Model Whirlpool SF315PEPQ2 30`` GAS FREESTANDING STANDARD CLEAN RANGE ELECTRO – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.99

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $16.99

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.99

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $27.29

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.99

814381 Whirlpool Pin In Stock WPL 814381 $4.82

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $56.69

WPL 799344 WPL 799344 Contact Us For Availability

WPL ARI129803A WPL ARI129803A Contact Us For Availability

WPL ARI129804A WPL ARI129804A Contact Us For Availability

1

WP98008545 Whirlpool Screw Backorder WPL WP98008545 $11.88

1

WPW10116396 Whirlpool Flue Box Backorder WPL WPW10116396 $63.59

1

Burner, Top (Right) WPL 98003939 Contact Us For Availability

1

Burner, Top (Left) WPL 98008971 Contact Us For Availability

1

Tech Sheet WPL 98007031 Contact Us For Availability

1

Safer Cooking Tips WPL 98007130 Contact Us For Availability

1

Instructions Installation WPL 98014965 Contact Us For Availability

1

Guide, Use & Care WPL 98015558 Contact Us For Availability

1

Installation Instr (Template) WPL 98015589 Contact Us For Availability

2

98013690 Whirlpool Clip Backorder WPL 98013690 $51.09

2

WP98003480 Whirlpool Grill Pan Backorder WPL WP98003480 $71.19

2

Venturi, Front (2) WPL 6610243 Contact Us For Availability

2

Cooktop WPL 98009677 Contact Us For Availability

3

98010182 Whirlpool Door Liner Backorder WPL 98010182 $216.52

3

WP98016005 Whirlpool Broiler Pan Backorder WPL WP98016005 $61.87

3

Brkt., Venturi (4) WPL 98005500 Contact Us For Availability

3

Shield, Insulation WPL 98014398 Contact Us For Availability

3

Panel, Manifold WPL 98009461 Contact Us For Availability

4

WP6610244 Whirlpool Venturi Assembly Backorder WPL WP6610244 $221.12

4

WP98006102 Whirlpool Knob In Stock WPL WP98006102 $14.57

4

WP98010042 Whirlpool Side Panel Backorder WPL WP98010042 $114.21

4

Insulation, Door WPL 98006753 Contact Us For Availability

5

98004952 Whirlpool Range Clip In Stock WPL 98004952 $56.92

5

98004953 Whirlpool Clip In Stock WPL 98004953 $8.56

5

W11590249 Whirlpool Spark Module In Stock WPL W11590249 $10.99

5

Clip, Oven Bottom WPL 98005502 Contact Us For Availability

6

8190014 Whirlpool Grate Kit Primary In Stock WPL 8190014 $171.86

6

Hinge, Door (2) WPL 98004734 Contact Us For Availability

6

Counterweight WPL 98006710 Contact Us For Availability

6

Regulator WPL 98007411 Contact Us For Availability

7

98006739 Whirlpool Range Wire Tie Backorder WPL 98006739 $57.09

7

98007192 Whirlpool Cover Model Backorder WPL 98007192 $53.22

7

Clip, Cooktop (2) WPL 98004722 Contact Us For Availability

8

3184020 Whirlpool Oven Wire Backorder WPL 3184020 $59.13

8

98015099 Whirlpool Range Burner Baffle Backorder WPL 98015099 $193.11

8

Panel, Door WPL 98006542 Contact Us For Availability

8

Frame, Front WPL 98005044 Contact Us For Availability

9

W10831827 Whirlpool Bumper Backorder WPL W10831827 $6.51

9

WP3196037 Whirlpool Leveling Foot In Stock WPL WP3196037 $53.98

9

WP98006801 Whirlpool Door Glass Backorder WPL WP98006801 $102.09

W11233072 Whirlpool Screw In Stock WPL W11233072 $19.85

WP98012138 Whirlpool Range Burner In Stock WPL WP98012138 $154.08

WPW10058460 Whirlpool Appliance Levelling Leg In Stock WPL WPW10058460 $4.98

Handle, Oven Door WPL 98006164 Contact Us For Availability

11

WP98004449 Whirlpool Range Bottom Backorder WPL WP98004449 $186.68

11

WP98005518 Whirlpool Burner Cap In Stock WPL WP98005518 $47.00

11

Actuator (2) WPL 98010557 Contact Us For Availability

WP59002061 Whirlpool Microwave Screw In Stock WPL WP59002061 $4.99

WP98007225 Whirlpool Screw Assembly Backorder WPL WP98007225 $4.82

WPW10361492 Whirlpool Wire Harness In Stock WPL WPW10361492 $138.58

Baffle, Side (2) WPL 98015736 Contact Us For Availability

WP98014893 Whirlpool Gas Safety Valve Assembl In Stock WPL WP98014893 $247.99

Baffle, Base WPL 98003847 Contact Us For Availability

Side Trim, Door (2) (White Right) WPL 98010188 Contact Us For Availability

Side Trim, Door (2) (White Left) WPL 98010191 Contact Us For Availability

Grate, Center WPL 98009723 Contact Us For Availability

14

98003830 Whirlpool Rail Base Backorder WPL 98003830 $67.89

