Model Electrolux TEF362BBBE RANGE – Common Parts &amp; Diagrams

*76808

SCREW-HEAT SHIELD, HD SHLDR SQDR, 8-18 X 1/2 WCI 5303288570 Contact Us For Availability

*76809

WCI 316001342 WCI 316001342 Contact Us For Availability

*76811

WCI 316021108 WCI 316021108 Contact Us For Availability

*76812

WCI 316078000 WCI 316078000 Contact Us For Availability

*76813

WCI 5303280311 WCI 5303280311 Contact Us For Availability

*76815

SCREW, TRUSS HEAD, 8-10 X 0.375 WCI 5303288574 Contact Us For Availability

*76816

WCI 5309951550 WCI 5309951550 Contact Us For Availability

*76817

WCI 316065301 WCI 316065301 Contact Us For Availability

*76818

SCREW, CR PAN HD SEMS, 8-32BP X 1.00 WCI 5303212671 Contact Us For Availability

*76819

5303271648 Frigidaire Oven Screw Backorder WCI 5303271648 $10.50

*76821

5303285179 Frigidaire Oven Door Screw Backorder WCI 5303285179 $10.53

*76822

131243700 Frigidaire Screw In Stock WCI 131243700 $2.65

1

WCI 316080801 WCI 316080801 Contact Us For Availability

1

DRAWER-UTILITY WCI 316011501 Contact Us For Availability

2

WCI 316063503 WCI 316063503 Contact Us For Availability

3

WCI 316081010 WCI 316081010 Contact Us For Availability

3

WCI 316081011 WCI 316081011 Contact Us For Availability

3

SHIELD, HEAT, BODY SIDE (NOT ILLUSTRATED) WCI 3200834 Contact Us For Availability

3

WCI 316067802 WCI 316067802 Contact Us For Availability

4

SCREW, HEX WASHER HEAD, 8-18(AB) X 1/2 (NOT I WCI 08067785 Contact Us For Availability

4

WCI 316056209 WCI 316056209 Contact Us For Availability

4

WCI 316089000 WCI 316089000 Contact Us For Availability

5

316116000 Frigidaire Screw Backorder WCI 316116000 $9.40

5

WCI 316088700 WCI 316088700 Contact Us For Availability

5

WCI 3934058 WCI 3934058 Contact Us For Availability

5

SCREW-LEVELING WCI 5303203397 Contact Us For Availability

5

NUT, T,TYPE, LEVELING SCREW (NOT ILLUSTRATED) WCI 5303288460 Contact Us For Availability

6

5304531722 Frigidaire Rack In Stock WCI 5304531722 $52.20

6

WCI 316088401 WCI 316088401 Contact Us For Availability

7

3051163 Frigidaire Oven Range Rear Broiler Dr In Stock WCI 3051163 $8.11

7

WCI 316007002 WCI 316007002 Contact Us For Availability

7

WCI 316076400 WCI 316076400 Contact Us For Availability

8

WCI 316088600 WCI 316088600 Contact Us For Availability

8

PANEL-OVEN BOTTOM WCI 3203540 Contact Us For Availability

9

WCI 316073800 WCI 316073800 Contact Us For Availability

9

WCI 316066610 WCI 316066610 Contact Us For Availability

10

SCREW-HANDLE MTG, WAFER HEAD, 10-24(T) X 2 WCI 5303280308 Contact Us For Availability

10

WCI 3205234 WCI 3205234 Contact Us For Availability

12

5303131601 Frigidaire Oven Seal Backorder WCI 5303131601 $273.99

12

SWITCH-OVEN LIGHT, DOOR FRAME WCI 316027701 Contact Us For Availability

13

WCI 316026800 WCI 316026800 Contact Us For Availability

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $49.48

14

5303208655 Frigidaire Reflector Assembly Backorder WCI 5303208655 $45.46

14

REFLECTOR, ALUMINUM FOIL WCI 5303208656 Contact Us For Availability

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $22.72

318198817 Frigidaire Oven Element In Stock WCI 318198817 $10.71

WCI 316049701 WCI 316049701 Contact Us For Availability

WCI 316081401 WCI 316081401 Contact Us For Availability

16

5304524341 Frigidaire Lens In Stock WCI 5304524341 $20.29

16

WCI 316035585 WCI 316035585 Contact Us For Availability

16

WCI 316085700 WCI 316085700 Contact Us For Availability

17

316087500 Frigidaire Oven Retainer Backorder WCI 316087500 $44.37

WCI 316036300 WCI 316036300 Contact Us For Availability

RIVET-POP, WARNING-PLATE (NOT ILLUSTRATED) WCI 3203618 Contact Us For Availability

