Model Electrolux RS249JCW2 REFRIGERATOR – Common Parts &amp; Diagrams

*10502

MOLDING-DOOR TRIM WCI G180613-01 Contact Us For Availability

*10508

PLUG-REFRIGERATOR LINER (2) WCI G162892-01 Contact Us For Availability

WCI 5303001047 WCI 5303001047 Contact Us For Availability

HEATER-HOUSING WCI G182738 Contact Us For Availability

HARNESS-DOOR WCI G185226 Contact Us For Availability

FOAM INSULATION-SIDES (2) WCI G189634 Contact Us For Availability

FOAM INSULATION-TOP & BOTTOM (2) WCI G189635 Contact Us For Availability

*10520

WCI G183076 WCI G183076 Contact Us For Availability

*10524

HOT TUBE REPAIR KIT WCI G189379 Contact Us For Availability

1

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $22.72

1

WCI G188250 WCI G188250 Contact Us For Availability

1

REFRIGERATOR DOOR-WHITE WCI 467B377A01 Contact Us For Availability

1

FERRULE - INNER (2) WCI G174733 Contact Us For Availability

1

TRIM (2) WCI G177343-06 Contact Us For Availability

1

FRAME-HOUSING WCI G182518-05 Contact Us For Availability

1

WCI G174403 WCI G174403 Contact Us For Availability

1

SADDLE VALVE KIT WCI G99428 Contact Us For Availability

1

WCI 3017362 WCI 3017362 Contact Us For Availability

1A

DOOR PLUG-BOTTOM (NON-ILLUSTRATED) WCI G152308-01 Contact Us For Availability

2

TRIM-FREEZER DOOR WCI G178328-05 Contact Us For Availability

2

TRIM-REFRIGERATOR DOOR WCI G178328-04 Contact Us For Availability

2

FERRULE-OUTER (2) WCI G174734 Contact Us For Availability

2

PAN WCI G179709-01 Contact Us For Availability

2

SOCKET LIGHT WCI G168302 Contact Us For Availability

2

LABEL WCI G182955-01 Contact Us For Availability

2

COUPLING WCI G174409 Contact Us For Availability

2

ADAPTER ASSEMBLY WCI G159415 Contact Us For Availability

2

COIL BLOCK WCI G169493 Contact Us For Availability

2A

NUT 1/8`` SELF THREAD (NON-ILLUSTRATED) WCI G188218 Contact Us For Availability

3

215456100 Frigidaire Refrigerator Water Inlet In Stock WCI 215456100 $82.64

3

5304455852 Frigidaire Refrigerator Screw Backorder WCI 5304455852 $9.96

3

BEARING-UPPER HINGE WCI G183139 Contact Us For Availability

3

PAN WCI G179915-01 Contact Us For Availability

3

GROMMET-TUBE WCI G175246 Contact Us For Availability

3

HOUSING WCI G175019 Contact Us For Availability

3

RING-RTNG. WCI G174422 Contact Us For Availability

3

WCI G190223 WCI G190223 Contact Us For Availability

4

215846602 Frigidaire Refrigerator 8-Hour Defr In Stock WCI 215846602 $21.17

4

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $11.09

4

WCI G177218-01 WCI G177218-01 Contact Us For Availability

4

TUBE, RUBBER WCI G85642 Contact Us For Availability

4

COVER-UPPER WCI G169711-01 Contact Us For Availability

4

CLIP-TRIM (2) WCI G179966 Contact Us For Availability

4

WCI G174445 WCI G174445 Contact Us For Availability

4

HEATER EXCHANGER WCI G189609 Contact Us For Availability

5

5303917954 Frigidaire Refrigerator Defrost Li In Stock WCI 5303917954 $37.85

5

FRAME-NAMEPLATE WCI G176986 Contact Us For Availability

5

WCI G174559 WCI G174559 Contact Us For Availability

5

GASKET WCI G180108-03 Contact Us For Availability

5

WCI G189359 WCI G189359 Contact Us For Availability

5

SKIRT WCI G180004-02 Contact Us For Availability

5

MOUNTING-MOTOR (2) WCI G177711 Contact Us For Availability

5

SCREW (3) WCI G174457 Contact Us For Availability

6

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $10.53

6

DOOR CLOSER WCI G161119 Contact Us For Availability

