Model Electrolux E23CS78HSS5 REFRIGERATOR – Common Parts &amp; Diagrams

1

241510202 Frigidaire Refrigerator Door Gasket Backorder WCI 241510202 $224.63

2

241510201 Frigidaire Refrigerator Door Gasket In Stock WCI 241510201 $174.17

2

241684701 Frigidaire Refrigerator Ice Auger Backorder WCI 241684701 $166.61

3

241685201 Frigidaire Refrigerator Drive Cam In Stock WCI 241685201 $32.71

4

241515202 Frigidaire Refrigerator Container Backorder WCI 241515202 $74.85

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $44.94

5

WCI 241516102 WCI 241516102 Contact Us For Availability

6

241515901 Frigidaire Refrigerator Dairy Compa Backorder WCI 241515901 $31.04

6

241516904 Frigidaire Refrigerator Service Cor In Stock WCI 241516904 $28.28

6

241685101 Frigidaire Refrigerator Ice Dispens In Stock WCI 241685101 $40.48

7

241515301 Frigidaire Refrigerator Cover Backorder WCI 241515301 $93.71

7

241515606 Frigidaire Refrigerator Door-Dairy In Stock WCI 241515606 $32.73

7

WCI 5304458382 WCI 5304458382 Contact Us For Availability

8

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $16.59

8

WCI 241680504 WCI 241680504 Contact Us For Availability

9

241518301 Frigidaire Refrigerator Bushing In Stock WCI 241518301 $46.05

10

241688901 Frigidaire Refrigerator Torsion Spr Backorder WCI 241688901 $16.62

10

241726501 Frigidaire Refrigerator Drive Bar In Stock WCI 241726501 $46.00

11

5304458400 Frigidaire Refrigerator Thermal Cu Backorder WCI 5304458400 $48.27

11A

240443358 Frigidaire Refrigerator Shelf Backorder WCI 240443358 $71.00

13

240581905 Frigidaire Refrigerator Door Stop In Stock WCI 240581905 $44.87

13

5304456665 Frigidaire Refrigerator Thermostat In Stock WCI 5304456665 $98.14

13

809069220 Frigidaire Evaporator Fan Motor In Stock WCI 809069220 $100.27

13A

240581906 Frigidaire Refrigerator Door Stop In Stock WCI 240581906 $50.47

14

242044113 Frigidaire Refrigerator Defrost Hea In Stock WCI 242044113 $80.96

14A

241547902 Frigidaire Refrigerator Light Switc In Stock WCI 241547902 $19.49

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $14.94

15

5303918480 Frigidaire Refrigerator Evaporator Backorder WCI 5303918480 $267.85

15

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $67.67

16

241559801 Frigidaire Light Socket Refrigerato In Stock WCI 241559801 $50.24

16

241622802 Frigidaire Refrigerator Light Socke Backorder WCI 241622802 $46.57

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $48.81

17

241679801 Frigidaire Screw Backorder WCI 241679801 $11.09

17

241684503 Frigidaire Ice Crusher Blade In Stock WCI 241684503 $12.72

19

WCI 5304458378 WCI 5304458378 Contact Us For Availability

20

241675502 Frigidaire Refrigerator Motor Cover Backorder WCI 241675502 $107.06

21

5303918214 Frigidaire Refrigerator Defrost Th In Stock WCI 5303918214 $20.06

21

5304458390 Frigidaire Refrigerator Ice Stripp Backorder WCI 5304458390 $42.02

21A

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $6.09

240597220 Frigidaire Sensor In Stock WCI 240597220 $3.67

241856501 Frigidaire Refrigerator Door Closer In Stock WCI 241856501 $17.75

242015302 Frigidaire Refrigerator Bearing Hin In Stock WCI 242015302 $7.77

WCI 5304458375 WCI 5304458375 Contact Us For Availability

22A

242000502 Frigidaire Hinge Bearing In Stock WCI 242000502 $4.44

22C

240328404 Frigidaire Refrigerator Upper Door In Stock WCI 240328404 $16.64

218513300 Frigidaire Refrigerator Compressor Backorder WCI 218513300 $33.26

