Model Electrolux 253.58082890 Side-By-Side Refrigerator (Kenmore 25358082890) – Common Parts &amp; Diagrams

1

Refrigerator Freezer Gasket WCI 215734311 Contact Us For Availability

1A

Refrigerator Water Tubing WCI 215294101 Contact Us For Availability

1B

Refrigerator Ice Maker Water Tubing WCI 218658301 Contact Us For Availability

1C

Refrigerator Water Inlet Tube WCI 218770401 Contact Us For Availability

2

241716101 Frigidaire Refrigerator Ice Auger Backorder WCI 241716101 $86.89

2

Spring WCI 3206348 Contact Us For Availability

2

Deflector-ic WCI 218505301 Contact Us For Availability

2

Refrigerator Gasket WCI 215734312 Contact Us For Availability

2

Refrigerator Knob Damper WCI 5303323264 Contact Us For Availability

3

241685201 Frigidaire Refrigerator Drive Cam Backorder WCI 241685201 $30.96

3

Refrigerator Ice Maker Decal WCI 3206299 Contact Us For Availability

3

Refrigerator Door Heater WCI 215484300 Contact Us For Availability

3

Refrigerator Inner Panel WCI 218749301 Contact Us For Availability

4

241734001 Frigidaire Refrigerator Ice Bucket In Stock WCI 241734001 $74.87

4

5304469403 Frigidaire Gear Backorder WCI 5304469403 $14.78

4

Refrigerator Door Shelf Rail WCI 215472100 Contact Us For Availability

4

Refrigerator Dispenser Housing WCI 218432101 Contact Us For Availability

5

215267701 Frigidaire Refrigerator White Door In Stock WCI 215267701 $3.29

5

215473602 Frigidaire Refrigerator White Left In Stock WCI 215473602 $3.84

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $43.01

5

Refrigerator Ice Maker Cover Bracket WCI 3206303 Contact Us For Availability

6

218359202 Frigidaire Refrigerator Screw Backorder WCI 218359202 $7.86

6

241685101 Frigidaire Refrigerator Ice Dispens In Stock WCI 241685101 $44.53

6

3206166 Frigidaire Refrigerator Freezer Door In Stock WCI 3206166 $7.34

6A

3206165 Frigidaire Bar Endcap Right Hand In Stock WCI 3206165 $5.65

7

241734201 Frigidaire Refrigerator Front Ice C Backorder WCI 241734201 $64.47

7

5303918277 Frigidaire Refrigerator Ice Maker In Stock WCI 5303918277 $68.28

7

Refrigerator Power Cord WCI 215459201 Contact Us For Availability

7

Refrigerator Switch WCI 218841901 Contact Us For Availability

7

Refrigerator Evaporator Fan Ring WCI 5308000124 Contact Us For Availability

7

Refrigerator Dairy Door WCI 215058116 Contact Us For Availability

7A

Refrigerator Shield WCI 215944300 Contact Us For Availability

8

Refrigerator Dispenser Ice Chute WCI 218835701 Contact Us For Availability

8

Refrigerator Freezer Door Rack WCI 215472200 Contact Us For Availability

8

Spacer WCI 3206312 Contact Us For Availability

8

Refrigerator Bushing WCI 5300157666 Contact Us For Availability

8A

Refrigerator Door Rack WCI 215806341 Contact Us For Availability

9

Cam WCI 3206313 Contact Us For Availability

9

Refrigerator Inner Panel WCI 218748601 Contact Us For Availability

9

Refrigerator Bracket WCI 5303205118 Contact Us For Availability

10

Clamp WCI 3206315 Contact Us For Availability

10

Cover-air Du WCI 218748901 Contact Us For Availability

10

Refrigerator Dispenser Spring WCI 218209800 Contact Us For Availability

10A

Refrigerator Control Cover Evaporator WCI 218751301 Contact Us For Availability

11

5303208309 Frigidaire Refrigerator Plug Hole In Stock WCI 5303208309 $31.49

11

Kenmore Pro Refrigerator Ice Maker Thermal Cu WCI 3206319 Contact Us For Availability

11

Wh Fz Dr Pnl WCI 5303918047 Contact Us For Availability

5303001147 Frigidaire Refrigerator Hole Harne Backorder WCI 5303001147 $16.51

Refrigerator Ice Maker Wire Harness WCI 3206349 Contact Us For Availability

Refrigerator Select Knob WCI 218836201 Contact Us For Availability

Refrigerator Air Diffuser WCI 215809600 Contact Us For Availability

12A

Refrigerator Ice Maker Wire Harness Connector WCI 3206321 Contact Us For Availability