6

WCI G180551-06 WCI G180551-06 Contact Us For Availability

6

COVER-LOWER WCI G169724-01 Contact Us For Availability

6

WCI G107080 WCI G107080 Contact Us For Availability

6

CLIP WCI G174411 Contact Us For Availability

6

MOTOR-ICE DISPENSER WCI G188235 Contact Us For Availability

6

SCREW (4) WCI G174469 Contact Us For Availability

6

WCI G167363 WCI G167363 Contact Us For Availability

7

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $48.23

7

SCREW, CLOSER WCI G169729 Contact Us For Availability

7

WCI G177720 WCI G177720 Contact Us For Availability

7

SHIM-TOP HINGE (2) WCI G183861 Contact Us For Availability

7

WCI G179710-01 WCI G179710-01 Contact Us For Availability

7

KNOB, TEMPERATURE CONTROL WCI G164906-01 Contact Us For Availability

7

SPRING WCI G174700 Contact Us For Availability

7

WCI G177710 WCI G177710 Contact Us For Availability

7

WCI G174430 WCI G174430 Contact Us For Availability

8

5304455649 Frigidaire Refrigerator Screw Backorder WCI 5304455649 $13.29

8

WCI G187880 WCI G187880 Contact Us For Availability

8

GASKET-REFRIGERATOR DOOR WCI G180551-02 Contact Us For Availability

8

WCI G183558-01 WCI G183558-01 Contact Us For Availability

8

SUPPORT, ICE MAKER (2) WCI G175103 Contact Us For Availability

8

STUD-ANCHOR (2) WCI G177724 Contact Us For Availability

8

WCI G174407-03 WCI G174407-03 Contact Us For Availability

8

WCI G174434 WCI G174434 Contact Us For Availability

8

WCI G188643 WCI G188643 Contact Us For Availability

9

WCI G179017 WCI G179017 Contact Us For Availability

9

PANEL-INNER DOOR WCI G179992-01 Contact Us For Availability

9

HINGE-TOP RS WCI G183715 Contact Us For Availability

9

WCI G166800 WCI G166800 Contact Us For Availability

9

WCI G162205-05 WCI G162205-05 Contact Us For Availability

9

ACTUATOR & CUP WCI G177725 Contact Us For Availability

9

WCI G174413-03 WCI G174413-03 Contact Us For Availability

9

WCI G174444 WCI G174444 Contact Us For Availability

9

BRACKET, CONDENSER MOUNTING (4) WCI G169666-01 Contact Us For Availability

9A

WCI G183716 WCI G183716 Contact Us For Availability

9A

FERRULE-OUTER (NON-ILLUSTRATED) WCI G166801 Contact Us For Availability

9B

GASKET-FERRULE (NON-ILLUSTRATED) WCI G167582 Contact Us For Availability

5303916855 Frigidaire Refrigerator Tube Backorder WCI 5303916855 $47.70

5308000039 Frigidaire Refrigerator Screw Backorder WCI 5308000039 $9.40

FLIPPER-ICE DOOR HINGE WCI G175040-03 Contact Us For Availability

WCI G179976-01 WCI G179976-01 Contact Us For Availability

WASHER-HINGE (2) WCI G170156 Contact Us For Availability

WCI G168625-07 WCI G168625-07 Contact Us For Availability

SOCKET-LIGHT WCI G177729 Contact Us For Availability

WCI G174416-05 WCI G174416-05 Contact Us For Availability

WCI G174484 WCI G174484 Contact Us For Availability

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $25.94

SPRING-FLIPPER WCI G184726 Contact Us For Availability

BEARING-LOWER HINGE WCI G183138 Contact Us For Availability

WCI G174738 WCI G174738 Contact Us For Availability

BASKET WCI G169661 Contact Us For Availability

WCI G166802 WCI G166802 Contact Us For Availability

WCI G185063-01 WCI G185063-01 Contact Us For Availability

WCI G177213-03 WCI G177213-03 Contact Us For Availability

PLATE, MOUNTING WCI G174504 Contact Us For Availability

DOOR SHELF (4) WCI G164109-18 Contact Us For Availability

GASKET-COIL COVER (2) WCI G165233 Contact Us For Availability

