Model Electrolux LFHB2741PF2 REFRIGERATOR – Common Parts &amp; Diagrams

1

242093003 Frigidaire Refrigerator Ice Contain In Stock WCI 242093003 $189.13

1

5304537408 Frigidaire Gasket In Stock WCI 5304537408 $64.27

2

241778315 Frigidaire Door Gasket In Stock WCI 241778315 $77.20

2

243297613 Frigidaire Refrigerator Ice Maker In Stock WCI 243297613 $105.27

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $9.48

4A

242176404 Frigidaire Refrigerator Trim Backorder WCI 242176404 $47.70

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $44.94

6

241516904 Frigidaire Refrigerator Service Cor In Stock WCI 241516904 $28.28

8

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $16.59

9

241518301 Frigidaire Refrigerator Bushing In Stock WCI 241518301 $46.05

10

241829001 Frigidaire Refrigerator Bar Drive In Stock WCI 241829001 $45.46

10

242072002 Frigidaire Refrigerator Cover Backorder WCI 242072002 $91.65

10A

WCI 242084102 WCI 242084102 Contact Us For Availability

11

241987936 Frigidaire Freezer Door Assembly Backorder WCI 241987936 $530.30

11

WCI 242185635 WCI 242185635 Contact Us For Availability

12

242016301 Frigidaire Refrigerator Nameplate Backorder WCI 242016301 $3.31

12

WCI 242072401 WCI 242072401 Contact Us For Availability

13

241868401 Frigidaire Refrigerator Door Stop Backorder WCI 241868401 $14.42

13

809069220 Frigidaire Evaporator Fan Motor In Stock WCI 809069220 $100.27

13A

241868402 Frigidaire Refrigerator Door Stop Backorder WCI 241868402 $14.42

14

242060202 Frigidaire Refrigerator Light Switc Backorder WCI 242060202 $31.61

14

5303918410 Frigidaire Refrigerator Defrost He In Stock WCI 5303918410 $99.82

15

5303918569 Frigidaire Refrigerator Evaporator In Stock WCI 5303918569 $198.01

15

5304517886 Frigidaire Refrigerator Light In Stock WCI 5304517886 $56.55

15

WCI 242185634 WCI 242185634 Contact Us For Availability

16

242072101 Frigidaire Refrigerator Cover Backorder WCI 242072101 $37.70

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $48.81

16A

240590403 Frigidaire Refrigerator Light Socke Backorder WCI 240590403 $19.43

16A

241510802 Frigidaire Refrigerator Wiring Harn Backorder WCI 241510802 $32.71

17

241928201 Frigidaire Refrigerator Air Duct Ga Backorder WCI 241928201 $13.88

17

WCI 242084201 WCI 242084201 Contact Us For Availability

241816602 Frigidaire Refrigerator Auger Motor In Stock WCI 241816602 $143.97

241860101 Frigidaire Refrigerator Gasket Backorder WCI 241860101 $13.86

242090501 Frigidaire Stainless Steel Door Han Backorder WCI 242090501 $149.20

WCI 242059301 WCI 242059301 Contact Us For Availability

19

242072601 Frigidaire Refrigerator Support Backorder WCI 242072601 $30.87

20

242072201 Frigidaire Refrigerator Cover Backorder WCI 242072201 $75.96

20

242095702 Frigidaire Refrigerator Air Handler In Stock WCI 242095702 $62.24

241690602 Frigidaire Refrigerator Screw In Stock WCI 241690602 $7.35

241732101 Frigidaire Refrigerator Screw Backorder WCI 241732101 $12.20

242017501 Frigidaire Refrigerator Screw Backorder WCI 242017501 $12.18

242046001 Frigidaire Refrigerator Defrost The In Stock WCI 242046001 $59.32

5303918568 Frigidaire Thermostat Defrost In Stock WCI 5303918568 $71.54

21C

241899703 Frigidaire Refrigerator Screw Backorder WCI 241899703 $10.29

22

WCI 242075601 WCI 242075601 Contact Us For Availability

22A

242075602 Frigidaire Refrigerator Cam Assembl In Stock WCI 242075602 $16.15

22C

241760401 Frigidaire Refrigerator Bearing Backorder WCI 241760401 $14.94

23

218513300 Frigidaire Refrigerator Compressor Backorder WCI 218513300 $33.26

23

242094603 Frigidaire Refrigerator Evaporator Backorder WCI 242094603 $89.88

23

242176503 Frigidaire Refrigerator Sump In Stock WCI 242176503 $89.29

24

242068701 Frigidaire Refrigerator Shelf Backorder WCI 242068701 $151.98

