Model Whirlpool KSSC36FMS00 36`` BUILT IN REFRIGERATOR – Common Parts &amp; Diagrams

1

Fan Motor WPL 2259385 Contact Us For Availability

1

Literature Parts (Use & Care Guide) WPL LIT2266808 Contact Us For Availability

1

Literature Parts (Installation Instructions) WPL LIT2266811 Contact Us For Availability

1

Literature Parts (Energy Label) WPL LIT2266816 Contact Us For Availability

1

Literature Parts (Service & Wiring Sheet) WPL LIT2300021 Contact Us For Availability

1

Modular Icemaker Service Sheet WPL LIT628370 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI105179A Contact Us For Availability

2

2256250 Whirlpool Refrigerator Shelf Trim Backorder WPL 2256250 $54.61

2

BRACE, DOOR CORNER WPL 2258951 Contact Us For Availability

2

Cabinet (Not A Serviceable Part) WPL ARI105178A Contact Us For Availability

3

2208970 Whirlpool Refrigerator Air Duct In Stock WPL 2208970 $97.38

3

W10841139 Whirlpool Refrigerator Compressor In Stock WPL W10841139 $413.99

3

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $30.99

4

2259081 Whirlpool Refrigerator Basket Backorder WPL 2259081 $219.36

4

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $20.98

4

Spacer-Door, Top WPL 2256381 Contact Us For Availability

4

RETAINER, FAN MOTOR WPL 2155590 Contact Us For Availability

4

Clip, Thermistor WPL 2209204 Contact Us For Availability

4

Housing, Control Board WPL 2257354 Contact Us For Availability

5

W10860229 Whirlpool Refrigerator Support Backorder WPL W10860229 $219.93

5

W10860448 Whirlpool Refrigerator Support Backorder WPL W10860448 $216.57

5

WP2155789 Whirlpool Refrigerator Gasket Backorder WPL WP2155789 $4.82

5

WP2259077 Whirlpool Ladder Assembly Backorder WPL WP2259077 $50.70

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

5

Bracket, Fan Motor WPL 2215641 Contact Us For Availability

6

2259317 Whirlpool Refrigerator Slide Backorder WPL 2259317 $158.71

6

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $19.90

6

8201663 Whirlpool Refrigerator Primary Fan Bl Backorder WPL 8201663 $102.33

6

876811 Whirlpool Grommet Backorder WPL 876811 $4.82

6

WP2259318 Whirlpool Refrigerator Slide Backorder WPL WP2259318 $215.89

6

Suction Tube WPL 2259303 Contact Us For Availability

6

Grommet, Wiring WPL 2005006 Contact Us For Availability

7

2006475 Whirlpool Refrigerator Screw Backorder WPL 2006475 $8.39

7

2222795 Whirlpool Refrigerator Rail Backorder WPL 2222795 $54.62

7

W11474472 Whirlpool Screw In Stock WPL W11474472 $3.91

7

WP8533928 Whirlpool Refrigerator Screw In Stock WPL WP8533928 $6.99

7

Shroud, Condenser (Right) WPL 2266803 Contact Us For Availability

7

Grommet, Flexible WPL 2005007 Contact Us For Availability

8

2259464 Whirlpool Refrigerator Wedge Backorder WPL 2259464 $62.16

8

W11724512 Whirlpool Door Hinge In Stock WPL W11724512 $176.96

8

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $6.17

8

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $42.99

8

WP2222981 Whirlpool Refrigerator Gasket In Stock WPL WP2222981 $140.92

8

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $3.91

8

Tube, Connect (Drier/Restrictor) WPL 2259304 Contact Us For Availability

8

Bracket, Switch WPL 2259096 Contact Us For Availability

9

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $61.35

9

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $5.51

9

Seal, Side Trim WPL 2005925 Contact Us For Availability

9

Glass, Meat Pan Cover WPL 2256276 Contact Us For Availability

9

Mounting Stud, Grill WPL 2006442 Contact Us For Availability

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $67.99

Glass, Crisper Cover WPL 2256426 Contact Us For Availability

Shroud, Condenser (Left) WPL 2259369 Contact Us For Availability

Lid, Meat Pan Baffle WPL 2257528 Contact Us For Availability

W10823805-includeCORE Whirlpool W10823805 Ref Backorder WPL W10823805-includeCORE $455.09

