Model Whirlpool YKHMS145JBT1 MICROWAVE OVEN 1.4 CU. FT. – Common Parts &amp; Diagrams

Rack WPL 4393826 Contact Us For Availability

Wall Template WPL 8169293 Contact Us For Availability

Upper Cab Template WPL 8169294 Contact Us For Availability

Installation, Hardware WPL 8169659 Contact Us For Availability

Miscellaneous WPL ARI138774A Contact Us For Availability

1

WP8206174 Whirlpool Microwave Mounting Bracke Backorder WPL WP8206174 $16.25

1

Reflector, Lamp WPL 8169652 Contact Us For Availability

1

Deflector, Air WPL 8184638 Contact Us For Availability

1

Motor, Stirrer WPL 4393746 Contact Us For Availability

2

Frame, Inner WPL 8169545 Contact Us For Availability

2

Reflector, Air WPL 8169557 Contact Us For Availability

2

Shaft, Stirrer WPL 8184633 Contact Us For Availability

3

6800 Whirlpool Charcoal Filter Kit In Stock WPL 6800 $14.68

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $50.07

3

Latch, Door WPL 4393913 Contact Us For Availability

3

Duct, Air WPL 8185083 Contact Us For Availability

4

6802A Whirlpool Grease Filter In Stock WPL 6802A $15.28

4

Body, Door (White) WPL 8169653 Contact Us For Availability

4

Lid, Power Cord WPL 8184313 Contact Us For Availability

4

Bracket, Thermostat WPL 8169558 Contact Us For Availability

5

Glass, Outer (Clear (Green Tint)) WPL 4393725 Contact Us For Availability

5

Plate, Bottom WPL 8184307 Contact Us For Availability

5

Thermostat WPL 4393945 Contact Us For Availability

5

Cover, Inlet (Includes Nails & Bushings) WPL 8184476 Contact Us For Availability

6

8169432 Whirlpool Microwave Power Cord Backorder WPL 8169432 $118.46

6

W10315274 Whirlpool Microwave Meal Rack Backorder WPL W10315274 $19.80

6

Glass, Lamp WPL 8169564 Contact Us For Availability

7

8169738 Whirlpool Microwave Door Handle In Stock WPL 8169738 $84.48

7

8204670 Whirlpool Microwave Halogen Lamp 10W In Stock WPL 8204670 $11.86

7

Holder, Glass WPL 8184308 Contact Us For Availability

7

Case, Outer (White) WPL 8169660 Contact Us For Availability

7

Case, Outer (Black) WPL 8169661 Contact Us For Availability

7

Case, Outer (Biscuit) WPL 8169664 Contact Us For Availability

7

Nails/Bushings (4 each) WPL 8184549 Contact Us For Availability

8

Turntable WPL 4393799 No Longer Available

8

8184608 Whirlpool Microwave Oven Vent Grille In Stock WPL 8184608 $30.59

8

Grille, Vent (White) WPL 8184148 Contact Us For Availability

8

Screw WPL 4393833 Contact Us For Availability

8

Grille, Vent (Biscuit) WPL 8184146 Contact Us For Availability

8

Guide, Air (Magnetron) WPL 8184309 Contact Us For Availability

8

Grille, Vent (Stainless) WPL 8184641 Contact Us For Availability

8

Wheel, Fan WPL 8204694 Contact Us For Availability

9

8206334 Whirlpool Microwave Mounting Bracket In Stock WPL 8206334 $2.83

9

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $23.22

9

Cover, Fan WPL 8183823 Contact Us For Availability

9

Motor, Fan WPL 8169632 Contact Us For Availability

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $4.77

WP8184485 Whirlpool Microwave Shield Backorder WPL WP8184485 $72.70

Frame, Outer (Black) WPL 8184592 Contact Us For Availability

Frame, Outer (White) WPL 8184149 Contact Us For Availability

Frame, Outer (Biscuit) WPL 8184744 Contact Us For Availability

Frame, Outer (Stainless) WPL 8184319 Contact Us For Availability

Switch, Micro WPL 8204656 Contact Us For Availability

Shield WPL 8184130 Contact Us For Availability

11

W10435116 Whirlpool Microwave Turntable Rolle Backorder WPL W10435116 $16.57

11

Spring, Interlock WPL 8169438 Contact Us For Availability

11

Housing, Fan WPL 8185085 Contact Us For Availability

12

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $88.39

12

Plate, Cam WPL 8183824 Contact Us For Availability

12

Bracket, Fan (Not Serviced) WPL ARI138773A Contact Us For Availability

8205572 Whirlpool Microwave Interlock Backorder WPL 8205572 $4.19

Screw WPL 8169474 Contact Us For Availability

Rod WPL 8169318 Contact Us For Availability

Cover, Terminal WPL 4393756 Contact Us For Availability

W10245183 Whirlpool Microwave Magnetron In Stock WPL W10245183 $178.22

Wheel, Fan WPL 8183825 Contact Us For Availability

Latch, Pivot WPL 8169319 Contact Us For Availability

Screw WPL 4393316 Contact Us For Availability

Thermostat WPL 4393943 Contact Us For Availability

Housing, Fan WPL 8184310 Contact Us For Availability

E-Ring WPL 8169320 Contact Us For Availability

Screw WPL 4393830 Contact Us For Availability

Motor, Fan WPL 8183826 Contact Us For Availability

Catch WPL 8185033 Contact Us For Availability

Nut WPL 8184404 Contact Us For Availability

Holder, Connector (L) WPL 8169540 Contact Us For Availability

Chassis WPL 8183827 Contact Us For Availability

Spring WPL 8169374 Contact Us For Availability

Humidity, Sensor WPL 4393808 Contact Us For Availability

Holder, Connector (R) WPL 8169705 Contact Us For Availability

Holder, Capacitor WPL 8184311 Contact Us For Availability

Plate, Damper WPL 8169697 Contact Us For Availability

Transformer, L.V. WPL 8185003 Contact Us For Availability

Screw WPL 4393838 Contact Us For Availability

19

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $15.24

19

Screw WPL 4393828 Contact Us For Availability

19

Holder, Lamp WPL 8169497 Contact Us For Availability

20

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $3.22

20

Capacitor, H.V. WPL 8204774 Contact Us For Availability

20

Filter WPL 8169561 Contact Us For Availability

21

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $14.93

21

Transformer, H.V. WPL 8185252 Contact Us For Availability

22

Plate, Side (R) WPL 4393705 Contact Us For Availability

22

Plate, Damper WPL 4393874 Contact Us For Availability

23

Cushion, Mtr WPL 8169635 Contact Us For Availability

23

Thermostat/Bracket WPL 8184585 Contact Us For Availability

24

Terminal Bracket WPL 8183832 Contact Us For Availability

25

Plate, Side (L) WPL 8169470 Contact Us For Availability

26

Capacitor WPL 4393709 Contact Us For Availability

27

Holder, Fuse WPL 8184312 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $23.48

29

Thermostat WPL 4393710 Contact Us For Availability

29

Glass, Lamp WPL 8169499 Contact Us For Availability

30

Frame, Glass WPL 8169646 Contact Us For Availability

31

Clip WPL 8169647 Contact Us For Availability

32

W10748097 Whirlpool Microwave Crisp Pan In Stock WPL W10748097 $32.37

32

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $10.17

33

W10851464 Whirlpool Microwave Handle Panel In Stock WPL W10851464 $17.57

34

Screw WPL 8169478 Contact Us For Availability

35

Screw WPL 8169475 Contact Us For Availability

37

Screw WPL 4393839 Contact Us For Availability

38

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $3.22