Refrigerator Door Stop WCI 5303289522 Contact Us For Availability

Refrigerator Ice Maker Thermostat WCI 3206322 Contact Us For Availability

Refrigerator Dispenser Lever Retainer WCI 215748101 Contact Us For Availability

Refrigerator Motor WCI 215426200 Contact Us For Availability

13A

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $13.64

14

Refrigerator Ice Maker Motor Screw WCI 3206323 Contact Us For Availability

14

Cover Label WCI 218416175 Contact Us For Availability

14

Refrigerator Bracket WCI 5303205119 Contact Us For Availability

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $12.40

5304456667 Frigidaire Refrigerator Micro Swit Backorder WCI 5304456667 $64.04

Refrigerator Bulb WCI 218284900 Contact Us For Availability

Wh Rf Dr Pnl WCI 5303918044 Contact Us For Availability

240548901 Frigidaire Refrigerator P-1 Socket In Stock WCI 240548901 $44.09

241559801 Frigidaire Light Socket Refrigerato Backorder WCI 241559801 $55.30

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.49

Support WCI 3206326 Contact Us For Availability

241684503 Frigidaire Ice Crusher Blade In Stock WCI 241684503 $12.06

241798231 Frigidaire Refrigerator Ice Maker A In Stock WCI 241798231 $145.94

Dispenser Screw WCI 215794400 Contact Us For Availability

Refrigerator Control Box WCI 5303289049 Contact Us For Availability

17A

Refrigerator Screw WCI 215840700 Contact Us For Availability

17A

Refrigerator Control Box WCI 5303321928 Contact Us For Availability

17AA

Flat Washer WCI 215923400 Contact Us For Availability

297272500 Frigidaire Refrigerator Door Handle In Stock WCI 297272500 $58.26

5304462594 Frigidaire Refrigerator Auger Moto Backorder WCI 5304462594 $232.73

Ejector WCI 3206328 Contact Us For Availability

Air Support WCI 5303289043 Contact Us For Availability

Refrigerator Temperature Complete Knob WCI 5303323263 Contact Us For Availability

18A

Air Support WCI 5303289044 Contact Us For Availability

18A

Wiring-hrnes WCI 5304404335 Contact Us For Availability

19

Bearing WCI 3206330 Contact Us For Availability

20

Screw WCI 3206331 Contact Us For Availability

20

Refrigerator Motor Cover WCI 5304404881 Contact Us For Availability

20

Refrigerator Label Control WCI 5303423117 Contact Us For Availability

20A

Refrigerator Label Control WCI 5303324116 Contact Us For Availability

218843801 Frigidaire Refrigerator Screw Backorder WCI 218843801 $9.96

241726501 Frigidaire Refrigerator Drive Bar In Stock WCI 241726501 $35.48

Refrigerator Temperature Control Thermostat WCI 5303300027 Contact Us For Availability

Ice Stripper WCI 3206332 Contact Us For Availability

21A

Refrigerator Door Stop Screw, #10-16 x 3/4-in WCI 218578600 Contact Us For Availability

21C

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $10.49

22

Refrigerator Door Hinge Bushing WCI 5303289320 Contact Us For Availability

22

Temperature Housing WCI 5303319683 Contact Us For Availability

22

Arm WCI 3206333 Contact Us For Availability

22A

Refrigerator Door Bushing WCI 215615300 Contact Us For Availability

22A

Refrigerator Tube WCI 218731102 Contact Us For Availability

215846602 Frigidaire Refrigerator 8-Hour Defr In Stock WCI 215846602 $23.29

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $31.49

241684001 Frigidaire Refrigerator Front Plate Backorder WCI 241684001 $110.76

Refrigerator Dispenser Drip Tray WCI 5303297844 Contact Us For Availability

Screw WCI 3206334 Contact Us For Availability

Refrigerator Door Hinge Bushing WCI 5303001020 Contact Us For Availability

23A

5304455649 Frigidaire Refrigerator Screw Backorder WCI 5304455649 $12.59

23B

Defrost Cover WCI 215277000 Contact Us For Availability

23C

Defrost Shield WCI 5303289058 Contact Us For Availability

24

5304456675 Frigidaire Refrigerator Lever Arm Backorder WCI 5304456675 $49.34

24

Refrigerator Dispenser Lever Actuator (White) WCI 218796501 Contact Us For Availability