WP489115 Whirlpool Refrigerator Rivet Backorder WPL WP489115 $4.82

Cam, Door Closer WPL 2005783 Contact Us For Availability

Trim, Glass Rear Side WPL 2257611 Contact Us For Availability

Clamp, Nylon WPL 488937 Contact Us For Availability

Baffle Control Assembly WPL 2257526 Contact Us For Availability

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $14.02

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $9.81

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $11.67

WP2209022 Whirlpool Refrigerator Housing In Stock WPL WP2209022 $165.50

Cover WPL 2169935 Contact Us For Availability

2256328 Whirlpool Bracket Assembly Backorder WPL 2256328 $46.45

Door Spacer, Bottom WPL 2257637 Contact Us For Availability

Trim, Glass Rear WPL 2257581 Contact Us For Availability

Jumper, Air Baffle WPL 2187619 Contact Us For Availability

W10407623 Whirlpool Refrigerator Crisper Pan Backorder WPL W10407623 $152.65

W11254898 Whirlpool Refrigerator Scroll Fan Backorder WPL W11254898 $212.50

Screw WPL 3400525 Contact Us For Availability

Screw WPL 488357 Contact Us For Availability

15

2259465 Whirlpool Refrigerator Wedge Backorder WPL 2259465 $64.64

15

EDR5RXD1 Whirlpool Refrigerator Ice and Water In Stock WPL EDR5RXD1 $61.83

15

W11624204 Whirlpool Screw Backorder WPL W11624204 $8.89

16

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $3.91

16

CONDENSER WPL 2259307 Contact Us For Availability

16

Deflector, Air WPL 2266801 Contact Us For Availability

2302954 Whirlpool Refrigerator Slide In Stock WPL 2302954 $221.69

2302955 Whirlpool Refrigerator Slide In Stock WPL 2302955 $221.69

W11769878 Whirlpool Screw Backorder WPL W11769878 $8.39

WP2221240 Whirlpool Refrigerator Heater In Stock WPL WP2221240 $125.60

WP2221296 Whirlpool Air Baffle In Stock WPL WP2221296 $268.89

Air Duct WPL 2259018 Contact Us For Availability

Grommet (4) WPL 943447 Contact Us For Availability

1113048 Whirlpool Refrigerator Clamp Backorder WPL 1113048 $7.19

2257644 Whirlpool Refrigerator Door Hinge Backorder WPL 2257644 $115.07

Trim, Glass Front WPL 2256227 Contact Us For Availability

Wire, Jumper WPL 2187679 Contact Us For Availability

2209066 Whirlpool Refrigerator Fan Block Backorder WPL 2209066 $59.00

8201798 Whirlpool Refrigerator Fan Block Backorder WPL 8201798 $126.77

Screw WPL 487522 Contact Us For Availability

Trim, Glass Rear WPL 2256253 Contact Us For Availability

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $5.99

WP8281250 Whirlpool Refrigerator Screw In Stock WPL WP8281250 $8.99

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $4.99

Gasket, Evaporator WPL 2220832 Contact Us For Availability

2005433 Whirlpool Refrigerator Spacer Backorder WPL 2005433 $14.81

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $37.99

WP2004994 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2004994 $4.82

WP2256247 Whirlpool Front Pan Backorder WPL WP2256247 $79.99

Liner (Not A Serviceable Part) WPL ARI105180A Contact Us For Availability

Diffuser Assembly WPL 2208997 Contact Us For Availability

1116793 Whirlpool Refrigerator Cover Backorder WPL 1116793 $9.15

W10759522 Whirlpool Screw Backorder WPL W10759522 $4.82

WP628356 Whirlpool Refrigerator Fill Cup Backorder WPL WP628356 $29.99

Bushing WPL 2002903 Contact Us For Availability

Pad, Air Baffle WPL 2266805 Contact Us For Availability

2259025 Whirlpool Refrigerator Air Cover Backorder WPL 2259025 $60.06

W10181323 Whirlpool Refrigerator Condenser Fa In Stock WPL W10181323 $220.99

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $25.99

WP627843 Whirlpool Refrigerator Ejector Arm In Stock WPL WP627843 $59.71

Trim, Glass Side WPL 2252255 Contact Us For Availability

Clamp, Filter Housing WPL 2209090 Contact Us For Availability

WP2004517 Whirlpool Refrigerator Spring In Stock WPL WP2004517 $60.46

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $55.70

Blade, Fan WPL 2190685 Contact Us For Availability

Light Shield WPL 2259367 Contact Us For Availability

Spacer, Air Baffle WPL 2259372 Contact Us For Availability

2256222 Whirlpool Refrigerator Track Backorder WPL 2256222 $57.59

2256223 Whirlpool Refrigerator Track Backorder WPL 2256223 $54.61

2309087 Whirlpool Refrigerator Cover Backorder WPL 2309087 $11.41

WP2001264 Whirlpool Refrigerator Drip Pan In Stock WPL WP2001264 $170.91

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $68.41

WP308544 Whirlpool Screw In Stock WPL WP308544 $4.82

Cover, Evaporator WPL 2259067 Contact Us For Availability

Orifice, Fan WPL 2003169 Contact Us For Availability

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.89

WP489236 Whirlpool Refrigerator Ring In Stock WPL WP489236 $7.64

Tube, Drier Transition WPL 2300190 Contact Us For Availability

Cover, Air Return WPL 2259066 Contact Us For Availability

2302956 Whirlpool Refrigerator Slide Backorder WPL 2302956 $203.21

2302957 Whirlpool Refrigerator Slide Backorder WPL 2302957 $155.33

8281160 Whirlpool Screw Backorder WPL 8281160 $5.46

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $71.99

Fastener (3) WPL 1113227 Contact Us For Availability

