Model Whirlpool KGRS205TBT0 30`` GAS FREESTANDING SELF CLEAN RANGE SEALED BURN – Common Parts &amp; Diagrams

1

Trim, Top (Black) WPL 3608F13970 Contact Us For Availability

1

Trim, Top (White) WPL 3608F13971 Contact Us For Availability

1

TRIM, TOP (BISCUIT) WPL 3608F13978 Contact Us For Availability

1

Endcap, Right Hand (Black) WPL 74009022 Contact Us For Availability

1

Endcap, Left Hand (Black) WPL 74009023 Contact Us For Availability

1

Endcap, Right Hand (White) WPL 74009077 Contact Us For Availability

1

ENDCAP, RIGHT HAND (BISCUIT) WPL 74009078 Contact Us For Availability

1

Endcap, Left Hand (White) WPL 74009079 Contact Us For Availability

1

ENDCAP, LEFT HAND (BISCUIT) WPL 74009080 Contact Us For Availability

1

Screw, Valve WPL 71003231 Contact Us For Availability

1

Vent, Oven WPL 74008817 Contact Us For Availability

2

74008690 Whirlpool Oven Spacer Backorder WPL 74008690 $15.96

2

W10154209 Whirlpool Orifice Holder Backorder WPL W10154209 $72.22

2

W11164114 Whirlpool Screw Backorder WPL W11164114 $4.53

2

WP74005546 Whirlpool RU Spacer Backorder WPL WP74005546 $6.56

2

WP74009099 Whirlpool Orifice Holder Backorder WPL WP74009099 $117.36

2

Heat Shield, Visor (Black) WPL 74010577 Contact Us For Availability

2

Heat Shield, Visor (White) WPL 74010578 Contact Us For Availability

2

Heat Shield,Visor (Biscuit) WPL 74010579 Contact Us For Availability

2

Holder, Orifice (CTR) WPL 7527P09760 Contact Us For Availability

2

Holder, Orifice (LF) WPL 7527P10160 Contact Us For Availability

2

Holder, Orifice (LR) WPL 7527P12560 Contact Us For Availability

3

74008761 Whirlpool Spacer Snap-In Backorder WPL 74008761 $8.89

3

WPW10160634 Whirlpool Membrane Switch Backorder WPL WPW10160634 $188.87

3

Handle, Door (White) WPL W10153013 Contact Us For Availability

3

Handle, Door (Biscuit) WPL W10153014 Contact Us For Availability

3

Handle, Door (Black) WPL W10153015 Contact Us For Availability

3

Handle, Door (S.Steel) WPL W10153016 Contact Us For Availability

3

PANEL, BACKGUARD & SWITCH ASSY (BISCUIT) WPL W10218263 Contact Us For Availability