HANGER R.H. WCI G168986 Contact Us For Availability

WCI G166803 WCI G166803 Contact Us For Availability

SWITCH (2) WCI G185542 Contact Us For Availability

GEAR-DRIVE WORM WCI G174406 Contact Us For Availability

WCI G174505 WCI G174505 Contact Us For Availability

WCI G162549-01 WCI G162549-01 Contact Us For Availability

12A

WCI G101890 WCI G101890 Contact Us For Availability

12B

SCREW-SHELF (8) (NON-ILLUSTRATED) WCI G167115 Contact Us For Availability

WCI G180637 WCI G180637 Contact Us For Availability

SUPPORT RS (4) WCI G163781-01 Contact Us For Availability

LIGHT SHIELD-REFRIGERATOR WCI 3016897 Contact Us For Availability

WCI G186987 WCI G186987 Contact Us For Availability

WCI G164575 WCI G164575 Contact Us For Availability

SCREW-ADJUSTABLE WCI G174414 Contact Us For Availability

HOUSING WCI G174408 Contact Us For Availability

WCI G174417 WCI G174417 Contact Us For Availability

5303001199 Frigidaire Refrigerator Wiring Har Backorder WCI 5303001199 $51.55

TRIM COVER-DOOR PANEL WCI G174402-01 Contact Us For Availability

SUPPORT LS (4) WCI G163780-01 Contact Us For Availability

GASKET-COVER LS WCI G174234-08 Contact Us For Availability

SHELF WCI G180425-05 Contact Us For Availability

CONTROL BOX-DAMPER WCI G164523 Contact Us For Availability

PLATE-MOUNTING WCI G185754 Contact Us For Availability

WCI G174412 WCI G174412 Contact Us For Availability

WIRE-SHUT OFF WCI G174420 Contact Us For Availability

WCI G175070 WCI G175070 Contact Us For Availability

GASKET-COVER RS WCI G174234-10 Contact Us For Availability

WCI G187267-15 WCI G187267-15 Contact Us For Availability

WCI G185373 WCI G185373 Contact Us For Availability

SPRING-DRIVE WCI G174701 Contact Us For Availability

WCI G174424 WCI G174424 Contact Us For Availability

PANEL-INNER DOOR WCI G180629-01 Contact Us For Availability

WCI G173948-19 WCI G173948-19 Contact Us For Availability

WCI G174712-03 WCI G174712-03 Contact Us For Availability

WCI G180426-06 WCI G180426-06 Contact Us For Availability

WCI G165217-01 WCI G165217-01 Contact Us For Availability

WCI G188308-02 WCI G188308-02 Contact Us For Availability

WORM GEAR WCI G174702 Contact Us For Availability

RING-RTNG. WCI G174426 Contact Us For Availability

WCI G182225-05 WCI G182225-05 Contact Us For Availability

WCI 3018335 WCI 3018335 Contact Us For Availability

WCI G165376 WCI G165376 Contact Us For Availability

WCI G169477-03 WCI G169477-03 Contact Us For Availability

WCI G171654-31 WCI G171654-31 Contact Us For Availability

BRACKET-MOTOR REAR WCI G185303 Contact Us For Availability

GRID-WATER WCI G182551-01 Contact Us For Availability

DISC. WCI G177694 Contact Us For Availability

WCI G174428 WCI G174428 Contact Us For Availability

WCI G188608 WCI G188608 Contact Us For Availability

218906802 Frigidaire Light Lamp Socket In Stock WCI 218906802 $24.62

SUPPORT-RS (5) WCI G179946-01 Contact Us For Availability

HANDLE-REFRIGERATOR DOOR WCI G177141-09 Contact Us For Availability

TRIM-REAR (3) WCI G172409-12 Contact Us For Availability

WCI G164571 WCI G164571 Contact Us For Availability

COVER-TANK WCI G163925-02 Contact Us For Availability

BEARING (2) WCI G177695 Contact Us For Availability

WCI G174435 WCI G174435 Contact Us For Availability

RETAINER, OVERLOAD WCI G188957 Contact Us For Availability

18A

5303001147 Frigidaire Refrigerator Hole Harne Backorder WCI 5303001147 $17.46

18B

HARNESS-I&W LOWER WIRING (NON-ILLUSTRATED) WCI G188236 Contact Us For Availability