Seal, Air Duct (Round Hole) WPL 2259412 Contact Us For Availability

2215648 Whirlpool Refrigerator Dampener Backorder WPL 2215648 $8.35

2256243 Whirlpool Refrigerator Track In Stock WPL 2256243 $53.81

2256244 Whirlpool Refrigerator Track Backorder WPL 2256244 $67.29

2259398 Whirlpool Refrigerator Seal Backorder WPL 2259398 $8.23

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $14.99

Tube, Heat Loop Transition WPL 2259301 Contact Us For Availability

Gap, Cover Assembly (Bottom) WPL 2006342 Contact Us For Availability

W10527053 Whirlpool Refrigerator Door Hinge Backorder WPL W10527053 $81.96

WP2006780 Whirlpool Refrigerator Door Hinge Backorder WPL WP2006780 $181.40

WP3400886 Whirlpool Refrigerator Screw Backorder WPL WP3400886 $4.82

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.82

Deflector, Air Duct WPL 2259054 Contact Us For Availability

1112260 Whirlpool EV Support Backorder WPL 1112260 $6.78

W10407626 Whirlpool Refrigerator Meat Pan Backorder WPL W10407626 $120.24

WP2302876 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2302876 $55.57

Housing, Power Supply WPL 2259349 Contact Us For Availability

W11721628 Whirlpool Screw Assembly Backorder WPL W11721628 $8.89

WP2196483 Whirlpool Refrigerator Shelf Stud In Stock WPL WP2196483 $6.50

WP2256365 Whirlpool Refrigerator Front Pan Backorder WPL WP2256365 $107.22

WP2259350 Whirlpool Refrigerator Electronic C Backorder WPL WP2259350 $100.99

32

WP2209024B Whirlpool Refrigerator Front Grill Backorder WPL WP2209024B $107.67

32

WP3400806 Whirlpool Screw In Stock WPL WP3400806 $4.99

32

Sleeve, Condenser WPL 2000645 Contact Us For Availability

2259355 Whirlpool Refrigerator Evaporator Rai Backorder WPL 2259355 $81.47

WP2307857 Whirlpool Refrigerator Extension In Stock WPL WP2307857 $59.99

WPW10121046 Whirlpool Refrigerator Extension In Stock WPL WPW10121046 $50.58

Evaporator, Cover Rail (Left Side) WPL 2221107 Contact Us For Availability

Cover, Electrical WPL 2259463 Contact Us For Availability

34

2220904 Whirlpool Refrigerator Gasket Backorder WPL 2220904 $16.21

34

W10528578 Whirlpool Refrigerator Tube Backorder WPL W10528578 $25.40

34

Grille Bottom, Front (Black) WPL 2209425B Contact Us For Availability

35

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $8.91

35

Screw WPL 2005921 Contact Us For Availability

36

2006556 Whirlpool Refrigerator Bracket Backorder WPL 2006556 $23.27

36

2006616 Whirlpool Refrigerator Bracket Backorder WPL 2006616 $59.47

36

Cover, Fan WPL 2209495 Contact Us For Availability

37

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $4.99

37

Harness, Evap Fan WPL 2187520 Contact Us For Availability

37

Cover, Condenser WPL 2259092 Contact Us For Availability

38

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $59.25

38

W11553819 Whirlpool Refrigerator Insulation In Stock WPL W11553819 $10.99

38

Grommet, Flexible WPL 2266857 Contact Us For Availability

39

WP2006346 Whirlpool Refrigerator Washer Backorder WPL WP2006346 $7.60

39

Service Cord WPL 2259197 Contact Us For Availability

40

WP2316859 Whirlpool Refrigerator Bushing In Stock WPL WP2316859 $35.70

41

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

41

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $4.82

42

WP2266802 Whirlpool Refrigerator Switch In Stock WPL WP2266802 $62.93

43

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $6.83

43

Gasket, Air Duct WPL 2259057 Contact Us For Availability

44

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $17.77

44

W11457217 Whirlpool Refrigerator Rocker Switc In Stock WPL W11457217 $17.77

44

Bracket, Light WPL 2257571 Contact Us For Availability

2215938 Whirlpool Refrigerator Switch Cover In Stock WPL 2215938 $59.36

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.88

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $79.99

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $82.11

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $86.15

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $66.99

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Spacer, Light Bracket WPL 2259446 Contact Us For Availability

Wiring Harness, Unit Compartment WPL 2187625 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI105182A Contact Us For Availability

and Optional Parts Not Included WPL ARI105183A Contact Us For Availability

REFRIGERANT CHARGE 7.75 oz. (R-134A) WPL ARI105184A Contact Us For Availability

46

WP2259032 Whirlpool Ladder Backorder WPL WP2259032 $49.71

46

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $6.51

47

2221096 Whirlpool Refrigerator Bracket Backorder WPL 2221096 $63.54

47

2221097 Whirlpool Refrigerator Bracket Backorder WPL 2221097 $63.54

47

Support, Screw WPL 2259397 Contact Us For Availability

48

2215612 Whirlpool Refrigerator Duct Cover Backorder WPL 2215612 $65.16

48

Gasket, Air Duct WPL 2259466 Contact Us For Availability

49

THERMISTOR WPL 2266949 Contact Us For Availability

55

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $23.99

56

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $7.55

100

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $130.99
