Model Whirlpool MH1160XSB2 Microwave Oven 1.7 Cu. Ft. – Common Parts & Diagrams

Template, Upper
Template, Upper WPL 8205871 Contact Us For Availability
View on Model
1
Deflector, Air
Deflector, Air WPL 8206340 Contact Us For Availability
View on Model
1
Cover, Inlet Includes Nails and Bushings
Cover, Inlet Includes Nails and Bushings WPL 8206389 Contact Us For Availability
View on Model
1
Reflector, Lamp
Reflector, Lamp WPL 8206387 Contact Us For Availability
View on Model
1
Cook Guide Label
Cook Guide Label WPL 8205879 Contact Us For Availability
View on Model
1
U & C Guide
U & C Guide WPL W10110881 Contact Us For Availability
View on Model
1
Tech Sheet
Tech Sheet WPL W10110888 Contact Us For Availability
View on Model
2
Screw
Screw WPL 8206181 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8206423 Contact Us For Availability
View on Model
3
Bracket, Control
Bracket, Control WPL W10156814 Contact Us For Availability
View on Model
3
Handle (Black)
Handle (Black) WPL W10114515 Contact Us For Availability
View on Model
3
Holder, Lamp
Holder, Lamp WPL 8206374 Contact Us For Availability
View on Model
4
Turntable
Turntable WPL 4393799 No Longer Available
View on Model
4
Microcomputer
Microcomputer WPL W10108790 Contact Us For Availability
View on Model
5
Plate, Bottom
Plate, Bottom WPL 8206386 Contact Us For Availability
View on Model
6
Glass, Lamp
Glass, Lamp WPL 8206376 Contact Us For Availability
View on Model
7
Holder, Glass
Holder, Glass WPL 8206375 Contact Us For Availability
View on Model
12
Filter
Filter WPL 8206624 Contact Us For Availability
View on Model
15
Brkt-Mntg, Filter
Brkt-Mntg, Filter WPL W10156815 Contact Us For Availability
View on Model
16
Socket, Motor Wire
Socket, Motor Wire WPL W10139750 Contact Us For Availability
View on Model
16
Thermistor (PCBA)
Thermistor (PCBA) WPL 8206421 Contact Us For Availability
View on Model
17
Cover, Terminal
Cover, Terminal WPL W10110598 Contact Us For Availability
View on Model
17
Plate, Side
Plate, Side WPL W10138792 Contact Us For Availability
View on Model
18
Chassis Assembly
Chassis Assembly WPL 8206358 Contact Us For Availability
View on Model
20
Holder, Fuse
Holder, Fuse WPL 8184312 Contact Us For Availability
View on Model
22
Terminal Cvr, Lamp
Terminal Cvr, Lamp WPL 8206359 Contact Us For Availability
View on Model
23
Support, Diode
Support, Diode WPL 8206370 Contact Us For Availability
View on Model
25
Transformer, H.V.
Transformer, H.V. WPL 8206343 Contact Us For Availability
View on Model
28
Diode, H.V.
Diode, H.V. WPL W10138796 Contact Us For Availability
View on Model
29
Chassis
Chassis WPL W10138791 Contact Us For Availability
View on Model