18C

HARNESS-ICE MAKER (NON-ILLUSTRATED) WCI G174737 Contact Us For Availability

5304455651 Frigidaire Refrigerator Screw In Stock WCI 5304455651 $10.50

SUPPORT-LS (5) WCI G179947-01 Contact Us For Availability

END- TOP HANDLE WCI G177142 Contact Us For Availability

FRAME (3) WCI G178323-07 Contact Us For Availability

PANEL, FRONT WCI G182643-01 Contact Us For Availability

COUPLING WCI G189278 Contact Us For Availability

WCI G174436 WCI G174436 Contact Us For Availability

5303006412 Frigidaire Refrigerator Cover Moun Backorder WCI 5303006412 $2.20

TRIM, TOP WCI G179270 Contact Us For Availability

GASKET-COIL COVER WCI G188000-03 Contact Us For Availability

TRIM (4) WCI G187267-13 Contact Us For Availability

WCI G182654-01 WCI G182654-01 Contact Us For Availability

DEFLECTOR WCI G177697-03 Contact Us For Availability

WCI G174440 WCI G174440 Contact Us For Availability

5300158289 Frigidaire Evaporator Fan Motor In Stock WCI 5300158289 $103.87

CLIP-HANDLE (4) WCI G177144 Contact Us For Availability

WCI G164912-03 WCI G164912-03 Contact Us For Availability

SHELF, GLASS WCI G171654-32 Contact Us For Availability

BUTTON (2) WCI G187106-01 Contact Us For Availability

LABEL-ICE CONTAINER WCI G180632 Contact Us For Availability

SCREW WCI G174442 Contact Us For Availability

COMPRESSOR W/ ELECTRIC WCI G189461 Contact Us For Availability

TRIM, BOTTOM WCI G179271 Contact Us For Availability

WASHER-HINGE (2) WCI G164355 Contact Us For Availability

SCREW (2) WCI G184823 Contact Us For Availability

BRACKET-MOTOR FRONT WCI G185302 Contact Us For Availability

LABEL-PAD (2) WCI G182929 Contact Us For Availability

SPRING, DOOR WCI G184853 Contact Us For Availability

BEARING-GAUGE ARM WCI G174459 Contact Us For Availability

CLIP COMPRESSOR (40 WCI G163204 Contact Us For Availability

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $45.43

WCI G185566 WCI G185566 Contact Us For Availability

END-BOTTOM HANDLE WCI G177143 Contact Us For Availability

HINGE-BOTTOM RS WCI G162383 Contact Us For Availability

HANGER, LH WCI G187215-02 Contact Us For Availability

TANK-WATER WCI R900930 Contact Us For Availability

WCI 3016895 WCI 3016895 Contact Us For Availability

RACK, GEAR WCI G174461 Contact Us For Availability

WASHER-COMPRESSOR (4) WCI G164634 Contact Us For Availability

23A

HINGE-BOTTOM LS (NON-ILLUSTRATED) WCI G175068 Contact Us For Availability

23B

WCI G141673 WCI G141673 Contact Us For Availability

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $33.26

SHIM-BOTTOM HINGE (3) WCI G162903 Contact Us For Availability

HANGER, RH WCI G187216-02 Contact Us For Availability

RING-ORIFICE WCI G167217 Contact Us For Availability

WCI G174462 WCI G174462 Contact Us For Availability

24A

WCI G142361 WCI G142361 Contact Us For Availability

24B

WCI G77210 WCI G77210 Contact Us For Availability

SCREW-HINGE MOUNTING (2) WCI G99167 Contact Us For Availability

FRAME - M.K. WCI G187217-03 Contact Us For Availability

WCI R900929 WCI R900929 Contact Us For Availability

WCI G174485 WCI G174485 Contact Us For Availability

WCI G188555 WCI G188555 Contact Us For Availability

25A

BRACKET-PLATE (4) (NON-ILLUSTRATED) WCI G171111 Contact Us For Availability

25B

WCI G171123 WCI G171123 Contact Us For Availability

25C

