Model LG LP120HSD-Y8 AC – Common Parts & Diagrams

237200
Panel,Control
Panel,Control LGE 3720A20710A Contact Us For Availability
View on Model
249941B
Case,Control(Indoor)
Case,Control(Indoor) LGE 4994A20128A Contact Us For Availability
View on Model
249951
Case Assembly,Control
Case Assembly,Control LGE ABQ72273013 Contact Us For Availability
View on Model
263230A
THERMISTOR ASSEMBLY
THERMISTOR ASSEMBLY LGE 6323A20006A Contact Us For Availability
View on Model
263230A
Thermistor Assembly,NTC
Thermistor Assembly,NTC LGE 6323A20006B Contact Us For Availability
View on Model
263230A
Thermistor Assembly,NTC
Thermistor Assembly,NTC LGE 6323A20006H Contact Us For Availability
View on Model
264110
POWER CORD ASSEMBLY
POWER CORD ASSEMBLY LGE 6411A20048M Contact Us For Availability
View on Model
268711A
PCB Assembly,Display
PCB Assembly,Display LGE 6871A00085A Contact Us For Availability
View on Model
268711B
PCB Assembly,Main
PCB Assembly,Main LGE 6871A00084A Contact Us For Availability
View on Model
330871
DRAIN PAN ASSEMBLY
DRAIN PAN ASSEMBLY LGE 3087A20033A Contact Us For Availability
View on Model
337000
Mesh,Metal
Mesh,Metal LGE 3700A20009B Contact Us For Availability
View on Model
346810
Motor Assembly,AC,Indoor
Motor Assembly,AC,Indoor LGE 4681A20064N Contact Us For Availability
View on Model
346810
MOTOR ASSEMBLY,INDOOR
MOTOR ASSEMBLY,INDOOR LGE 4681A20064A Contact Us For Availability
View on Model
346810
Motor Assembly,AC,Indoor
Motor Assembly,AC,Indoor LGE EAU60688701 Contact Us For Availability
View on Model
349600A
MOUNT,MOTOR
MOUNT,MOTOR LGE 4960A20032A Contact Us For Availability
View on Model
349600B
MOUNT,MOTOR
MOUNT,MOTOR LGE 4960A20005A Contact Us For Availability
View on Model
352390
Guide Assembly,Air
Guide Assembly,Air LGE 5239A10019C Contact Us For Availability
View on Model
354210
EVAPORATOR ASSEMBLY,FIRST
EVAPORATOR ASSEMBLY,FIRST LGE 5421A20118A Contact Us For Availability
View on Model
435300A
GRILLE,REAR
GRILLE,REAR LGE 3530A30015A Contact Us For Availability
View on Model
435300B
GRILLE,REAR
GRILLE,REAR LGE 3530A30002A Contact Us For Availability
View on Model
435301
GRILLE,DISCHARGE
GRILLE,DISCHARGE LGE 3530A20040B Contact Us For Availability
View on Model
546810
Motor Assembly,AC,Outdoor
Motor Assembly,AC,Outdoor LGE EAU37533504 Contact Us For Availability
View on Model
546810
Motor Assembly,AC,Outdoor
Motor Assembly,AC,Outdoor LGE EAU60688401 Contact Us For Availability
View on Model
546810
MOTOR ASSEMBLY,OUTDOOR
MOTOR ASSEMBLY,OUTDOOR LGE 4681A20200A Contact Us For Availability
View on Model
549990
Shroud Assembly
Shroud Assembly LGE 4999A20004A Contact Us For Availability
View on Model
552112
TUBE ASSEMBLY,CONDENSER IN
TUBE ASSEMBLY,CONDENSER IN LGE 5211A20678A Contact Us For Availability
View on Model
552113
Tube Assembly,Condenser(Out)
Tube Assembly,Condenser(Out) LGE 5211A24129H Contact Us For Availability
View on Model
552116
Tube Assembly,Reverse
Tube Assembly,Reverse LGE 5211A21792C Contact Us For Availability
View on Model
552206
Valve,Drain
Valve,Drain LGE 5220A30006B Contact Us For Availability
View on Model
554160
Compressor Set,China
Compressor Set,China LGE 2520UCDK025 Contact Us For Availability
View on Model
753010
Heater Assembly,Electric
Heater Assembly,Electric LGE 5301A20036B Contact Us For Availability
View on Model