14

WP98008544 Whirlpool Screw Assembly In Stock WPL WP98008544 $9.16

98004564 Whirlpool Range Retainer Backorder WPL 98004564 $125.80

98004629 Whirlpool Range Retainer Backorder WPL 98004629 $125.80

98012175 Whirlpool Range Support Backorder WPL 98012175 $91.36

Valve, Burner (4) (9,500 BTU) WPL 98005574 Contact Us For Availability

Valve, Burner (4) (11,500 BTU) WPL 98005626 Contact Us For Availability

WP98010185 Whirlpool Door Trim In Stock WPL WP98010185 $66.74

WPW10277003 Whirlpool Screw In Stock WPL WPW10277003 $3.52

Button, Plug (25/32``) WPL 98007388 Contact Us For Availability

Button, Plug (5/16``) WPL 98007389 Contact Us For Availability

Button, Plug (15/32``) WPL 98007390 Contact Us For Availability

17

98013574 Whirlpool Range Manifold Pipe Backorder WPL 98013574 $19.15

17

WP3400805 Whirlpool Screw Assembly Backorder WPL WP3400805 $4.82

18

98004227 Whirlpool Range Bumper Backorder WPL 98004227 $14.02

18

98009179 Whirlpool Range Nut Backorder WPL 98009179 $8.89

19

98004938 Whirlpool Range Retainer Backorder WPL 98004938 $90.64

19

Switch, Door WPL 98005765 Contact Us For Availability

20

98015100 Whirlpool Range Rear Cover Backorder WPL 98015100 $384.38

20

Insulation, Retainer-Bottom WPL 98012904 Contact Us For Availability

21

W10918546 Whirlpool Oven Range Igniter In Stock WPL W10918546 $30.51

21

WPW10217472 Whirlpool Door Gasket In Stock WPL WPW10217472 $100.99

21

Retainer, Upper WPL 98016117 Contact Us For Availability

22

W10837731 Whirlpool Screw Assembly In Stock WPL W10837731 $4.99

22

Retainer, Lower WPL 98016118 Contact Us For Availability

22

Washer, Valve (4) WPL 98007132 Contact Us For Availability

23

98007193 Whirlpool Oven Washer Backorder WPL 98007193 $6.92

23

WPW10469571 Whirlpool Gas Tubing Backorder WPL WPW10469571 $125.58

24

98007126 Whirlpool Range Stand Bracket Backorder WPL 98007126 $54.32

24

98013314 Whirlpool Range Support Bracket Backorder WPL 98013314 $62.97

25

98007410 Whirlpool Range Mounting Bracket Backorder WPL 98007410 $66.02

26

98007431 Whirlpool Range Fitting Backorder WPL 98007431 $83.77

27

98007191 Whirlpool Range Heat Shield Backorder WPL 98007191 $94.43

27

98013634 Whirlpool Range Screw Backorder WPL 98013634 $44.99

28

WP98006631 Whirlpool Screw Backorder WPL WP98006631 $4.82

28

Screw WPL 1180823 Contact Us For Availability

29

W11173616 Whirlpool Power Cord Backorder WPL W11173616 $72.67

30

98005026 Whirlpool Range Clip Backorder WPL 98005026 $6.92

31

98015346 Whirlpool Insulation Backorder WPL 98015346 $97.00

31

Tubing, Inlet WPL 98007429 Contact Us For Availability

32

Screw WPL 98006634 Contact Us For Availability

32

Fitting 1/4to9/16 WPL 98007430 Contact Us For Availability

33

98004447 Whirlpool Top Backorder WPL 98004447 $108.75

34

98004451 Whirlpool Range Side Panel Backorder WPL 98004451 $97.62

34

98004452 Whirlpool Range Side Backorder WPL 98004452 $108.18

34

W11676351 Whirlpool Screw Backorder WPL W11676351 $8.89

35

98013777 Whirlpool Back Liner Backorder WPL 98013777 $219.09

35

W10837674 Whirlpool Screw In Stock WPL W10837674 $4.99

36

98015363 Whirlpool Range Support Backorder WPL 98015363 $55.74

36

WPW10209656 Whirlpool Surface Ignitor In Stock WPL WPW10209656 $41.99

36

WPW10209657 Whirlpool Range Surface Igniter In Stock WPL WPW10209657 $28.96

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $9.81

WPW10278150 Whirlpool Clip Assembly In Stock WPL WPW10278150 $24.99

LP Spud Kit (For Use With LP) WPL 98013676 Contact Us For Availability

Natural Spud Kit (For use with Natural Gas) WPL 98013677 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI129796A Contact Us For Availability

38

W10856866 Whirlpool Light Socket In Stock WPL W10856866 $4.98

40

98007205 Whirlpool Range Vent Cap Backorder WPL 98007205 $64.35

41

WPW10181986 Whirlpool Range Sensor In Stock WPL WPW10181986 $70.79

42

98014105 Whirlpool Range Access Cover Backorder WPL 98014105 $114.80

98004294 Whirlpool Insulation Wire Backorder WPL 98004294 $6.92

98014104 Whirlpool Access Cover Backorder WPL 98014104 $83.23

W11311894 Whirlpool Insulation Backorder WPL W11311894 $65.71

W11706555 Whirlpool Insulation Backorder WPL W11706555 $15.68

Insulation WPL ARI129797A Contact Us For Availability