25

Screw WCI 3206336 Contact Us For Availability

25A

Refrigerator Crisper Drawer Trim WCI 218015301 Contact Us For Availability

26

5303288971 Frigidaire Refrigerator Storage Pa In Stock WCI 5303288971 $121.19

26

Screw WCI 3206337 Contact Us For Availability

26A

Refrigerator Crisper Drawer WCI 5303288968 Contact Us For Availability

27

Slide Cam WCI 218432600 Contact Us For Availability

27

Screw WCI 3206338 Contact Us For Availability

27A

Refrigerator Dispenser Rocker Switch WCI 218814901 Contact Us For Availability

28

Screw WCI 3206339 Contact Us For Availability

28

Refrigerator Bolt Roller WCI 5303289062 Contact Us For Availability

28

Refrigerator Module Cover WCI 218700601 Contact Us For Availability

29

Refrigerator Washer WCI 215003200 Contact Us For Availability

29

Screw WCI 3206340 Contact Us For Availability

29A

Refrigerator Door Hinge Washer WCI 215314301 Contact Us For Availability

29B

Flat Washer WCI 215598900 Contact Us For Availability

30

Screw WCI 3206341 Contact Us For Availability

30

Refrigerator Lower Bracket WCI 5303289060 Contact Us For Availability

30

Door Assy-ic WCI 215753600 Contact Us For Availability

30A

Refrigerator Lower Bracket WCI 215009000 Contact Us For Availability

30B

Refrigerator Door Left Hinge Plate WCI 218730700 Contact Us For Availability

30C

Tapping Plate WCI 218730800 Contact Us For Availability

31

Insulator WCI 3206342 Contact Us For Availability

32

Refrigerator Ice Maker Fill Switch Bracket WCI 3206343 Contact Us For Availability

33

241684802 Frigidaire Refrigerator Spacer In Stock WCI 241684802 $6.29

33

Spring WCI 3206344 Contact Us For Availability

33

Heater Dispenser WCI 218849801 Contact Us For Availability

34

241689802 Frigidaire Refrigerator Spacer In Stock WCI 241689802 $5.76

34

Screw WCI 3206345 Contact Us For Availability

35

Refrigerator Ice Dispenser Door Heat Motor WCI 218740003 Contact Us For Availability

35

Screw WCI 3206346 Contact Us For Availability

35A

241684303 Frigidaire Refrigerator Fixed Blade In Stock WCI 241684303 $12.06

35B

241684203 Frigidaire Refrigerator Fixed Blade Backorder WCI 241684203 $12.59

36

Cover WCI 3206347 Contact Us For Availability

36

Refrigerator Selector Switch Cover WCI 218835601 Contact Us For Availability

37

Refrigerator Corner Trim WCI 5303321081 Contact Us For Availability

37

Refrigerator Door Handle Trim, Upper (White) WCI 218779307 Contact Us For Availability

37

Technical Data Sheet WCI 5303320544 Contact Us For Availability

37A

241684107 Frigidaire Refrigerator Ice Crusher Backorder WCI 241684107 $15.21

37A

Refrigerator Handle Trim WCI 218779304 Contact Us For Availability

37AA

Refrigerator Lock Handle WCI 215940700 Contact Us For Availability

37B

241684108 Frigidaire Refrigerator Ice Crusher Backorder WCI 241684108 $15.21

37C

241684109 Frigidaire Ice Crusher Blade Backorder WCI 241684109 $15.21

38

Technical Data Sheet WCI 5303207442 Contact Us For Availability

38

Bracket-uppe WCI 218215213 Contact Us For Availability

38A

Refrigerator Dispenser Switch WCI 218479900 Contact Us For Availability

38A

Brkt Upr Hin WCI 218215215 Contact Us For Availability

38B

241689106 Frigidaire Refrigerator Micro Switc In Stock WCI 241689106 $6.87

39

241690501 Frigidaire Refrigerator Screw Backorder WCI 241690501 $12.06

39

Wire-ice Doo WCI 218284600 Contact Us For Availability

40

Refrigerator Door Hinge Cover, Upper (White) WCI 5303318773 Contact Us For Availability

40

Refrigerator Dispenser Ice Chute Door Motor Y WCI 218284500 Contact Us For Availability

