Model Samsung RF24FSEDBSR/AA-00 Refrigerator – Common Parts &amp; Diagrams

1

DA96-00631C Samsung Refrigerator Evaporator A Backorder SMG DA96-00631C $254.75

1

DA97-12522S Samsung Refrigerator Gasket Assem Backorder SMG DA97-12522S $155.80

1

Refrigerator Door Assembly SMG DA97-13797A Contact Us For Availability

1-1

DA34-00043A Samsung Refrigerator Switch Reed- Backorder SMG DA34-00043A $31.86

1-2

Refrigerator LED Light SMG DA41-00676G Contact Us For Availability

1-3

DA61-08227A Samsung Refrigerator Hinge Cover Backorder SMG DA61-08227A $18.64

1-4

DA64-04477B Samsung Refrigerator Table Top As Backorder SMG DA64-04477B $78.89

1-5

DA47-00318A Samsung Refrigerator Metal Sheath Backorder SMG DA47-00318A $147.30

1-5

DA96-00962A Samsung Refrigerator Reed Switch Backorder SMG DA96-00962A $20.23

1-6

DA61-05845A Samsung Refrigerator Heater Fixer Backorder SMG DA61-05845A $9.59

1-7

DA61-06182A Samsung Refrigerator Freezer Sens Backorder SMG DA61-06182A $10.11

2

DA61-03769A Samsung Refrigerator Door Magnet In Stock SMG DA61-03769A $3.07

2

DA97-08434E Samsung Refrigerator Evaporator C Backorder SMG DA97-08434E $184.03

2

DA97-12522Q Samsung Refrigerator Middle Gaske Backorder SMG DA97-12522Q $139.63

2

DA97-12573A Samsung Refrigerator Upper Left H In Stock SMG DA97-12573A $77.03

2-1

DA61-08309A Samsung Refrigerator Door Hinge A Backorder SMG DA61-08309A $59.18

2-1

Refrigerator Evaporator Fan Blade SMG DA31-00124A Contact Us For Availability

2-2

DA31-00146H Samsung Refrigerator Freezer Evap In Stock SMG DA31-00146H $133.46

2-2

DA63-50192A Samsung Refrigerator Upper Hinge Backorder SMG DA63-50192A $1.60

2-3

DA66-00950A Samsung Refrigerator Left Auto Cl Backorder SMG DA66-00950A $5.04

2-7

DA96-00042D Samsung Refrigerator Motor Harnes Backorder SMG DA96-00042D $21.29

3

DA61-04285A Samsung Refrigerator French Guide Backorder SMG DA61-04285A $6.15

3

DA97-08608A Samsung Refrigerator Sensor Cover Backorder SMG DA97-08608A $32.41

3

DA97-12574A Samsung Refrigerator Upper Right Backorder SMG DA97-12574A $88.64

3

Refrigerator door handle SMG DA97-12714C Contact Us For Availability

3-1

DA63-05470B Samsung Refrigerator Sensor Cover Backorder SMG DA63-05470B $5.04

3-2

DA32-00033C Samsung Refrigerator Temperature In Stock SMG DA32-00033C $26.43

3-3

DA66-00951A Samsung Refrigerator Auto Close D Backorder SMG DA66-00951A $5.04

4

DA63-05630A Samsung Refrigerator Control Cove Backorder SMG DA63-05630A $12.78

4

DA97-13947A Samsung Refrigerator Middle Left Backorder SMG DA97-13947A $123.87

4

Refrigerator Freezer Upper Tray SMG DA97-13773A Contact Us For Availability

4-3

DA61-04154A Samsung Refrigerator Upper Freeze Backorder SMG DA61-04154A $9.50

4-4

DA66-00554A Samsung Refrigerator Upper Freeze Backorder SMG DA66-00554A $5.59

4-5

DA71-20277A Samsung Refrigerator Fixer-Roller Backorder SMG DA71-20277A $1.60

5

DA97-12684D Samsung Refrigerator French Door In Stock SMG DA97-12684D $202.16

5

DA97-13015C Samsung Refrigerator Gray Door Ga In Stock SMG DA97-13015C $123.55

5

DA97-13774A Samsung Refrigerator Lower Tray A Backorder SMG DA97-13774A $156.46

5

DA97-13793A Samsung Refrigerator Middle Right Backorder SMG DA97-13793A $122.51

5-3

DA61-08305A Samsung Refrigerator French Door In Stock SMG DA61-08305A $6.77

5-4