241512901 Frigidaire Refrigerator Sensor Cove Backorder WCI 241512901 $65.45

241531102 Frigidaire Refrigerator Drip Tray Backorder WCI 241531102 $179.72

241684001 Frigidaire Refrigerator Front Plate Backorder WCI 241684001 $117.03

WCI 240402702 WCI 240402702 Contact Us For Availability

23A

WCI 241531601 WCI 241531601 Contact Us For Availability

24

241685704 Frigidaire Refrigerator Actuator Backorder WCI 241685704 $146.44

24A

241682304 Frigidaire Refrigerator Ice Actuato Backorder WCI 241682304 $180.26

25

240555002 Frigidaire Refrigerator Screw #8-32 Backorder WCI 240555002 $10.50

25

WCI 241565002 WCI 241565002 Contact Us For Availability

25

WCI 240491503 WCI 240491503 Contact Us For Availability

25A

241564301 Frigidaire Refrigerator Cover Backorder WCI 241564301 $61.58

25B

241565701 Frigidaire Refrigerator Cover Backorder WCI 241565701 $69.89

26

240351061 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351061 $83.99

26

241690602 Frigidaire Refrigerator Screw In Stock WCI 241690602 $7.35

26

241697502 Frigidaire Defrost Drain Pan Backorder WCI 241697502 $123.03

27

240351240 Frigidaire Refrigerator Crisper Pan In Stock WCI 240351240 $151.58

27A

240362201 Frigidaire Refrigerator Humidity Co Backorder WCI 240362201 $54.34

27A

240396102 Frigidaire Refrigerator Retainer Backorder WCI 240396102 $14.97

30

241577505 Frigidaire Refrigerator Inverter In Stock WCI 241577505 $235.21

30

241688401 Frigidaire Ice Door Bracket In Stock WCI 241688401 $38.83

30A

241688501 Frigidaire Refrigerator Door Center In Stock WCI 241688501 $39.37

30B

241688601 Frigidaire Refrigerator Door Insula In Stock WCI 241688601 $43.75

30C

241688701 Frigidaire Refrigerator Door Seal In Stock WCI 241688701 $29.95

33

241684802 Frigidaire Refrigerator Spacer Backorder WCI 241684802 $6.61

34

240405201 Frigidaire Refrigerator Grommet In Stock WCI 240405201 $13.71

34

241689802 Frigidaire Refrigerator Spacer Backorder WCI 241689802 $6.09

35

241689301 Frigidaire Refrigerator Rotary Damp Backorder WCI 241689301 $51.55

35A

241684303 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684303 $12.72

35B

241684203 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684203 $13.29

36

241533501 Frigidaire Refrigerator Button Backorder WCI 241533501 $282.32

37A

241684107 Frigidaire Refrigerator Ice Crusher Backorder WCI 241684107 $16.07

37B

241684108 Frigidaire Washer Poly V-Belt Backorder WCI 241684108 $16.07

37C

241684109 Frigidaire Ice Crusher Blade Backorder WCI 241684109 $16.07

38

240327207 Frigidaire Refrigerator Upper Hinge Backorder WCI 240327207 $44.92

38

241527601 Frigidaire Refrigerator Board Switc In Stock WCI 241527601 $370.28

38A

241689106 Frigidaire Refrigerator Micro Switc In Stock WCI 241689106 $6.09

39

241688801 Frigidaire Refrigerator Hinge Pin Backorder WCI 241688801 $33.82

39

WCI 240367604 WCI 240367604 Contact Us For Availability

40

WCI 5304458401 WCI 5304458401 Contact Us For Availability

41

241550801 Frigidaire Refrigerator Shelf Mount Backorder WCI 241550801 $46.57

41

241689001 Frigidaire Refrigerator Actuator Sp In Stock WCI 241689001 $17.18

41

WCI 241637601 WCI 241637601 Contact Us For Availability

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $11.07

43

215005101 Frigidaire Refrigerator Screw Backorder WCI 215005101 $11.64

43

241720601 Frigidaire Refrigerator Extension In Stock WCI 241720601 $16.05

43

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $18.27

45

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.96

45B

