Model JGBS19DEN6WW – Common Parts & Diagrams

Common parts from model JGBS19DEN6WW

WB03K10218 GE Oven Control Knob

WB03K10218 GE Oven Control Knob In Stock GEN WB03K10218 $7.41

WB28K10023 GE Oven Orifice

WB28K10023 GE Oven Orifice In Stock GEN WB28K10023 $9.05

WB01K10037 GE Oven Economic Nut

WB01K10037 GE Oven Economic Nut Out of Stock GEN WB01K10037 $7.54

WB01K10002 GE Oven Screw 8-32

WB01K10002 GE Oven Screw 8-32 In Stock GEN WB01K10002 $21.00

WB02K10361 GE Oven Orifice Holder

WB02K10361 GE Oven Orifice Holder In Stock GEN WB02K10361 $10.31

WB18X31208 GE Oven Harness Burner Box

WB18X31208 GE Oven Harness Burner Box Out of Stock GEN WB18X31208 $44.60

WB28K10457 GE Oven Manifold Pipe

WB28K10457 GE Oven Manifold Pipe Out of Stock GEN WB28K10457 $53.26

WB28K10578 GE Oven Surface Burner Valve

WB28K10578 GE Oven Surface Burner Valve Out of Stock GEN WB28K10578 $25.65

WB2K24 GE Oven Cover Valve

WB2K24 GE Oven Cover Valve Out of Stock GEN WB2K24 $37.36

WB28K10188 GE Oven Rear Orifice H R 150N 9500

WB28K10188 GE Oven Rear Orifice H R 150N 9500 Out of Stock GEN WB28K10188 $21.65

WB28K10190 GE Oven Left Front Orifice

WB28K10190 GE Oven Left Front Orifice In Stock GEN WB28K10190 $19.75

WB1X1293 GE Oven Screw

WB1X1293 GE Oven Screw Out of Stock GEN WB1X1293 $5.69

WB20K10015 GE Oven Temperature Sensor

WB20K10015 GE Oven Temperature Sensor In Stock GEN WB20K10015 $35.09

COVER BACK UPPER

COVER BACK UPPER Out of Stock GEN WB34K10093 $36.64

WB34K10094 GE Oven Cover Back Lower

WB34K10094 GE Oven Cover Back Lower Out of Stock GEN WB34K10094 $53.37

WB1X5364 GE Oven Screw Mounting

WB1X5364 GE Oven Screw Mounting Out of Stock GEN WB1X5364 $7.54

WB13K10029 GE Oven Spark Module 4+0

WB13K10029 GE Oven Spark Module 4+0 Out of Stock GEN WB13K10029 $64.68

WB31K10035 GE Oven Grate (Gray)

