Samsung DV448AGE/XAA-00 Dryer Parts List

1

DC97-07526B Samsung Duct Outlet Assembly Backorder SMG DC97-07526B $85.26

View on Model

1

Dryer Motor and Blower Assembly SMG DC93-00101H Contact Us For Availability

View on Model

1

Dryer Burner Duct Assembly SMG DC97-10720A Contact Us For Availability

View on Model

1-1

6021-001201 Samsung Dryer Left Turn Nut 3/8"- In Stock SMG 6021-001201 $3.68

View on Model

1-2

DC32-00008A Samsung Radiant Sensor Assembly Backorder SMG DC32-00008A $186.73

View on Model

1-2

DC63-10001K Samsung Dryer Absorber Sponge Backorder SMG DC63-10001K $3.74

View on Model

1-3

DC61-01576A Samsung Support Hinge Assembly Backorder SMG DC61-01576A $11.19

View on Model

1-3

DC97-07602B Samsung Duct Cone Backorder SMG DC97-07602B $103.40

View on Model

1-3

Kenmore Dryer Blower Housing SMG DC93-00098C Contact Us For Availability

View on Model

1-4

DC61-00891A Samsung Washer Dryer Hinge Guide In Stock SMG DC61-00891A $1.69

View on Model

1-5

6002-000241 Samsung Self Tapping Screw Backorder SMG 6002-000241 $1.18

View on Model

1-6

DC47-00016A Samsung Thermostat In Stock SMG DC47-00016A $17.72

View on Model

1-7

6002-001306 Samsung Washer Tapping Screw Backorder SMG 6002-001306 $1.69

View on Model

1-7

DC32-00007A Samsung Dryer Thermistor Sensor Backorder SMG DC32-00007A $23.98

View on Model

1-7

DC47-00017A Samsung Washer Dryer Thermostat A In Stock SMG DC47-00017A $84.41

View on Model

1-8

DC61-01214A Samsung Spring Plate Assembly Backorder SMG DC61-01214A $4.49

View on Model

1-9

DC31-00055D Samsung Clothes Dryer Induction M In Stock SMG DC31-00055D $256.86

View on Model

1-9

DC66-00395A Samsung Dryer Door Lever Strike L In Stock SMG DC66-00395A $8.61

View on Model

1-11

DC62-00262A Samsung Dryer Door Seal Assembly In Stock SMG DC62-00262A $61.60

View on Model

1-12

3405-001077 Samsung Micro Switch Backorder SMG 3405-001077 $21.24

View on Model

1-13

DC63-00919A Samsung Switch Cover Assembly Backorder SMG DC63-00919A $3.35

View on Model

1-14

DC61-01213A Samsung Motor Bracket Assembly In Stock SMG DC61-01213A $120.09

View on Model

1-15

DC61-01215B Samsung Dryer Idler Tension Sprin In Stock SMG DC61-01215B $6.65

View on Model

1-16

DC93-00634A Samsung Dryer Idler Pulley Assemb In Stock SMG DC93-00634A $60.18

View on Model

1-18

Dryer Idler Pulley SMG DC97-07509B Contact Us For Availability

View on Model

1-19

Dryer Idler Pulley SMG DC66-00402A Contact Us For Availability

View on Model

1-21

6009-001342 Samsung Dryer Special Puller Scre Backorder SMG 6009-001342 $1.69

View on Model

2

6602-001655 Samsung Dryer Drive Belt In Stock SMG 6602-001655 $52.37

View on Model

2

DC97-14492A Samsung Burner Assembly Backorder SMG DC97-14492A $270.96

View on Model

2

Dryer Lint Screen SMG DC61-01521A Contact Us For Availability

View on Model

2

Dryer electronic control board SMG DC92-00127A Contact Us For Availability

View on Model

2-1

6006-001174 Samsung Tapping Screw Th + Wt 2s Backorder SMG 6006-001174 $1.69

View on Model

2-1

DC63-10001C Samsung EPDM Sponge Backorder SMG DC63-10001C $3.90