241676001 Frigidaire Refrigerator E-Ring Sole Backorder WCI 241676001 $54.88

45C

241676101 Frigidaire Refrigerator Solenoid-Ac Backorder WCI 241676101 $50.46

46

WCI 241684402 WCI 241684402 Contact Us For Availability

47

240350649 Frigidaire Refrigerator Glass Inser In Stock WCI 240350649 $97.60

47

241513001 Frigidaire Refrigerator Shelf Mount In Stock WCI 241513001 $62.86

47

241731801 Frigidaire Refrigerator Control Rod Backorder WCI 241731801 $11.09

47A

240350603 Frigidaire Glass Shelf Backorder WCI 240350603 $90.42

48

241684602 Frigidaire Refrigerator Control Rod Backorder WCI 241684602 $83.77

49

WCI 241676501 WCI 241676501 Contact Us For Availability

241675601 Frigidaire Refrigerator Solenoid Gu Backorder WCI 241675601 $62.67

WCI 241511112 WCI 241511112 Contact Us For Availability

WCI 241635501 WCI 241635501 Contact Us For Availability

WCI 241508401 WCI 241508401 Contact Us For Availability

51

241514501 Frigidaire Refrigerator Basket Hang Backorder WCI 241514501 $57.69

51

WCI 241676301 WCI 241676301 Contact Us For Availability

51A

241514701 Frigidaire Refrigerator Glass Shelf Backorder WCI 241514701 $49.90

51C

240579821 Frigidaire Refrigerator Basket Hang Backorder WCI 240579821 $98.14

51D

240579822 Frigidaire Refrigerator Basket Hang Backorder WCI 240579822 $70.56

52

241514601 Frigidaire Refrigerator Basket Hang Backorder WCI 241514601 $59.88

52

241684901 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684901 $22.19

52A

241514801 Frigidaire Refrigerator Glass Shelf Backorder WCI 241514801 $318.41

52B

WCI 240579804 WCI 240579804 Contact Us For Availability

53

241690402 Frigidaire Refrigerator Spiral Pin Backorder WCI 241690402 $14.94

54

241532401 Frigidaire Refrigerator Channel In Stock WCI 241532401 $18.24

54

241685001 Frigidaire Auger Nut Backorder WCI 241685001 $15.51

55

241690306 Frigidaire Refrigerator Washer Backorder WCI 241690306 $38.83

56

241689201 Frigidaire Refrigerator Micro Switc Backorder WCI 241689201 $10.50

56

241690201 Frigidaire Refrigerator E-Ring Backorder WCI 241690201 $14.97

58

241548003 Frigidaire Refrigerator Screw In Stock WCI 241548003 $2.20

59

241946106 Frigidaire Refrigerator Condenser F Backorder WCI 241946106 $35.48

60

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $9.44

60

WCI 241510301 WCI 241510301 Contact Us For Availability

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $16.05

62

240599706 Frigidaire Refrigerator Pan Backorder WCI 240599706 $281.21

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $8.31

66

WCI 241513602 WCI 241513602 Contact Us For Availability

68

241525101 Frigidaire Refrigerator Ice Chute Backorder WCI 241525101 $60.13

70

241515801 Frigidaire Refrigerator Compartment Backorder WCI 241515801 $139.21

70

WCI 241504601 WCI 241504601 Contact Us For Availability

72

WCI 241554708 WCI 241554708 Contact Us For Availability

79

218755402 Frigidaire Refrigerator Set Screw In Stock WCI 218755402 $4.86

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $35.90

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $28.21

85

WCI 241871501 WCI 241871501 Contact Us For Availability

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $49.36

87

241688302 Frigidaire Refrigerator Bearing Pla Backorder WCI 241688302 $15.51

87A

241688301 Frigidaire Refrigerator Bearing Pla Backorder WCI 241688301 $15.51

89

5304520905 Frigidaire Assembly Cover Refriger Backorder WCI 5304520905 $54.36

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $10.53

