Model Whirlpool ED26MKXRWR0 SIDE BY SIDE REFRIGERATOR – Common Parts & Diagrams
Common parts from model Whirlpool ED26MKXRWR0 SIDE BY SIDE REFRIGERATOR
1

Support, Light R.S. WPL 842355 Contact Us For Availability
1

Support, Light L.S. WPL 842356 Contact Us For Availability
1

Liner (Not A Serviceable Part) WPL ARI28255A6 Contact Us For Availability
1

Cabinet (Not A Serviceable Part) WPL ARI28254A2 Contact Us For Availability
1

Evaporator WPL 1105040 Contact Us For Availability
1

Freezer, Door Panel (Also Order Item 28) (Toa WPL 1101411 Contact Us For Availability
1

Freezer, Door Panel (Also Order Item 28) (Pla WPL 1101412 Contact Us For Availability
1

Freezer, Door Panel (Also Order Item 28) (Whi WPL 941902 Contact Us For Availability
1

Freezer, Door Panel (Also Order Item 28) (Gol WPL 941904 Contact Us For Availability
1

Freezer, Door Panel (Also Order Item 28) (Alm WPL 941906 Contact Us For Availability
2

Clip, Tubular WPL 843945 Contact Us For Availability
2

Breaker Frame, Mullion WPL 935613 Contact Us For Availability
2

Roller, Front (2) WPL 981127 Contact Us For Availability
2

Tap Plate WPL 988402 Contact Us For Availability
3

Hole, Plug WPL 659598 Contact Us For Availability
3

Mullion, Front (Toast) WPL 1101403 Contact Us For Availability
3

Mullion, Front (Platinum) WPL 1101404 Contact Us For Availability
3

Mullion, Front (White) WPL 935614 Contact Us For Availability
3

Mullion, Front (Golden Harvest) WPL 935616 Contact Us For Availability
3

Mullion, Front (Almond) WPL 935618 Contact Us For Availability
3

Screw, 5/16-24 x 1 WPL 488681 Contact Us For Availability
3

Grommet, Screw WPL 944454 Contact Us For Availability
3

Screw Anchor WPL 941242 Contact Us For Availability
4

Grommet WPL 842339 Contact Us For Availability
4

Box, Control WPL 984550 Contact Us For Availability
4

Heater, Mullion WPL 935620 Contact Us For Availability
4

Screw Anchor WPL 983604 Contact Us For Availability
4

Support, Evaporator WPL 842436 Contact Us For Availability
4

Cap, Hinge Sleeve WPL 509929 Contact Us For Availability
5

Hole, Plug WPL 519890 Contact Us For Availability
5

Bracket, Mullion WPL 935619 Contact Us For Availability
5

Hole Plug WPL 534927 Contact Us For Availability
6

Hole, Plug (Toast) WPL 1101314 Contact Us For Availability
6

Hole, Plug (Platinum) WPL 1101315 Contact Us For Availability
6

Hole, Plug (White) WPL 849391 Contact Us For Availability
6

Hole, Plug (Golden Harvest) WPL 989957 Contact Us For Availability
6

Hole Plug (Almond) WPL 989958 Contact Us For Availability
7

Control Box Front WPL 934045 Contact Us For Availability
7

Shelf Stud, Saddle WPL 937516 Contact Us For Availability
7

Shelfladder (2) WPL 934264 Contact Us For Availability
7

Hole Plug (Toast) WPL 1101316 Contact Us For Availability
7

Hole Plug (Platinum) WPL 1101317 Contact Us For Availability
7

Hole Plug (White) WPL 992770 Contact Us For Availability
7

Hole Plug (Golden Harvest) WPL 992773 Contact Us For Availability
7

Hole Plug (Almond) WPL 992774 Contact Us For Availability
7

Compress Kit (Includes Items 39, 40, 41, 42 & WPL 482614 Contact Us For Availability
8