24

242094802 Frigidaire Defrost Heater In Stock WCI 242094802 $77.07

24

5304515677 Frigidaire Package of 4 Screws In Stock WCI 5304515677 $6.61

24A

240383412 Frigidaire Refrigerator Screw Backorder WCI 240383412 $8.87

24B

242068703 Frigidaire Refrigerator Shelf Backorder WCI 242068703 $143.10

25

241949502 Frigidaire Refrigerator Clip Backorder WCI 241949502 $14.94

25

WCI 240491503 WCI 240491503 Contact Us For Availability

26

241801801 Frigidaire Crisper Pan In Stock WCI 241801801 $151.98

26

241920609 Frigidaire Side-by-Side Defrost Pan Backorder WCI 241920609 $108.13

27

241752703 Frigidaire Refrigerator Retainer Backorder WCI 241752703 $40.48

30

241778701 Frigidaire Refrigerator Anti-Tip Br Backorder WCI 241778701 $19.43

33

WCI 242094401 WCI 242094401 Contact Us For Availability

34

241868301 Frigidaire Refrigerator Washer Asse Backorder WCI 241868301 $24.38

36

241868201 Frigidaire Refrigerator Spacer Backorder WCI 241868201 $38.80

36A

241868202 Frigidaire Refrigerator Spacer Backorder WCI 241868202 $17.18

38

241761301 Frigidaire Upper Bracket Hinge Backorder WCI 241761301 $51.57

38A

241761302 Frigidaire Refrigerator Upper Hinge Backorder WCI 241761302 $50.46

38C

WCI 242058223 WCI 242058223 Contact Us For Availability

40

5304504483 Frigidaire Refrigerator Gray Upper Backorder WCI 5304504483 $48.25

40A

5304504482 Frigidaire Refrigerator Upper Left Backorder WCI 5304504482 $48.79

40B

218515401 Frigidaire Refrigerator Clip Backorder WCI 218515401 $12.25

40B

241862405 Frigidaire Refrigerator Upper Hinge Backorder WCI 241862405 $82.07

41

240555002 Frigidaire Refrigerator Screw #8-32 Backorder WCI 240555002 $10.50

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $11.07

42

242067901 Frigidaire Refrigerator Roller Supp Backorder WCI 242067901 $16.87

42A

242067801 Frigidaire Refrigerator Door Suppor Backorder WCI 242067801 $34.37

43

241641502 Frigidaire Refrigerator Screw Backorder WCI 241641502 $6.61

43

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $18.27

47B

242082303 Frigidaire Refrigerator Glass Backorder WCI 242082303 $79.29

48

242071401 Frigidaire Refrigerator White Door Backorder WCI 242071401 $72.09

48

242122101 Frigidaire Refrigerator Channel She Backorder WCI 242122101 $62.69

49

242079701 Frigidaire Refrigerator Door Bin In Stock WCI 242079701 $83.18

49

242122202 Frigidaire Refrigerator Channel Backorder WCI 242122202 $52.68

49

WCI 242159401 WCI 242159401 Contact Us For Availability

49A

242071301 Frigidaire Refrigerator Clear Door In Stock WCI 242071301 $74.40

49A

242122001 Frigidaire Refrigerator Shelf Mount Backorder WCI 242122001 $34.37

49A

WCI 241780815 WCI 241780815 Contact Us For Availability

49B

242011701 Frigidaire Bin Shelf Door Backorder WCI 242011701 $38.26

49B

242122301 Frigidaire Refrigerator Shelf Mount Backorder WCI 242122301 $61.01

49C

242079901 Frigidaire Refrigerator Door Bin In Stock WCI 242079901 $72.09

51

242095501 Frigidaire Refrigerator Anti-Twist Backorder WCI 242095501 $16.07

51

242197901 Frigidaire Refrigerator Slide Backorder WCI 242197901 $104.85

51

5303918690 Frigidaire Refrigerator Wire Baske In Stock WCI 5303918690 $201.90

51A

241894223 Frigidaire Drawer Right Slide Rail Backorder WCI 241894223 $103.71

52

WCI 242130507 WCI 242130507 Contact Us For Availability

52A

241894224 Frigidaire Refrigerator Slide Assem Backorder WCI 241894224 $103.15

53A

5303918801 Frigidaire Refrigerator Retainer S Backorder WCI 5303918801 $9.42

54

241532401 Frigidaire Refrigerator Channel In Stock WCI 241532401 $18.24

55

242253002 Frigidaire Refrigerator Water Valve In Stock WCI 242253002 $158.07

58

241853202 Frigidaire Refrigerator Screw Backorder WCI 241853202 $7.74

59

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $6.09

