Model Whirlpool MH3184XPQ5 Microwave Oven 1.8 Cu. Ft. – Common Parts & Diagrams

Main Harness
Main Harness WPL W10258600 Contact Us For Availability
View on Model
Harns-Wire (Main Filter)
Harns-Wire (Main Filter) WPL W10259142 Contact Us For Availability
View on Model
1
Pivot, Door
Pivot, Door WPL 8184922 Contact Us For Availability
View on Model
1
Reflector, Lamp
Reflector, Lamp WPL 8205096 Contact Us For Availability
View on Model
1
Motor, Stirrer
Motor, Stirrer WPL 8205044 Contact Us For Availability
View on Model
1
Cook Guide Label
Cook Guide Label WPL 8205810 Contact Us For Availability
View on Model
1
Tech Sheet
Tech Sheet WPL W10132021 Contact Us For Availability
View on Model
1
U & C Guide
U & C Guide WPL W10170440 Contact Us For Availability
View on Model
2
Stirrer Shaft/Blade
Stirrer Shaft/Blade WPL 8205202 Contact Us For Availability
View on Model
2
Handle, Door (Stainless)
Handle, Door (Stainless) WPL 8206176 Contact Us For Availability
View on Model
2
Handle, Door (White)
Handle, Door (White) WPL W10113945 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8205374 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8205375 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8205376 Contact Us For Availability
View on Model
3
Thermostat/Bracket
Thermostat/Bracket WPL 8206454 Contact Us For Availability
View on Model
3
Lower Hinge
Lower Hinge WPL W10256901 Contact Us For Availability
View on Model
3
Bracket, Control
Bracket, Control WPL W10114256 Contact Us For Availability
View on Model
4
Case, Outer (White)
Case, Outer (White) WPL W10258593 Contact Us For Availability
View on Model
4
Case, Outer (Black)
Case, Outer (Black) WPL W10258594 Contact Us For Availability
View on Model
4
Plate, Bottom
Plate, Bottom WPL W10244597 Contact Us For Availability
View on Model
4
Cover, Inlet Includes Nails and Bushings
Cover, Inlet Includes Nails and Bushings WPL 8184476 Contact Us For Availability
View on Model
4
Microcomputer
Microcomputer WPL W10233386 Contact Us For Availability
View on Model
5
Grille, Vent (Universal Silver)
Grille, Vent (Universal Silver) WPL 8206193 Contact Us For Availability
View on Model
5
Glass, Lamp
Glass, Lamp WPL 8184141 Contact Us For Availability
View on Model
6
Holder, Glass
Holder, Glass WPL 8184889 Contact Us For Availability
View on Model
6
Bushings (4 of each)
Bushings (4 of each) WPL 8204659 Contact Us For Availability
View on Model
7
Turntable
Turntable WPL 4393799 No Longer Available
View on Model
7
Screw
Screw WPL 8169475 Contact Us For Availability
View on Model
7
Upper Hinge
Upper Hinge WPL W10256902 Contact Us For Availability
View on Model
8
Complete Door (White)
Complete Door (White) WPL 8205370 Contact Us For Availability
View on Model
8
Complete Door (Stainless)
Complete Door (Stainless) WPL 8205371 Contact Us For Availability
View on Model
8
Complete Door (Black)
Complete Door (Black) WPL 8205372 Contact Us For Availability
View on Model
8
Complete Door (Universal Silver)
Complete Door (Universal Silver) WPL 8206194 Contact Us For Availability
View on Model
9
Spring, Interlock
Spring, Interlock WPL 8169438 Contact Us For Availability
View on Model
9
Cover, Fan Mtr
Cover, Fan Mtr WPL 8206452 Contact Us For Availability
View on Model
10
Screw
Screw WPL 8169474 Contact Us For Availability
View on Model
10
Plate, Cam
Plate, Cam WPL 8205211 Contact Us For Availability
View on Model
11
Support, Interlock
Support, Interlock WPL 8185189 Contact Us For Availability
View on Model
11
Cover, Terminal
Cover, Terminal WPL W10253653 Contact Us For Availability
View on Model
12
Humidity, Sensor
Humidity, Sensor WPL 8206446 Contact Us For Availability
View on Model
12
Fan, DC 12 Volt
Fan, DC 12 Volt WPL W10239608 Contact Us For Availability
View on Model
13
Filter
Filter WPL 8206624 Contact Us For Availability
View on Model
13
Housing, Fan
Housing, Fan WPL 8205364 Contact Us For Availability
View on Model
13
Thermostat
Thermostat WPL 8184951 Contact Us For Availability
View on Model
14
Diffuser, Housing
Diffuser, Housing WPL 8205357 Contact Us For Availability
View on Model
14
Rack
Rack WPL 8205549 Contact Us For Availability
View on Model
15
Rod-Locking Link
Rod-Locking Link WPL 8185190 Contact Us For Availability
View on Model
15
Screw
Screw WPL 4393838 Contact Us For Availability
View on Model
17
Plate, Side
Plate, Side WPL 8206455 Contact Us For Availability
View on Model
19
Cover, Terminal
Cover, Terminal WPL 8184202 Contact Us For Availability
View on Model
19
Nail, Plastic
Nail, Plastic WPL 8204660 Contact Us For Availability
View on Model
20
Motor, Capacitor
Motor, Capacitor WPL 8184091 Contact Us For Availability
View on Model
21
Holder, Fuse
Holder, Fuse WPL W10117908 Contact Us For Availability
View on Model
23
SCREW
SCREW WPL 8184199 Contact Us For Availability
View on Model
25
SCREW
SCREW WPL 8184200 Contact Us For Availability
View on Model
28
Transformer, H.V.
Transformer, H.V. WPL 8206456 Contact Us For Availability
View on Model
29
Bracket, Capacitor
Bracket, Capacitor WPL 8206457 Contact Us For Availability
View on Model
30
Capacitor, H.V.
Capacitor, H.V. WPL W10258597 Contact Us For Availability
View on Model
32
Chassis
Chassis WPL 8206567 Contact Us For Availability
View on Model