Screw, 8 x 1-1/4 (5) WPL 488357 Contact Us For Availability
8

Shelf Stud, Saddle WPL 523264 Contact Us For Availability
8

Control Connector & Gasket Assembly WPL 848433 Contact Us For Availability
8

Hinge, Top WPL 842039 Contact Us For Availability
8

Bracket, Door Stop WPL 988420 Contact Us For Availability
9

Defrost Timer, 10 Hr. WPL 943435 Contact Us For Availability
9

Shelf, Stud WPL 529758 Contact Us For Availability
9

Screw, 8-32 x 1-1/4 WPL 488960 Contact Us For Availability
9

Screw (Repair) WPL 488980 Contact Us For Availability
9

Shim, Hinge Top WPL 992854 Contact Us For Availability
9

Heater, Defrost WPL 989607 Contact Us For Availability
9

Shim WPL 988421 Contact Us For Availability
10

Shelf Stud WPL 509108 Contact Us For Availability
10

Grommet, Wiring WPL 851020 Contact Us For Availability
10

Shelf, Stud WPL 984779 Contact Us For Availability
10

Hinge Cover (Toast) WPL 1100172 Contact Us For Availability
10

Hinge Cover (Golden Harvest) WPL 989896 Contact Us For Availability
10

Clamp, Heater WPL 938023 Contact Us For Availability
10

Screw, 89 x 1/2 WPL 488549 Contact Us For Availability
11

Shelf Stud WPL 937521 Contact Us For Availability
11

Stud, Shelf WPL 937513 Contact Us For Availability
11

Escutcheon Meat WPL 984101 Contact Us For Availability
11

Screw (Repair) WPL 488949 Contact Us For Availability
11

Retainer, Gasket Side (2) WPL 982887 Contact Us For Availability
12

Shelf Stud WPL 936591 Contact Us For Availability
12

Stud, Shelf WPL 991924 Contact Us For Availability
12

Slide, Meat Pan WPL 984102 Contact Us For Availability
12

Hinge Bottom (R.H) WPL 986763 Contact Us For Availability
12

Hinge Bottom (L.H) WPL 986764 Contact Us For Availability
12

Clamp WPL 850664 Contact Us For Availability
12

Retainer, Gasket Top & Bottom (2) WPL 983643 Contact Us For Availability
13

Shelf, Stud WPL 208500 Contact Us For Availability
13

Stud, Shelf WPL 936958 Contact Us For Availability
13

Pad, Foam WPL 992358 Contact Us For Availability
13

Shield, Evaporator (4) WPL 989200 Contact Us For Availability
13

Door Gasket, Magnetic WPL 939342 Contact Us For Availability
14

Expansion Clip WPL 537095 Contact Us For Availability
14

Shelf, Stud WPL 936957 Contact Us For Availability
14

Stud Light Lens (L.S.) WPL 935982 Contact Us For Availability
14

Baffle, Air WPL 851167 Contact Us For Availability
15

Knob, Temperature Control WPL 836482 Contact Us For Availability
15

Shelf Stud WPL 521878 Contact Us For Availability
15

Screw 8-15 x 1/2 WPL 486214 Contact Us For Availability
15

Stud, Light Lens (R.S.) WPL 935243 Contact Us For Availability
15

Shim, Bottom Hinge WPL 836196 Contact Us For Availability
15

Handle, Center WPL 1108897 Contact Us For Availability
15

Handle, Center (For Platinum Model Only) WPL 1108914 Contact Us For Availability
16

