contact Us For Availability

Screw WPL 488280 Contact Us For Availability

WP2203408W Whirlpool Refrigerator Cover Backorder WPL WP2203408W $14.54

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $6.87

WP489491 Whirlpool Refrigerator Screw Backorder WPL WP489491 $4.82

Refrigerator Rod WPL 1123959 Contact Us For Availability

23A

WP2203408B Whirlpool Refrigerator Cover Backorder WPL WP2203408B $12.92

24

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $60.81

24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $59.60

24

Refrigerator Air Damper Control Clip WPL 489285 Contact Us For Availability

2157405 Whirlpool Refrigerator Blade Block Backorder WPL 2157405 $14.02

WP2182179 Whirlpool Cam Closer In Stock WPL WP2182179 $5.19

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $63.48

Refrigerator Extension WPL 2194706W Contact Us For Availability

Refrigerator Escutcheon WPL 2205929 Contact Us For Availability

489229 Whirlpool Refrigerator Roll Pin Backorder WPL 489229 $33.86

WP2182181 Whirlpool Refrigerator Thimble In Stock WPL WP2182181 $5.30

WP2195051 Whirlpool Refrigerator Clip Backorder WPL WP2195051 $7.19

Refrigerator Temperature Control Knob WPL 2182111 Contact Us For Availability

Refrigerator Door Handle Trim WPL 2194705W Contact Us For Availability

Refrigerator Wire Harness WPL 2187399 Contact Us For Availability

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $31.99

WP489483 Whirlpool Screw In Stock WPL WP489483 $7.58

Spacer WPL 625834 Contact Us For Availability

Refrigerator Temperature Control Knob WPL 2197871 Contact Us For Availability

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $8.68

W10309990 Whirlpool Refrigerator Compressor In Stock WPL W10309990 $390.17

WP2186443 Whirlpool Water Filter Housing In Stock WPL WP2186443 $62.29

WP2206629B Whirlpool Refrigerator Bracket Backorder WPL WP2206629B $23.94

28A

W10845583 Whirlpool Refrigerator Track Backorder WPL W10845583 $87.65

29

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $6.47

29

WP2195327 Whirlpool Refrigerator Clip Backorder WPL WP2195327 $4.82

29

WP489500 Whirlpool Refrigerator Screw Backorder WPL WP489500 $4.82

W10852691 Whirlpool Refrigerator Baffle Backorder WPL W10852691 $20.97

WP2154473 Whirlpool Refrigerator Connector Backorder WPL WP2154473 $15.58

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $38.88

Refrigerator Microcomputer WPL 2203385 Contact Us For Availability

Refrigerator Frame WPL 2160499 Contact Us For Availability

30A

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $38.68

30B

WP2186494T Whirlpool Water Filter Cap In Stock WPL WP2186494T $7.35

31

WP1119018 Whirlpool Refrigerator Bearing Backorder WPL WP1119018 $4.82

32

WP2181929 Whirlpool Refrigerator Bracket Backorder WPL WP2181929 $7.28

32

WP8281227 Whirlpool Screw In Stock WPL WP8281227 $6.84

33

1119020 Whirlpool Refrigerator Spring Backorder WPL 1119020 $12.12

33

W11500948 Whirlpool Refrigerator Bracket In Stock WPL W11500948 $22.41

33

WP2323197 Whirlpool Refrigerator Heater Backorder WPL WP2323197 $86.68

34

1119021 Whirlpool Refrigerator Clip Backorder WPL 1119021 $6.92

34

Refrigerator Defrost Clip WPL 2161330 Contact Us For Availability

35

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $34.91

37

SCREW WPL 489473 Contact Us For Availability

38

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

38

WP1119017 Whirlpool Refrigerator Deflector Backorder WPL WP1119017 $4.82

39

489234 Whirlpool Refrigerator Washer Backorder WPL 489234 $8.89

39

W11661108 Whirlpool Grommet Backorder WPL W11661108 $9.12

39A

WP4387558 Whirlpool Refrigerator Compressor G Backorder WPL WP4387558 $4.82

40

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $6.83

40

WP489236 Whirlpool Refrigerator Ring Backorder WPL WP489236 $7.64

41

Refrigerator Air Baffle WPL 2196201 Contact Us For Availability

42

Exchange Clip WPL 2155547 Contact Us For Availability

44

Refrigerator Ice Bin Cover, Front WPL 2171709 Contact Us For Availability

46

WP2171706 Whirlpool Refrigerator Light Lens Backorder WPL WP2171706 $69.80

48

Rail Unit WPL 2149718 Contact Us For Availability

49

W11544659 Whirlpool Refrigerator Screw Backorder WPL W11544659 $8.89

50

Fan Guard WPL 2186496 Contact Us For Availability

51

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $13.22

52

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $4.99

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $4.82

54

Nut WPL 850145 Contact Us For Availability

55

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $4.82

59

Ice Maker Wire Harness Clamp WPL 2208280 Contact Us For Availability

63

WP4373559 Whirlpool Fitting In Stock WPL WP4373559 $32.30

NI01

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

NI02

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

NI03

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $87.85

NI04

Refrigerator Service Valve WPL 978028 Contact Us For Availability

NI05

Refrigerator Service Valve WPL 978029 Contact Us For Availability

NI06

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $92.18

NI07

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $32.12

NI08

350942 Whirlpool Spray Paint Backorder WPL 350942 $64.04

NI09

285006 Whirlpool Spray In Stock WPL 285006 $52.65

NI10

350930 Whirlpool White Spray Paint In Stock WPL 350930 $26.50

NI11

350956 Whirlpool Spray Assembly In Stock WPL 350956 $26.25

NI12

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $53.67

NI13

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $9.04

NI14

WP72107 Whirlpool Touchup In Stock WPL WP72107 $10.96

NI15

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $13.78

NI16

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $14.22

NI17

Pnt-blk-qrt WPL 799340 Contact Us For Availability

NI18

Appliance Porcelain Touch-Up Paint, 1-qt (Whi WPL 799344 Contact Us For Availability

NI19

Touch-Up Paint (Almond) WPL 978883 Contact Us For Availability

NI20

Paint, Bsq WPL 4392900 Contact Us For Availability

NI21

4210463RW Whirlpool Refrigerator Coil Brush In Stock WPL 4210463RW $24.24

NI22

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $37.42

NI23

Refrigerator Vinyl Tape WPL 479502 Contact Us For Availability

NI25

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $151.82

NI27

Foam Slab WPL 876029 Contact Us For Availability

NI28

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $119.63

NI29

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $80.29

NI30

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

NI31

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $43.18

NI32

Adhesive WPL 542639 Contact Us For Availability

NI33

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $56.74

NI34

Epoxy WPL 799833 Contact Us For Availability

NI35

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.82

NI36

Refrigerator Ice Container WPL 2209778 Contact Us For Availability

NI37

Refrigerator Ice Maker Torx Key Wrench WPL 1117510 Contact Us For Availability