View on Model

2-3

DC62-00201A Samsung Dryer Gas Valve Assembly In Stock SMG DC62-00201A $257.56

View on Model

2-4

DC97-07510B Samsung Dryer Door Lever Holder C In Stock SMG DC97-07510B $17.32

View on Model

2-4

DC99-00507A Samsung Assembly Pipe Backorder SMG DC99-00507A $165.16

View on Model

2-5

6001-001773 Samsung Washer Dryer Machine Scre Backorder SMG 6001-001773 $1.69

View on Model

2-6

DC64-00828A Samsung Dryer Door Switch Assembl Backorder SMG DC64-00828A $34.97

View on Model

2-7

6002-000239 Samsung Air Conditioner Tapping S Backorder SMG 6002-000239 $1.18

View on Model

3

DC97-07895A Samsung Dryer Connector Duct Asse Backorder SMG DC97-07895A $56.12

View on Model

3-1

DC47-00021A Samsung Socket Lamp Assembly Backorder SMG DC47-00021A $26.09

View on Model

3-2

4713-001199 Samsung Dryer Drum Incandescent L Backorder SMG 4713-001199 $10.61

View on Model

3-4

Dryer Drum Light Lens SMG DC63-00531A Contact Us For Availability

View on Model

3-6

DC97-16782A Samsung Dryer Plastic Roller Whee In Stock SMG DC97-16782A $49.43

View on Model

3-7

DC61-01228A Samsung Dryer Drum Support Roller In Stock SMG DC61-01228A $2.23

View on Model

3-9

DC60-50145A Samsung Hex Nut Backorder SMG DC60-50145A $3.35

View on Model

3-11

DC63-00675A Samsung Dryer Filter Cover Backorder SMG DC63-00675A $29.35

View on Model

3-12

DC97-08894A Samsung Dryer Moisture Sensor Gui Backorder SMG DC97-08894A $37.79

View on Model

3-13

DC96-00766A Samsung Dryer Wire Harness Assemb In Stock SMG DC96-00766A $14.53

View on Model

3-14

DC97-08889A Guide Sensor Assembly MDE9700A fo In Stock SMG DC97-08889A $25.03

View on Model

3-15

DC61-01231A Samsung Dryer Wings Plate Sensor Backorder SMG DC61-01231A $6.15

View on Model

3-16

DC61-01235A Samsung Sensor Guide Assembly Backorder SMG DC61-01235A $6.39

View on Model

4

DC47-00022A Samsung Dryer Heater Igniter In Stock SMG DC47-00022A $179.34

View on Model

4

Dryer Drum SMG DC97-14849A Contact Us For Availability

View on Model

5

DC61-01522A Samsung Dryer Drying Rack Assembl Backorder SMG DC61-01522A $149.63

View on Model

6

Dryer electronic control board SMG DC92-00123A Contact Us For Availability

View on Model

6-7

DC97-07523B Samsung Dryer Drum Roller Assembl Backorder SMG DC97-07523B $56.78

View on Model

6-11

DC62-30042A Samsung Dryer Steam Water Valve A Backorder SMG DC62-30042A $142.06

View on Model

6-12

DC61-02063A Samsung Nozzle Guide Assembly Backorder SMG DC61-02063A $4.98

View on Model

11-1

DC61-02008B Samsung Dryer Guide Panel Backorder SMG DC61-02008B $24.49

View on Model

14

DC61-03128A Samsung Dryer Adjustable Leveling In Stock SMG DC61-03128A $12.90

View on Model

15

DC97-07519A Samsung Dryer Exhaust Duct Assemb Backorder SMG DC97-07519A $80.58

View on Model

17

DC62-40178A Samsung Seal Water Backorder SMG DC62-40178A $1.60

View on Model

19

DC63-00534B Samsung Back Cover Assembly Backorder SMG DC63-00534B $52.73

View on Model

20

DC96-00038G Samsung Dryer Power Cord Assembly Backorder SMG DC96-00038G $111.81

View on Model