Shim, Door Closer WPL 987179 Contact Us For Availability
16

Duct, Air WPL 983651 Contact Us For Availability
16

Shelf, Stud WPL 536410 Contact Us For Availability
16

Track, Divider (Top) WPL 988458 Contact Us For Availability
16

Shelf, Cantilever WPL 936787 Contact Us For Availability
16

Blade, Fan WPL 989524 Contact Us For Availability
16

Center End Cap (2) WPL 935103 Contact Us For Availability
17

Baffle, Air WPL 946697 Contact Us For Availability
17

Track, Divider (Back & Bottom) WPL 1103303 Contact Us For Availability
17

Trim Shelf Cantilever WPL 849021 Contact Us For Availability
17

Tap Plate WPL 836162 Contact Us For Availability
17

Relay WPL 1101014 Contact Us For Availability
17

Shim, Center End Cap (2) WPL 935075 Contact Us For Availability
18

Air Deflector Freezer WPL 983652 Contact Us For Availability
18

Track, Shelf (R.S.) WPL 837554 Contact Us For Availability
18

Track, Shelf (L.S.) WPL 837557 Contact Us For Availability
18

Glass, Cantilever Shelf WPL 1108782 Contact Us For Availability
18

Grille, Exterior (Toast) WPL 1101407 Contact Us For Availability
18

Grille, Exterior (Platinum) WPL 1101408 Contact Us For Availability
18

Grille, Exterior (White) WPL 944263 Contact Us For Availability
18

Grille, Exterior (Golden Harvest) WPL 944265 Contact Us For Availability
18

Grille, Exterior (Almond) WPL 944267 Contact Us For Availability
19

Retainer Bracket, Divider WPL 935666 Contact Us For Availability
19

Reflector, Cantilever Shelf WPL 849028 Contact Us For Availability
19

Bracket WPL 548695 Contact Us For Availability
19

Insert, Handle (Bottom) (White) WPL 1108903 Contact Us For Availability
19

Insert, Handle (Bottom) (Golden Wheat) WPL 1108904 Contact Us For Availability
19

