Model Whirlpool KBLS36FKT01 BUILT-IN BOTTOM MOUNT REFRIGERATOR – Common Parts &amp; Diagrams

1

Freezer Door Panel (Includes Item 9) WPL 2188601 Contact Us For Availability

1

Literature Parts (Installation Instructions) WPL LIT2215852 Contact Us For Availability

1

Literature Parts (Energy Label) WPL LIT2221286 Contact Us For Availability

1

Literature Parts (Use & Care Guide) WPL LIT2254715 Contact Us For Availability

1

Literature Parts (Service & Wiring Sheet) WPL LIT2254723 Contact Us For Availability

1

Modular Icemaker Service Sheet WPL LIT628370 Contact Us For Availability

1

Top Grille Assembly (Etched Aluminum) WPL 2215973 Contact Us For Availability

1

Top Grille Assembly (Black) WPL 2215973B Contact Us For Availability

1

Top Grille Assembly (Biscuit) WPL 2215973T Contact Us For Availability

1

Top Grille Assembly (White) WPL 2215973W Contact Us For Availability

1

Slide, Freezer Basket (Right Side) WPL 2221278 Contact Us For Availability

1

Slide, Freezer Basket (Left Side) WPL 2221279 Contact Us For Availability

1

Refrigerator Door (Includes Item 9) WPL 2188600 Contact Us For Availability

2

WP2221240 Whirlpool Refrigerator Heater In Stock WPL WP2221240 $82.83

2

Divider, Basket WPL 2204525 Contact Us For Availability

2

Cabinet (Not A Serviceable Part) WPL ARI78962A2 Contact Us For Availability

2

Cover, Unit WPL 2209490 Contact Us For Availability

2

Screw, 8-15 x 1.00 WPL 9751808 Contact Us For Availability

2

Cover-Trim, Handle (Etched Aluminum) WPL 2006337 Contact Us For Availability

2

Cover-Trim, Handle (White) WPL 2006338 Contact Us For Availability

2

Cover-Trim, Handle (Biscuit) WPL 2006340 Contact Us For Availability

2

Cover-Trim, Handle (Black) WPL 2006341 Contact Us For Availability

3

876765 Whirlpool Primary Mounting Kit Refrige In Stock WPL 876765 $31.62

3

W10841139 Whirlpool Refrigerator Compressor In Stock WPL W10841139 $377.65

3

WP3400806 Whirlpool Screw In Stock WPL WP3400806 $2.75

3

WP489115 Whirlpool Refrigerator Rivet Backorder WPL WP489115 $5.76

3

Clamp, Divider WPL 2207429 Contact Us For Availability

3

Grommet, Tube Crossover WPL 2005004 Contact Us For Availability

3

Hinge Assembly, Top WPL 2005171 Contact Us For Availability

4

2256466 Whirlpool Refrigerator Unit Cover Backorder WPL 2256466 $243.11

4

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $20.53

4

Housing, Control Board WPL 2199929 Contact Us For Availability

4

Spacer, Crisper (Right Side) WPL 2005138 Contact Us For Availability

4

Spacer, Crisper (Left Side) WPL 2005139 Contact Us For Availability

4

Spacer-Hinge, Top WPL 2004520 Contact Us For Availability

5

Backorder WPL 2179404 $14.15

5

W10860229 Whirlpool Refrigerator Support Backorder WPL W10860229 $225.57

5

W10860448 Whirlpool Refrigerator Support Backorder WPL W10860448 $179.61

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $5.91

5

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $12.28

5

Bracket, Fan Motor WPL 2215641 Contact Us For Availability

5

Guard, Wiring WPL 2209492 Contact Us For Availability

6

2171846 Whirlpool Refrigerator Release Valve Backorder WPL 2171846 $16.76

6

876811 Whirlpool Grommet Backorder WPL 876811 $4.19

6

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $7.10

6

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $3.38

6

Cover-Trim, Handle (Etched Aluminum) WPL 2006327 Contact Us For Availability

6

Cover-Trim, Handle (White) WPL 2006328 Contact Us For Availability

6

Cover-Trim, Handle (Biscuit) WPL 2006330 Contact Us For Availability

6

Cover-Trim, Handle (Black) WPL 2006331 Contact Us For Availability

6

Grommet, Wiring WPL 2005006 Contact Us For Availability

6

Hinge Assembly, Bottom WPL 2003985 Contact Us For Availability

7

