Model Whirlpool 665.62612300 Microwave – Common Parts &amp; Diagrams

1

Reflector, Lamp WPL 4393688 Contact Us For Availability

1

Deflector, Air WPL 8185096 Contact Us For Availability

1

Cover, Inlet WPL 8185117 Contact Us For Availability

2

W10315274 Whirlpool Microwave Meal Rack Backorder WPL W10315274 $33.69

2

Frame, Inner WPL 8169545 Contact Us For Availability

2

Socket, Motor Wire WPL 8185097 Contact Us For Availability

3

8206444A Whirlpool Microwave Charcoal Filter In Stock WPL 8206444A $13.99

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $44.61

3

Latch, Door WPL 4393913 Contact Us For Availability

3

Base Plate WPL 8185116 Contact Us For Availability

3

Nail, Plastic WPL 4393291 Contact Us For Availability

4

Turntable WPL 4393799 No Longer Available

4

6802A Whirlpool Grease Filter In Stock WPL 6802A $18.42

4

Air Guide (Right) WPL 8185098 Contact Us For Availability

5

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $36.06

5

Plate, Bottom WPL 8185105 Contact Us For Availability

5

Thermostat WPL 4393945 Contact Us For Availability

6

W10708076 Whirlpool Microwave Power Cord In Stock WPL W10708076 $7.81

6

Frame, Outer — White WPL 8185110 Contact Us For Availability

6

Wheel, Plastic WPL 4393861 Contact Us For Availability

6

Glass, Lamp WPL 8169564 Contact Us For Availability

6

Deflector, Cooling Air WPL 8185099 Contact Us For Availability

7

4393777 Whirlpool Microwave Door Handle - Whi Backorder WPL 4393777 $61.92

7

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $6.34

7

W10435116 Whirlpool Microwave Turntable Rolle In Stock WPL W10435116 $23.67

7

Handle, Door — Bisque WPL 8169642 Contact Us For Availability

7

Holder, Glass WPL 8184308 Contact Us For Availability

7

Case, Outer — White WPL 8185091 Contact Us For Availability

7

Case, Outer — Bisque WPL 8185092 Contact Us For Availability

7

Case, Outer — Black WPL 8185093 Contact Us For Availability

8

8183851 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183851 $45.02

8

8183852 Whirlpool Microwave Primary Vent Gril In Stock WPL 8183852 $56.93

8

8183948 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183948 $52.05

8

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $73.80

8

TCO, Bracket Assembly WPL 8184586 Contact Us For Availability

8

Cooling Air Guide WPL 8185103 Contact Us For Availability

9

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $4.82

9

8206334 Whirlpool Microwave Mounting Bracket In Stock WPL 8206334 $5.54

9

Motor, Fan WPL 8184825 Contact Us For Availability

9

Cover, Terminal WPL 4393756 Contact Us For Availability

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $40.52

W10844213 Whirlpool Microwave Magnetron Backorder WPL W10844213 $234.74

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $4.82

Shield WPL 8185101 Contact Us For Availability

11

Spring, Interlock (2) WPL 8169438 Contact Us For Availability

11

Air Guide, Sealing Plate WPL 8185114 Contact Us For Availability

11

Thermostat WPL 8184829 Contact Us For Availability

12

Plate, Cam (2) WPL 8183824 Contact Us For Availability

12

Rack, Cooking WPL 8183813 Contact Us For Availability

12

Screw WPL 4393828 Contact Us For Availability

8205572 Whirlpool Microwave Interlock In Stock WPL 8205572 $4.82

Screw WPL 8169474 Contact Us For Availability

Screw WPL 4393838 Contact Us For Availability

Rod WPL 8169318 Contact Us For Availability

14

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $4.99

14

Screw WPL 8169478 Contact Us For Availability

14

Latch Pivot WPL 8169319 Contact Us For Availability

15

Screw WPL 4393833 Contact Us For Availability

15

Screw WPL 4393830 Contact Us For Availability

15

E−Ring WPL 8169320 Contact Us For Availability

16

Air Guide (Left) WPL 8185115 Contact Us For Availability

16

Bushing, Nail For Models: 665.62612200, 665.6 WPL 4393290 Contact Us For Availability

16

Catch WPL 8185033 Contact Us For Availability

17

Chassis WPL 8185104 Contact Us For Availability

17

Cover, Light WPL 8185118 Contact Us For Availability

17

Spring WPL 8169374 Contact Us For Availability

WP8169704 Whirlpool Screw In Stock WPL WP8169704 $6.10

Holder, Lamp For Models: 665.62612200, 665.62 WPL 8169539 Contact Us For Availability

Holder, Capacitor WPL 8185102 Contact Us For Availability

Cover, Motor Miscellaneous WPL 8185090 Contact Us For Availability

Installation, Hardware WPL 8169659 Contact Us For Availability

Upper Template WPL 8184731 Contact Us For Availability

Wall Template For Models: 665.62612200, 665.6 WPL 8183743 Contact Us For Availability

19

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $19.71

20

W10850446 Whirlpool Microwave Magnetron Capac In Stock WPL W10850446 $123.23

21

Transformer, H.V. WPL 8184826 Contact Us For Availability

23

W10269458 Whirlpool Microwave Door Switch In Stock WPL W10269458 $18.29

24

W10211974 Whirlpool Microwave Door Interlock In Stock WPL W10211974 $41.89

25

Bracket, Right WPL 8185100 Contact Us For Availability

26

Capacitor WPL 8184091 Contact Us For Availability

27

Holder, Fuse WPL 8184312 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $35.86

29

Thermostat WPL 4393710 Contact Us For Availability

32

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $15.81

36

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $6.28

37

Screw For Models: 665.62612200, 665.62614200, WPL 4393839 Contact Us For Availability