241885001 Frigidaire Refrigerator Ice Crusher In Stock WCI 241885001 $50.74

5304509705 Frigidaire Refrigerator Grommet In Stock WCI 5304509705 $7.31

5308000039 Frigidaire Refrigerator Screw Backorder WCI 5308000039 $8.91

Spring-actua WCI 215765400 Contact Us For Availability

41A

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.71

43

Refrigerator Roller WCI 218615300 Contact Us For Availability

43A

Refrigerator Screw WCI 5308017044 Contact Us For Availability

44

5308000133 Frigidaire Refrigerator Clamp Backorder WCI 5308000133 $8.39

44

Refrigerator Roller WCI 218738300 Contact Us For Availability

44

Refrigerator Screw WCI 218359200 Contact Us For Availability

45

241675704 Frigidaire Refrigerator Solenoid As In Stock WCI 241675704 $48.53

45

5304455651 Frigidaire Refrigerator Screw In Stock WCI 5304455651 $9.96

46

5303001193 Frigidaire Refrigerator Clamp Backorder WCI 5303001193 $12.06

46

Refrigerator Crisper Drawer Window WCI 5303317753 Contact Us For Availability

46

Refrigerator Control Rod WCI 5304404341 Contact Us For Availability

Refrigerator Water Inlet Valve Connection WCI 5308000205 Contact Us For Availability

Refrigerator Shelf Support WCI 218659500 Contact Us For Availability

Refrigerator Rod Spring WCI 5304404342 Contact Us For Availability

Refrigerator Wiring Harness WCI 218849901 Contact Us For Availability

48

241684602 Frigidaire Refrigerator Control Rod Backorder WCI 241684602 $79.26

48A

Refrigerator Bracket Screw WCI 5304404364 Contact Us For Availability

49

215441502 Frigidaire Refrigerator Door Bin Backorder WCI 215441502 $124.68

49

Heat Bracket WCI 215794000 Contact Us For Availability

49

Refrigerator Rail Assembly WCI 5304404880 Contact Us For Availability

50

241675601 Frigidaire Refrigerator Solenoid Gu Backorder WCI 241675601 $59.31

51

Refrigerator Hanger Basket WCI 5303288960 Contact Us For Availability

51

Fill Tube WCI 215811600 Contact Us For Availability

51

Rotation Stop WCI 5304404336 Contact Us For Availability

52

Refrigerator Ice Maker Fill Tube WCI 215454600 Contact Us For Availability

52

Refrigerator Hanger Basket WCI 215162501 Contact Us For Availability

52

SPACER-FIXED BLADES WCI 530440354 Contact Us For Availability

53

241690402 Frigidaire Refrigerator Spiral Pin Backorder WCI 241690402 $14.16

53

Box Damper Control WCI 215809509 Contact Us For Availability

54

Refrigerator Nut Auger WCI 530440357 Contact Us For Availability

55

241690306 Frigidaire Refrigerator Washer In Stock WCI 241690306 $36.74

55

Refrigerator Water Inlet Valve WCI 218698900 Contact Us For Availability

55A

Refrigerator Ice Maker Water Inlet Valve Cap WCI 218835800 Contact Us For Availability