Trim-Door, Side (Etched Aluminum) WPL 2005868 Contact Us For Availability

7

Trim-Door, Side (White) WPL 2005869 Contact Us For Availability

7

Trim-Door, Side (Biscuit) WPL 2006303 Contact Us For Availability

7

Trim-Door, Side (Black) WPL 2006304 Contact Us For Availability

7

Corner Trim (White) WPL 2006270 Contact Us For Availability

7

Corner Trim (Biscuit) WPL 2006272 Contact Us For Availability

7

Corner Trim (Black) WPL 2006273 Contact Us For Availability

7

Shroud, Condenser (Right) WPL 2209038 Contact Us For Availability

7

Grommet, Flexible WPL 2005007 Contact Us For Availability

7

Wire Assembly WPL 2187423 Contact Us For Availability

7

Roller WPL 2188212 Contact Us For Availability

8

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $5.70

8

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $3.46

8

Trim-Door, Bottom (Etched Aluminum) WPL 2006278 Contact Us For Availability

8

Trim-Door, Bottom (White) WPL 2006279 Contact Us For Availability

8

Trim-Door, Bottom (Biscuit) WPL 2006281 Contact Us For Availability

8

Trim-Door, Bottom (Black) WPL 2006282 Contact Us For Availability

8

Panel, Condenser Front WPL 2215665 Contact Us For Availability

8

Baffle-Air, Condenser WPL 2215678 Contact Us For Availability

8

Bracket, Spacer (Right) WPL 2221280 Contact Us For Availability

8

Bracket, Spacer (Left) WPL 2221281 Contact Us For Availability

8

Trim-Door, Side (Etched Aluminum) WPL 2005859 Contact Us For Availability

8

Trim-Door, Side (White) WPL 2005860 Contact Us For Availability

8

Trim-Door, Side (Biscuit) WPL 2006276 Contact Us For Availability

8

Trim-Door, Side (Black) WPL 2006277 Contact Us For Availability

9

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $60.77

9

Heater, Drain Pan WPL 2209451 Contact Us For Availability

9

Seal, Side Trim WPL 2005925 Contact Us For Availability

9

Eyelet, Roller WPL 2174478 Contact Us For Availability

9

Door Gasket, Magnetic WPL 2188533 Contact Us For Availability

9

Mounting Bracket, Grill WPL 2006442 Contact Us For Availability

9

Door Gasket, Magnetic WPL 2188532 Contact Us For Availability

W10851443 Whirlpool Refrigerator Screw In Stock WPL W10851443 $3.22

WP681414 Whirlpool Screw In Stock WPL WP681414 $3.46

Screw WPL 2005921 Contact Us For Availability

Cover-Trim, Side (Etched Aluminum) WPL 2006322 Contact Us For Availability

Cover-Trim, Side (White) WPL 2006323 Contact Us For Availability

Cover-Trim, Side (Biscuit) WPL 2006325 Contact Us For Availability

Cover-Trim, Side (Black) WPL 2006326 Contact Us For Availability

Screw 8-15 x 1/2 (White) WPL 8281251 Contact Us For Availability

Screw 8-15 x 1/2 (Biscuit) WPL 8281253 Contact Us For Availability

Shroud, Condenser (Left) WPL 2209037 Contact Us For Availability

WP489261 Whirlpool Refrigerator Screw Backorder WPL WP489261 $4.77

Handle, Door (Etched Aluminum) WPL 2005188 Contact Us For Availability

Handle, Door (White) WPL 2005392 Contact Us For Availability

Handle, Door (Biscuit) WPL 2006291 Contact Us For Availability

Handle, Door (Black) WPL 2006292 Contact Us For Availability

Control Board WPL 2254740 Contact Us For Availability

Cap, Grommet WPL 1112849 Contact Us For Availability

Handle, Door (Etched Aluminum) WPL 2005853 Contact Us For Availability

Handle, Door (White) WPL 2005854 Contact Us For Availability

Handle, Door (Biscuit) WPL 2006299 Contact Us For Availability

Handle, Door (Black) WPL 2006300 Contact Us For Availability

W11214482 Whirlpool Refrigerator Roller Backorder WPL W11214482 $45.45

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $11.55

Cover WPL 2169935 Contact Us For Availability

Gasket (2) WPL 2005982 Contact Us For Availability

2207457 Whirlpool Refrigerator Door Trim Backorder WPL 2207457 $65.92

2256328 Whirlpool Bracket Assembly Backorder WPL 2256328 $46.01

