Model Whirlpool GX5FHDXVB04 REFRIGERATOR – Common Parts &amp; Diagrams

1

WP2256087 Whirlpool Refrigerator Bracket Backorder WPL WP2256087 $62.84

1

WPW10326469 Whirlpool Drawer Slide Rail In Stock WPL WPW10326469 $13.92

2

W11120581 Whirlpool Refrigerator Water Tube Backorder WPL W11120581 $76.94

2

WP12825803 Whirlpool Refrigerator Fan Blade In Stock WPL WP12825803 $62.87

2

TRIM, CRISPER WPL W10231508 Contact Us For Availability

3

OVERLAY WPL W10316011 Contact Us For Availability

3

Clamp WPL 10526702 Contact Us For Availability

4

B5759655 Whirlpool Refrigerator Gasket In Stock WPL B5759655 $11.97

4

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.46

4

Module, Control WPL 12806407 Contact Us For Availability

5

W10208592 Whirlpool Refrigerator Valve Cover Backorder WPL W10208592 $56.38

5

WP2315576 Whirlpool Water Inlet Valve In Stock WPL WP2315576 $51.57

5

WPW10128551 Whirlpool Evaporator Fan Motor In Stock WPL WPW10128551 $53.43

5

WPW10289497 Whirlpool Refrigerator Shelf Bin In Stock WPL WPW10289497 $52.84

5

Basket, Freezer (Lower) WPL W10150039 Contact Us For Availability

6

W11285509 Whirlpool Refrigerator Shut-Off Arm Backorder WPL W11285509 $81.85

6

WPW10141622 Whirlpool Leveler In Stock WPL WPW10141622 $9.63

6

WPW10233569 Whirlpool Refrigerator Tube Backorder WPL WPW10233569 $81.50

7

W10215666 Whirlpool Refrigerator Screw Backorder WPL W10215666 $8.81

7

W11260592 Whirlpool Refrigerator Wire Harness In Stock WPL W11260592 $51.49

7

W11592375 Whirlpool Door Hinge Backorder WPL W11592375 $16.49

7

WPW10289690 Whirlpool Ice Maker Cover In Stock WPL WPW10289690 $3.90

8

W11368721 Whirlpool Refrigerator French Door In Stock WPL W11368721 $124.62

8

WPA3223101 Whirlpool Refrigerator Insert PL Backorder WPL WPA3223101 $5.76

9

W10241046 Whirlpool Refrigerator Divider Backorder WPL W10241046 $19.38

9

W11351146 Whirlpool Refrigerator Handle Backorder WPL W11351146 $166.44

9

WPW10190929 Whirlpool Refrigerator Ice Maker In Stock WPL WPW10190929 $231.85

W10122561 Whirlpool Refrigerator Cup Fill In Stock WPL W10122561 $17.62

W10825088 Whirlpool Refrigerator Defrost Heat In Stock WPL W10825088 $106.65

W10847995 Whirlpool Divider Assembly Backorder WPL W10847995 $56.47

W11469652 Whirlpool Refrigerator Shield Backorder WPL W11469652 $16.76

11

W11661170 Whirlpool Clip Backorder WPL W11661170 $7.20

11

W11727809 Whirlpool Evaporator Cover Backorder WPL W11727809 $54.25

11

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $59.14

12

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $55.17

12

WPW10194431 Whirlpool Start Device In Stock WPL WPW10194431 $72.13

12

Nameplate WPL 2220214 Contact Us For Availability

12726003 Whirlpool Refrigerator Water Cover Backorder WPL 12726003 $11.90

W10121318 Whirlpool Refrigerator Grommet Backorder WPL W10121318 $44.63

WP12806701 Whirlpool Refrigerator Box Cover Backorder WPL WP12806701 $71.18

WP12992902 Whirlpool Refrigerator Screw Backorder WPL WP12992902 $7.13

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $67.76

14

Backorder WPL W11750607 $29.93

14

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $7.15

14

WPW10277025 Whirlpool Refrigerator Housing Backorder WPL WPW10277025 $86.44

15

W10918164 Whirlpool Refrigerator Door Hinge Backorder WPL W10918164 $76.61

15

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $63.53

15

CLIP, EVAP. MOTOR WPL 13058002 Contact Us For Availability

16

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.93

16

W11592374 Whirlpool Refrigerator Top Door Hin In Stock WPL W11592374 $15.68

17

WP12642303WD Whirlpool Refrigerator Drawer Su Backorder WPL WP12642303WD $70.51

17

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.76

18

WP13005401SP Whirlpool Can Rack In Stock WPL WP13005401SP $51.91

18

WPD7813010 Whirlpool Refrigerator Wire Harnes In Stock WPL WPD7813010 $38.87

18

WPW10329866 Whirlpool Frame In Stock WPL WPW10329866 $131.14

19

WPM0114003 Whirlpool Microwave Speed Clip Cla Backorder WPL WPM0114003 $7.15

19

BUCKET-CAN DISP. WPL W10169346 Contact Us For Availability

20

