Model Electrolux 253.38674890 Top-Mount Refrigerator (Kenmore 25338674890) – Common Parts &amp; Diagrams

1

Refrigerator Freezer Door Gasket (White) WCI 5308007123 Contact Us For Availability

1

Refrigerator Mullion WCI 218651800 Contact Us For Availability

1

Refrigerator Fan Cover WCI 218672501 Contact Us For Availability

1A

5303017691 Frigidaire Refrigerator Tube Space Backorder WCI 5303017691 $47.76

2

218730603 Frigidaire Door Gasket In Stock WCI 218730603 $37.40

2

Refrigerator Knob Damper WCI 5303307351 Contact Us For Availability

3

Refrigerator Inner Panel WCI 218359301 Contact Us For Availability

3

Refrigerator Push Nut WCI 5303001028 Contact Us For Availability

4

Refrigerator Air Damper Control WCI 218722200 Contact Us For Availability

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $43.01

5

Heater Mullion WCI 218781001 Contact Us For Availability

5A

215473602 Frigidaire Refrigerator White Left In Stock WCI 215473602 $3.84

6

Tapping Plate WCI 218279800 Contact Us For Availability

6

Refrigerator Button (White) WCI 5303001388 Contact Us For Availability

7

Refrigerator Panel WCI 218740400 Contact Us For Availability

7

Refrigerator Dairy Door WCI 218287818 Contact Us For Availability

8

215366002 Frigidaire Refrigerator Wide Door R In Stock WCI 215366002 $44.52

8

Divider Styf WCI 218781300 Contact Us For Availability

8

Refrigerator Bushing WCI 5300157666 Contact Us For Availability

9

Refrigerator Bottom WCI 3206187 Contact Us For Availability

9

Refrigerator Inner Door Panel WCI 218358801 Contact Us For Availability

9

Refrigerator Bracket WCI 5303205118 Contact Us For Availability

10

Refrigerator Door Hinge Hole Cover (White) WCI 5308000134 Contact Us For Availability

10

Refrigerator Control Cover Evaporator WCI 218829701 Contact Us For Availability

10A

Refrigerator Nut WCI 5303209814 Contact Us For Availability

5303208309 Frigidaire Refrigerator Plug Hole In Stock WCI 5303208309 $31.49

Refrigerator Freezer Wire Shelf WCI 5303283107 Contact Us For Availability

Kenmore Pro Refrigerator Ice Maker Thermal Cu WCI 3206319 Contact Us For Availability

Refrigerator Freezer Drive Panel WCI 5303918005 Contact Us For Availability

12

Refrigerator Air Deflector WCI 218730000 Contact Us For Availability

12

Refrigerator Ice Maker Wire Harness WCI 3206349 Contact Us For Availability

12A

5303001449 Frigidaire Refrigerator Seal Backorder WCI 5303001449 $1.56

12A

Refrigerator Ice Maker Wire Harness Connector WCI 3206321 Contact Us For Availability

5300158289 Frigidaire Evaporator Fan Motor In Stock WCI 5300158289 $95.68

Refrigerator Air Damper Cover WCI 218631001 Contact Us For Availability

Refrigerator Ice Maker Thermostat WCI 3206322 Contact Us For Availability

Refrigerator Door Stop WCI 5303212491 Contact Us For Availability

13A

Refrigerator Door Stop (White) WCI 218249001 Contact Us For Availability

14

5309918806 Frigidaire Refrigerator Light Swit Backorder WCI 5309918806 $16.26

14

Refrigerator Defrost Heater WCI 5308009754 Contact Us For Availability

14

Refrigerator Mounting Bracket WCI 5303322992 Contact Us For Availability

14A

240494001 Frigidaire Refrigerator Plug Button In Stock WCI 240494001 $12.59

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $13.48

15

Refrigerator Evaporator WCI 218818701 Contact Us For Availability

15

Refrigerator Drive Panel WCI 5303918007 Contact Us For Availability

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $42.93

16A

218906802 Frigidaire Light Lamp Socket In Stock WCI 218906802 $15.24

17

Refrigerator Evaporator Insulation WCI 5316651102 Contact Us For Availability

17

Refrigerator Control Box WCI 5303321455 Contact Us For Availability

17

Refrigerator Drain Trough WCI 218725602 Contact Us For Availability

17A

Refrigerator Nut Anchor WCI 5308016567 Contact Us For Availability

18

218779901 Frigidaire Refrigerator White Fresh In Stock WCI 218779901 $53.29

18

Refrigerator Temperature Complete Knob WCI 5303311079 Contact Us For Availability