56

Micro Screw WCI 218434300 Contact Us For Availability

56

Refrigerator E-Ring WCI 530440361 Contact Us For Availability

57

241734101 Frigidaire Refrigerator Front Acces Backorder WCI 241734101 $37.47

58

Solenoid Screw WCI 5304404331 Contact Us For Availability

58

Refrigerator Door Inner Liner Screw WCI 218749600 Contact Us For Availability

59

Sleeve WCI 5303001191 Contact Us For Availability

60

5304455852 Frigidaire Refrigerator Screw Backorder WCI 5304455852 $9.44

60

Refrigerator Condenser Fan Motor WCI 215501901 Contact Us For Availability

61

218721500 Frigidaire Refrigerator Leveling Br Backorder WCI 218721500 $54.06

61

Refrigerator Retainer Ring WCI 215766000 Contact Us For Availability

61B

Grommet WCI 215004800 Contact Us For Availability

62

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $9.96

62

Refrigerator Drain Trough WCI 215048201 Contact Us For Availability

64

241957901 Frigidaire Refrigerator Drain Tube Backorder WCI 241957901 $45.14

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $7.86

65

Refrigerator Spacer Tube WCI 5303289301 Contact Us For Availability

65

Refrigerator Push Pin WCI 5303001361 Contact Us For Availability

66

Meat Damper WCI 215050201 Contact Us For Availability

66A

Meat Keeper Cover WCI 218171301 Contact Us For Availability

68

Refrigerator Dispenser Ice Chute WCI 218020600 Contact Us For Availability

70

Refrigerator Bracket Evaporator WCI 5303289041 Contact Us For Availability

71

218515401 Frigidaire Refrigerator Clip Backorder WCI 218515401 $13.11

72

Refrigerator Door Handle Mounting Grommet WCI 218397000 No Longer Available

72

Refrigerator Toe Grille WCI 218359613 Contact Us For Availability

73

218396700 Frigidaire Door Handle Mounting Blo In Stock WCI 218396700 $39.05

74

215503203 Frigidaire Refrigerator Door Handle In Stock WCI 215503203 $5.24

75

Refrigerator Light Shield WCI 218465101 Contact Us For Availability

76

Refrigerator Light Cover WCI 218225800 Contact Us For Availability

77

Washer WCI 5303001216 Contact Us For Availability

80

Complete Seal Coil WCI 218249802 Contact Us For Availability

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $10.49

82

Refrigerator Screw WCI 215296300 Contact Us For Availability

83

Refrigerator Bracket WCI 5308000107 Contact Us For Availability

85

Cov-lo Hi,wh WCI 218359801 Contact Us For Availability

89

Cover-machin WCI 5303288947 Contact Us For Availability

90

Refrigerator Foam Seal WCI 215022602 Contact Us For Availability

91

Air Deflector WCI 218769900 Contact Us For Availability

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $9.96

96

Refrigerator Water Reservoir Support WCI 215192600 Contact Us For Availability

100A

Refrigerator Crisper Drawer Cover Support WCI 218015501 Contact Us For Availability

100B

Refrigerator Crisper Drawer Shelf Frame Suppo WCI 218015601 Contact Us For Availability

101

Refrigerator Foam Seal WCI 215305701 Contact Us For Availability

111

Wireway WCI 5303289024 Contact Us For Availability

112

Rod-damper E WCI 215277101 Contact Us For Availability

113

Cover-dmpr R WCI 5303289047 Contact Us For Availability

114

5303289051 Frigidaire Refrigerator Light Swit Backorder WCI 5303289051 $19.41

115

Refrigerator Air Damper Assembly WCI 215011504 Contact Us For Availability

116

Seal Damper WCI 215011400 Contact Us For Availability

125

Refrigerator Auger Kill Switch WCI 215334201 Contact Us For Availability

137

Frigidaire WFCB PureSource Plus Refrigerator In Stock WCI WFCB $39.24

138

Refrigerator Filter Cup WCI 218657404 Contact Us For Availability

138A

Refrigerator Water Filter Cup O-Ring WCI 218720100 Contact Us For Availability

139

Refrigerator Filter Housing WCI 218657500 Contact Us For Availability

140

Refrigerator Water Line Elbow Fitting WCI 218518700 Contact Us For Availability

141

Refrigerator Water Inlet Valve WCI 218658000 Contact Us For Availability

142

Refrigerator Indicator Knob WCI 218657701 Contact Us For Availability

143

Refrigerator Water Heater WCI 218696700 Contact Us For Availability

218710300 Frigidaire Refrigerator Water Filte In Stock WCI 218710300 $3.33

218769500 Frigidaire Use and Care Label Backorder WCI 218769500 $3.66

5303321319 Frigidaire Refrigerator White Touc In Stock WCI 5303321319 $9.96

Refrigerator Door Insulation WCI 5303917276 Contact Us For Availability

Tape WCI 5300460947 Contact Us For Availability

Refrigerator Liner Button Hole Plug WCI 5308016571 Contact Us For Availability

Genuine Kenmore Refrigerator Water Filter, 2- WCI 9906P Contact Us For Availability

Refrigerator Screw Control WCI 215188300 Contact Us For Availability

Solenoid Screw WCI 215290100 Contact Us For Availability

Refrigerator Shelf Clip WCI 215328300 Contact Us For Availability

Refrigerator Tube Clip WCI 215781700 Contact Us For Availability

Refrigerator Wiring Harness WCI 218646000 Contact Us For Availability

Refrigerator Service Data Sheet WCI 218764500 Contact Us For Availability

Air Deflector WCI 218836401 Contact Us For Availability

Refrigerator Owner's Manual WCI 218860000 Contact Us For Availability

Refrigerator Freezer Door Wire Harness WCI 218863101 Contact Us For Availability

Refrigerator Nut WCI 5303209814 Contact Us For Availability

Hot Tube Rep WCI 5303917166 Contact Us For Availability

Washer WCI 5308009617 Contact Us For Availability

Refrigerator Repair Parts List WCI 5995305298 Contact Us For Availability
