Model Whirlpool YGH7145XFB2 MICROWAVE OVEN 1.4 CU. FT. – Common Parts &amp; Diagrams

1

Reflector, Lamp WPL 4393688 Contact Us For Availability

1

Motor, Stirrer WPL 4393746 Contact Us For Availability

2

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $3.39

2

Frame, Inner WPL 8169545 Contact Us For Availability

2

Shaft, Stirrer WPL 4393794 Contact Us For Availability

3

6800 Whirlpool Charcoal Filter Kit In Stock WPL 6800 $14.68

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $50.07

3

Latch, Door WPL 4393913 Contact Us For Availability

3

Panel, Control (White) WPL 8183926 Contact Us For Availability

3

Panel, Control (Black) WPL 8183927 Contact Us For Availability

3

Stirrer WPL 4393748 Contact Us For Availability

4

6802A Whirlpool Grease Filter In Stock WPL 6802A $15.28

4

Body, Door (White) WPL 8169653 Contact Us For Availability

4

Bracket, Control WPL 8183821 Contact Us For Availability

4

Guide, Stirrer WPL 4393749 Contact Us For Availability

4

Lid, Power Cord WPL 4393714 Contact Us For Availability

5

Glass, Outer (Black) WPL 4393725 Contact Us For Availability

5

Thermostat WPL 8183697 Contact Us For Availability

5

Plate, Hinge WPL 4393744 Contact Us For Availability

5

Plate, Bottom WPL 8185209 Contact Us For Availability

5

Cover, Inlet WPL 8184476 Contact Us For Availability

6

8169432 Whirlpool Microwave Power Cord Backorder WPL 8169432 $118.46

6

Hook, Rack (4) WPL 8204662 Contact Us For Availability

6

PCB Assembly WPL 8169718 Contact Us For Availability

6

Glass, Lamp WPL 8185210 Contact Us For Availability

7

4393777 Whirlpool Microwave Door Handle - Whi In Stock WPL 4393777 $65.76

7

4393782 Whirlpool Microwave Door Handle In Stock WPL 4393782 $79.01

7

Holder, Glass WPL 8184308 Contact Us For Availability

7

Nail, Plastic WPL 4393291 Contact Us For Availability

7

Case, Outer (Black) WPL 8169660 Contact Us For Availability

7

Case, Outer (White) WPL 8169661 Contact Us For Availability

8

Turntable WPL 4393799 No Longer Available

8

8183851 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183851 $30.78

8

8183948 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183948 $29.01

8

Screw WPL 4393833 Contact Us For Availability

8

Screw WPL 4393346 Contact Us For Availability

8

Guide, Air (Magnetron) WPL 8184309 Contact Us For Availability

9

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $23.22

9

Switch, Membrane (White) WPL 8169405 Contact Us For Availability

9

Switch, Membrane (Black) WPL 8169472 Contact Us For Availability

9

Cover, Fan WPL 8183823 Contact Us For Availability

9

Grille, Holder WPL 8184313 Contact Us For Availability

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $32.32

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $4.77

Frame, Outer (White) WPL 8169471 Contact Us For Availability

Frame, Outer (Black) WPL 8169352 Contact Us For Availability

Wheel, Plastic WPL 4393861 Contact Us For Availability

11

W10435116 Whirlpool Microwave Turntable Rolle Backorder WPL W10435116 $16.57

11

Spring, Interlock (2) WPL 8169438 Contact Us For Availability

11

Screw WPL 4393839 Contact Us For Availability

12

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $88.39

12

Plate, Cam (2) WPL 8183824 Contact Us For Availability

12

Screw WPL 4393828 Contact Us For Availability

13

8205572 Whirlpool Microwave Interlock Backorder WPL 8205572 $4.19

13

Cover, Terminal WPL 4393756 Contact Us For Availability

13

Rod WPL 8169318 Contact Us For Availability

14

W10245183 Whirlpool Microwave Magnetron In Stock WPL W10245183 $178.22

14

Wheel, Fan WPL 8183825 Contact Us For Availability

14

Latch, Pivot WPL 8169319 Contact Us For Availability

15

Thermostat Open temp: 257 Fahrenheit Close te WPL 8183698 Contact Us For Availability

15

Housing, Fan WPL 8184310 Contact Us For Availability

15

E-Ring WPL 8169320 Contact Us For Availability

16

Motor, Fan WPL 8185211 Contact Us For Availability

16

Holder, Connector (L) WPL 8169540 Contact Us For Availability

16

Catch WPL 8169321 Contact Us For Availability

17

Chassis WPL 8185212 Contact Us For Availability

17

Holder, Connector (R) WPL 8169705 Contact Us For Availability

17

Spring WPL 8169374 Contact Us For Availability

Holder, Capacitor WPL 8184311 Contact Us For Availability

Screw WPL 4393838 Contact Us For Availability

Filler Kit (Black) WPL 4158311 Contact Us For Availability

Filler Kit WPL 4158439 Contact Us For Availability

Rack WPL 4393826 Contact Us For Availability

Installation, Hardware WPL 8169659 Contact Us For Availability

Plate, Damper WPL 8169697 Contact Us For Availability

Template - Wall WPL 8169765 Contact Us For Availability

Template - Upper WPL 8183734 Contact Us For Availability

Miscellaneous WPL ARI136470A Contact Us For Availability

ACCESSORY PARTS WPL ARI136471A Contact Us For Availability

19

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $15.24

20

8206562 Whirlpool Microwave Capacitor MG Backorder WPL 8206562 $92.19

20

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $3.22

21

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $14.93

21

Transformer, H.V. WPL 8185252 Contact Us For Availability

22

Plate, Side (R) WPL 8204657 Contact Us For Availability

23

Cushion, Mtr WPL 8169635 Contact Us For Availability

23

Bracket, Transformer WPL 4393706 Contact Us For Availability

24

Pipe WPL 8184129 Contact Us For Availability

25

Plate, Side (L) WPL 8204658 Contact Us For Availability

26

Capacitor WPL 4393709 Contact Us For Availability

27

Holder, Fuse WPL 8184312 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $23.48

29

Thermostat WPL 8183703 Contact Us For Availability

30

Screw WPL 8169474 Contact Us For Availability

32

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $10.17

34

Screw WPL 8169478 Contact Us For Availability

35

Screw WPL 8169475 Contact Us For Availability

36

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $6.22
