Model Whirlpool GX5SHDXVA01 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2256087 Whirlpool Refrigerator Bracket Backorder WPL WP2256087 $62.84

1

WPW10326469 Whirlpool Drawer Slide Rail In Stock WPL WPW10326469 $13.92

1

Energy Guide WPL W10187811 Contact Us For Availability

1

Use & Care Guide WPL W10200283 Contact Us For Availability

1

Tech Sheet WPL W10238844 Contact Us For Availability

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $56.56

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $42.74

2

DOOR, RIGHT (BLACK) WPL 12978075BQ Contact Us For Availability

2

TRIM, CRISPER WPL W10231508 Contact Us For Availability

2

DOOR, RIGHT (SATINA) WPL 12978034LQ Contact Us For Availability

2

CABINET (NOT A SERVICABLE PART) WPL NP Contact Us For Availability

3

W10337647 Whirlpool Refrigerator Cover Backorder WPL W10337647 $15.34

3

W11173556 Whirlpool Refrigerator Shaft Backorder WPL W11173556 $14.98

3

WPW10169346 Whirlpool Refrigerator Beverage H Backorder WPL WPW10169346 $336.70

3

WPW10180451 Whirlpool Refrigerator Overlay Backorder WPL WPW10180451 $59.51

3

WPW10337634 Whirlpool Refrigerator Cover Backorder WPL WPW10337634 $15.34

3

WPW10337648 Whirlpool Refrigerator Cover Backorder WPL WPW10337648 $15.02

3

COVER, LEFT HINGE (BISCUIT) WPL 12962301Q Contact Us For Availability

3

Clamp WPL 10526702 Contact Us For Availability

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $11.97

4

WP12806407 Whirlpool Refrigerator Housing Backorder WPL WP12806407 $76.24

4

WP13005401SP Whirlpool Can Rack In Stock WPL WP13005401SP $40.16

4

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.46

4

WPW10348246 Whirlpool Refrigerator Freezer Ba Backorder WPL WPW10348246 $219.62

5

WP2315576 Whirlpool Water Inlet Valve In Stock WPL WP2315576 $51.57

5

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $53.43

5

Roller Assy. (2) WPL 12580304 Contact Us For Availability

5

Basket, Freezer (Lower) WPL W10150039 Contact Us For Availability

6

W10205737 Whirlpool Refrigerator Glass Shelf Backorder WPL W10205737 $181.24

6

W11177593 Whirlpool Leveling Feet Backorder WPL W11177593 $8.00

6

WP67004028 Whirlpool Refrigerator Shut-Off Ar In Stock WPL WP67004028 $40.88

6

WPW10233569 Whirlpool Refrigerator Tube Backorder WPL WPW10233569 $52.10

7

W10709795 Whirlpool Refrigerator Screw Backorder WPL W10709795 $12.17

7

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $11.56

7

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $3.46

8

71003131 Whirlpool Oven Screw Backorder WPL 71003131 $7.55

8

W11368721 Whirlpool Refrigerator French Door In Stock WPL W11368721 $121.03

8

WP67005864 Whirlpool Humidity Control In Stock WPL WP67005864 $4.19

8

WPA3223101 Whirlpool Refrigerator Insert PL Backorder WPL WPA3223101 $4.19

9

W10241046 Whirlpool Refrigerator Divider Backorder WPL W10241046 $15.92

9

W10829281 Whirlpool Refrigerator Screw Backorder WPL W10829281 $6.43

9

W11351146 Whirlpool Refrigerator Handle Backorder WPL W11351146 $106.53

9

WP8281196 Whirlpool Screw In Stock WPL WP8281196 $4.53

