Model Whirlpool 665.75808002 Gas Freestanding Range (Kenmore 66575808002) – Common Parts &amp; Diagrams

1

Screw WPL 8273096 Contact Us For Availability

1

End Cap Panel WPL 8272631 Contact Us For Availability

1A

End Cap Panel WPL 8272632 Contact Us For Availability

2

WP3191898 Whirlpool Surface Burner Cap Black Backorder WPL WP3191898 $51.68

2

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $62.36

2

WP3196164 Whirlpool Screw In Stock WPL WP3196164 $5.30

2

Support WPL 8272637 Contact Us For Availability

2A

WP3191901 Whirlpool Burner Cap Backorder WPL WP3191901 $79.78

2A

Support WPL 8272638 Contact Us For Availability

2B

WP3191904 Whirlpool Burner Cap Backorder WPL WP3191904 $118.65

3

WP3196076 Whirlpool Broil Pan Backorder WPL WP3196076 $213.57

3

Control Panel WPL 8272734 Contact Us For Availability

4

Utility Drawer WPL 8053343 Contact Us For Availability

4A

Panel WPL 8053831 Contact Us For Availability

5

W11759228 Whirlpool Mounting Bracket Backorder WPL W11759228 $18.06

5

WP8053948 Whirlpool Door Glass In Stock WPL WP8053948 $98.63

5

WPW10331686 Whirlpool Range Spark Module In Stock WPL WPW10331686 $269.04

5

Range Surface Burner Igniter Switch Assembly WPL 8273075 Contact Us For Availability