WB31K10035 GE Oven Grate (Gray) In Stock GEN WB31K10035 $234.78

SUPPORT COOKTOP

SUPPORT COOKTOP Out of Stock GEN WB02K10276 $7.54

WB14K5 GE Oven Pin Hinge

WB14K5 GE Oven Pin Hinge Out of Stock GEN WB14K5 $7.54

WB1K45 GE Oven Screw & Washer Assembly

WB1K45 GE Oven Screw & Washer Assembly Out of Stock GEN WB1K45 $7.54

WB1K5119 GE Oven Screw

WB1K5119 GE Oven Screw Out of Stock GEN WB1K5119 $7.54

WB01K10008 GE Oven Mounting Screw

WB01K10008 GE Oven Mounting Screw In Stock GEN WB01K10008 $5.69

WB27K10256 GE Oven Overlay T09

WB27K10256 GE Oven Overlay T09 In Stock GEN WB27K10256 $69.11

WB29K10004 GE Oven Burner Cap Gray

WB29K10004 GE Oven Burner Cap Gray In Stock GEN WB29K10004 $39.59

WB16K10055 GE Oven Burner Base

WB16K10055 GE Oven Burner Base In Stock GEN WB16K10055 $31.57

WB01K10112 GE Range Stove Oven Electrode Clip

WB01K10112 GE Range Stove Oven Electrode Clip In Stock GEN WB01K10112 $7.54

WB18K10036 GE Oven Line Cord

WB18K10036 GE Oven Line Cord In Stock GEN WB18K10036 $15.55

WB1K5062 GE Oven Screw

WB1K5062 GE Oven Screw In Stock GEN WB1K5062 $7.54

WZ4X345D GE Screw Package 12 C92

WZ4X345D GE Screw Package 12 C92 Out of Stock GEN WZ4X345D $22.91

WB01K10091 GE Oven Screw

WB01K10091 GE Oven Screw Out of Stock GEN WB01K10091 $7.57

WB19K10044 GE Oven Valve Control Assembly

WB19K10044 GE Oven Valve Control Assembly In Stock GEN WB19K10044 $115.63

WB2K65 GE Oven Bracket SAF Valve

WB2K65 GE Oven Bracket SAF Valve Out of Stock GEN WB2K65 $7.54

WB13K21 GE Oven Ignitor 3 3/4 7Leads

WB13K21 GE Oven Ignitor 3 3/4 7Leads In Stock GEN WB13K21 $50.80

WB02K10294 GE Oven Grommet

WB02K10294 GE Oven Grommet Out of Stock GEN WB02K10294 $7.54

WB08T10026 GE Range Receptacle Push-In

WB08T10026 GE Range Receptacle Push-In In Stock GEN WB08T10026 $7.54

WB28X25363 GE Oven Tube Manifold Supply Assem

WB28X25363 GE Oven Tube Manifold Supply Assem In Stock GEN WB28X25363 $13.36

WB63K10029 GE Bottom Range

WB63K10029 GE Bottom Range Out of Stock GEN WB63K10029 $88.25

WB02K10182 GE Oven Levelling Leg

WB02K10182 GE Oven Levelling Leg In Stock GEN WB02K10182 $7.59

WB53K10002 GE Oven Top

WB53K10002 GE Oven Top Out of Stock GEN WB53K10002 $84.51

WB38K10001 GE Oven Vent Assembly

WB38K10001 GE Oven Vent Assembly Out of Stock GEN WB38K10001 $53.82

WB35K10157 GE Oven Insulation Oven Wrap

WB35K10157 GE Oven Insulation Oven Wrap Out of Stock GEN WB35K10157 $75.27

WB39K6 GE Oven Broil Weld A

WB39K6 GE Oven Broil Weld A Out of Stock GEN WB39K6 $98.13

WB10K5 GE Oven Hinge Broil R

WB10K5 GE Oven Hinge Broil R Out of Stock GEN WB10K5 $13.12

WB10K6 GE Oven Hinge Broil L

WB10K6 GE Oven Hinge Broil L In Stock GEN WB10K6 $11.68

WB1K7 GE Oven Pin Broiler

WB1K7 GE Oven Pin Broiler Out of Stock GEN WB1K7 $7.54

WB39K10029 GE Oven Slide Broiler Pan

WB39K10029 GE Oven Slide Broiler Pan Out of Stock GEN WB39K10029 $8.47

WB39K10030 GE Oven Slide Broiler Pan

WB39K10030 GE Oven Slide Broiler Pan Out of Stock GEN WB39K10030 $8.47

WB39K9 GE Oven Slide BroilR

WB39K9 GE Oven Slide BroilR Out of Stock GEN WB39K9 $31.78

WB9K3 GE Oven Spring Broil L

WB9K3 GE Oven Spring Broil L Out of Stock GEN WB9K3 $7.54

WB56X21199 GE Oven Panel Drawer

WB56X21199 GE Oven Panel Drawer Out of Stock GEN WB56X21199 $38.63

WB39K10028 GE Oven Liner Drawer

WB39K10028 GE Oven Liner Drawer Out of Stock GEN WB39K10028 $47.55

WB15K10008 GE Oven Handle-Broil

WB15K10008 GE Oven Handle-Broil Out of Stock GEN WB15K10008 $33.75

WB2K14 GE Oven Spacer

WB2K14 GE Oven Spacer In Stock GEN WB2K14 $7.54

WB2K15 GE Oven Grate Bumper/Foot

WB2K15 GE Oven Grate Bumper/Foot In Stock GEN WB2K15 $7.54

GE Range Washer

GE Range Washer Out of Stock GEN WB1X119D $13.67

WB1X5731D GE Oven Nut PKG/12

WB1X5731D GE Oven Nut PKG/12 Out of Stock GEN WB1X5731D $27.05

WB57K10120 GE Oven Glass Oven Door

WB57K10120 GE Oven Glass Oven Door Out of Stock GEN WB57K10120 $140.24

WB35K10041 GE Oven Reflector

WB35K10041 GE Oven Reflector Out of Stock GEN WB35K10041 $13.38

WB35X29720 GE Oven Door Gasket

WB35X29720 GE Oven Door Gasket In Stock GEN WB35X29720 $21.60

WB02K10161 GE Oven Spacer

WB02K10161 GE Oven Spacer Out of Stock GEN WB02K10161 $7.54

WB1X558D GE Oven Screw Package 12

WB1X558D GE Oven Screw Package 12 Out of Stock GEN WB1X558D $22.04

WB35K10151 GE Oven Insulation Door

WB35K10151 GE Oven Insulation Door Out of Stock GEN WB35K10151 $43.38

WB56K5 GE Oven Crystal Wind

WB56K5 GE Oven Crystal Wind In Stock GEN WB56K5 $120.07

WB56K10032 GE Oven Guard Insulation

WB56K10032 GE Oven Guard Insulation Out of Stock GEN WB56K10032 $58.28

WB1K67 GE Oven Screw 8-22

WB1K67 GE Oven Screw 8-22 Out of Stock GEN WB1K67 $7.54

WB07K10250 GE Oven Range Stove Door Trim Asse

WB07K10250 GE Oven Range Stove Door Trim Asse In Stock GEN WB07K10250 $10.43

WB01K10073 GE Oven Screw 10-16PL PNT 2.22S

WB01K10073 GE Oven Screw 10-16PL PNT 2.22S Out of Stock GEN WB01K10073 $7.54

WB1K63 GE Oven Screw

WB1K63 GE Oven Screw Out of Stock GEN WB1K63 $41.82

WB15K10096 GE Oven Handle White

WB15K10096 GE Oven Handle White In Stock GEN WB15K10096 $62.18

WB7X7188 GE Oven LH Endcap

WB7X7188 GE Oven LH Endcap Out of Stock GEN WB7X7188 $15.05

WB1X536 GE Oven Screw

WB1X536 GE Oven Screw Out of Stock GEN WB1X536 $9.21

WB01K10043 GE Oven Screw

WB01K10043 GE Oven Screw Out of Stock GEN WB01K10043 $7.54

WB01K10080 GE Oven Thermostat Screw

WB01K10080 GE Oven Thermostat Screw Out of Stock GEN WB01K10080 $7.54

WB02K10263 GE Oven Round Valve Bracket

WB02K10263 GE Oven Round Valve Bracket Out of Stock GEN WB02K10263 $7.54

WB01T10016 GE Oven Screw 8-18 AB HXW 5/8 S

WB01T10016 GE Oven Screw 8-18 AB HXW 5/8 S Out of Stock GEN WB01T10016 $7.54

WB02K10179 GE Range Bumper

WB02K10179 GE Range Bumper Out of Stock GEN WB02K10179 $7.54
