Model Bosch B20CS50SNB/02 Fridge Freezer – Common Parts & Diagrams
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Common parts from model Bosch B20CS50SNB/02 Fridge Freezer
0107
PC board BOS 00640603 Contact Us For Availability
0110
Tube BOS 00640562 Contact Us For Availability
0123
Hose connection inlet BOS 00604203 Contact Us For Availability
0124
Holder BOS 00640564 No Longer Available
0126
Cap BOS 00605009 Contact Us For Availability
0201
Tray BOS 00446038 Contact Us For Availability
0202
Tray BOS 00446040 Contact Us For Availability
0203
Tray BOS 00705812 Contact Us For Availability
0205
Handle-door BOS 00661271 Contact Us For Availability
0206
Fixture BOS 00601243 Contact Us For Availability
0212
Spring BOS 00601295 Contact Us For Availability
0213
Dispenser - for a B20CS* series order # 10001 BOS 00498002 Contact Us For Availability
0215
Valve-magnet BOS 00606103 No Longer Available
0218
Key BOS 00601306 Contact Us For Availability
0301
Tray BOS 00446134 No Longer Available
0302
Tray BOS 00446135 Contact Us For Availability
0303
Shelf BOS 00446136 Contact Us For Availability
0307
Tray BOS 00660362 Contact Us For Availability
0401
Evaporator BOS 00244307 Contact Us For Availability
0402
Heater-defrost BOS 00701751 Contact Us For Availability
0405
Fuse-thermal BOS 00620925 Contact Us For Availability
0410
Damper BOS 00601066 Contact Us For Availability
0414
Fan Motor BOS 00601068 Contact Us For Availability
0422
Ice maker BOS 00649288 Contact Us For Availability
0428
Ice maker BOS 00497882 Contact Us For Availability
0429
Cover BOS 00446023 Contact Us For Availability
0431
Light socket BOS 00605020 Contact Us For Availability
0436
Sensor BOS 00601087 Contact Us For Availability
0440
Frozen food container BOS 00446035 Contact Us For Availability
0441
Frozen food container BOS 00446037 Contact Us For Availability
0502
Fan BOS 00497841 Contact Us For Availability
0505
Sensor BOS 00601048 Contact Us For Availability
0512
Switch-door BOS 00611397 Contact Us For Availability
0513
Egg Container BOS 00497852 Contact Us For Availability
0514
Glass plate BOS 00670866 Contact Us For Availability
0515
Glass plate BOS 00670867 Contact Us For Availability
0518
Rail BOS 00445985 Contact Us For Availability
0519
Rail BOS 00445987 Contact Us For Availability
0523
Rail BOS 00445996 Contact Us For Availability
0524
Rail BOS 00445997 Contact Us For Availability
0526
Tank BOS 00497859 Contact Us For Availability
0604
Capacitor BOS 00618153 Contact Us For Availability
0605
Compressor BOS 00144935 Contact Us For Availability
0606
Starting device BOS 00605015 No Longer Available
0610
Valve access BOS 00640574 Contact Us For Availability
0611
Condenser BOS 00657187 Contact Us For Availability
0617
Fan blade BOS 00640117 Contact Us For Availability
× ![]()