HINGE-MAIN TOP (RH) WCI 5303273062 Contact Us For Availability

HINGE-MAIN TOP (LH) WCI 5303273063 Contact Us For Availability

21

SPACER-BODYSIDE, (8) WCI 3014099 Contact Us For Availability

25

WCI 3200848 WCI 3200848 Contact Us For Availability

28

SHAFT-PUSH BUTTON, CLOCK/TIMER/EOC WCI 316080600 No Longer Available

28

WCI 316045000 WCI 316045000 Contact Us For Availability

29

3051162 Frigidaire Oven Range Front Broiler D In Stock WCI 3051162 $6.60

30

BRACKET-HINGE, MAIN TOP RH WCI 5303283574 Contact Us For Availability

30

BRACKET-HINGE, MAIN TOP, LH WCI 5303283575 Contact Us For Availability

36

WCI 316023301 WCI 316023301 Contact Us For Availability

36

WCI 316041001 WCI 316041001 Contact Us For Availability

36

WCI 316077901 WCI 316077901 Contact Us For Availability

37

5304497424 Frigidaire Oven Temperature Sensor In Stock WCI 5304497424 $42.64

39

WCI 08067961 WCI 08067961 Contact Us For Availability

39

WCI 316008306 WCI 316008306 Contact Us For Availability

41

WCI 3131570 WCI 3131570 Contact Us For Availability

44

3131903 Frigidaire Door/Drawer Bumper Backorder WCI 3131903 $40.48

45

WCI 316066101 WCI 316066101 Contact Us For Availability

49

3205821 Frigidaire Clip Backorder WCI 3205821 $27.73

49

WCI 5303307192 WCI 5303307192 Contact Us For Availability

49

WCI 5303307193 WCI 5303307193 Contact Us For Availability

50

WCI 316072100 WCI 316072100 Contact Us For Availability

51

WCI 316034801 WCI 316034801 Contact Us For Availability

52

WCI 316078100 WCI 316078100 Contact Us For Availability

52

WCI 316081303 WCI 316081303 Contact Us For Availability

54

5304528972 Frigidaire Switch In Stock WCI 5304528972 $41.70

57

WCI 316081101 WCI 316081101 Contact Us For Availability

316047707 Frigidaire Insulation Backorder WCI 316047707 $110.37

316054202 Frigidaire Insulation Backorder WCI 316054202 $56.03

316403803 Frigidaire Insulation In Stock WCI 316403803 $34.39

INSULATION, OVEN TOP WCI 3131304 Contact Us For Availability

59

WCI 316023600 WCI 316023600 Contact Us For Availability

59

BRACKET-VENT TUBE (NOT ILLUSTRATED) WCI 316072400 Contact Us For Availability

59

WCI 316073602 WCI 316073602 Contact Us For Availability

60

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $8.85

60

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $10.53

62

5304409888 Frigidaire Oven Terminal Block Ass In Stock WCI 5304409888 $24.86

63

PLATE=GROUND STRAP WCI 5301145190 Contact Us For Availability

66

5303051140 Frigidaire Broil Element In Stock WCI 5303051140 $158.64

67

316075103 Frigidaire Range Bake Element In Stock WCI 316075103 $24.43

68

316203400 Frigidaire Oven Support Backorder WCI 316203400 $51.80

71

WCI 316015805 WCI 316015805 Contact Us For Availability

72

COVER-LIGHT/SWITCH ROD WCI 5303285692 Contact Us For Availability

82

SHIELD, OVEN BOTTOM WCI 3200825 Contact Us For Availability

87

WCI 316081201 WCI 316081201 Contact Us For Availability

88

WCI 316026400 WCI 316026400 Contact Us For Availability

89

WCI 316028101 WCI 316028101 Contact Us For Availability

105

WCI 316071900 WCI 316071900 Contact Us For Availability
