Whirlpool JUW248LBRS00 WINE CELLAR Parts List

1

Drain Pan WPL W10163193 Contact Us For Availability

View on Model

1

Door (Black) WPL W10163188 Contact Us For Availability

View on Model

1

Use & Care Guide WPL 2300282B Contact Us For Availability

View on Model

1

Wiring Diagram WPL 4344900 Contact Us For Availability

View on Model

2

W11241702 Whirlpool Refrigerator Washer Backorder WPL W11241702 $8.39

View on Model

2

Bracket, Defrost Timer WPL 4344773 Contact Us For Availability

View on Model

3

W11609704 Whirlpool Refrigerator Defrost Time In Stock WPL W11609704 $71.46

View on Model

3

GASKET-PUSH PLATE WPL W10163191 Contact Us For Availability

View on Model

3

Lens, Light WPL 4344739 Contact Us For Availability

View on Model

4

4344787 Whirlpool Refrigerator Door Hinge Backorder WPL 4344787 $149.71

View on Model

4

WP22002263 Whirlpool Dryer 10W Light Bulb In Stock WPL WP22002263 $9.39

View on Model

4

Hinge, Bottom (Black) WPL W10163069 Contact Us For Availability

View on Model

5

4344754 Whirlpool Refrigerator Door Hinge Backorder WPL 4344754 $56.51

View on Model

5

WP4344776 Whirlpool Refrigerator Start Device In Stock WPL WP4344776 $118.04

View on Model

5

Heater, Defrost WPL 4344746 Contact Us For Availability

View on Model

5

Hinge, Top (Black) WPL W10162991 Contact Us For Availability

View on Model

6

4344747 Whirlpool Refrigerator Shield Backorder WPL 4344747 $53.17

View on Model

6

4344755 Whirlpool Refrigerator Spacer Backorder WPL 4344755 $11.97

View on Model

6

Mounting Plate, Compressor WPL 4344777 Contact Us For Availability

View on Model

7

4344756 Whirlpool Refrigerator Spacer Backorder WPL 4344756 $12.68

View on Model

7

GRILLE WPL 4344761 Contact Us For Availability

View on Model

8

WP4344779 Whirlpool Refrigerator Grommet Backorder WPL WP4344779 $4.82

View on Model

8

Actuator, Switch WPL 4344757 Contact Us For Availability

View on Model

8

Plate, Bottom WPL 4344762 Contact Us For Availability

View on Model

9

4344758 Whirlpool Refrigerator Bracket Backorder WPL 4344758 $11.47

View on Model

9

W10772873 Whirlpool Screw Backorder WPL W10772873 $34.85

View on Model

9

W11106296 Whirlpool Refrigerator Leveler Backorder WPL W11106296 $10.50

View on Model

9

Door Stop (Black) WPL W10163074 Contact Us For Availability

View on Model

10

WPW10238068 Whirlpool Refrigerator Gasket In Stock WPL WPW10238068 $240.38

View on Model

10

WPW10299090 Whirlpool Refrigerator Condenser In Stock WPL WPW10299090 $156.85

View on Model

10

Brace, Support WPL 4344764 Contact Us For Availability

View on Model

11

Control Box WPL 4344898 Contact Us For Availability

View on Model

11

Handle, Door WPL W10163184 Contact Us For Availability

View on Model

11

Baffle, Air WPL 4344782 Contact Us For Availability

View on Model

12

4344789 Whirlpool Refrigerator Support Backorder WPL 4344789 $228.72

View on Model

12

Door Skin, Stainless Steel WPL W10163182 Contact Us For Availability

View on Model

12

Frame, Side (Right Side) WPL 4344790 Contact Us For Availability

View on Model

13

4344760 Whirlpool Refrigerator Washer Backorder WPL 4344760 $9.81

View on Model

13

4344771 Whirlpool Refrigerator Clip Backorder WPL 4344771 $73.02

View on Model

13

4344784 Whirlpool Bracket Backorder WPL 4344784 $158.99

View on Model

14

4344785 Whirlpool Bracket Backorder WPL 4344785 $125.42

View on Model

14

4344788 Whirlpool Refrigerator Spacer Backorder WPL 4344788 $119.11

View on Model

14

Evaporator Fan Assembly WPL 4344840 Contact Us For Availability

View on Model

15

4344786 Whirlpool Back Cover Backorder WPL 4344786 $158.99

View on Model

15

WP4344859 Whirlpool Refrigerator Thermostat Backorder WPL WP4344859 $179.40

View on Model

15

PLATE WPL 4344904 Contact Us For Availability

View on Model

16