218843801 Frigidaire Refrigerator Screw Backorder WCI 218843801 $10.50

WCI G164643 WCI G164643 Contact Us For Availability

SHELF-LOWER WCI G174571-01 Contact Us For Availability

WCI G187033-01 WCI G187033-01 Contact Us For Availability

WCI R900928 WCI R900928 Contact Us For Availability

RETAINER-INSULATION WCI G174427 Contact Us For Availability

WCI G183584 WCI G183584 Contact Us For Availability

26A

WCI G169100 WCI G169100 Contact Us For Availability

26A

WCI G169297 WCI G169297 Contact Us For Availability

MULLION TRIM-WHITE WCI G169745-01 Contact Us For Availability

LABEL WCI G177706-02 Contact Us For Availability

SUPPORT (3) WCI G163938 Contact Us For Availability

INSULATOR-THERMOSTAT WCI G174479 Contact Us For Availability

WCI G169641 WCI G169641 Contact Us For Availability

5303289051 Frigidaire Refrigerator Light Swit Backorder WCI 5303289051 $20.53

SHELF-UPPER WCI G174556-01 Contact Us For Availability

TRAY WCI G174487 Contact Us For Availability

WIRING HARNESS-COMPRESSOR & LIGHTS WCI G164579 Contact Us For Availability

28A

WCI G177706-01 WCI G177706-01 Contact Us For Availability

CHANNEL-SHELF (2) WCI G170694 Contact Us For Availability

SHIELD-SWITCH WCI G174400 Contact Us For Availability

HOUSING WCI G174490 Contact Us For Availability

WIRING HARNESS-CONTROL WCI 3015098 Contact Us For Availability

30

GRILLE WCI G174597-01 Contact Us For Availability

30

SCREW-SWITCH WCI G177686 Contact Us For Availability

30

WCI G174492 WCI G174492 Contact Us For Availability

31

5304509705 Frigidaire Refrigerator Grommet In Stock WCI 5304509705 $7.31

31

CLIP, GRILLE WCI G170328 Contact Us For Availability

31

CAM-ICE LVL. WCI G174497 Contact Us For Availability

32

ROLLER-FRONT (2) WCI G186731 Contact Us For Availability

32

WCI G163952 WCI G163952 Contact Us For Availability

32

PC BOARD WCI G181942 Contact Us For Availability

33

SCREW-ROLLER MOUNTING (20 WCI G187491 Contact Us For Availability

33

SUPPORT, ICE CONTAINER, SHELF (2) WCI G163105 Contact Us For Availability

33

WCI G173135 WCI G173135 Contact Us For Availability

34

WCI G171125 WCI G171125 Contact Us For Availability

34

TRIM-REAR WCI G172409-13 Contact Us For Availability

34

WCI G177709-05 WCI G177709-05 Contact Us For Availability

35

241957901 Frigidaire Refrigerator Drain Tube Backorder WCI 241957901 $47.70

35

WCI G180633 WCI G180633 Contact Us For Availability

36

WCI G171193 WCI G171193 Contact Us For Availability

36

VALVE, WATER WCI G189174 Contact Us For Availability

37

5308010366 Frigidaire Refrigerator Water Inle In Stock WCI 5308010366 $12.72

37

WCI G177743 WCI G177743 Contact Us For Availability

37A

NUT-ELBOW (NON-ILLUSTRATED) WCI G143689 Contact Us For Availability

38

WCI G162809 WCI G162809 Contact Us For Availability

39

WCI G162808 WCI G162808 Contact Us For Availability

40

PUSH NUT (2) WCI G162662 Contact Us For Availability

41

COVER-BOTTOM HINGE WCI G174658-01 Contact Us For Availability

42

BRACKET, COVER MOUNTING WCI G158022 Contact Us For Availability

42A

LOCK WASHER (2) (NON-ILLUSTRATED) WCI G164820 Contact Us For Availability

42B

WCI G184851 WCI G184851 Contact Us For Availability

43

SUPPORT-COIL COVER (4) WCI G169471 Contact Us For Availability

44

SUPPORT-COIL COVER WCI G163669 Contact Us For Availability
