Model Whirlpool AGR5844VDS0 GAS RANGE – Common Parts &amp; Diagrams

1

W11219370 Whirlpool Endcap Panel Backorder WPL W11219370 $38.94

1

W11219664 Whirlpool Endcap Panel In Stock WPL W11219664 $135.83

1

W11219665 Whirlpool Panel Endcap Backorder WPL W11219665 $22.68

1

W11457094 Whirlpool Range Flue Backorder WPL W11457094 $106.62

1

Screw, Valve WPL 8273096 Contact Us For Availability

2

8053505 Whirlpool Range Shield Backorder WPL 8053505 $114.33

2

WPW10169975 Whirlpool Burner Cap Backorder WPL WPW10169975 $47.28

2

WPW10169984 Whirlpool Burner Cap Backorder WPL WPW10169984 $52.22

2

WPW10169985 Whirlpool Burner Cap Backorder WPL WPW10169985 $48.52

2

WPW10173832 Whirlpool Burner Cap Backorder WPL WPW10173832 $53.18

2

WPW10200660 Whirlpool Range Oven Door Handle In Stock WPL WPW10200660 $5.30

2

Cap, Burner R. Front, L. Rear (Grey) WPL W10169974 Contact Us For Availability

2

Cap, Burner Left Front (Black) WPL W10173833 Contact Us For Availability

3

Handle, Door (Black) WPL W10144889 Contact Us For Availability

3

Handle, Door (White) WPL W10144888 Contact Us For Availability

3

Tubing, Burner W/Orifice (Right Front) WPL W10177323 Contact Us For Availability

3

Handle, Door (Stainless Model) WPL W10144890 Contact Us For Availability

4

WP3196813 Whirlpool Rivet Backorder WPL WP3196813 $6.64

4

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $6.64

4

WP9761344 Whirlpool Door Liner In Stock WPL WP9761344 $244.75

4

Tubing (Manifold to Regulator) WPL W10157928 Contact Us For Availability

5

8523249 Whirlpool Range Support Bracket Backorder WPL 8523249 $55.16

5

8523855 Whirlpool Range Manifold Panel Backorder WPL 8523855 $117.32

5

W11230486 Whirlpool Drawer Panel Backorder WPL W11230486 $137.05

5

W11230490 Whirlpool Drawer Panel Backorder WPL W11230490 $137.05

5

WP8523854 Whirlpool Manifold Panel Backorder WPL WP8523854 $197.47

5

WPW10031790 Whirlpool Screw In Stock WPL WPW10031790 $5.30

5

WPW10295998 Whirlpool Wire Harness Backorder WPL WPW10295998 $159.08

6

W11190817 Whirlpool Knob Assembly In Stock WPL W11190817 $59.02

6

WP8053334 Whirlpool Drawer Glide In Stock WPL WP8053334 $5.30

6

WPW10163287 Whirlpool Knob Backorder WPL WPW10163287 $15.95

6

WPW10216419 Whirlpool Surface Igniter In Stock WPL WPW10216419 $25.77

7

W10198745 Whirlpool Rear Cover Backorder WPL W10198745 $90.90

7

WP3196037 Whirlpool Leveling Foot Backorder WPL WP3196037 $57.82

8

WP9757218 Whirlpool Burner Valve Backorder WPL WP9757218 $214.83

8

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $4.56

8

VALVE(RIGHT REAR) WPL 8273004 Contact Us For Availability

9

WP3195097 Whirlpool Range Bottom In Stock WPL WP3195097 $102.28

9

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $5.30

9

Cover, Back WPL W10184370 Contact Us For Availability

10

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $5.30

10

WPW10181986 Whirlpool Range Sensor In Stock WPL WPW10181986 $80.94

8053967 Whirlpool Range Heat Baffle Backorder WPL 8053967 $215.43

WP9781235 Whirlpool Clip Backorder WPL WP9781235 $7.80

WPW10118454 Whirlpool Range Outer Door Glass In Stock WPL WPW10118454 $258.96

WPW10118455 Whirlpool Door Glass Assembly In Stock WPL WPW10118455 $227.76

12