4344796 Whirlpool Refrigerator Screw Backorder WPL 4344796 $10.30

View on Model

16

WP1188476 Whirlpool Air Conditioner Capacitor Backorder WPL WP1188476 $125.90

View on Model

16

WP3402573 Whirlpool Appliance Knob Backorder WPL WP3402573 $74.13

View on Model

16

Screw (Black) WPL W10162988 Contact Us For Availability

View on Model

17

WP4344767 Whirlpool Refrigerator Switch Backorder WPL WP4344767 $40.56

View on Model

17

WP4344836 Whirlpool Clip Backorder WPL WP4344836 $58.23

View on Model

17

Screw, Lower Hinge (Quantity 1) WPL 4344906 Contact Us For Availability

View on Model

18

W10163276 Whirlpool Refrigerator Trap Backorder WPL W10163276 $62.45

View on Model

19

4344797 Whirlpool Screw Backorder WPL 4344797 $9.71

View on Model

19

W10243123 Whirlpool Refrigerator Screw Backorder WPL W10243123 $10.30

View on Model

19

Power Cord WPL 4344861 Contact Us For Availability

View on Model

20

4344801 Whirlpool Refrigerator Screw Backorder WPL 4344801 $10.30

View on Model

20

4344829 Whirlpool Tie Wire Backorder WPL 4344829 $9.71

View on Model

20

Clip, Grille WPL 4344819 Contact Us For Availability

View on Model

21

WP4344828 Whirlpool Refrigerator Dryer Tube Backorder WPL WP4344828 $20.84

View on Model

21

Screw WPL W10163183 Contact Us For Availability

View on Model

22

4344823 Whirlpool Refrigerator Seal Backorder WPL 4344823 $70.65

View on Model

22

Bushing WPL 4344838 Contact Us For Availability

View on Model

23

4344820 Whirlpool Refrigerator Support Backorder WPL 4344820 $148.43

View on Model

23

4344821 Whirlpool Refrigerator Support Backorder WPL 4344821 $94.38

View on Model

23

Clip, Bushing WPL 4344831 Contact Us For Availability

View on Model

24

W10163274 Whirlpool Pad Backorder WPL W10163274 $83.23

View on Model

24

W11456069 Whirlpool Refrigerator Clamp In Stock WPL W11456069 $17.02

View on Model

25

4344826 Whirlpool Refrigerator Screw Backorder WPL 4344826 $10.30

View on Model

25

4344857 Whirlpool Refrigerator Wire Harness Backorder WPL 4344857 $58.19

View on Model

26

SCREW WPL 4344825 Contact Us For Availability

View on Model

26

SCREW WPL 4344827 Contact Us For Availability

View on Model

27

4344792 Whirlpool Refrigerator Bi-Metal Backorder WPL 4344792 $79.15

View on Model

28

4344793 Whirlpool Screw Backorder WPL 4344793 $9.71

View on Model

28

8201787 Whirlpool Refrigerator Compressor Backorder WPL 8201787 $374.42

View on Model

29

SCREW WPL 4344834 Contact Us For Availability

View on Model

29

SCREW WPL 4344791 Contact Us For Availability

View on Model

30

WP90767 Whirlpool Screw In Stock WPL WP90767 $4.26

View on Model

30

Fan Blade WPL 4344783 Contact Us For Availability

View on Model

31

Transformer WPL 4344862 Contact Us For Availability

View on Model

31

SCREW WPL 4344878 Contact Us For Availability

View on Model

32

W10163278 Whirlpool Refrigerator Thermostat Backorder WPL W10163278 $182.85

View on Model

32

Evaporator Fan Motor WPL 4344865 Contact Us For Availability

View on Model

33

Harness, Wire WPL 4344877 Contact Us For Availability

View on Model

33

Bracket, Thermostat WPL 4344864 Contact Us For Availability

View on Model

34

Screw, Ground WPL W11380570 No Longer Available

View on Model

34

Ballast WPL 4344881 Contact Us For Availability

View on Model

35

4344907 Whirlpool Trim Backorder WPL 4344907 $148.72

View on Model

35

Grommet, Fan Motor WPL 4344778 Contact Us For Availability

View on Model

36

4344899 Whirlpool Refrigerator Bracket Backorder WPL 4344899 $118.65

View on Model

36

Support, Drain WPL 4344908 Contact Us For Availability

View on Model

38

4344858 Whirlpool Refrigerator Switch Backorder WPL 4344858 $73.48

View on Model

39

Transformer Cable WPL 4344917 Contact Us For Availability

View on Model

NI

Cleaner, Stainless Steel (10 oz) WPL 31462 Contact Us For Availability

View on Model