3

Support, Oven Bottom WPL 3807P68045 Contact Us For Availability

4

74009098 Whirlpool Spark Module In Stock WPL 74009098 $180.03

4

WP3405F037-80 Whirlpool Utility Drawer Backorder WPL WP3405F037-80 $284.89

4

Liner, Door WPL 74008926 Contact Us For Availability

4

Tubing, Main Supply WPL 74008829 Contact Us For Availability

4

PANEL, SIDE (2) (BISCUIT) WPL 74008708 Contact Us For Availability

4

Panel, Side (2) (White) WPL 74008709 Contact Us For Availability

4

Panel, Side (2) (Black) WPL 74008710 Contact Us For Availability

5

5171P936-60 Whirlpool Wire Harness Backorder WPL 5171P936-60 $173.65

5

74003645 Whirlpool Range Oven Door Inner Glas In Stock WPL 74003645 $105.30

5

Cover, Upper WPL 74010983 Contact Us For Availability

5

Harness, Igniter Includes Switches WPL 7403P98360 Contact Us For Availability

5

PLATE, CONVECT WPL 74005783 Contact Us For Availability

6

WP74009958 Whirlpool Spark Electrode Assembly In Stock WPL WP74009958 $17.29

6

Tape, White WPL 74004224 Contact Us For Availability

6

Shield, Vent WPL 74009444 Contact Us For Availability

6

Fan, Convect WPL 74009142 Contact Us For Availability

7

WP3801F656-51 Whirlpool Range Anti-Tip Bracke In Stock WPL WP3801F656-51 $3.70

7

WPW10160372 Whirlpool Knob Backorder WPL WPW10160372 $24.78

7

WPW10160374 Whirlpool Knob Backorder WPL WPW10160374 $22.18

7

WPW10160375 Whirlpool Oven Control Knob In Stock WPL WPW10160375 $28.67

7

Knob, Control (5) (Biscuit) WPL W10160373 Contact Us For Availability

7

Control WPL W10178396 Contact Us For Availability

7

Pipe, Manifold WPL 7513P49960 Contact Us For Availability

7

Panel, Drawer Frnt (White) WPL W10159223 Contact Us For Availability

7

Panel, Drawer Frnt (Black) WPL W10159224 Contact Us For Availability

7

Panel, Drawer Frnt (Biscuit) WPL W10159225 Contact Us For Availability

8

74010751 Whirlpool Oven 16K Valve Backorder WPL 74010751 $149.05

8

WP7502P499-60 Whirlpool Burner Valve Backorder WPL WP7502P499-60 $236.52

8

WP90767 Whirlpool Screw In Stock WPL WP90767 $3.46

8

Insulation, Door WPL 74003647 Contact Us For Availability

8

Valve (LR/RR/CTR) WPL 74010752 Contact Us For Availability

8

Panel, Inner WPL 74009519 Contact Us For Availability

8

FRAME, FRONT (NOT SERVICED) WPL NP Contact Us For Availability

9

7103P030-60 Whirlpool Wing Nut Backorder WPL 7103P030-60 $7.55

9

WP74010551 Whirlpool Receiver Backorder WPL WP74010551 $8.30

9

Screw (8) WPL 7101P68560 Contact Us For Availability

9

Retainer, Insulation WPL 3601F38051 Contact Us For Availability

9

Bracket, Control WPL 3801F94551 Contact Us For Availability

9

Drawer, Stop WPL 74008688 Contact Us For Availability

74010546 Whirlpool Range Oven Door Hinge In Stock WPL 74010546 $57.19

W11233072 Whirlpool Screw In Stock WPL W11233072 $10.90

W11665456 Whirlpool Range Level Foot In Stock WPL W11665456 $12.84

Burner, Broiler WPL 74008820 Contact Us For Availability

Screw WPL 7101P07260 Contact Us For Availability

WPW10211368 Whirlpool Oven Bottom Backorder WPL WPW10211368 $215.64

Glass, Outer Door (Black) WPL W10182773 Contact Us For Availability

Glass, Outer Door (White) WPL W10182776 Contact Us For Availability

GLASS, OUTER DOOR (BISCUIT) WPL W10183574 Contact Us For Availability

Cover, Main Wire WPL 74009652 Contact Us For Availability

Burner, Bake WPL 31945701 Contact Us For Availability

Rail, Drawer WPL 3406P03451 Contact Us For Availability

12001655 Whirlpool Oven Sensor In Stock WPL 12001655 $24.34

Trim, Door Side (Black) WPL 74010560 Contact Us For Availability

Trim, Door Side (White) WPL 74010561 Contact Us For Availability

Trim, Door Side (Biscuit) WPL 74010562 Contact Us For Availability

Bottom, Wire Cover WPL 74008867 Contact Us For Availability

Valve/Regulator WPL 74010218 Contact Us For Availability

Shaft, Storage Drawer Roller WPL 74005231 Contact Us For Availability

74007498 Whirlpool Range Flat Igniter In Stock WPL 74007498 $40.93

WP74004078 Whirlpool Door Roller In Stock WPL WP74004078 $5.15

WP7432P136-60 Whirlpool Oven Igniter In Stock WPL WP7432P136-60 $56.23

WP98008545 Whirlpool Screw Backorder WPL WP98008545 $3.38

Baffle, Burner WPL 74008846 Contact Us For Availability

74008830 Whirlpool Oven Broil Tubing Backorder WPL 74008830 $55.30

WP3608F092-71 Whirlpool Bottom Trim Backorder WPL WP3608F092-71 $56.68

TRIM, LOWER DOOR (BISCUIT) WPL 74008758 Contact Us For Availability

Trim, Lower Door (Black) WPL 74008889 Contact Us For Availability

Nut WPL 7103P08260 Contact Us For Availability

Screw WPL 7101P33860 Contact Us For Availability

74008818 Whirlpool Broil Burner Fitting Backorder WPL 74008818 $53.07

WP74009025 Whirlpool Double Sided Tape Backorder WPL WP74009025 $7.72

Tape, Double Sided (White) WPL 74009014 Contact Us For Availability

