Model Whirlpool JS42NXFXDW01 REFRIGERATOR – Common Parts &amp; Diagrams

1

Cabinet, Trim (Side) WPL W10207387 Contact Us For Availability

1

Shield, Valve WPL W10129653 Contact Us For Availability

2

WP2169142 Whirlpool Fan Blade In Stock WPL WP2169142 $24.18

2

COVER, FILL TUBE HEATER WPL W10176577 Contact Us For Availability

3

2208970 Whirlpool Refrigerator Air Duct Backorder WPL 2208970 $104.19

3

2310136 Whirlpool Refrigerator Wire Harness Backorder WPL 2310136 $123.97

3

2318189 Whirlpool Refrigerator Drip Pan Backorder WPL 2318189 $103.52

3

W10199873 Whirlpool Refrigerator Cover Trim Backorder WPL W10199873 $93.19

3

W10841139 Whirlpool Refrigerator Compressor In Stock WPL W10841139 $368.46

3

SUCTION TUBE OIL TRAP WPL W10306442 Contact Us For Availability

3

Cabinet, Trim (Bottom) WPL W10188505 Contact Us For Availability

4

2259081 Whirlpool Refrigerator Basket Backorder WPL 2259081 $234.71

4

W10234194 Whirlpool Refrigerator Hinge Pin Backorder WPL W10234194 $10.30

4

W10388653 Whirlpool Refrigerator Tube Backorder WPL W10388653 $24.52

4

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $32.24

4

WPW10171433 Whirlpool Refrigerator Diffuser Backorder WPL WPW10171433 $106.03

4

WPW10200659-includeCORE Whirlpool WPW10200659 Backorder WPL WPW10200659-includeCORE $317.00