DA67-01650A Samsung Refrigerator French End C Backorder SMG DA67-01650A $5.04

5-5

DA63-03454B Samsung Refrigerator Center Hinge Backorder SMG DA63-03454B $8.38

5-6

DA67-01701A Samsung Refrigerator Cap Case Fre Backorder SMG DA67-01701A $5.33

6

DA97-13805A Samsung Refrigerator Door Shelf B Backorder SMG DA97-13805A $124.24

6

DA97-25147B Samsung Assy Cover Housing;fdr, C Backorder SMG DA97-25147B $46.24

6

Refrigerator door handle SMG DA97-12715C Contact Us For Availability

6-1

DA61-07972B Samsung Refrigerator Black Front In Stock SMG DA61-07972B $9.22

6-1

DA61-08228A Samsung Refrigerator Handle Suppo Backorder SMG DA61-08228A $12.30

6-2

DA61-04702A Samsung Refrigerator Front Caster In Stock SMG DA61-04702A $7.99

6-2

DA61-08246A Samsung Refrigerator Upper Handle Backorder SMG DA61-08246A $27.95

6-4

DA67-02788A Samsung Refrigerator Handle Suppo Backorder SMG DA67-02788A $14.53

6-6

DA61-07973B Samsung Refrigerator Black Rear F Backorder SMG DA61-07973B $2.79

6-7

DA97-13807A Samsung Refrigerator Front Suppor Backorder SMG DA97-13807A $46.69

7

DA97-13818A Samsung Refrigerator Middle Bin G Backorder SMG DA97-13818A $111.07

7

Refrigerator door hinge, right SMG DA97-13828A Contact Us For Availability

7-1

DA61-04703A Samsung Refrigerator Rear Caster In Stock SMG DA61-04703A $6.77

7-1

DA61-09173A Samsung Refrigerator Right Door S Backorder SMG DA61-09173A $17.04

7-2

DA66-00649A Samsung Refrigerator Caster Shaft Backorder SMG DA66-00649A $3.97

8

DA61-04335A Samsung Refrigerator Handle Sprin Backorder SMG DA61-04335A $1.50

8

DA97-13804A Samsung Refrigerator Guard Assemb Backorder SMG DA97-13804A $136.02

8-1

DA61-03166A Samsung Refrigerator Vegetable Co In Stock SMG DA61-03166A $1.69

8-1

DA63-06897A Samsung Refrigerator Drain Water Backorder SMG DA63-06897A $34.57

8-1

DA66-00437F Samsung Gear Shaft Refrigerator Backorder SMG DA66-00437F $64.13

8-2

DA61-04292A Samsung Refrigerator Vegetable Re Backorder SMG DA61-04292A $166.73

8-3

DA61-03154A Samsung Refrigerator Gear Fixer Backorder SMG DA61-03154A $1.69

8-3

Refrigerator Condenser Coil SMG DA97-08464F Contact Us For Availability

8-4

DA66-00718A Samsung Refrigerator Humidity Lev Backorder SMG DA66-00718A $6.39

8-5

DA97-13386A Samsung Refrigerator Roller Assem Backorder SMG DA97-13386A $13.11

8-7

DA61-08818A Samsung Refrigerator Low Slide Ra Backorder SMG DA61-08818A $198.91

8-8

DA61-08819A Samsung Refrigerator Low Slide Ra Backorder SMG DA61-08819A $170.37

8-11

DA61-02738A Samsung Refrigerator Magnet-Assem Backorder SMG DA61-02738A $6.71

8-41

Refrigerator Condenser Fan Motor SMG DA31-00305C Contact Us For Availability

8-42

DA31-00320A Samsung Refrigerator Fan Blade As Backorder SMG DA31-00320A $26.26

8-43

DA61-08427A Samsung Refrigerator Motor Circui Backorder SMG DA61-08427A $22.89

9

DA61-11161A Samsung Refrigerator Door Handle In Stock SMG DA61-11161A $6.77

9

DA97-13809B Samsung Refrigerator Dispenser Co Backorder SMG DA97-13809B $359.41

9-2

DA63-06377A Samsung Refrigerator Rear PCB Cov Backorder SMG DA63-06377A $11.70

9-41

DA34-00011B Samsung Refrigerator Micro Switch Backorder SMG DA34-00011B $17.88

10

DA97-13829C Samsung Refrigerator Ice Route Gu In Stock SMG DA97-13829C $148.84

10

MKV190CL2B/ASH Samsung Refrigerator Compresso In Stock SMG MKV190CL2B/ASH $334.64

