Model Whirlpool YGH8155XMT0 MICROWAVE HOOD COMBINATION – Common Parts &amp; Diagrams

Filler Kit (Black) WPL 8171337 Contact Us For Availability

Filler Kit (White) WPL 8171336 Contact Us For Availability

1

Literature Parts (Installation Instructions) WPL LIT8183732 Contact Us For Availability

1

Literature Parts (Use & Care Guide) WPL LIT8185486 Contact Us For Availability

1

Literature Parts (Cooking Guide Label (Englis WPL LIT8185487 Contact Us For Availability

1

Literature Parts (Tech Sheet) WPL LIT8185488 Contact Us For Availability

1

Literature Parts (Cookig Guide Label (French) WPL LIT8204747 Contact Us For Availability

1

Reflector, Lamp WPL 4393688 Contact Us For Availability

1

Motor, Stirrer WPL 4393746 Contact Us For Availability

2

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $3.39

2

Frame, Inner WPL 8169545 Contact Us For Availability

2

Lens (B/Q Models) WPL 8183708 Contact Us For Availability

2

Lens (Biscuit Model) WPL 8183724 Contact Us For Availability

2

Stirrer Shaft/Blade WPL 8184633 Contact Us For Availability

3

6800 Whirlpool Charcoal Filter Kit In Stock WPL 6800 $14.68

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $50.07

3

Latch, Door WPL 4393913 Contact Us For Availability

3

Panel, Control (Black) WPL 8183709 Contact Us For Availability

3

Panel, Control (White) WPL 8183710 Contact Us For Availability

3

Panel, Control (Biscuit) WPL 8183725 Contact Us For Availability

3

Rack, Meal WPL 8204725 Contact Us For Availability

4

6802A Whirlpool Grease Filter In Stock WPL 6802A $15.28

4

Body, Door (White) WPL 8169653 Contact Us For Availability

4

Lid, Power Cord WPL 8184313 Contact Us For Availability

4

Bracket, Control WPL 8183821 Contact Us For Availability

4

Bracket, Support WPL 8183832 Contact Us For Availability

5

Thermostat WPL 8183697 Contact Us For Availability

5

Plate, Hinge WPL 4393744 Contact Us For Availability

5

Plate, Bottom WPL 8185209 Contact Us For Availability

5

Cover, Inlet WPL 8184476 Contact Us For Availability

6

Hook, Rack (4) WPL 8204662 Contact Us For Availability

6

Cord, Power WPL 8189432 Contact Us For Availability

6

Microcomputer WPL 8204859 Contact Us For Availability

6

Glass, Lamp WPL 8185210 Contact Us For Availability

7

4393777 Whirlpool Microwave Door Handle - Whi In Stock WPL 4393777 $65.76

7

4393782 Whirlpool Microwave Door Handle In Stock WPL 4393782 $79.01

7

Handle, Door (Biscuit) WPL 8169642 Contact Us For Availability

7

Case, Outer (White) WPL 8169660 Contact Us For Availability

7

Case, Outer (Black) WPL 8169661 Contact Us For Availability

7

Case, Outer (Biscuit) WPL 8169664 Contact Us For Availability

7

Screw WPL 4393828 Contact Us For Availability

7

Holder, Glass WPL 8184308 Contact Us For Availability

7

Nails/Bushings (5 of each) WPL 8184549 Contact Us For Availability

8

Turntable WPL 4393799 No Longer Available

8

8183851 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183851 $30.78

8

8183852 Whirlpool Microwave Primary Vent Gril In Stock WPL 8183852 $32.95

8

8183948 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183948 $29.01

8

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $4.77

8

Screw WPL 4393346 Contact Us For Availability

8

Guide, Air (Magnetron) WPL 8184309 Contact Us For Availability

9

8206334 Whirlpool Microwave Mounting Bracket In Stock WPL 8206334 $2.83

9

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $23.22

9

Cover, Fan WPL 8183823 Contact Us For Availability

8169464 Whirlpool Microwave Door Panel Backorder WPL 8169464 $133.52

Wheel, Plastic WPL 4393861 Contact Us For Availability

Switch, Membrane (White) WPL 8204777 Contact Us For Availability

Switch, Membrane (Black) WPL 8204778 Contact Us For Availability

Switch, Membrane (Biscuit) WPL 8204779 Contact Us For Availability

Switch, Micro (3) WPL 8204656 Contact Us For Availability

11

W10435116 Whirlpool Microwave Turntable Rolle Backorder WPL W10435116 $16.57

11

Spring, Interlock (2) WPL 8169438 Contact Us For Availability

12

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $88.39

12

Plate, Cam (2) WPL 8183824 Contact Us For Availability

8205572 Whirlpool Microwave Interlock Backorder WPL 8205572 $4.19

Screw WPL 8169474 Contact Us For Availability

Rod WPL 8169318 Contact Us For Availability

Cover, Terminal WPL 4393756 Contact Us For Availability

14

W10245183 Whirlpool Microwave Magnetron In Stock WPL W10245183 $178.22

14

Latch, Pivot WPL 8169319 Contact Us For Availability

14

Wheel, Fan WPL 8183825 Contact Us For Availability

15

Thermostat WPL 8183698 Contact Us For Availability

15

E-Ring WPL 8169320 Contact Us For Availability

15

Housing, Fan WPL 8184310 Contact Us For Availability

16

Catch WPL 8185033 Contact Us For Availability

16

Motor, Fan WPL 8185211 Contact Us For Availability

16

Holder, Connector (L) WPL 8169540 Contact Us For Availability

Spacer, Copper Pipe WPL 8184129 Contact Us For Availability

Spring WPL 8169374 Contact Us For Availability

Chassis WPL 8185212 Contact Us For Availability

Holder, Connector (R) WPL 8169705 Contact Us For Availability

Cushion, Mtr WPL 8169635 Contact Us For Availability

Plate, Damper WPL 8169697 Contact Us For Availability

Holder, Capacitor WPL 8184311 Contact Us For Availability

Screw WPL 4393838 Contact Us For Availability

19

8169539 Whirlpool Microwave Light Bulb Socket Backorder WPL 8169539 $35.16

19

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $15.24

20

8206562 Whirlpool Microwave Capacitor MG Backorder WPL 8206562 $92.19

20

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $3.22

21

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $14.93

21

Transformer, H.V. WPL 8185252 Contact Us For Availability

22

Plate, Side (R) WPL 8204657 Contact Us For Availability

23

WP8184485 Whirlpool Microwave Shield Backorder WPL WP8184485 $72.70

24

Thermostat And Bracket WPL 8184585 Contact Us For Availability

25

8184109 Whirlpool Microwave Spacer In Stock WPL 8184109 $4.51

25

Plate, Side (L) WPL 8204658 Contact Us For Availability

26

Capacitor WPL 4393709 Contact Us For Availability

27

Holder, Fuse WPL 8184312 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $23.48

29

Thermostat WPL 8183703 Contact Us For Availability

32

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $10.17

33

Screw WPL 4393833 Contact Us For Availability

34

Screw WPL 8169478 Contact Us For Availability

35

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $3.22

36

Screw WPL 4393839 Contact Us For Availability