5

W10138451 Whirlpool Refrigerator Cabinet Trim Backorder WPL W10138451 $145.25

5

W10414681 Whirlpool Bracket Backorder WPL W10414681 $54.79

5

W11623101 Whirlpool Heater-Pan Backorder WPL W11623101 $235.26

5

W11669856 Whirlpool Grommet Backorder WPL W11669856 $9.12

5

WP628379 Whirlpool Refrigerator Clip Backorder WPL WP628379 $6.90

5

Ladder, Shelf WPL W10175171 Contact Us For Availability

6

2259317 Whirlpool Refrigerator Slide Backorder WPL 2259317 $169.82

6

2259445 Whirlpool Support Assembly Backorder WPL 2259445 $57.55

6

876811 Whirlpool Grommet Backorder WPL 876811 $4.82

6

W11448696 Whirlpool Refrigerator Bin Backorder WPL W11448696 $103.19

6

W11565275 Whirlpool Refrigerator Water Tube Backorder WPL W11565275 $42.66

6

WP2259318 Whirlpool Refrigerator Slide Backorder WPL WP2259318 $231.00

6

WP2260518B Whirlpool Water Filter Cap In Stock WPL WP2260518B $22.93

7

2006475 Whirlpool Refrigerator Screw Backorder WPL 2006475 $8.39

7

2302954 Whirlpool Refrigerator Slide Backorder WPL 2302954 $237.21

7

2302955 Whirlpool Refrigerator Slide Backorder WPL 2302955 $237.21

7

W11662302 Whirlpool Water Tube Backorder WPL W11662302 $56.75

7

WP8533928 Whirlpool Refrigerator Screw In Stock WPL WP8533928 $5.30

7

SEAL-TRIM, SIDE WPL 2005925 Contact Us For Availability

7

Gasket, Utility Bin WPL 2222982 Contact Us For Availability

7

SUPPORT, CONDENSER (RIGHT) WPL W10415668 Contact Us For Availability

8

W10412488 Whirlpool Refrigerator Tube Backorder WPL W10412488 $80.78

8

WP1106508 Whirlpool Refrigerator Gasket In Stock WPL WP1106508 $6.17

8

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $5.30

8

WPW10191429 Whirlpool Refrigerator Socket In Stock WPL WPW10191429 $5.30

8

Bracket, Switch WPL W10209446 Contact Us For Availability

9

2215676 Whirlpool Refrigerator Terminal Cover Backorder WPL 2215676 $65.65

9

W10187549 Whirlpool Refrigerator Support Backorder WPL W10187549 $207.46

9

W11533506 Whirlpool Refrigerator Water Tube In Stock WPL W11533506 $19.00

9

WPW10121451 Whirlpool Refrigerator Insert Backorder WPL WPW10121451 $4.82

W11812025 Whirlpool Heater Backorder WPL W11812025 $52.03

WP2307650 Whirlpool Refrigerator Inlet Valve In Stock WPL WP2307650 $114.94

WPA3073101 Whirlpool Light Bulb In Stock WPL WPA3073101 $7.71

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $126.34

SUPPORT, CONDENSER (LEFT) WPL W10415666 Contact Us For Availability

1113048 Whirlpool Refrigerator Clamp Backorder WPL 1113048 $7.19

2003577 Whirlpool Refrigerator Guard Backorder WPL 2003577 $8.90

2302956 Whirlpool Refrigerator Slide In Stock WPL 2302956 $217.43

2302957 Whirlpool Refrigerator Slide Backorder WPL 2302957 $166.20

W10182713 Whirlpool Refrigerator Front Grille Backorder WPL W10182713 $104.44

W10199955 Whirlpool Refrigerator Bracket Backorder WPL W10199955 $65.15

W11215550 Whirlpool Ice Level Arm In Stock WPL W11215550 $43.87

WPW10356040-includeCORE Whirlpool WPW10356040 Backorder WPL WPW10356040-includeCORE $269.85