Roller Stop WPL 1113169 Contact Us For Availability

Tube, Drain Condensate WPL 2204516 Contact Us For Availability

Spacer-Hinge, Bottom WPL 2003982 Contact Us For Availability

2207470 Whirlpool Refrigerator Hinge Shim Backorder WPL 2207470 $31.66

W11624204 Whirlpool Screw Backorder WPL W11624204 $14.93

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $35.14

WP8281250 Whirlpool Refrigerator Screw In Stock WPL WP8281250 $4.71

Screw WPL 486899 Contact Us For Availability

Trim-Door, Bottom (Etched Aluminum) WPL 2005862 Contact Us For Availability

Trim-Door, Bottom (White) WPL 2005863 Contact Us For Availability

Trim-Door, Bottom (Biscuit) WPL 2006285 Contact Us For Availability

Trim-Door, Bottom (Black) WPL 2006286 Contact Us For Availability

489348 Whirlpool Refrigerator Tube Clamp Backorder WPL 489348 $8.38

W10833902 Whirlpool Refrigerator Clamp Backorder WPL W10833902 $6.99

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $3.22

Bracket, Assembly Freezer Basket WPL 2207533 Contact Us For Availability

Support, Crisper Shelf (2) WPL 2005987 Contact Us For Availability

Cover-Trim, Side (Etched Aluminum) WPL 2006332 Contact Us For Availability

Cover-Trim, Side (White) WPL 2006333 Contact Us For Availability

Cover-Trim, Side (Biscuit) WPL 2006335 Contact Us For Availability

Cover-Trim, Side (Black) WPL 2006336 Contact Us For Availability

488946 Whirlpool Air Conditioner Clamp Backorder WPL 488946 $15.96

WP2155590 Whirlpool Refrigerator Retainer Backorder WPL WP2155590 $3.22

Condenser WPL 2209062 Contact Us For Availability

Rail, Deli Center WPL 2006454 Contact Us For Availability

WP2221296 Whirlpool Air Baffle In Stock WPL WP2221296 $233.21

WP489235 Whirlpool Refrigerator Washer Backorder WPL WP489235 $5.88

Heater, Defrost (Front) WPL 2207485 Contact Us For Availability

Screw, Door Stop WPL 2001295 Contact Us For Availability

Basket, Upper WPL 2005376 Contact Us For Availability

Grommet (4) WPL 943447 Contact Us For Availability

Trim-Door, Top (Etched Aluminum) WPL 2005865 Contact Us For Availability

Trim-Door, Top (White) WPL 2005866 Contact Us For Availability

Trim-Door, Top (Biscuit) WPL 2006289 Contact Us For Availability

Trim-Door, Top (Black) WPL 2006290 Contact Us For Availability

2257644 Whirlpool Refrigerator Door Hinge Backorder WPL 2257644 $113.97

Pan, Ice Cube WPL 2174124 Contact Us For Availability

Wire, Jumper WPL 2187422 Contact Us For Availability

Shelf (4) WPL 2005571 Contact Us For Availability

Tub WPL 2005482 Contact Us For Availability

WP2207454 Whirlpool Refrigerator Nut Backorder WPL WP2207454 $7.13

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $5.76

Cam-Closer, Door WPL 2005783 Contact Us For Availability

Air Damper, Deli WPL 2005429 Contact Us For Availability

WPL 2005417 WPL 2005417 Contact Us For Availability

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $30.40

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.46

Screw WPL 487522 Contact Us For Availability

Bushing WPL 2207471 Contact Us For Availability

Rail-Rear, Deli WPL 2005151 Contact Us For Availability

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $58.69

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $26.71

Screw WPL 3400507 Contact Us For Availability

Glass Shelf, Deli WPL 2005152 Contact Us For Availability

WPL 2005542 WPL 2005542 Contact Us For Availability

WP628356 Whirlpool Refrigerator Fill Cup In Stock WPL WP628356 $19.04

Bushing WPL 2002903 Contact Us For Availability

Basket, Freezer Lower WPL 2006244 Contact Us For Availability

Rail-Front, Deli WPL 2220883 Contact Us For Availability

WPL 2005541 WPL 2005541 Contact Us For Availability

W10181323 Whirlpool Refrigerator Condenser Fa In Stock WPL W10181323 $187.43

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $25.76