18

Refrigerator Support Evaporator WCI 215245000 Contact Us For Availability

18A

Refrigerator Door Handle (White) WCI 218779801 Contact Us For Availability

19

Refrigerator Rocker Switch WCI 5303286905 Contact Us For Availability

19

Refrigerator Tube WCI 5303001198 Contact Us For Availability

20

Refrigerator Ferrule WCI 5303001286 Contact Us For Availability

21

5304404821 Frigidaire Cold Control Thermostat In Stock WCI 5304404821 $109.51

21

Refrigerator Ferrule WCI 5303001287 Contact Us For Availability

21A

Refrigerator Screw WCI 5303001260 Contact Us For Availability

21C

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $10.49

22

215774901 Frigidaire Refrigerator Button Plug In Stock WCI 215774901 $12.59

22

Refrigerator Door Hinge Bushing WCI 218519300 Contact Us For Availability

22A

5303916855 Frigidaire Refrigerator Tube Backorder WCI 5303916855 $45.14

22B

Refrigerator Air Deflector Tube WCI 218731104 Contact Us For Availability

23

215846602 Frigidaire Refrigerator 8-Hour Defr In Stock WCI 215846602 $23.29

23

Refrigerator Drain Tube and Seal WCI 5303210377 Contact Us For Availability

23A

5304455649 Frigidaire Refrigerator Screw Backorder WCI 5304455649 $12.59

24

Refrigerator Drain Tube Seal WCI 5303207353 Contact Us For Availability

24

Refrigerator Shelf WCI 218272501 Contact Us For Availability

25

Refrigerator Crisper Cover WCI 218314110 Contact Us For Availability

25

Spout Drain WCI 215774100 Contact Us For Availability

25A

Cover Trim WCI 5304403087 Contact Us For Availability

26

Refrigerator Crisper Drawer WCI 3206180 Contact Us For Availability

26

Refrigerator Cabinet Base WCI 218605001 Contact Us For Availability

28

Refrigerator Freezer Shelf End Cap WCI 3201150 Contact Us For Availability

28

Refrigerator Defrost Drain Pan Retainer Kit WCI 5303916001 Contact Us For Availability