10-1

DA31-00079D Samsung Refrigerator Geared Dispe Backorder SMG DA31-00079D $99.68

10-3

DA61-09161A Samsung Refrigerator Left Vegetab Backorder SMG DA61-09161A $122.51

10-4

DA63-07552A Samsung Refrigerator Left Front V Backorder SMG DA63-07552A $50.23

10-5

DA97-05368A Samsung Refrigerator Ice Route Co Backorder SMG DA97-05368A $54.71

11

DA97-10848N Samsung Refrigerator All Wire Com Backorder SMG DA97-10848N $82.59

11

DA97-13819A Samsung Refrigerator Lower Door S Backorder SMG DA97-13819A $96.53

11-1

DA34-00004D Samsung Refrigerator Compressor O In Stock SMG DA34-00004D $35.00

11-2

DA39-00154M Samsung Refrigerator Compressor W Backorder SMG DA39-00154M $25.10

DA41-00519Q Samsung Refrigerator LED Lamp PBA Backorder SMG DA41-00519Q $26.25

DA61-06658A Samsung Refrigerator Reinforcemen In Stock SMG DA61-06658A $3.74

DA63-01866A Samsung Refrigerator Compressor O Backorder SMG DA63-01866A $14.90

DA63-05506A Samsung Assembly Refrigerator Dis In Stock SMG DA63-05506A $32.97

12-1

DA41-00519S Samsung Refrigerator LED Lamp PCB Backorder SMG DA41-00519S $63.71

12-2

DA62-03103A Samsung Refrigerator Gray Tube Fi Backorder SMG DA62-03103A $22.92

12-3

DA62-04027A Samsung Refrigerator 2-Way Water In Stock SMG DA62-04027A $175.15

DA61-08234A Samsung Refrigerator Slider Assem Backorder SMG DA61-08234A $4.79

DA66-00579A Samsung Refrigerator Freezer Hand Backorder SMG DA66-00579A $9.50

Refrigerator Drain Tube Kit SMG DA97-04049E No Longer Available

Refrigerator door hinge, left SMG DA97-13827A Contact Us For Availability

14-3

Refrigerator Freezer Drawer Gear SMG DA66-00751A Contact Us For Availability

15

DA97-12594A Samsung Refrigerator Ice Chute Ca In Stock SMG DA97-12594A $60.04

15

Refrigerator Drain Cap SMG DA97-04049J Contact Us For Availability

15-1

DA62-01266E Samsung Refrigerator PVC Tube Backorder SMG DA62-01266E $4.25

15-1

DA63-06945A Samsung Refrigerator Ice Chute Ca Backorder SMG DA63-06945A $70.47

15-2

DA67-03312A Samsung Refrigerator Ice Cap Chut Backorder SMG DA67-03312A $11.73

15-2

Refrigerator Gear Rail SMG DA66-00750A Contact Us For Availability

15-4

DA96-00640B Samsung Refrigerator Wire Harness In Stock SMG DA96-00640B $144.60

16

DA61-05930A Samsung Refrigerator Fixer Shaft In Stock SMG DA61-05930A $2.23

16

DA97-13757A Samsung Refrigerator Evaporator C In Stock SMG DA97-13757A $167.08

16-1

DA32-00011D Samsung Refrigerator Temperature In Stock SMG DA32-00011D $13.61

16-2

DA97-13756A Samsung Refrigerator Motor Case A In Stock SMG DA97-13756A $114.12

DA32-00034B Samsung Refrigerator Humidity Sen Backorder SMG DA32-00034B $79.96

DA61-05899A Samsung Refrigerator Shaft Fixer In Stock SMG DA61-05899A $1.72

DA96-00842A Samsung Refrigerator Evaporator A In Stock SMG DA96-00842A $233.01

DA97-08442A Samsung Refrigerator Printed Circ Backorder SMG DA97-08442A $50.01

17-1

DA32-10104N Samsung Refrigerator Temperature In Stock SMG DA32-10104N $24.87

17-3

DA47-00434A Samsung Refrigerator Metal Sheath In Stock SMG DA47-00434A $160.60

17-4

DA61-03644A Samsung Refrigerator Defrost Evap Backorder SMG DA61-03644A $10.06

17-5

DA61-03683A Samsung Refrigerator Sensor Fixer Backorder SMG DA61-03683A $1.69

17-6

DA61-05835B Samsung Refrigerator Heater Fixer Backorder SMG DA61-05835B $6.39

18

DA63-04825A Samsung Refrigerator Grommet Chas Backorder SMG DA63-04825A $3.20

18