59

241946106 Frigidaire Refrigerator Condenser F Backorder WCI 241946106 $35.48

60

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $9.44

60

242018301 Frigidaire Refrigerator Condenser F In Stock WCI 242018301 $114.51

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $16.05

62

WCI 242096801 WCI 242096801 Contact Us For Availability

63

216396900 Frigidaire Dryer Adjustable Levelin In Stock WCI 216396900 $18.27

65

242232701 Frigidaire Refrigerator Cover Backorder WCI 242232701 $24.95

68

242095002 Frigidaire Refrigerator Cover Backorder WCI 242095002 $78.20

72

242054804 Frigidaire Refrigerator Kickplate G Backorder WCI 242054804 $65.43

73

242075701 Frigidaire Refrigerator Lower Hinge Backorder WCI 242075701 $16.64

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $10.50

81

134154100 Frigidaire Screw 10-32 x 0.375 Co In Stock WCI 134154100 $10.55

81

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.76

82

241779401 Frigidaire Refrigerator Flipper Hin In Stock WCI 241779401 $16.07

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $35.90

82

WCI 242168701 WCI 242168701 Contact Us For Availability

83

241812202 Frigidaire Refrigerator Magnet Backorder WCI 241812202 $56.55

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $28.21

84A

242190501 Frigidaire Refrigerator Mullion Ass Backorder WCI 242190501 $20.51

85

241778811 Frigidaire Refrigerator Flipper Mul In Stock WCI 241778811 $209.10

85

242130901 Frigidaire Refrigerator Divider Backorder WCI 242130901 $67.13

85A

WCI 242168501 WCI 242168501 Contact Us For Availability

85B

WCI 241872204 WCI 241872204 Contact Us For Availability

86

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $49.36

86

241779802 Frigidaire Door Hinge Mullion Flipp In Stock WCI 241779802 $26.62

86

WCI 242090701 WCI 242090701 Contact Us For Availability

87

WCI 241871501 WCI 241871501 Contact Us For Availability

89

241972302 Frigidaire Refrigerator Drawer Brac Backorder WCI 241972302 $79.87

89

5304520905 Frigidaire Assembly Cover Refriger Backorder WCI 5304520905 $54.36

89

WCI 215346900 WCI 215346900 Contact Us For Availability

90

240597220 Frigidaire Sensor In Stock WCI 240597220 $3.67

90

WCI 242136903 WCI 242136903 Contact Us For Availability

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $10.53

93

241835505 Frigidaire Refrigerator Light Switc In Stock WCI 241835505 $49.92

96

241860601 Frigidaire Refrigerator Evaporator Backorder WCI 241860601 $103.15

97A

WCI 242117301 WCI 242117301 Contact Us For Availability

100

242157601 Frigidaire Refrigerator Cover Backorder WCI 242157601 $8.85

101

242157801 Frigidaire Refrigerator Cover Backorder WCI 242157801 $17.75

102

242157501 Frigidaire Refrigerator Cover Backorder WCI 242157501 $17.75

107

241971202 Frigidaire Refrigerator Light Shiel Backorder WCI 241971202 $26.60

107

241971601 Frigidaire Refrigerator Light Shiel Backorder WCI 241971601 $26.06

108

241971801 Frigidaire Refrigerator Wiring Cove Backorder WCI 241971801 $71.93

108

WCI 241971402 WCI 241971402 Contact Us For Availability

115

5303918899 Frigidaire Damper Control Assembly In Stock WCI 5303918899 $58.18

116

241518601 Frigidaire Refrigerator Damper Seal In Stock WCI 241518601 $7.20

122

241860117 Frigidaire Gasket Backorder WCI 241860117 $8.31

123

242135301 Frigidaire Refrigerator Evaporator Backorder WCI 242135301 $6.09

125

242071201 Frigidaire Refrigerator Cover Backorder WCI 242071201 $89.84

139

242009602 Frigidaire Refrigerator Water Filte In Stock WCI 242009602 $51.81

145

242200003 Frigidaire Refrigerator Right Deli Backorder WCI 242200003 $57.12

145

242200004 Frigidaire Refrigerator Left Hand D Backorder WCI 242200004 $60.43

147

5304493604 Frigidaire Refrigerator Gasket & F In Stock WCI 5304493604 $80.98