28

Refrigerator Bolt WCI 5303271412 Contact Us For Availability

29

Refrigerator Shelf Trim WCI 218366101 Contact Us For Availability

29

Washer WCI 218666700 Contact Us For Availability

29A

Refrigerator Roller Wheel Washer WCI 5308011326 Contact Us For Availability

30

Refrigerator Lower Bracket WCI 218220200 Contact Us For Availability

30A

Tapping Plate WCI 218605200 Contact Us For Availability

30B

Tapping Plate WCI 218605300 Contact Us For Availability

30C

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $10.49

34

5303212918 Frigidaire Refrigerator Control Backorder WCI 5303212918 $72.44

35

Refrigerator Crisper Trim WCI 5303317419 Contact Us For Availability

35

Refrigerator Bracket WCI 218220101 Contact Us For Availability

36

218251300 Frigidaire Refrigerator Center Hing Backorder WCI 218251300 $44.09

37

Refrigerator Corner Trim WCI 5303321081 Contact Us For Availability

37

Technical Data Sheet WCI 5303320544 Contact Us For Availability

37A

Refrigerator Door Handle Trim WCI 218771201 Contact Us For Availability

38

Envelope WCI 5303207445 Contact Us For Availability

38

Refrigerator Bracket WCI 3206100 Contact Us For Availability

38A

Refrigerator Plate WCI 5308012296 Contact Us For Availability

39

Refrigerator Wire Harness WCI 3206358 Contact Us For Availability

40

5305877995 Frigidaire Refrigerator P-1 Sealin In Stock WCI 5305877995 $40.94

40

Refrigerator Hinge Cover (White) WCI 3206101 Contact Us For Availability

41

5304509705 Frigidaire Refrigerator Grommet In Stock WCI 5304509705 $7.31

41

5308000039 Frigidaire Refrigerator Screw Backorder WCI 5308000039 $8.91

41A

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.71

43

5303001199 Frigidaire Refrigerator Wiring Har Backorder WCI 5303001199 $48.81

43

Refrigerator Roller Assembly WCI 218703001 Contact Us For Availability

44

5308000133 Frigidaire Refrigerator Clamp Backorder WCI 5308000133 $8.39

44

Refrigerator Roller Assembly WCI 218713600 Contact Us For Availability

45

5304455651 Frigidaire Refrigerator Screw In Stock WCI 5304455651 $9.96

45A

Wiring Screw WCI 218754500 Contact Us For Availability

46

5303001193 Frigidaire Refrigerator Clamp Backorder WCI 5303001193 $12.06

46

Refrigerator Crisper Drawer WCI 5303307450 Contact Us For Availability

46

Refrigerator Screw WCI 5308009762 Contact Us For Availability

47

Refrigerator Water Inlet Valve Connection WCI 3206360 Contact Us For Availability

47

Refrigerator Glass WCI 218498143 Contact Us For Availability

48

Nut WCI 5308000200 Contact Us For Availability

48

Refrigerator Door Bucket WCI 218286008 Contact Us For Availability

49

5303001147 Frigidaire Refrigerator Hole Harne Backorder WCI 5303001147 $16.51

49

Refrigerator Door Bucket WCI 5304401374 Contact Us For Availability

52

215456100 Frigidaire Refrigerator Water Inlet In Stock WCI 215456100 $82.64

55

Refrigerator Water Valve WCI 218720300 Contact Us For Availability

55A

Refrigerator Ice Maker Water Inlet Valve Cap WCI 5303015102 Contact Us For Availability

56

Lower Hinge Pin WCI 218220300 Contact Us For Availability

58

Refrigerator Door Inner Liner Screw WCI 218749600 Contact Us For Availability

59

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $5.76

59

Sleeve WCI 5303001191 Contact Us For Availability

60

5304455852 Frigidaire Refrigerator Screw Backorder WCI 5304455852 $9.44

61

218721500 Frigidaire Refrigerator Leveling Br Backorder WCI 218721500 $54.06

62

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $9.96

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $7.86

72

Refrigerator Door Handle Mounting Grommet WCI 218397000 No Longer Available

73

218396700 Frigidaire Door Handle Mounting Blo In Stock WCI 218396700 $39.05

74

215503203 Frigidaire Refrigerator Door Handle In Stock WCI 215503203 $5.24

83

Refrigerator Bracket WCI 5308000107 Contact Us For Availability

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $9.96

98

Refrigerator Door Hole Plug WCI 215099701 Contact Us For Availability

100

Refrigerator Crisper Drawer Cover Support Stu WCI 5303288973 Contact Us For Availability

145

Refrigerator Clip WCI 218660800 Contact Us For Availability

218827100 Frigidaire Owner's Manual Backorder WCI 218827100 $9.87

5303321319 Frigidaire Refrigerator White Touc In Stock WCI 5303321319 $9.96

Refrigerator Door Insulation WCI 5303917276 Contact Us For Availability

Refrigerator Pad WCI 08000185 Contact Us For Availability

Technical Data Sheet WCI 218755000 Contact Us For Availability

Hot Tube WCI 5300189383 Contact Us For Availability

Refrigerator Label WCI 5303270944 Contact Us For Availability

Refrigerator Parts List WCI 5995302147 Contact Us For Availability