5

Shield WPL 3196137 Contact Us For Availability

6

8053505 Whirlpool Range Shield Backorder WPL 8053505 $114.33

6

WP3196814 Whirlpool Rivet Backorder WPL WP3196814 $6.64

6

Manifold Bracket WPL 3186405 Contact Us For Availability

6A

Manifold Bracket WPL 3186406 Contact Us For Availability

6A

Range Broil Drawer Handle Push Rivet WPL 3196815 Contact Us For Availability

7

Shield WPL 3196136 Contact Us For Availability

7

Panel WPL 8272596 Contact Us For Availability

7

Mounting Bracket WPL 8273553 Contact Us For Availability

7A

Panel WPL 8272597 Contact Us For Availability

7A

Mounting Bracket WPL 8273554 Contact Us For Availability

8

(LEFT W/DUAL) WPL N/P Contact Us For Availability

8

Rear Cover WPL 8272474 Contact Us For Availability

8A

Range Surface Burner Valve WPL 8273004 Contact Us For Availability

9

8272766 Whirlpool Range Knob Backorder WPL 8272766 $13.92

9

WP3196037 Whirlpool Leveling Foot Backorder WPL WP3196037 $57.82

9

WP8053334 Whirlpool Drawer Glide In Stock WPL WP8053334 $5.30

9

Nut WPL 8273060 Contact Us For Availability

9

Shield WPL 8053910 Contact Us For Availability

WP3400832 Whirlpool Screw In Stock WPL WP3400832 $3.92

WP8053807 Whirlpool Range Door Hinge In Stock WPL WP8053807 $64.87

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $5.30

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $4.53

Rear Cover WPL 8273132 Contact Us For Availability

11

WP3195097 Whirlpool Range Bottom In Stock WPL WP3195097 $94.10

WP3195060 Whirlpool Cooktop Pin In Stock WPL WP3195060 $7.88

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $168.34

WP8273340 Whirlpool Sensor Backorder WPL WP8273340 $169.17

Microcomputer WPL 8273640 Contact Us For Availability

13

8053967 Whirlpool Range Heat Baffle Backorder WPL 8053967 $215.43

13

Oven Baffle WPL 8053970 Contact Us For Availability

14

8053969 Whirlpool Heat Shield Backorder WPL 8053969 $74.13

15

8053968 Whirlpool Range Heat Shield Backorder WPL 8053968 $61.59

15

Oven Door Clip WPL 3196925 Contact Us For Availability

15

Mounting Bracket WPL 8272629 Contact Us For Availability

WP8054129 Whirlpool Range Igniter In Stock WPL WP8054129 $81.24

WPW10306546 Whirlpool Base Rail In Stock WPL WPW10306546 $93.00

Door Handle WPL 8272439 Contact Us For Availability

Range Touch Control Panel Assembly WPL 8273122 Contact Us For Availability

16A

Door Handle WPL 8272441 Contact Us For Availability

17

238614 Whirlpool Bumper Hinge Backorder WPL 238614 $70.41

17

Gas Tubing WPL 8272222 Contact Us For Availability

18

3196200 Whirlpool Clip In Stock WPL 3196200 $7.48

18

Range Broil Burner Fitting WPL 3186489 Contact Us For Availability

18

Oven Seal WPL 3195737 Contact Us For Availability

19

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $37.66

19

WP8273564 Whirlpool Clip Backorder WPL WP8273564 $7.79

20

WP8273064 Whirlpool Orifice Backorder WPL WP8273064 $69.23

20

Rear Cover WPL 8272921 Contact Us For Availability

20A

WP8273065 Whirlpool Orifice Backorder WPL WP8273065 $69.23

20B

WP8273067 Whirlpool Orifice Backorder WPL WP8273067 $69.45

21

W11542153 Whirlpool Door Gasket In Stock WPL W11542153 $38.17

22

Brace WPL 8053971 Contact Us For Availability

23

3196265 Whirlpool Range Screw Backorder WPL 3196265 $8.89

23

Retainer WPL 3196523 Contact Us For Availability

23A

Retainer WPL 3195726 Contact Us For Availability

24

Range Body Side Panel Clip WPL 3196576 Contact Us For Availability

25

W11684507 Whirlpool Screw In Stock WPL W11684507 $12.99

25

WP9757891 Whirlpool Power Cord Backorder WPL WP9757891 $90.38

26

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $8.91

26

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $4.82

27

WP3196262 Whirlpool Light Switch Backorder WPL WP3196262 $112.89

28

W11594027 Whirlpool Range Oven Light Socket In Stock WPL W11594027 $61.44

29

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $16.02

30

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $180.29

31

W10078370 Whirlpool Latch Rod Backorder WPL W10078370 $64.29

32

WPW10107820 Whirlpool Door Latch In Stock WPL WPW10107820 $127.40

33

WP3195546 Whirlpool Drawer Glide In Stock WPL WP3195546 $5.30

36

Button Plug WPL 3196439 Contact Us For Availability

38

Screw WPL 3196152 Contact Us For Availability

39

3196166 Whirlpool Screw Backorder WPL 3196166 $4.67

40

W11233072 Whirlpool Screw In Stock WPL W11233072 $11.38

41

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $4.99

42

Screw WPL 3196179 Contact Us For Availability

43

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $5.30

44

WP7101P246-60 Whirlpool Screw Backorder WPL WP7101P246-60 $4.82

46

W11244557 Whirlpool Screw Backorder WPL W11244557 $8.89

16515 Whirlpool Clip Backorder WPL 16515 $12.46

285006 Whirlpool Spray In Stock WPL 285006 $52.65

3196696 Whirlpool Clip Backorder WPL 3196696 $8.41

3196896 Whirlpool Clip Backorder WPL 3196896 $7.69

3400964 Whirlpool Range Clip Backorder WPL 3400964 $62.15

350930 Whirlpool White Spray Paint In Stock WPL 350930 $25.69

350942 Whirlpool Spray Paint Backorder WPL 350942 $64.04

350956 Whirlpool Spray Assembly In Stock WPL 350956 $26.25

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $8.31

814381 Whirlpool Pin Backorder WPL 814381 $4.82

8212471 Whirlpool Oven Paint Backorder WPL 8212471 $46.71

8273888A Whirlpool Range Oven Anchor Anti-Tip In Stock WPL 8273888A $18.92

W11688737 Whirlpool Insulation Backorder WPL W11688737 $81.75

WP72107 Whirlpool Touchup In Stock WPL WP72107 $10.96

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $60.66

Aluminum Foil WPL 241430 Contact Us For Availability

Paint 1qt WPL 799344 Contact Us For Availability

Wire (Black) WPL 242820 Contact Us For Availability

Wire (Blue) WPL 242821 Contact Us For Availability

Wire (Brown) WPL 242822 Contact Us For Availability

Wire (Green) WPL 242823 Contact Us For Availability

Wire (Orange) WPL 242824 Contact Us For Availability

Wire (Red) WPL 242825 Contact Us For Availability

Wire (White) WPL 242826 Contact Us For Availability

Appliance Splicing Wire, 25-ft, 14-gauge (Yel WPL 242827 Contact Us For Availability

Wire (Black) WPL 242828 Contact Us For Availability

Wire WPL 242829 Contact Us For Availability

Wire (Brown) WPL 242830 Contact Us For Availability

Cooking Appliance 14-gauge Splicing Wire, 200 WPL 242831 Contact Us For Availability

Wire (Yellow) WPL 242832 Contact Us For Availability

Grease WPL 261582 Contact Us For Availability

Epoxy WPL 799832 Contact Us For Availability

Clip WPL 8053527 Contact Us For Availability

Wire Harness WPL 8273127 Contact Us For Availability

Wire Harness WPL 8273341 Contact Us For Availability

Orifice Spud WPL 8273358 Contact Us For Availability

Wire WPL 8273557 Contact Us For Availability

Wire Harness WPL 8273966 Contact Us For Availability

Wire Harness WPL 8273967 Contact Us For Availability

Paint-al WPL 978883 Contact Us For Availability