W10273463 Whirlpool Refrigerator Ladder Backorder WPL W10273463 $18.71

20

W11547653 Whirlpool Refrigerator Drip Tray Backorder WPL W11547653 $48.05

21

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $113.58

21

W10211854 Whirlpool Refrigerator Back Cover Backorder WPL W10211854 $116.79

21

W10251969 Whirlpool Refrigerator Ladder Backorder WPL W10251969 $19.87

22

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $7.10

22

W10171558 Whirlpool Refrigerator Divider Backorder WPL W10171558 $45.34

22

W11256565 Whirlpool Refrigerator Evaporator In Stock WPL W11256565 $200.85

23

W11176463 Whirlpool Refrigerator Water Tube In Stock WPL W11176463 $65.18

23

WP13062602 Whirlpool Refrigerator Support Backorder WPL WP13062602 $54.74

23

Dam (Left Side) WPL 12225602 Contact Us For Availability

24

12918001 Whirlpool Refrigerator Funnel Backorder WPL 12918001 $11.97

24

W11613295 Whirlpool Condenser Motor In Stock WPL W11613295 $91.82

24

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $35.14

25

W11673433 Whirlpool Clip Backorder WPL W11673433 $98.81

25

WPW10171529 Whirlpool Refrigerator Ice Pan In Stock WPL WPW10171529 $100.30

26

WPW10234024 Whirlpool Refrigerator Wire Harne Backorder WPL WPW10234024 $282.12

26

Fiber, Acoustic WPL 12820505 Contact Us For Availability

27

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $17.11

27

WPW10280608 Whirlpool Refrigerator Bracket Backorder WPL WPW10280608 $57.43

27

WPW10280613 Whirlpool Refrigerator Bracket Backorder WPL WPW10280613 $57.43

28

W11658402 Whirlpool Drawer Slide Rail In Stock WPL W11658402 $91.23

29

W10348260 Whirlpool Refrigerator Bracket Backorder WPL W10348260 $55.99

29

WPW10284684 Whirlpool Refrigerator Bracket In Stock WPL WPW10284684 $19.87

29

WPW10284685 Whirlpool Refrigerator Bracket In Stock WPL WPW10284685 $20.00

30

W10348259 Whirlpool Refrigerator Bracket Asse Backorder WPL W10348259 $56.00

12999501 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999501 $52.78

12999502 Whirlpool Refrigerator Hinge Shim Backorder WPL 12999502 $65.04

W10149389 Whirlpool Refrigerator Handle Backorder WPL W10149389 $57.88

W11028221 Whirlpool Refrigerator Shaft In Stock WPL W11028221 $17.61

W11556315 Whirlpool Shroud Backorder WPL W11556315 $43.29

32

12002497 Whirlpool Refrigerator Drawer Gear K In Stock WPL 12002497 $10.84

33

W10829281 Whirlpool Refrigerator Screw In Stock WPL W10829281 $7.90

33

W10918168 Whirlpool Refrigerator Door Hinge Backorder WPL W10918168 $48.34

33

W11173556 Whirlpool Refrigerator Shaft Backorder WPL W11173556 $17.82

34

W10157765 Whirlpool Refrigerator Deflector Backorder WPL W10157765 $57.88

37

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $34.57

38

EXTENSION-BASEPAN WPL W10206338 Contact Us For Availability

39

W10206339 Whirlpool Fastener Backorder WPL W10206339 $7.32

100

D7824706Q Whirlpool Refrigerator Ice Maker As In Stock WPL D7824706Q $125.77

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $31.99

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.72

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.73

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.92

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.79

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $16.32

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $146.78

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $5.76

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.43

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $50.33

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $81.33

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $85.33

WP12868601 Whirlpool Refrigerator Wire Harnes Backorder WPL WP12868601 $88.13

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $74.33

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $110.74

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.40

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $40.33

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

REFRIGERANT CHARGE (5.25 OZS. (R-134A)) WPL NP Contact Us For Availability