9

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $146.06

67005958 Whirlpool Refrigerator Top Hinge Cov Backorder WPL 67005958 $13.67

W10122561 Whirlpool Refrigerator Cup Fill Backorder WPL W10122561 $11.17

W10825088 Whirlpool Refrigerator Defrost Heat In Stock WPL W10825088 $87.91

W10847995 Whirlpool Divider Assembly Backorder WPL W10847995 $56.47

W11447232 Whirlpool Refrigerator Socket In Stock WPL W11447232 $5.85

WP67005956 Whirlpool Refrigerator Cover Backorder WPL WP67005956 $18.78

WPW10191117 Whirlpool Refrigerator Cover Backorder WPL WPW10191117 $14.12

COVER, RIGHT HINGE (BISCUIT) WPL 12962302Q Contact Us For Availability

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $43.15

67003900 Whirlpool Refrigerator Insert Damper In Stock WPL 67003900 $4.20

W11661170 Whirlpool Clip Backorder WPL W11661170 $6.05

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $3.22

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $59.14

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $32.35

WP400021-1 Whirlpool Screw In Stock WPL WP400021-1 $5.58

WP67003405 Whirlpool Pivot Block In Stock WPL WP67003405 $4.51

WPW10194431 Whirlpool Start Device In Stock WPL WPW10194431 $72.13

Nameplate WPL 2220214 Contact Us For Availability

PAN, DELI WPL 12802801SP Contact Us For Availability

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $9.16

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $29.16

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $45.66

WP12992902 Whirlpool Refrigerator Screw Backorder WPL WP12992902 $5.85

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $44.78

WP67001054 Whirlpool Left Glide In Stock WPL WP67001054 $4.20

14

Backorder WPL W11750607 $29.70

14

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $5.88

14

WP67001053 Whirlpool Drawer Glide In Stock WPL WP67001053 $4.53

W10917988 Whirlpool Refrigerator Door Hinge Backorder WPL W10917988 $38.56

W10918113 Whirlpool Refrigerator Door Hinge Backorder WPL W10918113 $40.66

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $50.48

W11233072 Whirlpool Screw In Stock WPL W11233072 $10.90

WP12028505AP Whirlpool Closing Cam In Stock WPL WP12028505AP $37.24

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $50.57

WPW10196393 Whirlpool Control Damper In Stock WPL WPW10196393 $108.00

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

12002355 Whirlpool Refrigerator Thermistor Ki In Stock WPL 12002355 $29.84

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $9.88

W11592374 Whirlpool Refrigerator Top Door Hin Backorder WPL W11592374 $11.56

WP67004515 Whirlpool Crisper Drawer In Stock WPL WP67004515 $90.73

12587703W Whirlpool Refrigerator Cover Backorder WPL 12587703W $16.76

67003485 Whirlpool Refrigerator Corner Cover Backorder WPL 67003485 $12.24

W11478401 Whirlpool Refrigerator Housing Backorder WPL W11478401 $101.64

WP12587703AP Whirlpool Refrigerator Filler Backorder WPL WP12587703AP $4.19

WP12642303WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12642303WD $44.43

