LG NN-S244BL MWO-OTR Parts List

1

3213W1A049F LG Microwave Door Frame Assembly Backorder LGE 3213W1A049F $77.91

View on Model

5

Handle,Door LGE 3650W1A026F Contact Us For Availability

View on Model

6

PANEL,DOOR LGE 3720W0D197D Contact Us For Availability

View on Model

7

4026W2A019A LG Microwave Door Latch Hook - Bl In Stock LGE 4026W2A019A $6.96

View on Model

8

GLASS LGE 4890W1A044H Contact Us For Availability

View on Model

9

4970WRA001G LG Spring Backorder LGE 4970WRA001G $6.53

View on Model

17

GRILLE,VENT LGE 3530W0A019F Contact Us For Availability

View on Model

18

4810W1A149A LG Bracket Mounting Backorder LGE 4810W1A149A $6.53

View on Model

19

4810W1A150C LG Lamp Bracket Backorder LGE 4810W1A150C $10.38

View on Model

20

4890W1A045A LG Glass Backorder LGE 4890W1A045A $6.53

View on Model

22

5230W1A012A LG Grease Filter Backorder LGE 5230W1A012A $7.57

View on Model

24

6912W1Z004B LG Microwave Incandescent Lamp Li In Stock LGE 6912W1Z004B $6.49

View on Model

28

3500W1A013R LG Locker Holder Backorder LGE 3500W1A013R $15.56

View on Model

30

4510W3A012B LG Microwave Lever Backorder LGE 4510W3A012B $6.53

View on Model

33

1B71961H LG Microwave Turntable Glass In Stock LGE 1B71961H $33.07

View on Model

34

PROTECTOR (MECH) LGE 3740W1A014A Contact Us For Availability

View on Model

35

SHAFT,TURN TABLE LGE 4370W1A011B Contact Us For Availability

View on Model

36

ROTATING RING ASSEMBLY LGE 5889W1A010D Contact Us For Availability

View on Model

37

6549W1S011M LG Microwave AC Turntable Synchro Backorder LGE 6549W1S011M $25.49

View on Model

38

0CZZW1H004B LG Microwave Oven High Voltage Ca In Stock LGE 0CZZW1H004B $27.91

View on Model

39

PLATE,BOTTOM LGE 3300W1A045B Contact Us For Availability

View on Model

40

PLATE,BOTTOM LGE 3300W1A046A Contact Us For Availability

View on Model

41

4810W1A141A LG Capacitor Bracket Backorder LGE 4810W1A141A $6.53

View on Model

42

TRANSFORMER,HIGH VOLTAGE LGE 6170W1D052B Contact Us For Availability

View on Model

43

6021W3B001G LG Cable,Assembly Backorder LGE 6021W3B001G $15.56

View on Model

44

6324W1A001L LG Microwave Oven Magnetron In Stock LGE 6324W1A001L $109.79

View on Model

45

MOTOR(CIRC),VENTILATION LGE 6549W1V006F Contact Us For Availability

View on Model

46

COVER,LAMP LGE 3550W1A189B Contact Us For Availability

View on Model

47

CAP,FUSE LGE 5006WRA002D Contact Us For Availability

View on Model

48

5230W1A011E LG Microwave Charcoal Filter In Stock LGE 5230W1A011E $10.38

View on Model

49

DUCT LGE 5208W0A010A Contact Us For Availability

View on Model

50

POWER CORD ASSEMBLY LGE 6411W1A010X Contact Us For Availability

View on Model

51

LAMP HOLDER - ALL LGE 6804W3A001A Contact Us For Availability

View on Model

52

Harness,Single LGE 6877W1A582A Contact Us For Availability

View on Model

53

6912W1Z004A LG Microwave Incandescent Lamp Backorder LGE 6912W1Z004A $4.97

View on Model

54

3B74133Q LG Microwave Oven Main Inline Time D In Stock LGE 3B74133Q $5.57

View on Model

55

6930W1A003E LG Oven Microwave High Limit Ther In Stock LGE 6930W1A003E $10.38

View on Model

56

PLATE,MOUNTING LGE 3300W0A018A Contact Us For Availability

View on Model

57

KIT ASSEMBLY LGE 3861W1A043A Contact Us For Availability

View on Model

58

4810W1A151A LG Microwave Oven Idle Bracket In Stock LGE 4810W1A151A $8.88