WP2209022 Whirlpool Refrigerator Housing In Stock WPL WP2209022 $111.88

Control Knob, Deli WPL 2005415 Contact Us For Availability

WPL 2006152 WPL 2006152 Contact Us For Availability

WP2004517 Whirlpool Refrigerator Spring In Stock WPL WP2004517 $37.24

WP2182124 Whirlpool Refrigerator Stripper Arm Backorder WPL WP2182124 $32.35

Blade, Fan WPL 2190685 Contact Us For Availability

Drain Tube, Condensate WPL 2209208 Contact Us For Availability

Spacer WPL 2207576 Contact Us For Availability

WP2001264 Whirlpool Refrigerator Drip Pan In Stock WPL WP2001264 $108.49

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $44.78

Insulation, Baffle WPL 2215530 Contact Us For Availability

Orifice, Fan WPL 2003169 Contact Us For Availability

Washer WPL 2006252 Contact Us For Availability

EDR5RXD1 Whirlpool Refrigerator Ice and Water In Stock WPL EDR5RXD1 $61.38

Cover, Air Diffuser WPL 2215531 Contact Us For Availability

Roller WPL 2207550 Contact Us For Availability

Connector, Deli Pan WPL 2005165 Contact Us For Availability

WPL 2005983 WPL 2005983 Contact Us For Availability

8281160 Whirlpool Screw Backorder WPL 8281160 $8.29

WP2316859 Whirlpool Refrigerator Bushing In Stock WPL WP2316859 $35.14

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $50.57

Heater-Tube, Drain WPL 2204595 Contact Us For Availability

Lid, Deli Pan WPL 2222655 Contact Us For Availability

WPL 2006154 WPL 2006154 Contact Us For Availability

2215648 Whirlpool Refrigerator Dampener Backorder WPL 2215648 $12.11

W10188434 Whirlpool Refrigerator Hinge Gap Backorder WPL W10188434 $42.76

Insulation, Tube Drain WPL 2204538 Contact Us For Availability

Hinge Rod, Deli Pan WPL 2005923 Contact Us For Availability

WPL 2165792 WPL 2165792 Contact Us For Availability

2005101 Whirlpool Refrigerator Bottom Hinge Backorder WPL 2005101 $57.54

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $4.19

Cover, Tube Drain WPL 2204537 Contact Us For Availability

Cripser Pan WPL 2005157 Contact Us For Availability

30

Handle, Crisper Pan WPL 2005480 Contact Us For Availability

31

2006253 Whirlpool Refrigerator Screw Backorder WPL 2006253 $14.93

31

W11474472 Whirlpool Screw In Stock WPL W11474472 $3.46

31

Housing, Switch WPL 2215835 Contact Us For Availability

WP2209024B Whirlpool Refrigerator Front Grill Backorder WPL WP2209024B $82.78

Sleeve, Condenser WPL 2000645 Contact Us For Availability

Skirt, Grille- Bottom (Biscuit) WPL 2209024T Contact Us For Availability

SKIRT-GRILLE, BOTTOM (WHITE) WPL 2209024W Contact Us For Availability

Overlay, Crisper Pan WPL 2005986 Contact Us For Availability

33

WP2006346 Whirlpool Refrigerator Washer In Stock WPL WP2006346 $5.88

33

Wire, Jumper WPL 2187377 Contact Us For Availability

33

Rail-Front, Crisper Shelf WPL 2220885 Contact Us For Availability

W10528578 Whirlpool Refrigerator Tube Backorder WPL W10528578 $18.71

Grille Base, Front (Black) WPL 2215889B Contact Us For Availability

Grille Base, Front (Biscuit) WPL 2215889T Contact Us For Availability

Grille Base, Front (White) WPL 2215889W Contact Us For Availability

Vent, Crisper Shelf WPL 2005425 Contact Us For Availability

35

Clip, Thermistor WPL 2209204 Contact Us For Availability

35

Screw WPL 3400878 Contact Us For Availability

35

Slide-Humidity, Crisper Shelf WPL 2005413 Contact Us For Availability

2006254 Whirlpool Refrigerator Screw Backorder WPL 2006254 $12.60

2215612 Whirlpool Refrigerator Duct Cover Backorder WPL 2215612 $64.54

Cover, Fan WPL 2209495 Contact Us For Availability

Cover, Rear WPL 2209133 Contact Us For Availability

37

Control Panel WPL 2215816 Contact Us For Availability

37

Cover, Condenser WPL 2215628 Contact Us For Availability

37

Glass, Crisper Shelf WPL 2005477 Contact Us For Availability

38