DA92-00215C Samsung Refrigerator Inverter Pow In Stock SMG DA92-00215C $255.37

18

DA97-12540D Samsung Refrigerator Auger Motor Backorder SMG DA97-12540D $263.36

18-2

DA31-00070E Samsung Refrigerator DC Motor Box In Stock SMG DA31-00070E $94.45

18-3

DA31-00105M Samsung Refrigerator Geared Auger Backorder SMG DA31-00105M $191.13

18-7

DA74-40151G Samsung Refrigerator Ice Dispense Backorder SMG DA74-40151G $110.76

19

DA61-05274A Samsung Refrigerator Door Switch Backorder SMG DA61-05274A $11.73

19

DA63-07512A Samsung Refrigerator Freezer Guar Backorder SMG DA63-07512A $72.69

19-1

DA63-07185A Samsung Refrigerator Ice Bucket T Backorder SMG DA63-07185A $3.35

19-2

DA61-20124D Samsung Refrigerator Dispenser Sp Backorder SMG DA61-20124D $7.82

20

DA34-00066C Samsung Refrigerator Door Interlo In Stock SMG DA34-00066C $24.11

20

DA60-00280A Samsung Refrigerator Fitting-Lokr Backorder SMG DA60-00280A $6.91

20

Refrigerator Ice Maker SMG DA97-18859A No Longer Available

21

DA97-12654A Samsung Refrigerator Cap Angle As Backorder SMG DA97-12654A $7.99

22

DA97-10605C Samsung Refrigerator Cover Contro Backorder SMG DA97-10605C $165.48

23

6002-000630 Samsung Refrigerator Tapping Scre Backorder SMG 6002-000630 $1.18

24

DA97-12712C Samsung Refrigerator Freezer Door Backorder SMG DA97-12712C $200.55

24-1

DA61-08229A Samsung Refrigerator Freezer Hand In Stock SMG DA61-08229A $12.29

24-2

DA61-08247A Samsung Refrigerator Freezer Door In Stock SMG DA61-08247A $27.41

24-3

DA67-02787A Samsung Refrigerator Freezer Door In Stock SMG DA67-02787A $12.90

24-4

Refrigerator Door Handle Set Screw SMG 6009-001526 Contact Us For Availability

25

DA27-00022B Samsung Refrigerator Coil Filter In Stock SMG DA27-00022B $142.41

25

DA97-08430A Samsung Refrigerator Convection I Backorder SMG DA97-08430A $237.39

25-1

DA31-00101C Samsung Refrigerator DC Motor Dam Backorder SMG DA31-00101C $186.37

26

DA63-05524A Samsung Refrigerator Door LED Cap Backorder SMG DA63-05524A $41.02

26-1

DA60-00143B Samsung Refrigerator Housing Reta In Stock SMG DA60-00143B $1.69

27

DA62-03914A Samsung Refrigerator Water Tube F In Stock SMG DA62-03914A $46.24

27

DA63-05462C Samsung Refrigerator Convection D Backorder SMG DA63-05462C $100.09

27

DA97-08413B Samsung Refrigerator Assembly Cov Backorder SMG DA97-08413B $17.32

30

3903-001003 Samsung Refrigerator CBF Power Co In Stock SMG 3903-001003 $63.58

30

DA97-13831A Samsung Refrigerator Shelf Folder Backorder SMG DA97-13831A $162.10

31

DA97-13837A Samsung Refrigerator Right Vegeta Backorder SMG DA97-13837A $35.30

32

DA97-13838A Samsung Refrigerator Left Vegetab Backorder SMG DA97-13838A $34.81

33

DA61-04932A Samsung Refrigerator Door Hinge F Backorder SMG DA61-04932A $8.46

35

DA62-00305A Samsung Refrigerator PU Valve Fit In Stock SMG DA62-00305A $31.82

36

DA74-00070B Samsung Refrigerator Fitting Nut Backorder SMG DA74-00070B $21.80

37

6002-000217 Samsung Refrigerator Tapping Scre Backorder SMG 6002-000217 $1.18

1210

DA61-04522A Samsung Refrigerator Clip Lock Fi Backorder SMG DA61-04522A $1.69

1621

DA81-06013A Samsung Refrigerator Evaporator F Backorder SMG DA81-06013A $126.54

NI

6002-000239 Samsung Air Conditioner Tapping S Backorder SMG 6002-000239 $1.18

NI

6003-001727 Samsung Refrigerator Television T Backorder SMG 6003-001727 $2.23

NI

DA67-02795C Samsung Refrigerator Shaft Hole C Backorder SMG DA67-02795C $1.69