Insert, Handle (Bottom) (Almond) WPL 1108905 Contact Us For Availability
19

Insert, Handle (Bottom) (Toast) WPL 1108906 Contact Us For Availability
19

Insert, Handle (Bottom) (Platinum) WPL 1108907 Contact Us For Availability
20

Blade, Fan WPL 992920 Contact Us For Availability
20

Solid Shelf WPL 986557 Contact Us For Availability
20

Screw, 8-22 x 5/16 WPL 489085 Contact Us For Availability
20

Insert, Handle (Top) (White) WPL 1108922 Contact Us For Availability
20

Insert Handle (Top) (Golden Wheat) WPL 1108923 Contact Us For Availability
20

Insert, Handle (Top) (Almond) WPL 1108924 Contact Us For Availability
20

Insert, Handle (Top) (Toast) WPL 1108925 Contact Us For Availability
20

Insert, Handle (Top) (Platinum) WPL 1108926 Contact Us For Availability
21

Trim, Shelf WPL 986437 Contact Us For Availability
21

Divider, Mullion WPL 1103360 Contact Us For Availability
21

Bumper, Grille WPL 546131 Contact Us For Availability
21

Retainer Insert WPL 941262 Contact Us For Availability
22

Fan, Bracket Double WPL 548263 Contact Us For Availability
22

Trim Shelf, Front WPL 985542 Contact Us For Availability
22

Retainer, Hole Insert WPL 843888 Contact Us For Availability
22

Clip, Grille WPL 989068 Contact Us For Availability
22

Box, Junction WPL 850482 Contact Us For Availability
22

Retainer Insert WPL 941297 Contact Us For Availability
23

Fan Bracket, Single WPL 938224 Contact Us For Availability
23

Wire Shelf WPL 935495 Contact Us For Availability
23

Insert, Hole WPL 843887 Contact Us For Availability
23

End Cap (2) WPL 941259 Contact Us For Availability
24

Screw, Ground WPL 488474 Contact Us For Availability
24

Fan, Grommet WPL 548268 Contact Us For Availability
24

Reflector, Shelf WPL 935496 Contact Us For Availability
24

Pan Slide & Cover WPL 1101202 Contact Us For Availability
24

Screw, 10-32 x 5/8 WPL 489075 Contact Us For Availability
25

Interior Panel WPL 988620 Contact Us For Availability
25

Screw Grommet WPL 538449 Contact Us For Availability
25

Reflector, Clip WPL 939348 Contact Us For Availability
25

Pan Slide & Cover WPL 1108778 Contact Us For Availability
25

Wire Connector WPL 227991 Contact Us For Availability
25

Interior Panel WPL 1101416 Contact Us For Availability
26

Trim, Door Shelf WPL 1108919 Contact Us For Availability
26

Scroll Fan WPL 983650 Contact Us For Availability
26

Wire Shelf WPL 943996 Contact Us For Availability
26

Shield, Divider WPL 987054 Contact Us For Availability
26

Crisper Gasket Rear WPL 982588 Contact Us For Availability
26

Water Inlet Tube WPL 983656 Contact Us For Availability
26

Cord, Service WPL 850626 Contact Us For Availability
26

Trim, Door WPL 1108964 Contact Us For Availability
27

Support, Trim WPL 849223 Contact Us For Availability
27

Air Scoop Assembly WPL 841269 Contact Us For Availability
27

Breaker, Trim Top Refrigerator WPL 992041 Contact Us For Availability
27

Crisper Gasket Front WPL 982587 Contact Us For Availability
28

WPL 876029 WPL 876029 Contact Us For Availability
28

Gasket, Air Scoop WPL 844871 Contact Us For Availability
28

Shelf Stud (L.S.) WPL 836492 Contact Us For Availability
28

Breaker, Trim Refrigerator Side WPL 935637 Contact Us For Availability
28

Pan Crisper WPL 943112 Contact Us For Availability
28

Wire Assembly (Water Valve) WPL 548734 Contact Us For Availability
29

Trim, Door Shelf WPL 1108918 Contact Us For Availability
29

Retainer, Damper WPL 938439 Contact Us For Availability
29

Breaker, Trim Refrigerator Bottom WPL 992044 Contact Us For Availability
29

Housing, Humidity Control WPL 942234 Contact Us For Availability
29

Drain Fitting, Liner WPL 982904 Contact Us For Availability
29

Tray, Evaporator WPL 982899 Contact Us For Availability
30

Control Knob WPL 837445 Contact Us For Availability
30

Basket, Freezer WPL 935499 Contact Us For Availability
30

Breaker Retainer WPL 836090 Contact Us For Availability
30

Slide, Humidity Control WPL 942235 Contact Us For Availability
30

Extension, Drain Fitting WPL 841646 Contact Us For Availability
30

Screw, 8-15 x 3/8 WPL 488978 Contact Us For Availability
31

WPL 1108721 WPL 1108721 Contact Us For Availability
31

Knob, Retainer WPL 837444 Contact Us For Availability
31

Trim, Basket WPL 985546 Contact Us For Availability
31

Breaker Trim, Clip WPL 838849 Contact Us For Availability
31

Seal, Humidity Control WPL 942236 Contact Us For Availability
31

Clip, Drain Fitting WPL 841648 Contact Us For Availability
31

Overload WPL 1105018 Contact Us For Availability