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $168.34

12

WP8523166 Whirlpool Door Trim In Stock WPL WP8523166 $58.02

12

WP8523172 Whirlpool Left Door Trim In Stock WPL WP8523172 $58.01

13

Spreader, Flame (Oven) WPL 8053970 Contact Us For Availability

14

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $5.02

14

WP9758078 Whirlpool Range Burner In Stock WPL WP9758078 $118.54

15

Seal, Oven Flange WPL W10008830 Contact Us For Availability

16

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $37.66

16

WP8054129 Whirlpool Range Igniter In Stock WPL WP8054129 $88.30

16

WP9758079 Whirlpool Range Igniter In Stock WPL WP9758079 $35.87

W11594186 Whirlpool Door Trim In Stock WPL W11594186 $38.40

WP8523177 Whirlpool Door Trim Assembly In Stock WPL WP8523177 $72.46

Tubing (Broiler Fitting To Valve) WPL 8272222 Contact Us For Availability

Back, Main WPL W10222733 Contact Us For Availability

Trim, Bottom (Universal Silver) WPL W10067550 Contact Us For Availability

18

Fitting, Broiler WPL 3186489 Contact Us For Availability

19

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $4.82

9761448 Whirlpool Range Retainer Backorder WPL 9761448 $231.01

9761449 Whirlpool Range Retainer Backorder WPL 9761449 $231.01

W10178934 Whirlpool Orifice Assembly Backorder WPL W10178934 $75.41

WPW10170506 Whirlpool Orifice Spud Backorder WPL WPW10170506 $68.82

WPW10170508 Whirlpool Orifice Spud Backorder WPL WPW10170508 $70.60

21

W10137062 Whirlpool Burner Baffle Backorder WPL W10137062 $177.71

21

W10137382 Whirlpool Clip Backorder WPL W10137382 $33.85

22

3196265 Whirlpool Range Screw Backorder WPL 3196265 $8.89

22

W11582239 Whirlpool Range Power Cord Backorder WPL W11582239 $9.90

24

W11684507 Whirlpool Screw In Stock WPL W11684507 $13.02

24

WP9757262 Whirlpool Light Switch In Stock WPL WP9757262 $81.22

27

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $180.29

28

W10078370 Whirlpool Latch Rod Backorder WPL W10078370 $64.29

29

WPW10107820 Whirlpool Door Latch In Stock WPL WPW10107820 $138.48

30

WPW10114344 Whirlpool Drawer Glide In Stock WPL WPW10114344 $5.30

32

W11169708 Whirlpool Screw Backorder WPL W11169708 $8.89

34

SCREW WPL 3196152 Contact Us For Availability

35

3196166 Whirlpool Screw Backorder WPL 3196166 $4.67

40

9757239 Whirlpool Oven Door Rod Backorder WPL 9757239 $67.22

285006 Whirlpool Spray In Stock WPL 285006 $52.65

350930 Whirlpool White Spray Paint In Stock WPL 350930 $30.02

4396923 Whirlpool Broil Pan Set Gray Porcelai In Stock WPL 4396923 $39.84

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $19.58

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $21.50

W10045060 Whirlpool Grounding Wire Backorder WPL W10045060 $5.46

W11244557 Whirlpool Screw Backorder WPL W11244557 $8.89

W11447673 Whirlpool Range Tip Anchor In Stock WPL W11447673 $19.74

W11684915 Whirlpool Insulation Backorder WPL W11684915 $81.75

WP3196174 Whirlpool Screw Backorder WPL WP3196174 $4.82

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $60.66

Spuds, LP Gas (Kit of 4) WPL 8523418 Contact Us For Availability

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

PAINT, BULK (1 QT.) (WHITE UNCUT) WPL 799344 Contact Us For Availability

WPL W10182840 WPL W10182840 Contact Us For Availability
