Model Whirlpool GH8155XJT0 MICROWAVE OVEN – Common Parts &amp; Diagrams

1

Motor, Stirrer WPL 4393746 Contact Us For Availability

1

Film, Back WPL 4393870 Contact Us For Availability

1

Deflector, Air WPL 8169651 Contact Us For Availability

2

Frame, Inner WPL 8169545 Contact Us For Availability

2

Shaft, Stirrer WPL 4393794 Contact Us For Availability

2

Reflector, Air WPL 8169557 Contact Us For Availability

3

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $50.07

3

Latch, Door WPL 4393913 Contact Us For Availability

3

Stirrer WPL 4393748 Contact Us For Availability

3

Duct, Air WPL 8169465 Contact Us For Availability

4

Body, Door (White) WPL 8169653 Contact Us For Availability

4

Lid, Power Cord WPL 4393714 Contact Us For Availability

4

Guide, Stirrer WPL 4393749 Contact Us For Availability

4

Body, Door (Almond) WPL 8169429 Contact Us For Availability

4

Body, Door (Black) WPL 8169460 Contact Us For Availability

4

Body, Door (Biscuit) WPL 8169546 Contact Us For Availability

4

Bracket, Thermostat WPL 8169558 Contact Us For Availability

5

Glass, Outer (Clear (Green Tint)) WPL 4393725 Contact Us For Availability

5

Thermostat WPL 8183697 Contact Us For Availability

5

Cover, Inlet WPL 4393750 Contact Us For Availability

5

Glass, Outer (Clear) WPL 8183704 Contact Us For Availability

6

W10315274 Whirlpool Microwave Meal Rack Backorder WPL W10315274 $19.80

6

Cord, Power WPL 4393793 Contact Us For Availability

6

Housing, Lamp WPL 4393680 Contact Us For Availability

7

4393777 Whirlpool Microwave Door Handle - Whi In Stock WPL 4393777 $65.76

7

4393782 Whirlpool Microwave Door Handle In Stock WPL 4393782 $79.01

7

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $3.39

7

Handle, Door (Biscuit) WPL 8169642 Contact Us For Availability

7

Handle, Door (Almond) WPL 4393783 Contact Us For Availability

7

Case, Outer (White) WPL 8169660 Contact Us For Availability

7

Case, Outer (Black) WPL 8169661 Contact Us For Availability

7

Case, Outer (Almond) WPL 8169662 Contact Us For Availability

7

Case, Outer (Biscuit) WPL 8169664 Contact Us For Availability

7

Nail, Plastic WPL 4393291 Contact Us For Availability

8

Turntable WPL 4393799 No Longer Available

8

8183851 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183851 $30.78

8

8183852 Whirlpool Microwave Primary Vent Gril In Stock WPL 8183852 $32.95

8

8183948 Whirlpool Microwave Oven Vent Grille In Stock WPL 8183948 $29.01

8

Screw WPL 4393833 Contact Us For Availability

8

Grille, Vent (Almond) WPL 8169334 Contact Us For Availability

8

Wheel, Fan WPL 4393682 Contact Us For Availability

9

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $3.22

9

8206334 Whirlpool Microwave Mounting Bracket In Stock WPL 8206334 $2.83

9

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $23.22

9

Motor, Fan WPL 4393789 Contact Us For Availability

WP4393834 Whirlpool Microwave Screw Backorder WPL WP4393834 $4.77

Frame, Outer (White) WPL 8169471 Contact Us For Availability

Frame, Outer (Black) WPL 8169352 Contact Us For Availability

Wheel, Plastic WPL 4393861 Contact Us For Availability

Frame, Outer (Biscuit) WPL 8169641 Contact Us For Availability

Frame, Outer (Almond) WPL 8169430 Contact Us For Availability

Shield WPL 8169559 Contact Us For Availability

11

W10435116 Whirlpool Microwave Turntable Rolle Backorder WPL W10435116 $16.57

11

Spring, Interlock (2) WPL 8169438 Contact Us For Availability

11

Housing, Fan WPL 8169668 Contact Us For Availability

12

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $88.39

12

Screw WPL 4393828 Contact Us For Availability

12

Bracket, Fan (Not Serviceable) WPL ARI65349A2 Contact Us For Availability

13

8205572 Whirlpool Microwave Interlock Backorder WPL 8205572 $4.19

13

Rod WPL 8169318 Contact Us For Availability

13

Cover, Terminal WPL 4393756 Contact Us For Availability

W10245183 Whirlpool Microwave Magnetron In Stock WPL W10245183 $178.22

Wheel, Fan WPL 8183701 Contact Us For Availability

Screw WPL 8169478 Contact Us For Availability

Latch, Pivot WPL 8169319 Contact Us For Availability

Thermostat WPL 8183698 Contact Us For Availability

Housing, Fan WPL 8183702 Contact Us For Availability

E-Ring WPL 8169320 Contact Us For Availability

Screw WPL 4393830 Contact Us For Availability

16

Motor, Fan WPL 4393700 Contact Us For Availability

16

Catch WPL 8169321 Contact Us For Availability

16

Holder, Connector (L) WPL 8169540 Contact Us For Availability

Chassis WPL 8169740 Contact Us For Availability

Spring WPL 8169374 Contact Us For Availability

Holder, Connector (R) WPL 4393686 Contact Us For Availability

Humidity, Sensor WPL 4393808 Contact Us For Availability

8205262RB Whirlpool Refrigerator Crusher Blad Backorder WPL 8205262RB $44.52

WP8169704 Whirlpool Screw In Stock WPL WP8169704 $3.50

Filler Kit (Black) WPL 8171337 Contact Us For Availability

Filler Kit (White) WPL 8171336 Contact Us For Availability

Holder, Capacitor WPL 4393702 Contact Us For Availability

Upper Template WPL 8169298 Contact Us For Availability

Wall Template WPL 8169487 Contact Us For Availability

Plate, Damper WPL 8169697 Contact Us For Availability

Hardware, Installation WPL 8169768 Contact Us For Availability

Filler Kit (Biscut) WPL 8171338 Contact Us For Availability

Filler Kit (Almond) WPL 8171570 Contact Us For Availability

Rack WPL 8183714 Contact Us For Availability

Screw WPL 4393838 Contact Us For Availability

Cushion, Mtr WPL 8169569 Contact Us For Availability

19

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $15.24

19

Screw WPL 8169474 Contact Us For Availability

20

W10850446 Whirlpool Microwave Magnetron Capac In Stock WPL W10850446 $143.73

20

WP8181660 Whirlpool Screw In Stock WPL WP8181660 $3.22

21

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $14.93

21

Transformer, H.V. WPL 8169698 Contact Us For Availability

22

Plate, Side (R) WPL 4393705 Contact Us For Availability

22

Bushing, Nail WPL 4393290 Contact Us For Availability

25

Plate, Side (L) WPL 8169470 Contact Us For Availability

26

Capacitor WPL 4393709 Contact Us For Availability

27

Holder, Fuse WPL 4393538 Contact Us For Availability

28

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $23.48

29

Thermostat WPL 8183703 Contact Us For Availability

32

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $10.17

36

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $6.22