32

WPL 983804 WPL 983804 Contact Us For Availability
32

Evaporator, Cover WPL 1101038 Contact Us For Availability
32

Trim, Freezer Breaker (Top) WPL 992046 Contact Us For Availability
32

Screw, 6-19 x 7/16 WPL 489041 Contact Us For Availability
32

Clip, Wire (2) WPL 548745 Contact Us For Availability
33

Grommet WPL 848445 Contact Us For Availability
33

Light Lens, Freezer WPL 985539 Contact Us For Availability
33

Breaker, Trim Freezer Side WPL 935643 Contact Us For Availability
33

Front Cover, Crisper WPL 1108777 Contact Us For Availability
33

Insert, Air Baffle WPL 836372 Contact Us For Availability
34

Baffle, Liner Top WPL 983369 Contact Us For Availability
34

Breaker Trim, Freezer (Bottom) WPL 939829 Contact Us For Availability
34

Screw (Repair) WPL 488132 Contact Us For Availability
34

C WPL 851174 Contact Us For Availability
34

Overload Spring WPL 943320 Contact Us For Availability
35

WPL 1110077 WPL 1110077 Contact Us For Availability
35

WPL 945116 WPL 945116 Contact Us For Availability
35

Gasket, Evaporator Cover WPL 983649 Contact Us For Availability
35

Breaker, Trim Clip Bottom WPL 937668 Contact Us For Availability
35

Overlay, Pan Front WPL 984750 Contact Us For Availability
35

Frame Assembly WPL 945484 Contact Us For Availability
36

Gasket, Evaporator Cover Top WPL 987178 Contact Us For Availability
36

Receptacle Cap WPL 850738 Contact Us For Availability
36

Pan, Meats WPL 840037 Contact Us For Availability
36

Clip (2) WPL 548744 Contact Us For Availability
37

WPL 1108920 WPL 1108920 Contact Us For Availability
37

Air Diffuser Assembly WPL 946145 Contact Us For Availability
37

Front Cover, Meat Pan WPL 1108780 Contact Us For Availability
37

Terminal Cover WPL 1105055 Contact Us For Availability
38

Gasket, Air Diffuser WPL 842394 Contact Us For Availability
38

Heater, Stile WPL 934475 Contact Us For Availability
38

Terminal Cover Strap WPL 943322 Contact Us For Availability
39

Retainer Clip, Heater WPL 937205 Contact Us For Availability
39

Light Lens, Refrigerator WPL 943218 Contact Us For Availability
39

Spring WPL 549342 Contact Us For Availability
40

Wiring Assembly Ice Maker WPL 481658 Contact Us For Availability
40

Light Lens, Crisper WPL 935898 Contact Us For Availability
40

Case, Relay WPL 549505 Contact Us For Availability
41

Pan, Drain WPL 934121 Contact Us For Availability
41

Support Light Lens, Refrigerator WPL 984552 Contact Us For Availability
41

Overload Spring WPL 549086 Contact Us For Availability
42

Fitting, Drain Pan WPL 836088 Contact Us For Availability
42

Relay WPL 989509 Contact Us For Availability
43

Gasket, Drain Pan WPL 934130 Contact Us For Availability
43

Overload WPL 753526 Contact Us For Availability
44

Cap, Drain WPL 842259 Contact Us For Availability
44

Clamp WPL 548508 Contact Us For Availability
45

Cover, Heat Exchanger WPL 1103312 Contact Us For Availability
46

Heat Exchanger, Clip WPL 983605 Contact Us For Availability
46

Condenser Assembly WPL 945525 Contact Us For Availability
47

Wiring Assembly (Defrost Timer) WPL 481782 Contact Us For Availability
47

Clamp (4) WPL 548738 Contact Us For Availability
48

Grommet (4) WPL 943447 Contact Us For Availability
50

Screw Grommet WPL 509812 Contact Us For Availability
52

Exchanger, Heat WPL 1105019 Contact Us For Availability
54

Clamp (2) WPL 510716 Contact Us For Availability
55

Dampener (2) WPL 510769 Contact Us For Availability
56

Pan, Drip WPL 945572 Contact Us For Availability
57

Screw, 1/4-28 x 1/2 (2) WPL 488454 Contact Us For Availability
58

Strap WPL 851095 Contact Us For Availability
59

Rail, Front WPL 851177 Contact Us For Availability
64

Guard, Fan WPL 851165 Contact Us For Availability
65

WPL 978029 WPL 978029 Contact Us For Availability
65

WPL 479502 WPL 479502 Contact Us For Availability
65

WPL 799344 WPL 799344 Contact Us For Availability
65

WPL 488624 WPL 488624 Contact Us For Availability
65

Enamel, Gold (1 Qt. Uncut) WPL 261891 Contact Us For Availability
65

En WPL 285367 Contact Us For Availability
65

WPL 285368 WPL 285368 Contact Us For Availability
65

WPL 542639 WPL 542639 Contact Us For Availability
65

WPL 72112 WPL 72112 Contact Us For Availability
65

WPL 799832 WPL 799832 Contact Us For Availability
65

WPL 799833 WPL 799833 Contact Us For Availability
65

WPL 799908 WPL 799908 Contact Us For Availability
65

WPL 978028 WPL 978028 Contact Us For Availability
65

WPL 978883 WPL 978883 Contact Us For Availability
× ![]()
