Model Whirlpool MH1140XMB0 MICROWAVE HOOD COMBINATION – Common Parts &amp; Diagrams

1

Cover, Inlet WPL 8185117 Contact Us For Availability

1

Film, Back WPL 4393870 Contact Us For Availability

1

Deflector, Air WPL 8185096 Contact Us For Availability

1

Literature Parts (Installation Instructions) WPL LIT8184732 Contact Us For Availability

1

Literature Parts (Use & Care Guide) WPL LIT8184979 Contact Us For Availability

1

Literature Parts (Cook Guide Label) WPL LIT8184988 Contact Us For Availability

1

Literature Parts (Tech Sheet) WPL LIT8184995 Contact Us For Availability

2

Frame, Inner WPL 8169545 Contact Us For Availability

2

Cover (4) WPL 8169448 Contact Us For Availability

2

Socket, Motor Wire WPL 8185097 Contact Us For Availability

2

Lens WPL 4393739 Contact Us For Availability

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $50.07

3

Latch, Door WPL 4393913 Contact Us For Availability

3

Nail, Plastic WPL 4393291 Contact Us For Availability

3

Base Plate WPL 8185116 Contact Us For Availability

3

Panel, Control (White) WPL 8185235 Contact Us For Availability

3

Panel, Control (Black) WPL 8185236 Contact Us For Availability

4

Turntable WPL 4393799 No Longer Available

4

Body, Door (Includes 1) (White) WPL 8185107 Contact Us For Availability

4

Body, Door (Includes 1) (Black) WPL 8185109 Contact Us For Availability

4

Air Guide (Right) WPL 8185098 Contact Us For Availability

4

Bracket, Control WPL 8183821 Contact Us For Availability

5

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $23.22

5

Glass, Outer WPL 4393725 Contact Us For Availability

5

Thermostat WPL 4393945 Contact Us For Availability

5

Plate, Hinge WPL 4393744 Contact Us For Availability

6

8185233 Whirlpool Microwave Door Panel In Stock WPL 8185233 $193.19

6

8185234 Whirlpool Microwave Door Panel Backorder WPL 8185234 $224.67

6

W10708076 Whirlpool Microwave Power Cord In Stock WPL W10708076 $5.77

6

Wheel, Plastic WPL 4393861 Contact Us For Availability

6

Deflector, Cooling Air WPL 8185099 Contact Us For Availability

6

PCB Assembly WPL 8185237 Contact Us For Availability

7

4393777 Whirlpool Microwave Door Handle - Whi In Stock WPL 4393777 $65.76

7

4393782 Whirlpool Microwave Door Handle In Stock WPL 4393782 $79.01

7

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $3.39

7

W10435116 Whirlpool Microwave Turntable Rolle Backorder WPL W10435116 $16.57

7

Case, Outer (White) WPL 8185091 Contact Us For Availability

7

Case, Outer (Black) WPL 8185093 Contact Us For Availability

8

8183851 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183851 $30.78

8

8183948 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183948 $29.01

8

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $88.39

8

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $10.17

8

Cooling Air Guide WPL 8185215 Contact Us For Availability

8

Screw WPL 4393346 Contact Us For Availability

9

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $3.22

9

8206334 Whirlpool Microwave Mounting Bracket In Stock WPL 8206334 $2.83

9

Cover, Terminal WPL 4393756 Contact Us For Availability

9

Motor, Fan WPL 8184825 Contact Us For Availability

9

Foil, PCB WPL 8185122 Contact Us For Availability

W10844213 Whirlpool Microwave Magnetron Backorder WPL W10844213 $200.18

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $4.77

SHIELD WPL 8185101 Contact Us For Availability

Switch, Membrane (White) WPL 8185240 Contact Us For Availability

Switch, Membrane (Black) WPL 8185241 Contact Us For Availability

11

Spring, Interlock (2) WPL 8169438 Contact Us For Availability

11

Thermostat WPL 8184829 Contact Us For Availability

11

Air Guide, Sealing Plate WPL 8185114 Contact Us For Availability

12

Plate, Cam (2) WPL 8183824 Contact Us For Availability

12

Screw WPL 4393828 Contact Us For Availability

13

Screw WPL 4393838 Contact Us For Availability

13

Rod WPL 8169318 Contact Us For Availability

14

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $3.22

14

Screw WPL 8169478 Contact Us For Availability

14

Latch, Pivot WPL 8169319 Contact Us For Availability

15

Screw WPL 4393833 Contact Us For Availability

15

Screw WPL 4393830 Contact Us For Availability

15

E-Ring WPL 8169320 Contact Us For Availability

16

Bushing, Nail WPL 4393290 Contact Us For Availability

16

Air Guide (Left) WPL 8185115 Contact Us For Availability

16

Catch WPL 8185033 Contact Us For Availability

17

Cover, Light WPL 8185118 Contact Us For Availability

17

Spring WPL 8169374 Contact Us For Availability

8169539 Whirlpool Microwave Light Bulb Socket Backorder WPL 8169539 $35.16

WP8169704 Whirlpool Screw In Stock WPL WP8169704 $3.50

Installation, Hardware WPL 8169659 Contact Us For Availability

Wall Template WPL 8183743 Contact Us For Availability

Upper Template WPL 8184731 Contact Us For Availability

Cover, Motor WPL 8185090 Contact Us For Availability

Miscellaneous WPL ARI117975A Contact Us For Availability

30

Screw WPL 8169474 Contact Us For Availability

36

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $6.22

37

Screw WPL 4393839 Contact Us For Availability
