Model Electrolux PHT189JKM3 REFRIGERATOR – Common Parts &amp; Diagrams

1

241785404 Frigidaire Refrigerator Condenser Backorder WCI 241785404 $132.53

1

241872503 Frigidaire Freezer Door Gasket (Sin In Stock WCI 241872503 $119.99

2

240367001 Frigidaire Refrigerator Air Damper In Stock WCI 240367001 $42.13

4

WCI 241523701 WCI 241523701 Contact Us For Availability

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $44.94

7

240338313 Frigidaire Refrigerator Dairy Door In Stock WCI 240338313 $63.21

9

WCI 5303292396 WCI 5303292396 Contact Us For Availability

10

WCI 241652213 WCI 241652213 Contact Us For Availability

11

5303208309 Frigidaire Refrigerator Plug Hole Backorder WCI 5303208309 $33.28

12

241542001 Frigidaire Refrigerator Deflector In Stock WCI 241542001 $58.25

12

WCI 241808801 WCI 241808801 Contact Us For Availability

240312422 Frigidaire Refrigerator Door Stop Backorder WCI 240312422 $11.09

240362601 Frigidaire Refrigerator P1 Diffuser Backorder WCI 240362601 $32.71

241854501 Frigidaire Refrigerator Evaporator Backorder WCI 241854501 $136.45

5304456665 Frigidaire Refrigerator Thermostat In Stock WCI 5304456665 $98.14

13A

WCI 240312406 WCI 240312406 Contact Us For Availability

14

240356221 Frigidaire Refrigerator Defrost Hea Backorder WCI 240356221 $85.42

14

240438003 Frigidaire Refrigerator Bracket and Backorder WCI 240438003 $12.75

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $14.94

15

5303918274 Frigidaire Refrigerator Evaporator In Stock WCI 5303918274 $296.15

15

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $67.67

15A

241552802 Frigidaire Refrigerator Light Bulb Backorder WCI 241552802 $31.06

16

240364201 Frigidaire Refrigerator Light/Lamp Backorder WCI 240364201 $75.98

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $48.81

16A

241622802 Frigidaire Refrigerator Light Socke Backorder WCI 241622802 $46.57

17

241801301 Frigidaire Refrigerator Drain Troug Backorder WCI 241801301 $47.14

18

WCI 240360801 WCI 240360801 Contact Us For Availability

20

241551902 Frigidaire Refrigerator Insulation Backorder WCI 241551902 $8.85

21

241537103 Frigidaire Refrigerator Temperature In Stock WCI 241537103 $45.28

21

5303918202 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918202 $13.58

22

241665606 Frigidaire Refrigerator Compressor Backorder WCI 241665606 $142.00

22

5304507147 Frigidaire Refrigerator Hinge Bear In Stock WCI 5304507147 $5.52

22A

240468202 Frigidaire Refrigerator Tube Backorder WCI 240468202 $6.63

23

218513300 Frigidaire Refrigerator Compressor Backorder WCI 218513300 $33.26

24

241812301 Frigidaire Refrigerator Compressor Backorder WCI 241812301 $9.44

24

5304456675 Frigidaire Refrigerator Lever Arm Backorder WCI 5304456675 $52.12

24A

241616607 Frigidaire Refrigerator Spill Safe In Stock WCI 241616607 $133.01

25

240364787 Frigidaire Refrigerator Crisper Pan In Stock WCI 240364787 $94.84

25B

241613501 Frigidaire Refrigerator Humidity Co Backorder WCI 241613501 $9.42

25C

241613502 Frigidaire Refrigerator Humidity Co Backorder WCI 241613502 $34.91

26

240337103 Frigidaire Crisper Drawer In Stock WCI 240337103 $119.06

26

241920605 Frigidaire Refrigerator Defrost Pan In Stock WCI 241920605 $40.11

31

240530811 Frigidaire Refrigerator Meat Crispe In Stock WCI 240530811 $118.84

32

297030500 Frigidaire Refrigerator Clip Backorder WCI 297030500 $9.40

34

240311303 Frigidaire Refrigerator Nylon Hinge In Stock WCI 240311303 $8.42

34

240385201 Frigidaire Refrigerator Ice Contain In Stock WCI 240385201 $97.65

34

240405201 Frigidaire Refrigerator Grommet In Stock WCI 240405201 $13.71

35

240313802 Frigidaire Refrigerator Center Hing In Stock WCI 240313802 $54.90

35A

240336802 Frigidaire Refrigerator Hinge Space Backorder WCI 240336802 $14.40

41

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.98

42

240356501 Frigidaire Tray Hanger Pan In Stock WCI 240356501 $44.09

42

240365401 Frigidaire Refrigerator Left-Hand M Backorder WCI 240365401 $45.51

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $11.07

48

240338101 Frigidaire Refrigerator Bottom Door In Stock WCI 240338101 $43.99

48A

241808201 Frigidaire Refrigerator Door Bin In Stock WCI 241808201 $62.67

49

240495805 Frigidaire Freezer Door Bar In Stock WCI 240495805 $39.94

56

240516502 Frigidaire Refrigerator Lower Hinge In Stock WCI 240516502 $53.25

59

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $6.09

60

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $9.44

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $16.05

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $8.31

74

WCI 240354302 WCI 240354302 Contact Us For Availability

79

218755402 Frigidaire Refrigerator Set Screw In Stock WCI 218755402 $4.86

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $10.50

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $11.09

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $35.90

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $28.21

84

240500801 Frigidaire Refrigerator Drain Tube Backorder WCI 240500801 $51.03

85

WCI 241871501 WCI 241871501 Contact Us For Availability

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $49.36

89

241733911 Frigidaire Refrigerator Access Cove In Stock WCI 241733911 $38.14

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $10.53

114

241554901 Frigidaire Refrigerator Light/Lamp In Stock WCI 241554901 $52.78

123

215005101 Frigidaire Refrigerator Screw Backorder WCI 215005101 $11.64

136

WCI 241657701 WCI 241657701 Contact Us For Availability

142

WCI 241562202 WCI 241562202 Contact Us For Availability

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $16.59

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $11.07

240346701 Frigidaire Refrigerator Foam Seal T In Stock WCI 240346701 $23.27

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.76

240396801 Frigidaire Refrigerator Tube Clamp Backorder WCI 240396801 $14.99

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $16.07

241500305 Frigidaire Refrigerator Screw In Stock WCI 241500305 $1.61

241798231 Frigidaire Refrigerator Ice Maker A In Stock WCI 241798231 $144.03

5303321319 Frigidaire Refrigerator White Touc Backorder WCI 5303321319 $11.30

5303918263 Frigidaire Refrigerator Primary He In Stock WCI 5303918263 $418.86

WCI 5303918222 WCI 5303918222 Contact Us For Availability