View on Model

59

4900W1A001B LG Microwave Oven Vent Damper In Stock LGE 4900W1A001B $7.18

View on Model

60

1SBF0402418 LG Laptop Screw Backorder LGE 1SBF0402418 $6.53

View on Model

62

1TPL0402418 LG Tapping Screw Backorder LGE 1TPL0402418 $15.56

View on Model

63

1TTL0402418 LG Microwave Tapping Screw Backorder LGE 1TTL0402418 $5.06

View on Model

65

1TTL0402818 LG Oven Microwave Tapping Screw Backorder LGE 1TTL0402818 $6.53

View on Model

66

1TTL0402816 LG Screw Backorder LGE 1TTL0402816 $6.53

View on Model

70

MANUAL,OWNERS LGE 3828W5A8046 Contact Us For Availability

View on Model

71

MANUAL,INSTALLATION LGE 3828W5U0379 Contact Us For Availability

View on Model

72

TEMPLATE LGE 4922W1A021B Contact Us For Availability

View on Model

73

LGE 3890W3Y887A LGE 3890W3Y887A Contact Us For Availability

View on Model

BZ1

BUZZER,PIEZO CERAMIC LGE 6908W3YA01B Contact Us For Availability

View on Model

C01

CAPACITOR ELECTROLYTIC KCN21C2 LGE 0CE4776H618 Contact Us For Availability

View on Model

C03

CAPACITOR ELECTROLYTIC CE,47MF LGE 0CE4766K638 Contact Us For Availability

View on Model

C04

CAPACITOR ELECTROLYTIC LGE 0CE1076D638 Contact Us For Availability

View on Model

D02

DIODE,RECTIFIERS LGE 0DRSB00093A Contact Us For Availability

View on Model

D46

DIODE,SWITCHING LGE 0DSSB00023A Contact Us For Availability

View on Model

D81

DIODE,SWITCHING LGE 0DSSB00083A Contact Us For Availability

View on Model

PT1

TRANSFORMER POWER 120V/60HZ,14 LGE 6010W2P043A Contact Us For Availability

View on Model

Q20

TRANSISTOR MA-885M SGESEA MA-1 LGE 0TR107009AD Contact Us For Availability

View on Model

Q41

0TR107009AE LG Bipolar Transformer Backorder LGE 0TR107009AE $6.53

View on Model

Q46

TRANSISTOR KTA1266-TP-Y(KTA101 LGE 0TR126609AA Contact Us For Availability

View on Model

Q47

LGE 0TR105009AD LGE 0TR105009AD Contact Us For Availability

View on Model

Q85

TR,BIPOLAR Backorder LGE 0TR107009AG $6.53

View on Model

Q95

TRANSISTOR LGE 0TR107009AC Contact Us For Availability

View on Model

R01

RESISTOR FIXED CARBON FILM KCN LGE 0RD1001F609 Contact Us For Availability

View on Model

R02

RESISTOR FIXED CARBON FILM KCN LGE 0RD1501F609 Contact Us For Availability

View on Model

R03

RESISTOR,CARBON FILM Backorder LGE 0RD1002F609 $2.23

View on Model

R04

0RD1001G609 LG Carbon Film Resistor Backorder LGE 0RD1001G609 $6.53

View on Model

R20

LGE 0RD1002G609 LGE 0RD1002G609 Contact Us For Availability

View on Model

R25

LGE 0RD3301G608 LGE 0RD3301G608 Contact Us For Availability

View on Model

R44

RESISTOR FIXED CARBON FILM SKN LGE 0RD2001F609 Contact Us For Availability

View on Model

R50

LGE 0RD4701G609 LGE 0RD4701G609 Contact Us For Availability

View on Model

R55

Resistor,Carbon Film Backorder LGE 0RD1004F609 $2.23

View on Model

R90

LGE 0RN2202G408 LGE 0RN2202G408 Contact Us For Availability

View on Model

R95

Resistor,Carbon Film LGE 0RD1802F608 Contact Us For Availability

View on Model

R96

Resistor,Carbon Film LGE 0RD8202F608 Contact Us For Availability

View on Model

R110

RESISTOR FIXED CARBON FILM AXJ LGE 0RD1003F609 Contact Us For Availability

View on Model

R131

LGE 0RN2003F408 LGE 0RN2003F408 Contact Us For Availability

View on Model

U01

IC,DRAWING LGE 0IZZW5A119F Contact Us For Availability

View on Model