Plate, Conduit WPL 3605F14651 Contact Us For Availability

16

WPY706189 Whirlpool Stove Screw In Stock WPL WPY706189 $3.22

16

Cover, Igniter WPL 4005F42145 Contact Us For Availability

16

Panel, Access WPL 74008340 Contact Us For Availability

WP7101P434-60 Whirlpool Screw Backorder WPL WP7101P434-60 $4.77

ORIFICE, BURNER (CENTER) WPL 7509P12060 Contact Us For Availability

ORIFICE, BURNER (LR/RR) WPL 7509P12260 Contact Us For Availability

ORIFICE, BURNER (LEFT FRONT) WPL 7509P12360 Contact Us For Availability

ORIFICE, BURNER (RIGHT FRONT) WPL 7509P12460 Contact Us For Availability

18

Bracket, Handle (Right) WPL 3801P85745 Contact Us For Availability

18

Bracket, Handle (Left) WPL 3801P85845 Contact Us For Availability

18

Cover, Broil WPL 74009653 Contact Us For Availability

19

Insulation, Corner WPL 7002P48460 Contact Us For Availability

19

Cover, Lower Wire WPL 31955101 Contact Us For Availability

20

Tape, Foil (3``) WPL 8270P09060 Contact Us For Availability

20

Screw WPL 7101P02760 Contact Us For Availability

20

Back, Main WPL 74011911 Contact Us For Availability

21

3801F886-51 Whirlpool Mounting Bracket Backorder WPL 3801F886-51 $25.12

21

74008834 Whirlpool Oven Orifice Holder Backorder WPL 74008834 $47.71

21

W11562931 Whirlpool Door Gasket In Stock WPL W11562931 $43.61

22

3601P336-45 Whirlpool Burner Baffle Backorder WPL 3601P336-45 $174.71

22

WP3400029 Whirlpool Dishwasher Nut In Stock WPL WP3400029 $4.51

22

Screw WPL 7101P33660 Contact Us For Availability

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $2.85

Spacer, Handle (Black) WPL W10169552 Contact Us For Availability

Spacer, Handle (White) WPL W10169553 Contact Us For Availability

Spacer, Handle (Biscuit) WPL W10169554 Contact Us For Availability

Screw WPL 7101P35260 Contact Us For Availability

24

74008835 Whirlpool Clip Retainer Backorder WPL 74008835 $7.55

25

Cord, Power WPL 74008876 Contact Us For Availability

26

Bracket, Oven Bottom WPL 74008694 Contact Us For Availability

28

WP74011278 Whirlpool Light Backorder WPL WP74011278 $78.30

29

Bulb, Oven Light WPL 7407P10360 Contact Us For Availability

30

Latch, Door Lock WPL 8002P10460 Contact Us For Availability

31

Retainer, Insulation WPL 3804F31651 Contact Us For Availability

32

Shield, Heat WPL 3604P40951 Contact Us For Availability

33

WP74003976 Whirlpool Screw Backorder WPL WP74003976 $4.77

34

Bracket, Oven WPL 74011187 Contact Us For Availability

35

74003975 Whirlpool Screw P1 (8ABX3/8-BLK) Backorder WPL 74003975 $10.90

36

Insulation WPL 7002P49460 Contact Us For Availability

38

Screw (4) WPL 7101P28260 Contact Us For Availability

39

Bracket, Oven Support WPL 3801P79851 Contact Us For Availability

40

SCREW WPL 74005401 Contact Us For Availability

42

Insulator, Shield WPL 74008704 Contact Us For Availability

43

Screw WPL 74008798 Contact Us For Availability

242831 Whirlpool Oven Wire Backorder WPL 242831 $423.65

285006 Whirlpool Spray In Stock WPL 285006 $31.20

350930 Whirlpool White Spray Paint In Stock WPL 350930 $14.72

350942 Whirlpool Spray Paint Backorder WPL 350942 $50.73

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $7.51

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $30.92

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $24.57

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.79

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $6.37

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $146.78

8019P026-60 Whirlpool Clip Backorder WPL 8019P026-60 $11.73

8212471 Whirlpool Oven Paint In Stock WPL 8212471 $39.00

WP74008871 Whirlpool Orifice Assembly Backorder WPL WP74008871 $53.08

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $34.75

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, BLUE 14 G WPL 242821 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, BROWN 14 WPL 242822 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, GREEN 14 WPL 242823 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, ORANGE 14 WPL 242824 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, RED 14 GA WPL 242825 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, YELLOW 14 WPL 242827 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, BLACK 12 WPL 242828 Contact Us For Availability

SPLICING WIRES--25FT. LENGTH (WIRE, BROWN 14 WPL 242830 Contact Us For Availability

REFINISHING MATERIAL (GREASE) WPL 261582 Contact Us For Availability

PAINT, BULK (1 QT.) (BISCUIT (UNCUT)) WPL 4392900 Contact Us For Availability

WPL 5171P89360 WPL 5171P89360 Contact Us For Availability

WPL 799340 WPL 799340 Contact Us For Availability

WPL 799832 WPL 799832 Contact Us For Availability

Insulation, Back WPL 7002P49260 Contact Us For Availability

Insulation, Wrap WPL 74008700 Contact Us For Availability
