Model Whirlpool 665.68611891 Microwave/Hood Combo (Kenmore 66568611891) – Common Parts &amp; Diagrams

1

Deflct-ar WPL 4393807 Contact Us For Availability

1

Reflector WPL 4393810 Contact Us For Availability

1

Microwave Door Film WPL 4393870 Contact Us For Availability

2

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $6.34

2

Stirrer Shaft WPL 4393794 Contact Us For Availability

2

Reflector WPL 4393677 Contact Us For Availability

2

Choke Cover WPL 8169300 Contact Us For Availability

3

6800 Whirlpool Charcoal Filter Kit Backorder WPL 6800 $22.04

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $44.61

3

Microwave Door Latch WPL 4393913 Contact Us For Availability

3

Stirrer Blade WPL 8169330 Contact Us For Availability

3

Air Duct WPL 4393915 Contact Us For Availability

4

6802A Whirlpool Grease Filter In Stock WPL 6802A $18.42

4

Disk Holder WPL 4393749 Contact Us For Availability

4

Coverplate WPL 4393714 Contact Us For Availability

4

Thermostat Bracket WPL 4393679 Contact Us For Availability

4

Microwave Door WPL 4393722 Contact Us For Availability

4A

Microwave Door WPL 4393723 Contact Us For Availability

4B

Microwave Door WPL 4393724 Contact Us For Availability

5

Stirrer Cover WPL 4393750 Contact Us For Availability

5

Thermostat WPL 4393945 Contact Us For Availability

5

Base WPL 8169315 Contact Us For Availability

5

Door Glass WPL 4393811 Contact Us For Availability

5A

Door Glass WPL 8169323 Contact Us For Availability

5B

Door Glass WPL 8169301 Contact Us For Availability

6

W10315274 Whirlpool Microwave Meal Rack Backorder WPL W10315274 $33.69

6

Power Cord WPL 4393793 Contact Us For Availability

6

Housing WPL 4393680 Contact Us For Availability

6

Lamp Glass WPL 4393693 Contact Us For Availability

6

Panel WPL 4393814 Contact Us For Availability

6A

Panel WPL 4393815 Contact Us For Availability

6B

Panel WPL 4393816 Contact Us For Availability

7

4393823 Whirlpool Microwave Door Handle Backorder WPL 4393823 $145.61

7

Nail WPL 4393291 Contact Us For Availability

7

Wrapper Cabinet WPL 4393717 Contact Us For Availability

7

Light Cover WPL 8169316 Contact Us For Availability

7A

Microwave Door Handle (Black) WPL 4393824 Contact Us For Availability

7A

Wrapper Cabinet WPL 4393718 Contact Us For Availability

7B

Wrapper Cabinet WPL 4393719 Contact Us For Availability

7B

Microwave/Hood Door Handle WPL 4393825 Contact Us For Availability

8

Microwave Turntable Tray WPL 4393799 No Longer Available

8

8184599 Whirlpool Microwave Vent Grille Backorder WPL 8184599 $53.88

8

Microwave Screw WPL 4393833 Contact Us For Availability

8

Fan Wheel WPL 4393682 Contact Us For Availability

8

Air Guide WPL 4393695 Contact Us For Availability

8A

8184600 Whirlpool Microwave Vent Grille Backorder WPL 8184600 $53.88

9

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $4.82

9

8206334 Whirlpool Microwave Mounting Bracket In Stock WPL 8206334 $5.54

9

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $36.06

9

Fan Motor WPL 4393789 Contact Us For Availability

9

Lid Fan WPL 4393696 Contact Us For Availability

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $40.52

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $4.82

Microwave Turntable Tray Support Wheel WPL 4393861 Contact Us For Availability

Shield WPL 4393683 Contact Us For Availability

10A

8169573 Whirlpool Microwave Door Frame Backorder WPL 8169573 $187.80

10B

Door Frame WPL 8169302 Contact Us For Availability

11

W10435116 Whirlpool Microwave Turntable Rolle In Stock WPL W10435116 $23.67

11

Housng-blw WPL 4393684 Contact Us For Availability

11

Spring WPL 4393914 Contact Us For Availability

12

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $73.80

12

Cam Plate WPL 4393597 Contact Us For Availability

13

8205572 Whirlpool Microwave Interlock In Stock WPL 8205572 $4.82

13

Terminal Cover WPL 4393756 Contact Us For Availability

13

Release Rod WPL 8169318 Contact Us For Availability

14

W10245183 Whirlpool Microwave Magnetron In Stock WPL W10245183 $146.95

14

Latch WPL 8169319 Contact Us For Availability

14

Fan Wheel WPL 8169317 Contact Us For Availability

Microwave Thermal Cut-Off WPL 4393943 Contact Us For Availability

E-Ring WPL 8169320 Contact Us For Availability

Screw WPL 4393830 Contact Us For Availability

Housing WPL 4393699 Contact Us For Availability

Connector WPL 4393797 Contact Us For Availability

Screw WPL 4393828 Contact Us For Availability

Catch WPL 8169321 Contact Us For Availability

Fan Motor WPL 4393700 Contact Us For Availability

17

Connector WPL 4393686 Contact Us For Availability

17

Spring WPL 8169322 Contact Us For Availability

17

Base WPL 4393701 Contact Us For Availability

18

Screw WPL 4393838 Contact Us For Availability

18

Capacitor Bracket WPL 4393702 Contact Us For Availability

19

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $19.71

20

W10850446 Whirlpool Microwave Magnetron Capac In Stock WPL W10850446 $123.23

20

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $4.99

21

Microwave Turntable Motor Screw WPL 4393832 Contact Us For Availability

21

Transformer WPL 4393809 Contact Us For Availability

22

Plate WPL 4393705 Contact Us For Availability

23

Mounting Plate WPL 4393706 Contact Us For Availability

24

Resistor WPL 4393707 Contact Us For Availability

25

Plate WPL 4393708 Contact Us For Availability

26

Microwave Vent Motor Capacitor WPL 4393709 Contact Us For Availability

27

Fuse Block WPL 4393538 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $35.86

29

Thermostat WPL 4393710 Contact Us For Availability

30

Screw WPL 4393827 Contact Us For Availability

32

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $15.81

34

Screw WPL 4393346 Contact Us For Availability

35

Ul-switch WPL 4393448 Contact Us For Availability

36

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $6.28

37

Screw WPL 4393839 Contact Us For Availability

Filler Panel (Black) WPL 4158311 Contact Us For Availability

Filler Panel (White) WPL 4158439 Contact Us For Availability

Filler Panel WPL 4378403 Contact Us For Availability

Mounting Hardware WPL 4393757 Contact Us For Availability

Meat Rack WPL 4393826 Contact Us For Availability

Trmplate WPL 8169298 Contact Us For Availability

Template WPL 8169299 Contact Us For Availability

Cook Guide WPL LIT4393454 Contact Us For Availability

Technical Sheet WPL LIT4393767 Contact Us For Availability

Installation Instructions WPL LIT4393804 Contact Us For Availability

Owner's Manual WPL LIT4393853 Contact Us For Availability