WPW10121046 Whirlpool Refrigerator Extension In Stock WPL WPW10121046 $45.32

38

Overlay, Control Panel WPL 2221064 Contact Us For Availability

38

Rail-Rear, Crisper Shelf WPL 2005478 Contact Us For Availability

2221096 Whirlpool Refrigerator Bracket Backorder WPL 2221096 $62.93

Circuit Board (User Interface) WPL 2209159 Contact Us For Availability

Service Cord WPL 2003381 Contact Us For Availability

Seal-Front, Crisper Shelf WPL 2005479 Contact Us For Availability

40

2215938 Whirlpool Refrigerator Switch Cover Backorder WPL 2215938 $58.79

40

Insert, Control Box WPL 2215670 Contact Us For Availability

40

Insulation, Crisper Rail WPL 2005984 Contact Us For Availability

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $7.10

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $10.80

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $4.77

Baffle-Center, Crisper Shelf WPL 2005985 Contact Us For Availability

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $37.17

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $28.71

WP2186494T Whirlpool Water Filter Cap In Stock WPL WP2186494T $7.54

WP2186494W Whirlpool Water Filter Cap Backorder WPL WP2186494W $34.57

WP2266802 Whirlpool Refrigerator Switch In Stock WPL WP2266802 $37.17

Center Support, Left Half WPL 2005794 Contact Us For Availability

W10887190 Whirlpool Refrigerator Light Bulb In Stock WPL W10887190 $9.04

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $5.84

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $4.19

WP8204624 Whirlpool Bolt Backorder WPL WP8204624 $9.65

Center Support, Right Half WPL 2005795 Contact Us For Availability

44

Harness, Control Box WPL 2187424 Contact Us For Availability

44

Clip, Cord Plug WPL 653035 Contact Us For Availability

44

Bracket, Center Support WPL 2005796 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $37.43

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $33.30

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $40.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $42.85

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $17.32

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $31.24

WPW10272364 Whirlpool Refrigerator Screw In Stock WPL WPW10272364 $4.71

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Channel, Wiring Freezer Light WPL 8201534 Contact Us For Availability

Wiring Harness, Unit Compartment WPL 2187418 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

46

9791833 Whirlpool Refrigerator Clip Backorder WPL 9791833 $6.81

46

WP3400065 Whirlpool Refrigerator Screw Backorder WPL WP3400065 $3.22

46

CLIP, WIRING WPL 1115375 Contact Us For Availability

47

W11457217 Whirlpool Refrigerator Rocker Switc In Stock WPL W11457217 $17.32

47

WPL 2207578 WPL 2207578 Contact Us For Availability

47

Deli Pan WPL 2222741 Contact Us For Availability

48

Wiring Cover, Icemaker WPL 2005792 Contact Us For Availability

48

Ladder, Shelf (4) WPL 2005410 Contact Us For Availability

49

2006475 Whirlpool Refrigerator Screw Backorder WPL 2006475 $14.22

49

Defrost Bi-Metal WPL 2187378 Contact Us For Availability

50

Diffuser Assembly WPL 2215829 Contact Us For Availability

50

Ladder, Crisper Support WPL 2005797 Contact Us For Availability

51

2221121 Whirlpool Refrigerator Support Backorder WPL 2221121 $63.86

51

WP2196483 Whirlpool Refrigerator Shelf Stud Backorder WPL WP2196483 $5.56

52

WP488920 Whirlpool Refrigerator Screw Backorder WPL WP488920 $3.22

52

WPL 2221260 WPL 2221260 Contact Us For Availability

53

WPL 2207522 WPL 2207522 Contact Us For Availability

54

2207415 Whirlpool Refrigerator Nut Backorder WPL 2207415 $14.93

55

WPL 2207569 WPL 2207569 Contact Us For Availability

100

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $130.68