everydrop® Filter 3 EDR3RXD1 Whirlpool Refri In Stock WPL EDR3RXD1 $65.34

W10197748 Whirlpool Refrigerator Cover Backorder WPL W10197748 $11.84

W10833902 Whirlpool Refrigerator Clamp Backorder WPL W10833902 $7.06

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $11.67

WP2221296 Whirlpool Air Baffle In Stock WPL WP2221296 $198.86

2256328 Whirlpool Bracket Assembly Backorder WPL 2256328 $49.71

W10203322 Whirlpool Refrigerator Deflector Backorder WPL W10203322 $59.18

W10323602 Whirlpool Refrigerator Cantilever B Backorder WPL W10323602 $64.26

WP489399 Whirlpool Refrigerator Screw Backorder WPL WP489399 $3.49

Gasket, Evaporator WPL 2220832 Contact Us For Availability

Jumper, Fill Tube Heater WPL 2310108 Contact Us For Availability

2215648 Whirlpool Refrigerator Dampener Backorder WPL 2215648 $8.35

2320559 Whirlpool Bracket Backorder WPL 2320559 $64.63

W10234202 Whirlpool Refrigerator Hinge Pin Backorder WPL W10234202 $60.39

WP2317844 Whirlpool Refrigerator Cover Backorder WPL WP2317844 $7.52

BRACKET, VIBRATION CONDENSER WPL 2317031 Contact Us For Availability

W10167397 Whirlpool Refrigerator Door Hinge Backorder WPL W10167397 $282.12

W10167398 Whirlpool Refrigerator Door Hinge Backorder WPL W10167398 $251.01

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $7.20

WPW10323172 Whirlpool Refrigerator Retainer E Backorder WPL WPW10323172 $4.82

WPW10323173 Whirlpool Refrigerator Retainer E Backorder WPL WPW10323173 $4.82

16

2307998 Whirlpool Refrigerator Condenser Backorder WPL 2307998 $344.53

16

W10170104 Whirlpool Cover Backorder WPL W10170104 $53.18

16

W11755873 Whirlpool Bracket Backorder WPL W11755873 $50.40

W11553221 Whirlpool Refrigerator Door Compres Backorder WPL W11553221 $43.77

WP2221240 Whirlpool Refrigerator Heater In Stock WPL WP2221240 $90.46

Light Shield WPL 2307751 Contact Us For Availability

Cover, Air Diffuser WPL W10171428 Contact Us For Availability

W10323599 Whirlpool Refrigerator Cantilever B Backorder WPL W10323599 $100.25

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $6.02

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $4.82

ARM, VIBRATION CONDENSER WPL 2317030 Contact Us For Availability

19

W10323747 Whirlpool Refrigerator Cantilever B Backorder WPL W10323747 $98.27

19

ARM-SHUT In Stock WPL W11807379 $43.00

19

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $5.02

20

W10182692 Whirlpool Refrigerator Door Hinge Backorder WPL W10182692 $225.10

20

WPW10190929 Whirlpool Refrigerator Ice Maker Backorder WPL WPW10190929 $187.20

20

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $5.02

21

8201515 Whirlpool Refrigerator Motor and Gear In Stock WPL 8201515 $102.30

21

W11721628 Whirlpool Screw Assembly Backorder WPL W11721628 $8.89

21

WPW10143759 Whirlpool Dryer Filter In Stock WPL WPW10143759 $22.83

22

2310207 Whirlpool Wire Harness Backorder WPL 2310207 $64.82

22

W10122561 Whirlpool Refrigerator Cup Fill In Stock WPL W10122561 $17.79

22

WPW10188549 Whirlpool Refrigerator Front Gril Backorder WPL WPW10188549 $93.53

W11578915 Whirlpool Condenser Motor In Stock WPL W11578915 $60.03

W11739147 Whirlpool Front Grille Backorder WPL W11739147 $131.45

WP627843 Whirlpool Refrigerator Ejector Arm Backorder WPL WP627843 $63.89

Screw WPL W10191952 Contact Us For Availability

24

WPW10122563 Whirlpool Refrigerator Stripper A Backorder WPL WPW10122563 $66.33

24

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $48.87

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $63.40

2220904 Whirlpool Refrigerator Gasket Backorder WPL 2220904 $16.21

W10415670 Whirlpool Orifice Backorder WPL W10415670 $33.06

WP2195914 Whirlpool Refrigerator Ice Maker Ho Backorder WPL WP2195914 $73.20

2307566 Whirlpool Refrigerator Tube Backorder WPL 2307566 $10.91

W10139189 Whirlpool Refrigerator Wire Harness Backorder WPL W10139189 $114.81

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $4.82

WP2315522 Whirlpool Refrigerator Clip Backorder WPL WP2315522 $6.88

27

WP627985 Whirlpool Icemaker Cycling Thermosta In Stock WPL WP627985 $56.89

27

WP8281163 Whirlpool Refrigerator Screw Backorder WPL WP8281163 $6.83

27

WP8533993 Whirlpool Refrigerator Screw Backorder WPL WP8533993 $6.83

28

8533917 Whirlpool Refrigerator Screw In Stock WPL 8533917 $15.02

28

W10234131 Whirlpool Refrigerator Tube Backorder WPL W10234131 $10.52

28

WP2188820 Whirlpool Refrigerator Thermistor In Stock WPL WP2188820 $34.20

29

WP2221231 Whirlpool Refrigerator Shield Backorder WPL WP2221231 $65.03

29

Gasket, Condenser WPL 2309432 Contact Us For Availability

30

WP681249 Whirlpool Screw Assembly In Stock WPL WP681249 $3.49

30

WPW10184634-includeCORE Whirlpool WPW10184634 Backorder WPL WPW10184634-includeCORE $328.60

31

W10279393 Whirlpool Refrigerator Wire Harness Backorder WPL W10279393 $108.44

31

W10528578 Whirlpool Refrigerator Tube Backorder WPL W10528578 $25.40

32

WPW10141604 Whirlpool Screw Backorder WPL WPW10141604 $5.65

32

Cover, Condenser WPL 2309000 Contact Us For Availability

33

2310196 Whirlpool Refrigerator Power Cord Backorder WPL 2310196 $64.43

33

WPW10160570 Whirlpool Refrigerator Bimetallic In Stock WPL WPW10160570 $67.13

2005032 Whirlpool Refrigerator Leveler Backorder WPL 2005032 $135.30

489136 Whirlpool Refrigerator Screw Backorder WPL 489136 $6.83

W11624204 Whirlpool Screw Backorder WPL W11624204 $8.89

WPW10142283 Whirlpool Refrigerator Screw In Stock WPL WPW10142283 $7.58

35

WP2266802 Whirlpool Refrigerator Switch In Stock WPL WP2266802 $53.31

35

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $6.02

35

SIDE TRIM ASSY (LH) WPL W10344547 Contact Us For Availability

36

WP489128 Whirlpool Refrigerator Screw Backorder WPL WP489128 $6.83

37

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $8.91

38

W10209460 Whirlpool Refrigerator Wire Harness Backorder WPL W10209460 $222.09

39

W10209462 Whirlpool Refrigerator Wire Harness Backorder WPL W10209462 $222.09

40

SCREW WPL W10141645 Contact Us For Availability

100

WPW10277450 Whirlpool Refrigerator Icemaker In Stock WPL WPW10277450 $205.34

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $32.12

978026 Whirlpool Refrigerator Primary Valve In Stock WPL 978026 $80.02

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $87.85

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $92.18

W10234156 Whirlpool Refrigerator Installation Backorder WPL W10234156 $9.86

W11175806 Whirlpool Refrigerator Installation Backorder WPL W11175806 $170.81

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $67.02

AFFRESH STAINLESS STEEL CLEANER WPL W10355016 Contact Us For Availability

AFFRESH STAINLESS STEEL WIPES WPL W10355049 Contact Us For Availability

AFFRESH KITCHEN APPLIANCE CLEANER WPL W10355010 Contact Us For Availability

Valve, Access (5/8``) WPL 978029 Contact Us For Availability

DEODORIZER PACK WPL REFDEODOR Contact Us For Availability

SxS WPL W10222281 Contact Us For Availability

Grille WPL W10222283 Contact Us For Availability

REFRIGERANT CHARGE 7.50 OZ. (R-134A) WPL NP Contact Us For Availability

VALVE, ACCESS WPL 978028 Contact Us For Availability
