Model Electrolux 253.77189504 Refrigerator (Kenmore 25377189504) – Common Parts &amp; Diagrams

2

240367001 Frigidaire Refrigerator Air Damper Backorder WCI 240367001 $39.89

4

Refrigerator Freezer Fan Cover Damper WCI 241523701 Contact Us For Availability

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $43.01

9

Refrigerator Evaporator Fan Motor Bracket, Fr WCI 5303292396 Contact Us For Availability

10

240381301 Frigidaire Refrigerator Button Plug In Stock WCI 240381301 $13.11

10

240381303 Frigidaire Hinge Plug Backorder WCI 240381303 $48.29

11

5303208309 Frigidaire Refrigerator Plug Hole In Stock WCI 5303208309 $31.49

11

Refrigerator Freezer Wire Shelf WCI 240358006 Contact Us For Availability

11

Kenmore Pro Refrigerator Ice Maker Thermal Cu WCI 3206319 Contact Us For Availability

12

240545901 Frigidaire Refrigerator Air Diffuse Backorder WCI 240545901 $51.96

240312421 Frigidaire Refrigerator Door Stop Backorder WCI 240312421 $10.49

240312422 Frigidaire Refrigerator Door Stop Backorder WCI 240312422 $10.49

240362601 Frigidaire Refrigerator P1 Diffuser In Stock WCI 240362601 $30.96

Refrigerator Ice Maker Thermostat WCI 3206322 Contact Us For Availability

13A

240312414 Frigidaire Refrigerator Door Stop Backorder WCI 240312414 $14.16

13A

Refrigerator Door Stop WCI 240312406 Contact Us For Availability

240356217 Frigidaire Refrigerator Defrost Hea Backorder WCI 240356217 $80.84

240438003 Frigidaire Refrigerator Bracket and Backorder WCI 240438003 $12.06

240494001 Frigidaire Refrigerator Plug Button In Stock WCI 240494001 $12.59

240494003 Frigidaire Refrigerator Button Plug In Stock WCI 240494003 $12.59

241554901 Frigidaire Refrigerator Light/Lamp In Stock WCI 241554901 $57.24

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $12.40

15

5303918274 Frigidaire Refrigerator Evaporator In Stock WCI 5303918274 $236.59

16

241559801 Frigidaire Light Socket Refrigerato Backorder WCI 241559801 $55.30

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.49

18

218779901 Frigidaire Refrigerator White Fresh In Stock WCI 218779901 $49.02

18

Refrigerator Door Handle (Charcoal Gray) WCI 218779903 Contact Us For Availability

18

Refrigerator Temperature Control Knob WCI 240360801 Contact Us For Availability

18A

Refrigerator Freezer Door Handle Assembly (Wh WCI 218779812 Contact Us For Availability

18A

Refrigerator Freezer Door Handle Assembly (Ch WCI 218779814 Contact Us For Availability

20

241551902 Frigidaire Refrigerator Insulation Backorder WCI 241551902 $8.39

21

240383407 Frigidaire Refrigerator Screw Backorder WCI 240383407 $9.44

21

240383408 Frigidaire Refrigerator Screw In Stock WCI 240383408 $9.94

21

5303918202 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918202 $14.94

21A

240521303 Frigidaire Refrigerator Screw In Stock WCI 240521303 $12.18

215774901 Frigidaire Refrigerator Button Plug In Stock WCI 215774901 $12.59

215774918 Frigidaire Refrigerator Button Plug Backorder WCI 215774918 $6.81

5304507146 Frigidaire Refrigerator Hinge Bear In Stock WCI 5304507146 $6.08

5304507147 Frigidaire Refrigerator Hinge Bear In Stock WCI 5304507147 $5.10

22A

240468202 Frigidaire Refrigerator Tube Backorder WCI 240468202 $6.29

23

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $31.49

24

240358928 Frigidaire Refrigerator Spill Safe Backorder WCI 240358928 $123.62

25

Freezer Compressor Mounting Bolt WCI 240491503 Contact Us For Availability

25B

241613501 Frigidaire Refrigerator Humidity Co Backorder WCI 241613501 $8.91

25C

241613502 Frigidaire Refrigerator Humidity Co Backorder WCI 241613502 $33.06

26

240343803 Frigidaire Refrigerator Clear Crisp In Stock WCI 240343803 $121.19

34

240311303 Frigidaire Refrigerator Nylon Hinge In Stock WCI 240311303 $9.26

34

240385201 Frigidaire Refrigerator Ice Contain In Stock WCI 240385201 $88.47

34

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $14.69

35

240313803 Frigidaire Refrigerator Center Hing Backorder WCI 240313803 $119.16

35

Refrigerator Door Hinge, Center WCI 240313806 Contact Us For Availability

35A

240336802 Frigidaire Refrigerator Hinge Space Backorder WCI 240336802 $13.64

35A

240336803 Frigidaire Refrigerator Hinge Space Backorder WCI 240336803 $8.39

37

Refrigerator Corner Trim (Black) WCI 240337603 Contact Us For Availability

37A

Refrigerator Door Handle Trim WCI 218771201 Contact Us For Availability

37A

Refrigerator Door Handle Trim Cap (Black) WCI 218771203 Contact Us For Availability

40

240354401 Frigidaire Upper Hinge Cover Backorder WCI 240354401 $43.39

40

240354404 Frigidaire Refrigerator Upper Hinge In Stock WCI 240354404 $43.39

41

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $9.96

41

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.71

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $10.49

47

Refrigerator Glass Shelf WCI 240350689 Contact Us For Availability

48

240338101 Frigidaire Refrigerator Bottom Door In Stock WCI 240338101 $36.90

48A

240338201 Frigidaire Refrigerator Door Bin In Stock WCI 240338201 $48.87

49

240495804 Frigidaire Refrigerator Replacement In Stock WCI 240495804 $33.59

56

240516502 Frigidaire Refrigerator Lower Hinge Backorder WCI 240516502 $50.39

59

240442707 Frigidaire Refrigerator Screw #10-3 Backorder WCI 240442707 $2.09

59

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $5.76

60

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $8.91

61

218721500 Frigidaire Refrigerator Leveling Br Backorder WCI 218721500 $54.06

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $15.37

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $7.86

73

218396700 Frigidaire Door Handle Mounting Blo In Stock WCI 218396700 $39.05

74

Refrigerator Screw WCI 215503204 Contact Us For Availability

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $10.49

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $35.90

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $26.16

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $46.71

89

241733911 Frigidaire Refrigerator Access Cove In Stock WCI 241733911 $43.51

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $9.96

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $10.49

218515401 Frigidaire Refrigerator Clip Backorder WCI 218515401 $13.11

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $22.04

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.61

240388701 Frigidaire Refrigerator Wiring Harn Backorder WCI 240388701 $59.31

240396801 Frigidaire Refrigerator Tube Clamp Backorder WCI 240396801 $14.16

240561701 Frigidaire Refrigerator Seal In Stock WCI 240561701 $15.21

240568606 Frigidaire Refrigerator Coil Cover Backorder WCI 240568606 $9.44

5303321319 Frigidaire Refrigerator White Touc In Stock WCI 5303321319 $9.96

5303321321 Frigidaire Refrigerator Black Touc In Stock WCI 5303321321 $16.26

5303918330 Frigidaire Refrigerator Heat Excha In Stock WCI 5303918330 $248.21

Hot Tube WCI 5304421289 Contact Us For Availability