148

242095406 Frigidaire Refrigerator Gasket In Stock WCI 242095406 $13.83

149

5303918784 Frigidaire Refrigerator Air Handle In Stock WCI 5303918784 $99.30

151

242069701 Frigidaire Refrigerator Water Filte Backorder WCI 242069701 $19.40

154

WCI 242082401 WCI 242082401 Contact Us For Availability

157

241872201 Frigidaire Refrigerator Crisper Cov Backorder WCI 241872201 $39.37

209

242291001 Frigidaire Refrigerator Housing Backorder WCI 242291001 $14.97

241779101 Frigidaire Refrigerator Magnet In Stock WCI 241779101 $24.38

241983816 Frigidaire Refrigerator Water Filte Backorder WCI 241983816 $57.71

241998303 Frigidaire Refrigerator Water Filte In Stock WCI 241998303 $10.35

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $11.64

211

241979601 Frigidaire Refrigerator Bumper Backorder WCI 241979601 $17.73

212

242236801 Frigidaire Refrigerator Roller Asse Backorder WCI 242236801 $16.07

213

242010901 Frigidaire Refrigerator Assembly Ro Backorder WCI 242010901 $34.31

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $11.07

240346701 Frigidaire Refrigerator Foam Seal T In Stock WCI 240346701 $23.27

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $9.96

240383407 Frigidaire Refrigerator Screw Backorder WCI 240383407 $9.98

240396801 Frigidaire Refrigerator Tube Clamp Backorder WCI 240396801 $14.99

240451503 Frigidaire Refrigerator Screw Backorder WCI 240451503 $2.76

240494001 Frigidaire Refrigerator Plug Button Backorder WCI 240494001 $13.29

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.96

241503901 Frigidaire Refrigerator P-1 Tube Ad In Stock WCI 241503901 $39.94

241510904 Frigidaire Refrigerator Dispenser H Backorder WCI 241510904 $46.57

241695904 Frigidaire Refrigerator Screw Backorder WCI 241695904 $10.53

241810104 Frigidaire Refrigerator Seal Backorder WCI 241810104 $8.85

241842301 Frigidaire Refrigerator Thermistor In Stock WCI 241842301 $26.60

241844403 Frigidaire Refrigerator Tube Backorder WCI 241844403 $18.27

241860111 Frigidaire Refrigerator Evaporator Backorder WCI 241860111 $9.40

241947701 Frigidaire Refrigerator Spacer Backorder WCI 241947701 $73.20

241953902 Frigidaire Refrigerator Screw In Stock WCI 241953902 $13.31

241964707 Frigidaire Refrigerator Water Tube In Stock WCI 241964707 $14.40

241965906 Frigidaire Refrigerator Water Tube Backorder WCI 241965906 $18.84

242004802 Frigidaire Refrigerator Foam Strip Backorder WCI 242004802 $4.41

242011101 Frigidaire Refrigerator Pin Lock Backorder WCI 242011101 $11.09

242015001 Frigidaire Refrigerator Screw Backorder WCI 242015001 $12.75

242036801 Frigidaire Refrigerator Plastic Cli In Stock WCI 242036801 $75.41

242039701 Frigidaire Refrigerator Screw Backorder WCI 242039701 $10.53

242068601 Frigidaire Refrigerator Bumper Backorder WCI 242068601 $10.53

242072501 Frigidaire Refrigerator Insulation Backorder WCI 242072501 $14.40

242095425 Frigidaire Gasket Backorder WCI 242095425 $7.77

242095804 Frigidaire Refrigerator Wiring Harn Backorder WCI 242095804 $67.67

242096001 Frigidaire Refrigerator Insulation Backorder WCI 242096001 $14.42

242119001 Frigidaire Refrigerator Wiring Harn Backorder WCI 242119001 $89.29

242141401 Frigidaire Refrigerator Harness Wir In Stock WCI 242141401 $141.61

242146401 Frigidaire Refrigerator Screw In Stock WCI 242146401 $11.07

242220204 Frigidaire Water Inlet Tube In Stock WCI 242220204 $28.30

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $11.09

5304520993 Frigidaire Refrigerator Mullion Ha Backorder WCI 5304520993 $29.98

5304521649 Frigidaire Refrigerator Wiring Har Backorder WCI 5304521649 $74.28

WCI 5303918553 WCI 5303918553 Contact Us For Availability

WCI 242040802 WCI 242040802 Contact Us For Availability

WCI 242061606 WCI 242061606 Contact Us For Availability