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $4.19

COVER, CORNER (BISCUIT) WPL 12587703C Contact Us For Availability

18

WP67003854 Whirlpool Shelf Frame In Stock WPL WP67003854 $189.19

18

WPD7813010 Whirlpool Refrigerator Wire Harnes In Stock WPL WPD7813010 $38.87

18

Clip, Drain WPL W10157973 Contact Us For Availability

19

12906303WD Whirlpool Refrigerator Bracket Backorder WPL 12906303WD $54.96

19

WP67006704 Whirlpool Glass Crisper Cover In Stock WPL WP67006704 $148.30

19

WPM0114003 Whirlpool Microwave Speed Clip Cla Backorder WPL WPM0114003 $5.88

67006564 Whirlpool Refrigerator Screw Backorder WPL 67006564 $3.22

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $93.94

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $18.71

W11159728 Whirlpool Refrigerator Gasket In Stock WPL W11159728 $11.22

21

W10122551 Whirlpool Refrigerator Motor Model Backorder WPL W10122551 $226.38

21

W10211854 Whirlpool Refrigerator Back Cover Backorder WPL W10211854 $113.68

21

W10251969 Whirlpool Refrigerator Ladder Backorder WPL W10251969 $19.87

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $7.10

W10171558 Whirlpool Refrigerator Divider Backorder WPL W10171558 $43.18

WPW10534153 Whirlpool Refrigerator Black Kick In Stock WPL WPW10534153 $67.54

WPW10534154 Whirlpool Refrigerator Front Gril Backorder WPL WPW10534154 $67.15

WPW10534155 Whirlpool Refrigerator Gray Kickp In Stock WPL WPW10534155 $67.05

GRILLE, TOE (BISQUE) WPL W10244562 Contact Us For Availability

23

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $47.57

23

WP13062602 Whirlpool Refrigerator Support Backorder WPL WP13062602 $54.74

23

Dam (Left Side) WPL 12225602 Contact Us For Availability

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $8.42

W10619951 Whirlpool Drain Tube with Grommet In Stock WPL W10619951 $29.99

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $35.14

WP67001719 Whirlpool Refrigerator Track Backorder WPL WP67001719 $3.22

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $3.22

W11673433 Whirlpool Clip Backorder WPL W11673433 $69.92

WPW10171529 Whirlpool Refrigerator Ice Pan In Stock WPL WPW10171529 $59.18

Drawer, Pantry WPL 12645025 Contact Us For Availability

26

WPW10234024 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10234024 $268.70

26

Fiber, Acoustic WPL 12820505 Contact Us For Availability

26

TRIM, PANTRY WPL W10231507 Contact Us For Availability

67004556 Whirlpool Refrigerator Pantry Divide Backorder WPL 67004556 $15.55

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $17.11

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $42.36

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $42.36

Cover, Water Valve WPL 12479803 Contact Us For Availability

28

W10833902 Whirlpool Refrigerator Clamp Backorder WPL W10833902 $6.99

28

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $86.05

28

WPW10474715 Whirlpool Refrigerator Gear Backorder WPL WPW10474715 $15.11

29

W10348260 Whirlpool Refrigerator Bracket Backorder WPL W10348260 $36.65

30

W10348259 Whirlpool Refrigerator Bracket Asse Backorder WPL W10348259 $36.65

30

WP98165 Whirlpool Screw Backorder WPL WP98165 $3.46

12999501 Whirlpool Refrigerator Hinge Shim In Stock WPL 12999501 $37.05

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $65.04

W10149389 Whirlpool Refrigerator Handle Backorder WPL W10149389 $57.88

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $12.86

W11556315 Whirlpool Shroud Backorder WPL W11556315 $33.54

32

WP7101P126-60 Whirlpool Screw Backorder WPL WP7101P126-60 $3.22

32

WPW10474716 Whirlpool Refrigerator Gear Backorder WPL WPW10474716 $13.91

33

13000002WD Whirlpool Refrigerator Door Hinge Backorder WPL 13000002WD $101.91

33

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $33.34

34

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $51.03

34

W10208592 Whirlpool Refrigerator Valve Cover Backorder WPL W10208592 $56.38

35

WPL W10216614 WPL W10216614 Contact Us For Availability

100

D7824706Q Whirlpool Refrigerator Ice Maker As In Stock WPL D7824706Q $123.26

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

285006 Whirlpool Spray In Stock WPL 285006 $31.20

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.72

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.73

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.92

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.79

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $6.37

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $146.78

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $4.19

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.43

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $33.30

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $40.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $42.85

WP12868601 Whirlpool Refrigerator Wire Harnes Backorder WPL WP12868601 $49.76

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $47.27

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $70.54

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.40

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $31.24

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

CLEANER, 10 OZ. STAINLESS STEEL WPL 31462 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

KIT, EVAPORATOR REPAIR (ALUMINUM EPOXY) WPL 799833 Contact Us For Availability