94

WCI 241533301 WCI 241533301 Contact Us For Availability

97

241532005 Frigidaire Refrigerator Water Tank Backorder WCI 241532005 $110.37

240326304 Frigidaire Refrigerator Cover Backorder WCI 240326304 $57.71

241993001 Frigidaire Refrigerator Left Crispe In Stock WCI 241993001 $6.77

241993101 Frigidaire Refrigerator Right Crisp In Stock WCI 241993101 $4.21

WCI 241530402 WCI 241530402 Contact Us For Availability

101

218493101 Frigidaire Refrigerator Screw In Stock WCI 218493101 $10.00

115

5303918899 Frigidaire Damper Control Assembly In Stock WCI 5303918899 $58.18

116

241518601 Frigidaire Refrigerator Damper Seal In Stock WCI 241518601 $7.20

120

241691701 Frigidaire Refrigerator Ice Cream S Backorder WCI 241691701 $58.86

121

241504701 Frigidaire Refrigerator Ice Cream S Backorder WCI 241504701 $50.49

122

WCI 241504702 WCI 241504702 Contact Us For Availability

126

241674401 Frigidaire Refrigerator Channel Backorder WCI 241674401 $37.17

126

241674402 Frigidaire Refrigerator Channel Backorder WCI 241674402 $33.82

138

WCI 240397301 WCI 240397301 Contact Us For Availability

139

240396002 Frigidaire Refrigerator Primary Bas In Stock WCI 240396002 $99.76

149

242204504 Frigidaire Shroud Assembly Backorder WCI 242204504 $28.28

151

WCI 241526001 WCI 241526001 Contact Us For Availability

155

WCI 241526102 WCI 241526102 Contact Us For Availability

198

240397401 Frigidaire Refrigerator Retainer As Backorder WCI 240397401 $46.57

199

240398401 Frigidaire Refrigerator Filter Rele Backorder WCI 240398401 $43.24

199

WCI 240397501 WCI 240397501 Contact Us For Availability

205

WCI 241525901 WCI 241525901 Contact Us For Availability

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $11.07

218515403 Frigidaire Refrigerator Grille Clip Backorder WCI 218515403 $22.73

218976418 Frigidaire Refrigerator Water Inlet Backorder WCI 218976418 $50.49

218976421 Frigidaire Refrigerator Water Inlet Backorder WCI 218976421 $16.05

240346701 Frigidaire Refrigerator Foam Seal T In Stock WCI 240346701 $23.27

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.76

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $9.96

240542901 Frigidaire Water Valve Cap Backorder WCI 240542901 $12.28

240561701 Frigidaire Refrigerator Seal Backorder WCI 240561701 $16.07

241510802 Frigidaire Refrigerator Wiring Harn Backorder WCI 241510802 $32.71

241510902 Frigidaire Refrigerator Dispenser H Backorder WCI 241510902 $18.29

241519401 Frigidaire Refrigerator Clip Backorder WCI 241519401 $6.61

241522901 Frigidaire Refrigerator Electrical Backorder WCI 241522901 $85.99

241550701 Frigidaire Refrigerator Shelf Mount In Stock WCI 241550701 $13.29

241583301 Frigidaire Refrigerator Air Deflect Backorder WCI 241583301 $36.59

241595202 Frigidaire Refrigerator Clip Backorder WCI 241595202 $13.29

241806601 Frigidaire Refrigerator Water Conne In Stock WCI 241806601 $50.28

241850615 Frigidaire Ice Maker Fill Tube Asse In Stock WCI 241850615 $27.17

241914702 Frigidaire Refrigerator Ice Contain In Stock WCI 241914702 $199.54

5303918256 Frigidaire Refrigerator Heater Kit In Stock WCI 5303918256 $461.95

5303918327 Frigidaire Refrigerator Heat Excha In Stock WCI 5303918327 $216.33

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $11.64

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $11.09

WCI 5303918222 WCI 5303918222 Contact Us For Availability

WCI 241520403 WCI 241520403 Contact Us For Availability

WCI 241686201 WCI 241686201 Contact Us For Availability
